Getac Technology BWC2 Body Worn Camera User Manual BWC BC 02 QSG

Getac Technology Corporation Body Worn Camera BWC BC 02 QSG

Contents

User Manual

VERETOS MVS
BWC BC-02
Body-Worn Camera
QUICK START GUIDE
561588240001 R00
1
.
Unpacking
BWC BC-02 Body-Worn Camera
Chest mount
Molle mount
Charging dock
Adapter plug
2
.
Identifying Components
No. Description
On/Off Button: Wi-Fi wake-up supported
Microphone
Power Status LED
Camera Status LED
Mode Switch (Normal/Covert)
HD Camera Lens
Wheel Switch (C1/C2/C3/C4)
Main Button (Start/Stop/Mark/Confirm)
Speaker
Dock Connector: Connects to the
charging dock.
Interlocking Grooves: Fit the tongues of
the chest/molle mount.
3
.
Attaching to the Mount
To attach the camera to the mount:
1. Aligning the tongues and grooves, slide
the mount downwards to the camera
until the two fit and click into place.
2. Slide the latch inwards to secure the
camera to the mount.
To detach:
1. Slide the latch outwards to the unlocked
position.
2. Slide the camera off the mount.
4
.
Docking
1. Connect the power cable to the adapter
plug (
).
2. Connect the adapter plug to an electrical
outlet (
)
3. Put BWC BC-02 in the charging dock.
The LED on the dock lights up to indicate
power is connected.
5
.
Notices
FCC Regulations
This device complies with Part 15 of the FCC
Rules. Operation is subject to the following
two conditions: (1) This device may not cause
harmful interference, and (2) this device
must accept any interference received,
including interference that may cause
undesired operation.
To assure continued compliance, follow the
attached installation instructions and do
not make any unauthorized modifications.
Warning:
To assure continued FCC emission limit
compliance, the user must only use shielded
interface cables when connecting to external
units. Also, any unauthorized changes or
modifications to this equipment could void
the user’s authority to operate this device.
6
.
More Information
For detailed information of the product, go
to Getac web link at
http://www.getac.com
Support.
