USERS MANUAL
Bluetooth Module
Installation Guide
Model: BT3014-GP
BT3014-GP Bluetooth Module is an integrated module for implementation in various
applications to enable electronic devices to communicate wirelessly with other
BluetoothTM - enabled devices.
Specifications
User Interface:
USB : USB 1.2 compliant
Software:
Bluetooth HCI interface supports USB
(1.1)
Operating Frequency
Range:
2402 MHz to 2480MHz
Modulation:
GFSK
Tx Data Rate:
Downstream: 723 Kbps (max)
Upstream : 57 Kbps (max)
Sync : 433Kbps (max)
Rx Sensitivity:
-87 dB min
Hopping Channel:
79
Data Rate:
1Mbps
Antenna Interface:
50 ohm
2 Caring for the Computer
Federal Communication Commission Interference Statement
This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to Part 15 of the FCC Rules. These limits are designed
to provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may
cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.
FCC Caution:
1. The device complies with Part 15 of the FCC rules. Operation is subject to the
following two conditions:
(1) This device may not cause harmful interference, and (2) this device must
accept any interference received, including interference that may cause
undesired operation.
2. Any changes or modifications not expressly approved by the party
responsible for compliance could void the user's authority to operate this
equipment.
The antenna(s) used for this transmitter must be installed to provide a
separation distance of at least 20cm from all persons and must not be
co-located or operating in conjunction with any other antenna or
transmitter
IMPORTANT NOTE:
This module is intended for OEM integrator only and limited to host with
brand: Getac and model: M230 series. The OEM integrator is still
responsible for the FCC compliance requirement of the end product
which, integrates this module.
