1
Getting Started
Unpacking
EX80 Tablet PC
Charging cradle Stylus
Tether
AC adapter Screen cleaning cloth
Power plug
Document(s)
*
Driver disc (optional)
* The power plug type depends on country of
purchase. Only one type of the plus is shown in
this document.
Instal l ing the SIM Card (Optional )
1. Locate the SIM card cover. Unfasten two
screws and flip open the cover.
2. Noting the orientation, insert the SIM card all
the way into the slot.
3. Close the cover and secure with 2 screws.
Connecti ng to AC Power and Starting Up
The first time you use your
Tablet PC, connect the AC
adapter.
1. Aligning the docking
connectors, fit your Tablet
PC on the charging cradle.
2. Fit the power plug to the AC adapter ().
3. Connect the DC jack end of the AC adapter to
your device () and the other end to a wall
outlet ().
4. Press the power button ( ) to start up.
5. When turning on your Tablet PC for the very
first time, you will be guided through a setup
process.
Tap the touchscreen with your finger to
communicate with the Tablet PC.
NOTE: By default settings, your
touchscreen responds to fingertips
instead of the stylus. After Windows
setup wizard is completed, the Touch
Screen mode selection menu will
appear on the screen. If you prefer
using the stylus, select Pen in this
menu.
2
Taking a Look at the Tablet PC
1 Inside the cover.
2
There is one holder at each corner of the Tablet PC.
1
Camera
lens
G-Manager
Internet
Explorer
Start
Brightness
up
Brightness
down
Power button
Microphone
Touchscreen
Speaker
Tether holder2
Docking connector
Camera lens
Flash
NFC reader
Indicators:
Camera
Battery
Power
3
Taking Care of the Tablet PC
Loc ati on Guidel ines
• For optimal performance, use the Tablet PC
where the recommended tempe-
rature is between 0 °C (32 °F) and 50 °C (122
°F). (Actual operating temperature depends
on product specifications.)
• Avoid placing the Tablet PC in a location
subject to high humidity, extreme tempe-
ratures, mechanical vibration, direct sun-
light, or heavy dust. Using in extreme
environments for long periods can result in
product deterioration and a shortened
product life.
• Place the Tablet PC on a flat and steady
surface. Do not stand the Tablet PC on its
side or store it in an upside-down position. A
strong impact by dropping or hitting may
damage the Tablet PC.
• Do not cover or block any ventilation
openings on the Tablet PC. For example, do
not place the Tablet PC on a bed, sofa, rug,
or other similar surface. Otherwise,
overheating may occur that results in damage
to the Tablet PC.
• As the Tablet PC can become very hot during
operation, keep it away from objects that are
vulnerable to heat.
• Keep the Tablet PC at least 13 cm (5 inches)
away from electrical appliances that can
generate a strong magnetic field such as a
TV, refrigerator, motor, or a large audio
speaker.
• Avoid moving the Tablet PC abruptly from a
cold to a warm place. A temperature
difference of more than 10 °C (18 °F) may
cause condensation inside the unit, which
may damage the storage media.
General Guidel ines
• Do not place heavy objects on top of the
Tablet PC as this may damage the display.
• The screen surface is easily scratched. Avoid
touching it with a sharp object such as a pen
or pencil.
• LCD image sticking occurs when a fixed
pattern is displayed on the screen for a
prolonged period of time. You can avoid the
problem by limiting the amount of static
content on the display. It is recom-
mended that you use a screen saver or turn
off the display when it is not in use.
• To maximize the life of the backlight in the
display, allow the backlight to auto-
matically turn off as a result of power
management.
Cleaning Guidelines
• Never clean the Tablet PC with its power on.
• Use a soft, lint-free cloth to wipe the
exterior surfaces of the Tablet PC.
• If water or liquid is split onto the Tablet PC,
wipe it dry and clean when possible. Do not
leave the Tablet PC wet when you can dry it.
• If the Tablet PC gets wet where the tem-
perature is 0 °C (32 °F) or below, freeze
damage may occur. Make sure to dry the wet
Tablet PC.
Battery Pack Guidelines
• To charge the battery, connect the AC adapter
to the computer and an electrical outlet. The
Battery Charge Indicator ( ) on the Tablet
PC glows amber to indicate that charging is in
progress. When the battery is fully charged,
the Battery Charge Indicator glows green.
• Recharge the battery pack when it is nearly
discharged. When recharging, make sure that
the battery pack is fully charged. Doing so
may avoid harm to the battery pack.
• The battery pack is a consumable product
and the following conditions will shorten its
life:
– when frequently charging the battery
pack
– when using, charging, or storing the
battery in high temperature condition
• To avoid hastening the deterioration of the
battery pack thereby prolonging its useful life,
minimize the number of times you charge it
so as not to frequently increase its internal
temperature.
• Charge the battery pack between 10 °C ~ 30
°C (50 °F ~ 86 °F) temperature range.
A higher environment temperature will cause
the battery pack’s temperature to rise. Avoid
charging the battery pack inside a closed
vehicle and in hot weather con-
dition. Also, charging will not start if the
4
battery pack is not within the allowed
temperature range.
• It is recommended that you do not charge the
battery pack more than once a day.
• It is recommended that you charge the
battery pack with the Tablet PC’s power off.
• To maintain the battery pack’s operating
efficiency when the Tablet PC is not in use,
store it in a cool dark place and with 30% ~
40% charge remaining.
• The Tablet PC’s input voltage and sur-
rounding temperature will directly affect the
battery pack’s charge and discharge time:
– charging time will be prolonged when
the Tablet PC is turned on.
To shorten the charging time, it is recom-
mended that you place the Tablet PC in
Sleep or hibernation mode.
– a low temperature will prolong the
charging time as well as hasten the dis-
charge time.
• When using battery power in an extremely low
temperature environment, you may experience
shortened operating time and incorrect battery
level reading. This phe-
nomenon comes from the chemical char-
acteristics of batteries. The appropriate
operating temperature for the battery is
-10 °C ~ 50 °C (14 °F ~ 122 °F).
Touchsc reen Guidelines
• Use the finger or the included stylus on the
display. Using a sharp or metallic object other
than your finger or stylus may cause
scratches and damage the display, thereby
causing errors.
• Use a soft cloth to remove dirt on the dis-
play. The touchscreen surface has a special
protective coating that prevents dirt from
sticking to it. Not using a soft cloth may cause
damage to the special protective coating on
the touchscreen surface.
• Turn off the Tablet PC power when clean-
ing the display. Cleaning the display with the
power on may cause improper opera-
tion.
• Do not use excessive force on the display.
Avoid placing objects on top of the display as
this may cause the glass to break thereby
damaging the display.
• Using the touchscreen during low tempe-
rature (less than 5 oC / 41 °F) may cause a
slower response time. This is normal. A
normal response time may be restored upon
returning to room temperature.
• When there is a noticeable discrepancy in the
placement of the stylus on the screen and the
indicated position of the onscreen pointer,
use the calibration utility to reca-
librate the touchscreen display.
System Recovery
Tap Sett ings Update & sec urit y. You
have several options.
• System Restore
• Recover from a drive
• Reset this PC
See Microsoft website for more information.
More Infor mati on
For complete information of the product, refer to
the User Manual (in PDF format)
on your Window’s desktop or Driver Disc.
You can download the latest manual and drivers
by accessing the Getac web link at
ht tp:/ / www.getac.com Support.
FCC Regulations:
This device complies with part 15 of the FCC
Rules. Operation is subject to the following two
conditions: (1) This device may not cause
harmful interference, and (2) this device must
accept any interference received, including
interference that may cause undesired
operation.
Changes or modifications not expressly
approved by the party responsible for
compliance could void the user‘s authority to
operate the equipment.
This equipment has been tested and found to
comply with the limits for a Class B digital device,
pursuant to part 15 of the FCC Rules. These
limits are designed to provide reasonable
protection against harmful interference in a
residential installation. This equipment
generates, uses and can radiate radio frequency
561xxxxxxxxxR00
5
energy and, if not installed and used in
accordance with the instructions, may cause
harmful interference to radio communications.
However, there is no guarantee that interference
will not occur in a particular installation. If this
equipment does cause harmful interference to
radio or television reception, which can be
determined by turning the equipment off and on,
the user is encouraged to try to correct the
interference by one or more of the following
measures:
—Reorient or relocate the receiving antenna.
—Increase the separation between the
equipment and receiver.
—Connect the equipment into an outlet on a
circuit different from that to which the
receiver is connected.
—Consult the dealer or an experienced radio/TV
technician for help.
