Contents
Brochure
Features
• Up to 5X faster
2
and 2X greater range
2
• IEEE 802.11a/b/g and Draft-N1quad-mode
• Advanced security via 802.11i
• Wireless support for
Intel® Active Management Technology¨
Intel® Next-Gen Wireless-N
Feature Benefit
Performance
Up to 5X faster2
300 Mbps2Draft-N1data rates offer major improvement over 802.11a/g Allows more simultaneous activity for file transfers, network backups,
54 Mbps rates streaming video, multi-player gaming, VoIP, and more
Up to 2X greater range2
MIMO, diversity, and three-antennae support enable better wireless Dramatically improves connectivity throughout the home and enables more
reception for greater bandwidth at farther distances consistent coverage in the enterprise
Flexibility and Mobility
IEEE 802.11a/b/g/Draft-N1
Wi-Fi certified for existing 802.11a, .11b, and .11g standards, Draft-N1Increased connectivity options help mobile clients utilize multiple networks
certification is also expected when available (office, home, hot spots) and facilitate network upgrades to Draft-N1or 802.11n
Manageability and Security
Wireless support for Intel® Active Management Technology¨
Enhanced asset management, remote system diagnostics, network Allows IT managers to remotely discover, heal, and protect wireless notebooks,
protection and security independent of operating system functional state which may result in reduced on-site support costs
Advanced Security via 802.11i
Wireless security is supported by WPA2 AES, which is the strongest Helps ensure enterprise wireless networks are protected with stronger
encryption algorithm available today for mobile clients authentication and encryption security
Intel® PROSet v11.16
Intel® WLAN management software includes an optional toolkit for Well-known, easy-to-use application and IT administrator tools can help simplify
network managers client deployment and remote management of wireless settings and profiles
Interoperability
Business-Class Wireless Suite v2 (High-Density Networking)
Second-generation Intel and Cisco collaboration allows Access Points and Helps reduce interference and improve performance by enabling more dense
clients to change settings based on real-time network conditions AP deployment and increased throughput per client
Support for Cisco Compatible Extensions* v4
Cisco Centralized Key Management, Call Admission Control, Unscheduled Help prevent noticeable delays in VoIP calls when roaming between Access
Automatic PowerSave Delivery (U-APSD), and Voice Metrics Points and enable improved network diagnostics
Friendly Neighbor Assurance
40 MHz channels in the 5.0 GHz spectrum do not impact products that Supports current 802.11n standard direction, allowing maximum performance
use the 2.4 GHz spectrum and peaceful co-existence with legacy 802.11b/g devices
Intel® “Connect with Centrino®”
Intel has certified Access Points from leading vendors through extensive Selecting Access Points with the Intel “Connect with Centrino” identifier can
compatibility and real-world performance testing help Intel® Centrino® processor technology end-users connect with confidence
• Business-Class Wireless Suite (v2): High-Density Networking
• Support for Cisco Compatible Extensions* v4
• Easy-to-use Intel® PROSet v11.1 WLAN Software
• Intel® “Connect with Centrino®” program
• Friendly Neighbor Assurance
Product Brief
Intel® Next-Gen Wireless-N
Mobile Computing
Product Description
The Intel® Next-Gen Wireless-N product is an embedded 802.11a/b/g/Draft-N1PCIe*
Mini Card network adapter that operates in both the 2.4 GHz and 5.0 GHz spectra.
It delivers high throughput and a host of features that enhance today's mobile lifestyle.
1“Draft-N” refers to: IEEE P802.11 n*/D2.0 Draft Amendment to STANDARD [FOR] Information Technology-Telecommunications and information exchange between systems-Local and Metropolitan
networks-specific requirements-Part 11: Wireless LAN Medium Access Control (MAC) and Physical Layer (PHY) specifications: Enhancements for Higher Throughput.
2Up to 2X greater range and up to 5X better performance with optional Intel® Next-Gen Wireless N technology enabled by 2x3 Draft N1implementations with 2 spatial streams. Actual results may vary based on
your specific hardware, connection rate, site conditions, and software configurations. See http://www.intel.com/performance/mobile/wireless/index.htm for more information. Wireless n access points without the
Connect with Intel Centrino processor technology identifier may require additional firmware for increased performance results. Check with your PC and access point manufacturer for details.
3Wireless connectivity and some features may require the purchase of additional software, services, or external hardware. Availability of public wireless LAN access points is limited, wireless functionality may vary by
country. See http://www.intel.com/products/centrino/more_info for more information.
4Roaming is supported only between each respective band and mode of access points.
5Some security solutions may not be supported by your PC's operating system and/or by your PC manufacturer. Check with your PC manufacturer for details on availability.
6Intel® PROSet/Wireless Software may not be supported by your PC manufacturer. Check with your PC manufacturer for details on availability.
¨Intel® Active Management Technology requires the platform to have an Intel® AMT-enabled chipset, network hardware and software, connection with a power source and a network connection.
†Some features may only be supported on the latest hardware
INFORMATION IN THIS DOCUMENT IS PROVIDED IN CONNECTION WITH INTEL® PRODUCTS AND IS SUBJECT TO CHANGE WITHOUT NOTICE. NO LICENSE, EXPRESS OR IMPLIED, BY ESTOPPEL OR OTHERWISE, TO
ANY INTELLECTUAL PROPERTY RIGHTS IS GRANTED BY THIS DOCUMENT. EXCEPT AS PROVIDED IN INTEL'S TERMS AND CONDITIONS OF SALE FOR SUCH PRODUCTS, INTEL ASSUMES NO LIABILITY
WHATSOEVER, AND INTEL DISCLAIMS ANY EXPRESS OR IMPLIED WARRANTY, RELATING TO SALE AND/OR USE OF INTEL PRODUCTS INCLUDING, WITHOUT LIMITATION, LIABILITY OR WARRANTIES RELATING TO
FITNESS FOR A PARTICULAR PURPOSE, MERCHANTABILITY, OR INFRINGEMENT OF ANY PATENT, COPYRIGHT OR OTHER INTELLECTUAL PROPERTY RIGHT. INTEL PRODUCTS ARE NOT INTENDED FOR USE IN
MEDICAL, LIFE SAVING, LIFE SUSTAINING, CRITICAL CONTROL OR SAFETY SYSTEMS, OR IN NUCLEAR FACILITY APPLICATIONS. INTEL MAY MAKE CHANGES TO SPECIFICATIONS
AND PRODUCT DESCRIPTIONS AT ANY TIME, WITHOUT NOTICE. THE PRODUCTS DESCRIBED IN THIS DOCUMENT MAY CONTAIN DESIGN DEFECTS OR ERRORS KNOWN AS
ERRATA WHICH MAY CAUSE THE PRODUCT TO DEVIATE FROM PUBLISHED SPECIFICATIONS. CURRENT CHARACTERIZED ERRATA ARE AVAILABLE ON REQUEST.
FOR THE MOST CURRENT PRODUCT INFORMATION, PLEASE VISIT: HTTP://WWW.INTEL.COM/NETWORK/CONNECTIVITY/PRODUCTS/WIRELESS/INDEX.HTM
*Other names and brands may be claimed as the property of others.
Copyright ©2007 Intel Corporation. All rights reserved.
Intel, the Intel logo, Intel. Leap ahead., the Intel. Leap ahead. logo, Intel Centrino, and the Connect with Centrino logo are trademarks of Intel Corporation in the U.S.
and other countries.
Printed in USA 0507/CC/OCG/XX/PDF Please Recycle 316286-002US
Intel® PROSet for Windows Software6
Intel® PROSet/Wireless Software v11.1 helps enable a superior experience for end-users as well as
IT administrators. Features include support for:
• Wi-Fi Protected Setup
• Intel® Active Management Technology
• Intel/Cisco Business-Class Wireless Suite v2:
High-Density Networking Technology
• Added IT Administration Tool capabilities:
– Install package creator
– Central control over driver and application settings
– Single Sign On for Microsoft and Novell networks
• Hardware†: Intel® Wireless Wi-Fi Link 4965AGN,
Intel® PRO/Wireless 3945ABG, 2915ABG, 2200BG
Network Connections
Intel® Wireless Wi-Fi Link 4965AGN Technical Specifications
General
Dimensions (H x W x D) 2.00 in x 1.18 in x 0.13 in (50.95 mm x 30.00 mm x 3.30 mm)
Weight 7.2g
Diversity On-board diversity support for systems designed with two or three antennas
Radio ON/OFF Control3Supported in both hardware and software
Connector interface Mini Card form factor, based on PCIe electrical interface
LEDs Output Single LED (as per Mini Card specification)
Operating Temperature 0 to +80° Celsius
Humidity Non-Operating 50% to 90% RH non-condensing (at temperatures of 25° C to 35° C)
Operating Systems Microsoft Windows 2000*, XP* 32/64-bit, Vista* 32/64-bit
Wi-Fi Alliance Wi-Fi Certified* for 802.11a, 802.11b, 802.11g, WMM*, WPA*, and WPA2*
(Wi-Fi Alliance Draft-N1and 802.11n certifications expected when available)
Microsoft WHQL YES
IEEE WLAN Standard IEEE 802.11a, IEEE 802.11b, IEEE 802.11g, (targeting IEEE 802.11n when available)
Architecture Infrastructure or ad hoc (peer-to-peer)
Roaming4Supports seamless roaming between respective access points
(802.11b, 802.11g, 802.11a/b/g, and 802.11a/b/g/Draft-N1)
Security
Authentication WPA5and WPA25
, 802.1 X, LEAP, EAP-TLS, PEAP-TLS, and PEAP-MSCHAPv2*
Encryption Protocols CKIP, TKIP, 64-bit and 128-bit WEP (for 802.11a/b/g), AES-CCMP (for 802.11a/b/g/n)
Product Safety UL, C-UL, CB (IEC 60590)
Products Available Model Code Version
Intel® Wireless Wi-Fi Link 4965AGN 4965AGN 4965AGN (supports 802.11a/b/g/Draft-N1)
4965AG_ (supports 802.11a/b/g with Draft-N1functionality disabled)
