The LTE Indoor CPE
Quick installation Guide
Power Adapter & Plug
CAT5 8-wire Ethernet cable
WPS
LAN 1&2
VoIP
USB
Connectors
Connector
Description
LAN RJ45
The LAN port allows you to connect Modem to your
PC or Hub using a Cat.5e/6 Ethernet network
cable.
Voice- RJ11
The voice port allows you to connect your Phone to
this Modem
USB Type A
Host
Support USB 2.0 HostReserved HW only; no SW
support
Reset
Holds down the button for 5-seconds to factory
defaults.
WPS
Holds down the button for 5-seconds to WPS
enable
Power
The power port is where you connect the enclosed
power adapter.
WAN
ON/OFF
Power
Adapter Port
LED Indicators _Router
Type
Color
Action
Description
Power
Green
ON
Device Power On (AC plug in)
OFF
Device Off (AC not plug in or device
damaged)
WAN
Green
ON
The ODU is sync
OFF
No ODU detected
Ethernet
1-2
Green
ON
LAN device connected
Blinking
LAN traffic
OFF
The device does not have an Ethernet
connection on LAN
2.4GHz
WLAN
Green
ON
The wireless network is activated and is
operating in IEEE 802.11 b/g/n mode.
Blinking
The device is still communicating with
other wireless clients.
OFF
The wireless network is not activated.
5GHz WLAN
Green
ON
The wireless network is activated and is
operating in IEEE 802.11 b/g/n mode.
Blinking
The device is still communicating with
other wireless clients.
OFF
The device is still communicating with
other wireless clients.
Phone
Green
ON
A SIP account is registered
Blinking
Talk
Installation
Easy setup
Web IP: 192.168.0.1
OFF
Phone off
CAT5 8-wire Ethernet
cable for connecting
IDU and computer
