Recommended Owners Manual for Automatic-Dimming NVS Mirror with Homelink® series
Universal Garage Door Opener.
Automatic-Dimming NVS Mirror with Homelink®
Suggested Owner’s Manual Text
July, 2001
Automatic-Dimming Night Vision Safety (NVS) Mirror
The NVS Mirror in your vehicle is the most advanced way to eliminate dangerous and annoying glare
in the rearview mirror during any driving situation. For more information regarding NVS mirrors and
other applications, please refer to the Gentex website – www.gentex.com.
Precautions
The NVS Mirror automatically reduces glare during driving conditions based upon light levels
monitored in front of the vehicle and from the rear of the vehicle. These light sensors are visible through
openings in the front and rear of the mirror case. Any object that would obstruct either light sensor will
degrade the automatic dimming control feature.
Operation
The NVS Mirror operates automatically whenever the vehicle ignition is ON. The status of the
automatic dimming feature is indicated by a green light on the face of the mirror.
To turn the automatic dimming feature off, press the button with the •. The indicator light will turn off to
indicate that the automatic dimming feature is off.
To turn the automatic dimming feature on, press the button with the . The indicator light will also turn
on.
If the automatic dimming feature is off when the vehicle ignition is turned off, the automatic dimming
feature will become active when the vehicle ignition is turned back on.
HomeLink® Universal Transceiver
The HomeLink® Universal Transceiver included in your NVS Mirror with Homelink® provides a
convenient way to replace up to three hand-held transmitters with a single built-in component. This innovative
feature will learn the radio frequency codes of most current transmitters used to activate devices such as
garage doors, entry door locks, estate gates, security systems, and home or office lighting. For additional
information on HomeLink and/or HomeLink compatible products, call 1-800-355-3515 or refer to the
HomeLink web site at www.homelink.jci.com.
Precautions
When programming the HomeLink Universal Transceiver to a garage door opener or entry
gate, make sure that people and objects are out of the way to prevent potential harm or
damage.
Do not use the HomeLink Universal Transceiver with any garage door opener that
lacks the safety stop and reverse feature as required by federal safety standards. (This
includes any garage door opener model manufactured before April 1, 1982.) A garage
door opener which cannot detect an object, signaling the door to stop and reverse, does
not meet current federal safety standards. Using a garage door opener without these
features increases risk of serious injury or death. For more information, call
1-800-355-3515 or on the internet at www.homelink.jci.com.
Retain the original transmitter for future programming procedures (i.e., new vehicle
purchase). It is also suggested that upon the sale of the vehicle, the programmed
HomeLink Universal Transceiver buttons be erased for security purposes (follow step
1 in the “Programming” portion of this text).
Programming
Note: For best results, replace the battery in the hand-held transmitter with a new battery before programming.
If your garage door opener receiver (located in the garage) is equipped with an antenna, make sure the
antenna is completely uncoiled and hangs straight down.
1. Press and hold the two outside buttons - releasing only when the indicator light begins to
flash after 20 seconds. (This procedure erases the factory set default codes and does not have
to be followed to program additional hand-held transmitters.)
2. Hold the end of the hand-held transmitter of the device you wish to train approximately
one to three inches away from the HomeLink surface - keeping the indicator light in view.
(For placement questions, please contact HomeLink at 1-800-355-3515 or on the internet at
www.homelink.jci.com.)
3. Using both hands, simultaneously push the hand-held transmitter button and the desired
HomeLink button. Do not release the buttons until step 4 has been completed.
Note: Some entry gates and garage door openers may require you to replace this programming step (#3)
with the procedures noted in the “Canadian Programming / Gate Programming” section.
4. The HomeLink indicator light will flash, first slowly and then rapidly. When
the indicator light flashes rapidly, release both buttons. (The rapid flashing light
indicates successful programming of the new frequency signal.)
If, after 20 seconds, the indicator light does not flash rapidly, release both the HomeLink and the hand-held
transmitter buttons and repeat steps two through four. However, position the hand-held transmitter at a different
length and/or angle until the indicator light begins to flash rapidly. Release both buttons after the indicator light
flashes rapidly.
Refer to “Rolling Code Programming” and/or “Canadian Programming/Gate Programming” for additional procedures if
necessary.
To activate the garage door or other programmed device upon successfully completing the steps above, press and
hold the HomeLink button - releasing when the device begins to activate.
To program the remaining two buttons, follow steps 2 through 4.
If you do not successfully program the HomeLink Universal Transceiver to learn the signal of the hand-held
transmitter, refer to “Rolling Code Programming” within this text or call toll-free for customer assistance at 1-800-
355-3515 or on the internet at www.homelink.jci.com.
Canadian Programming / Gate Programming
Canadian frequency laws, and the technology of some entry gates, require you to “cycle” (press and re-press the
hand-held transmitter button every two seconds) during programming.
Continue to press and hold the desired HomeLink button (note steps 3 through 5 in the “Programming” portion of
this text) while you “cycle” your hand-held transmitter until the frequency signal has been learned. The indicator
light will flash slowly and then rapidly upon successful training.
Note: When programming a garage door opener or gate, it is advised to unplug the device
during the “cycling” process to prevent possible motor burn-up
Operating the HomeLink® Universal Transceiver
To operate, simply press the programmed HomeLink button. Activation will now occur for the trained product
(garage door, security system, entry door lock, estate gate, or home or office lighting). For convenience, the hand-
held transmitter of the device may also be used at any time.
Rolling Code Programming
Rolling code garage door openers (or other rolling code devices) which are “code protected” and manufactured after
1996, may be determined by the following:
A. Reference the garage door opener owner’s manual for verification.
B. The hand-held transmitter appears to program the HomeLink Universal
Transceiver but HomeLink does not activate the garage door.
C. Press and hold the trained HomeLink button. The garage door opener has
the rolling code feature if the HomeLink indicator light flashes rapidly and
then turns solid after 2 seconds.
To train a garage door opener with the rolling code feature, follow these instructions after completing the
“Programming” portion of this text (the aid of a second person may make the following training procedures quicker
and easier.)
1. Locate the training button on the garage door opener receiver (in the garage). Exact
location and color of the button may vary by garage door opener brand. If there is
difficulty locating the training button, reference the garage door opener owner’s
manual or contact HomeLink at 1-800-355-3515 or on the internet at
www.homelink.jci.com.
2. Press the “training” button on the garage door opener receiver (which will
activate the “training” light).
Note: Following step 2, there are 30 seconds in which to initiate step 3.
3. Firmly press and release the programmed HomeLink button. Press and release the HomeLink button a second
time to complete the training process. (Some garage door openers may require you to do this procedure a third
time to complete the training.)
The garage door opener should now recognize the HomeLink signal and activate when the HomeLink button is
pressed. The remaining two buttons may now be programmed if this has not previously been done. Refer to the
“Programming” portion of this text.
Erasing Programmed HomeLink® Buttons
Individual buttons cannot be erased, however, to erase the three programmed buttons:
1. Press and hold the two outside buttons until the indicator light beings to flash
after 20 seconds.
2. Release both buttons.
The HomeLink Universal Transceiver is now in the train (or learning) mode and can be programmed at any time
following steps 2 through 4 in the “Programming” portion of this text.
Reprogramming a Single HomeLink® Button
To program a device to HomeLink using a button previously trained, follow these steps:
1. Press and hold the desired HomeLink button. Do NOT release until step 4
has been completed.
2. When the indicator light begins to flash slowly (after 20 seconds), position
the hand-held transmitter 1 to 3 inches away from the HomeLink surface.
3. Press and hold the hand-held transmitter button.
4. The HomeLink indicator light will flash, first slowly and then rapidly. When
the indicator light begins to flash rapidly, release both buttons.
The previous device has now been erased and the new device can be activated by pushing the HomeLink button that
has just been programmed. This procedure will not affect any other programmed HomeLink buttons.
This device complies with FCC rules part 15. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and
(2) This device must accept any interference that may be received including interference that may cause undesired operation. WARNING: The transmitter has
been tested and complies with FCC and DOC/MDC rules. Changes or modifications not expressly approved by the party responsible for compliance could
void the user’s authority to operate the device.
DOC: XXXX XXXX XXX XXX Gentex MODEL/FCC ID: NZLSTDHL3
HomeLink® is a registered trademark owned by Johnson Controls, Inc.
