General Sensing M5K001 MedSense Badge User Manual M5K001 UserManual
General Sensing Limited MedSense Badge M5K001 UserManual
M5K001 UserManual
MedSense™
®
Badge M5K001
3
How MedSense Works 4
Wearing the MedSense Badge 7
Using the MedSense Badge 7
Legal Statements 8
Contents
Welcome to MedSense
Dear MedSense user,
We would like to thank you for using our product and welcome
you to the MedSense community. We share your goal of achieving
the highest possible level of hygiene in your hospital, and we hope
using our product makes your life simpler.
Sincerely,
The General Sensing Team
4 5
How MedSense Works
MedSense is a combination of four easy-to-use wireless devices that
monitor and record compliance performance at point-of-care areas.
These devices take advantage of low-power wireless communication
and the latest web technologies to offer you a simple, powerful, and
accurate hand hygiene compliance monitoring solution.
1. 2. 3.
4.
1. The MedSense Badge
The MedSense Badge, worn like an identity card, collects hand hygiene
compliance data as the healthcare worker delivers care around the
hospital.
2. The MedSense Beacon
The MedSense Beacon is a low-prole, battery-powered device that
is placed above a patient bed or other point of care with a semi-
permanent adhesive backing. The Beacon establishes a wireless patient
zone that allows the Badge to identify hand hygiene opportunities.
3. The MedSense Dispenser Monitor
The MedSense Dispenser Monitor acts as a holster for sanitizer
bottles. When a healthcare worker uses a sanitizer bottle, the
Dispenser Monitor signals the user’s Badge, which in turn records a
hand hygiene action.
4. The MedSense Base
The MedSense Base functions as a wireless base station through
which Badges upload compliance data to MedSense HQ. The Base also
functions as a battery charger for the Badge, capable of charging up to
sixteen Badge batteries to full capacity in two hours.
The MedSense HQ
MedSense HQ, General Sensing’s cloud-based web application, is what
ties all four devices together.
6 7
Using the MedSense Badge
The Badge will automatically upload data to MedSense HQ when in range
of a Base. The Badge will vibrate as a reminder to perform hand hygiene
when an opportunity is about to be missed.
The battery life is approximately one work week and should be swapped
out when a low battery indicator is shown. When outside of the
MedSense-equipped areas, the Badge goes into standby mode.
LED Status
Status: Blinking Blue
Explanation: Normal operation in MedSense-equipped area or in motion.
Status: Blinking Red
Explanation: Low battery
Status: Off
Explanation: Battery depleted or not in motion while outside
MedSense-equipped area.
Status: Blinking Pink
Explanation: Indicates possible connection problems.
Contact MedSense support team.
CARE INSTRUCTIONS
Wipe down with a damp cloth.
If the Badge is lost or broken, ask MedSense support team for an
exchange or replacement.
Wearing the MedSense Badge
• Write the health care worker’s name on a label provided and adhere
the label to the Badge.
• Attach a battery to the Badge.
• Clip the Badge on the torso, hanging in portrait mode and facing out,
for the most accurate performance.
• Placing the Badge in a pocket is not recommended.
YES NO
NO
98
Legal Statements
FCC Statement
This equipment has been tested and found to comply with the limits
for a Class B digital device, pursuant to part 15 of the FCC rules. These
limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses,
and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to
radio communications. However, there is no guarantee that interference
will not occur in a particular installation.
If this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and
on, the user is encouraged to try to correct the interference by one or
more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that
to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
To assure continued compliance, any changes or modications not
expressly approved by the party responsible for compliance could void
the user’s authority to operate this equipment.
Radiation Exposure Statement
This equipment complies with FCC radiation exposure limits set forth
for an uncontrolled environment and it also complies with Part 15 of
FCC RF Rules. Operation is subject to the following two conditions:
• This device may not cause interference, and
• This device must accept any interference, including interference that
may cause undesired operation of the device.
Caution!
The manufacturer is not responsible for any radio or TV interference
caused by unauthorized modications to this equipment. Such
modications could void the user authority to operate the equipment.
Canada Statement
• This device complies with Industry Canada RSS-210. Operation is
subject to the following two conditions: (1) this device may not cause
interference, and (2) this device must accept any interference, including
interference that may cause undesired operation of the device.
• Le présent appareil est conforme aux CNR d’Industrie Canada
applicables aux appareils radio RSS-210. L’exploitation est autorisée
aux deux conditions suivantes : (1) l’appareil ne doit pas produire de
brouillage, et (2) l’utilisateur de l’appareil doit accepter tout brouillage
radioélectrique subi, même si le brouillage est susceptible d’en
compromettre le fonctionnement.
• The device meets the exemption from the routine evaluation
limits in section 2.5 of RSS 102 and compliance with RSS-102 RF
exposure, users can obtain Canadian information on RF exposure and
compliance.
• Le dispositif rencontre l’exemption des limites courantes d’évaluation
dans la section 2.5 de RSS 102 et la conformité à l’exposition de
RSS-102 rf, utilisateurs peut obtenir l’information canadienne sur
l’exposition et la conformité de rf.
• This transmitter must not be co-located or operating in conjunction
with any other antenna or transmitter. This equipment should be
installed and operated with a minimum distance of 20 centimeters
between the radiator and your body.
• Cet émetteur ne doit pas être Co-placé ou ne fonctionnant en
même temps qu’aucune autre antenne ou émetteur. Cet équipement
devrait être installé et actionné avec une distance minimum de 20
centimètres entre le radiateur et votre corps.
