GemTek Technology M930916G Wireless 802.11g mini-PCI Card User Manual WMIB 114G
Gemtek Technology Co., Ltd. Wireless 802.11g mini-PCI Card WMIB 114G
Manual
WMIB-114G Wireless 802.11g miniPCI
Network Card User Manual
Features and Functions
IEEE 802.11g 54-Mbps standard compliant and Wi-Fi CERTIFIED™ to ensure
complete compatibility with 802.11b solutions and Interoperability with over 800
products tested by the Wi-Fi alliance.
Low-power consumption with a comprehensive power management technique.
Optimized for new, low-power mobile processors, the BCM94306M consumes up
to 75 percent less power than competing technologies for extended notebook
battery life.
Maximum performance speed, reach, and security with unique Broadcom®
features such as SmartRadio™ and Xpress™ technology. Maximizes
performance in presence of BlueTooth™ and other 2.4 GHz devices.
Advanced high performance baseband processor with integrated medium
access controller (MAC) that supports future IEEE standards, such as 802.11i
Security and 802.11e QoS for built-in future proof designs.
SmartRadio technology improves wireless LAN througWMIB-114Gut and range
with advanced signal processing techniques. The all-CMOS solutions are capable
of self-calibrating based on usage temperature and other environmental
conditions, reconfiguring constantly for optimum performance.
OneDriver™ works with all AirForce™ 802.11a/b/54g™ solutions, simplifying
the upgrade/update process for customers and end users. Driver certification and
extensive operating system support, including WHQL certified Microsoft®
Windows® drivers, Zero configuration with Microsoft XP, and embedded drivers
for Linux® and VxWorks®.
Comprehensive security portfolio including Cisco Compatible Extensions (CCX),
Wi-Fi Protected Access (WPA) CERTIFIED, built-in hardware support for
Advanced Encryption Standard (AES) protocol, Wired Equivalent Privacy (WEP)
weak key avoidance, TKIP, and 802.1x.
Xpress technology standards-based software enhancement. Increases
aggregate network performance by up to 75 percent in a mixed 802.11g+802.11b
environment. 54g™-based client devices with Xpress technology can achieve
more than six times greater performance than 802.11b products.
Product Specifications
Chipset
Baseband/MAC – BCM4306KFB,C0
RF Transeiver – BCM2050KML
Host interface
32-bit mini PCI.
Network standard
IEEE 802.11b and 802.11g standard.
Data rate
802.11b: 11 Mbps, 5.5 Mbps, 2 Mbps, 1 Mbps.
802.11g: 54 Mbps, 48 Mbps, 36 Mbps, 24 Mbps, 18 Mbps, 12 Mbps, 9 Mbps,
and 6 Mbps.
Modulation
802.11g: OFDM.
802.11b: CCK (11 Mbps, 5.5 Mbps), DQPSK (2 Mbps), and DBPSK (1 Mbps).
Network architectures
Infrastructure and ad hoc.
Operating frequencies
2.412–2.484 GHz.
Operating channels
802.11g and 802.11b: 11 for North America, 13 for Europe (ETSI), 14 for Japan
RF output power
13.5 dBm typical at 54Mbps
17.5 dBm typical at 11Mbps
Antenna connectors
Hardware diversity support. Transmit and receive on main and auxiliary
antenna connectors.
Receiver Sensitivity
-84dBm minimum @ 11Mbps @ 8% PER
-70dBm minimum @ 54Mbps @ 10% PER
Range
802.11g: 54 Mbps up to 50m Line of Sight (LOS), 20m indoors; 18 Mbps up to
150m LOS, 75m indoors.
802.11b: 11 Mbps up to 180m LOS, 60m indoors; 1 Mbps up to 570m LOS,
125m indoors.
Power consumption
TX: 350 mA, 3.3VDC
RX: 280 mA, 3.3VDC
Power Save mode: 13 mA, 3.3VDC
Radio disable: <10 mA, 3.3VDC
Security
Hardware 64/128-bit WEP engine; WEP weak key avoidance; TKIP; hardware
ES engine supporting CCM and OCB, WPA, 802.1x, and 802.11i.
Delay tolerance
802.11b: Multipath RMS delay spread @ 1% FER: 11 Mbps >250 ns, and 5.5
Mbps >300 ns
Client utility
Automatic location profile, site monitor, current link status, and diagnostics.
Software support
Microsoft WHQL certified for Windows XP, 2000.
FAA Switch
Manual radio on/off disables transmit and receive to comply with aviation
in-flight restrictions.
Temperatures
Operates from 0 to 70°C, and storage from -40 to 90° C.
Humidity (non-condensing)
5 to 95%
Appendix A:
Federal Communication Commission Interference Statement
This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to Part 15 of the FCC Rules. These limits are designed
to provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may
cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television reception, which
can be determined by turning the equipment off and on, the user is encouraged to
try to correct the interference by one of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that
to which the receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) This device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that
may cause undesired operation.
FCC Caution: Any changes or modifications not expressly approved by the party
responsible for compliance could void the user's authority to operate this
equipment.
IMPORTANT NOTE:
FCC Radiation Exposure Statement:
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled
environment. This equipment should be installed and operated with minimum distance
20cm between the radiator & your body.
This transmitter must not be co-located or operating in conjunction with any other
antenna or transmitter.
This device is intended only for OEM integrators under the following conditions:
1) The antenna must be installed such that 20 cm is maintained between the antenna
and users, and
2) The transmitter module may not be co-located with any other transmitter or antenna.
As long as 2 conditions above are met, further transmitter test will not be required.
However, the OEM integrator is still responsible for testing their end-product for any
additional compliance requirements required with this module installed (for example,
digital device emissions, PC peripheral requirements, etc.).
IMPORTANT NOTE: In the event that these conditions can not be met (for example
certain laptop configurations or co-location with another transmitter), then the FCC
authorization is no longer considered valid and the FCC ID can not be used on the final
product. In these circumstances, the OEM integrator will be responsible for re-evaluating
the end product (including the transmitter) and obtaining a separate FCC authorization.
End Product Labeling
This transmitter module is authorized only for use in device where the antenna may be
installed such that 20 cm may be maintained between the antenna and users (for
example: notebook, AP, Router…etc. ). The final end product must be labeled in a visible
area with the following: “Contains TX FCC ID: MXF-M930916G”.
Manual Information That Must be Included
The OEM integrator has to be aware not to provide information to the end user regarding
how to install or remove this RF module in the users manual of the end product which
integrate this module.
The users manual for OEM integrators must include the following information in a prominent location “ IMPORTANT NOTE: To
comply with FCC RF exposure compliance requirements, the antenna used for this transmitter must be installed to provide a
separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or
transmitter.
Appendix B: IC Statement
The device is certified to the requirements of RSS-210 for 2.4 GHz spread spectrum
devices. To prevent radio interference to the licensed service, this device is intended to be
operated indoors and away from windows to provide maximum shielding
