Giant Electronics T5000 Transmitter Portion of GMRS+FRS User Manual Manual
Giant Electronics Ltd Transmitter Portion of GMRS+FRS Manual
Manual
T5000 & T5500 user guide --- Pg 2
2
Contents
3
11
12
14
14
14
15
16
16
17
17
17
18
19
19
19
Special Features
Interference Eliminator Code
Push to Talk Timeout Timer
Locking the Keypad
Scanning Channels
Scan Advance
Alerts
Channel Busy Indicator
Setting and Transmitting Call Tones
Transmitting a Talk Confirmation Tone
QT Noise Filtering
Accessories
Using Audio Accessories
Voice Activation (VOX) Accessories
Setting the Sensitivity Level
Patent Information
Copyright Information
20
20
20
20
21
21
22
22
22
23
23
25
25
25
26
27
28
T5000 & T5500 user guide --- Pg 1
1
Contect
Safety and General Information
FCC Licensing Information
Control Buttons
Getting Started
Installing the the AA Batteries
Installing the NiCd Battery Pack
Battery Meter
Attaching the Belt Clip
Removing the Belt Clip
Turning Your Radio On and Off
Setting the Volume
Setting a Channel
Channels and Frequencies
Talking and Listening
Talk Range
Check the Channel Before Transmitting
Contents
4
T5000 & T5500 user guide --- Pg 4
T5000 & T5500 user guide --- Pg3
3
Safety and General Information
Safety and General Information
Important Information on Safe and Efficient Operation
Read This Information Before Using Your Radio
The information provided in this document supersedes the general safety information
contained in user guides published prior to July 2000.
Transmit and Receive Procedure
Your two-way radio contains a transmitter and a receiver. To control your exposure
and ensure compliance with the general population/uncontrolled environment exposure
limits, always adhere to the following procedure:
Exposure To Radio Frequency Energy
Your Motorola radio is designed to comply with the following national and international
standards and guidelines regarding exposure of human beings to radio frequency
electromagnetic energy:
Transmit no more than 50% of the time.
To transmit (talk), press the Push to Talk (PTT) button.
To receive calls, release the PTT button.
•
•
•
Transmitting 50% of the time, or less, is important because the radio generates
measurable RF energy exposure only when transmitting (in terms of measuring
standards compliance).
• United States Federal Communications Commission, Code of Federal Regulations;
47 CFR part 2 sub-part J
American National Standards Institute (ANSI) / Institute of Electrical and Electronic
Engineers (IEEE) C95. 1-1992
Institute of Electrical and Electronic Engineers (IEEE) C95.1-1999 Edition
International Commission on Non-Ionizing Radiation Protection (ICNIRP) 1998
Ministry of Health (Canada) Safety Code 6. Limits of Human Exposure to Radio
Frequency Electromagnetic Fields in the Frequency Range from 3 kHz to 300 GHz,
1999
Australian Communications Authority Radiocommunications (Electromagnetic
Radiation - Human Exposure) Standard 2001 (applicable to wireless phones only)
ANATEL, Brasil Regulatory Authority, Resolution 256 (April 11, 2002) "additional
requirements for SMR, cellular, and PCS product certification."
To assure optimal radio performance and make sure human exposure to radio frequency
electromagnetic energy is within the guidelines set forth in the above standards, always
adhere to the following procedures.
Portable Radio Operation and EME Exposure
Antenna Care
Use only the supplied or an approved replacement antenna. Unauthorized antennas,
modifications, or attachments could damage the radio and may violate FCC regulations.
DO NOT hold the antenna when the radio is “IN USE.” Holding the antenna affects
the effective range.
•
•
•
•
•
•
Safety and General Information
5
Safety and General Information
T5000 & T5500 user guide --- Pg 5
6
Safety and General Information
T5000 & T5500 user guide --- Pg 6
Body-Worn Operation
To maintain compliance with FCC/Health Canada RF exposure guidelines, if you wear
a radio on your body when transmitting, always place the radio in a Motorola-supplied
or approved clip, holder, holster, case, or body harness for this product. Use of non-
Motorola-approved accessories may exceed FCC/Health Canada RF exposure guidelines.
If you do not use one of the Motorola-supplied or approved body-worn accessories,
and are not using the radio held in the normal use position, ensure the radio and its
antenna are at least 1 inch (2.5 cm) from your body when transmitting *
Data Operation
If applicable, when using any data feature of the radio with or without an accessory
cable, position the radio and its antenna at least 1 inch (2.5 cm) from the body.
Approved Accessories
For a list of approved Motorola accessories, please contact place of purchase.
Electromagnetic Interference/Compatibility
Note: Nearly every electronic device is susceptible to electromagnetic interference
(EMI) if inadequately shielded, designed, or otherwise configured for
electromagnetic compatibility.
Two-way Radio Operation
When using your radio as a traditional two-way radio, hold the radio
in a vertical position with the microphone 1 to 2 inches (2.5 to 5 cm)
away from the lips.
Facilities
To avoid electromagnetic interference and/or compatibility conflicts, turn off your radio
in any facility where posted notices instruct you to do so. Hospitals or health care
facilities may be using equipment that is sensitive to external RF energy.
Aircraft
When instructed to do so, turn off your radio when on board an aircraft. Any use of a
radio must be in accordance with applicable regulations per airline crew instructions.
Medical Devices - Pacemakers
The Advanced Medical Technology Association recommends that a minimum separation
of 6 inches (15 cm) be maintained between a handheld wireless radio and a pacemaker.
These recommendations are consistent with the independent research by, and
recommendations of the U.S. Food and Drug Administration.
Persons with pacemakers should:
•
•
•
•
ALWAYS keep the radio more than 6 inches (15 cm) from their pacemaker
when the radio is turned ON.
Not carry the radio in the breast pocket.
Use the ear opposite the pacemaker to minimize the potential for
interference.
Turn the radio OFF immediately if you have any reason to suspect that
interference is taking place.
T5000 & T5500 user guide --- Pg 7
7
Safety and General Information
T5000 & T5500 user guide --- Pg 8
8
Safety and General Information
Potentially Explosive Atmospheres
Turn off your radio prior to entering any area with a potentially explosive atmosphere,
unless it is a radio type especially qualified for use in such areas as “Intrinsically Safe.”
Do not remove, install, or charge batteries in such areas. Sparks in a potentially
explosive atmosphere can cause an explosion or fire resulting in bodily injury or even
death.
Note: The areas with potentially explosive atmospheres referred to above include
fueling areas such as below decks on boats, fuel or chemical transfer or storage
facilities, areas where the air contains chemicals or particles, such as grain,
dust or metal powders, and any other area where you would normally be
advised to turn off your vehicle engine. Areas with potentially explosive
atmospheres are often but not always posted.
Blasting Caps and Areas
To avoid possible interference with blasting operations, turn off your radio when you
are near electrical blasting caps, in a blasting area, or in areas posted: “Turn off two-
way radio.” Obey all signs and instructions.
Operational Cautions
Antennas
Do not use any portable radio that has a damaged antenna. If a damaged antenna
comes into contact with your skin, a minor burn can result.
Other Medical Devices
If you use any other personal medical device, consult the manufacturer of your device
to determine if it is adequately shielded from RF energy. Your physician may be able
to assist you in obtaining this information.
Safety and General Use While Driving
Check the laws and regulations on the use of radios in the area where you drive.
Always obey them. When using your radio while driving, please:
•
•
•
Give full attention to driving and to the road.
Use hands-free operation, if available.
Pull off the road and park before making or answering a call if driving conditions
so require.
Operational Warnings
For Vehicles with an Air Bag
Do not place a portable radio in the area over an air bag or in the air bag deployment
area. Air bags inflate with great force. If a portable radio is placed in the air bag
deployment area and the air bag inflates, the radio may be propelled with great force
and cause serious injury to occupants of the vehicle.
Medical Devices - Hearing Aids
Some digital wireless radios may interfere with some hearing aids. In the event of
such interference, you may want to consult your hearing aid manufacturer to discuss
alternatives.
T5000 & T5500 user guide --- Pg 9
9
Safety and General Information
T5000 & T5500 user guide --- Pg 10
10
Safety and General Information
All batteries can cause property damage and/or bodily injury such as burns if a
conductive material such as jewelry, keys, or beaded chains touch exposed terminals.
The conductive material may complete an electrical circuit (short circuit) and become
quite hot. Exercise care in handling any charged battery, particularly when placing it
inside a pocket, purse, or other container with metal objects.
Battery Charger Safety Instructions
Save these Instructions
Do not expose the charger to rain or snow.
Do not operate or disassemble the charger if it has received a sharp blow, or has
been dropped or damaged in any way.
Never alter the AC cord or plug provided with the unit. If the plug will not fit the
outlet, have the proper outlet installed by a qualified electrician. An improper
condition can result in a risk of electric shock.
To reduce the risk of damage to the cord or plug, pull the plug rather than the cord
when disconnecting the charger from the AC receptacle.
To reduce the risk of electric shock, unplug the charger from the outlet before
attempting any maintenance or cleaning.
Use of an attachment not recommended or sold by Motorola may result in a risk
of fire, electric shock, or personal injury.
1.
2.
3.
4.
5.
6.
Make sure the cord is located so it will not be stepped on, tripped over, or subjected
to damage or stress.
An extension cord should not be used unless absolutely necessary. Use of an
improper extension cord could result in a risk of fire and/or electric shock. If an
extension cord must be used, make sure that:
The pins on the plug of the extension cord are the same number, size and shape
as those on the plug of the charger.
The extension cord is properly wired and in good electrical condition.
The cord size is 18 AWG for lengths up to 100 feet, and 16 AWG for lengths up
to 150 feet.
The supply cord of this charger cannot be replaced. If the cord is damaged, please
contact place of purchase.
7.
8.
9.
•
•
•
Batteries
T5000 & T5500 user guide --- Pg 11
11
T5000 & T5500 user guide --- Pg 12
12
FCC Licensing Information
Control Buttons - Models T5000
LED indicator light
Use to:
Use to:
Speaker
Use to:
Accessory Jack
Use to:
Use and to:
Microphone
Use to:
Transmit call tone
Select menu options
Exit the menu (when pressed
while in a menu)
Lock and unlock the
keypad (when held down and
not in a menu)
Scan
Your Motorola radio operates on General Mobile Radio Service (GMRS) frequencies
and is subject to the Rules and Regulations of the Federal Communications Commission
(FCC). The FCC requires that all operators using GMRS frequencies obtain a radio
license before operating their equipment. To obtain the FCC forms, please request
Form 605 and 159, which includes all forms and instructions. If you wish to have the
document faxed or mailed, or have questions, please use the following contact
information.
FCC Licensing Information
Faxed
Contact the Fax-On-
Demand system at:
Questions
Regarding FCC license
Contact the FCC at:
Mailed
Call the FCC forms
hotline at:
1-202-418-0177 1-800-418-FORM
1-800-418-3676
1-888-CALL-FCC
1-888-225-5322
Or: http://www.fcc.gov
Changes or modifications not expressly approved by Motorola may void the user’s
authority granted by the FCC to operate this radio and should not be made. To comply
with FCC requirements, transmitter adjustments should be made only by or under
the supervision of a person certified as technically qualified to perform transmitter
maintenance and repairs in the private land mobile and fixed services as certified by
an organization representative of the user of those services. Replacement of any
transmitter component (crystal, semiconductor, etc.) not authorized by the FCC
equipment authorization for this radio could violate FCC rules.
Note: Use of this radio outside the country where it was intended to be distributed
is subject to government regulations and may be prohibited.
Control Buttons - Models T5000
Turn radio on/off
Adjust volume
Talk
Save a setting
Scroll through menus
•
•
•
•
•
•
•
•
•
•
T5000 & T5500 user guide --- Pg 14
14
Getting Started
T5000 & T5500 user guide --- Pg 13
13
Control Buttons - Models T5500
LED Indicator Light
Use to:
Use to:
Speaker
Use to:
Removable Front Cover
Talk
Save a setting
Turn radio on/off
Adjust volume
Transmit call tone
Use to:
Accessory J ack
Use to:
Use and to:
Microphone
Scan
Scroll through menus
Select menu options
Exit the menu (when pressed
while in a menu)
Lock and unlock the
keypad(when held down and
not in a menu)
Your radio uses 3 AA Alkaline batteries.
With the back of the radio facing you, lift the battery latch
up to release the battery cover and remove the cover.
Insert 3 AA Alkaline batteries as shown on the inside of the
battery compartment.
Reposition the battery cover and press down to secure.
Installing the NiCd Battery Pack
Follow step 1 above to remove the battery cover.
Remove the battery pack from the clear plastic bag.
Do not disassemble or unwrap the battery pack.
Insert the NiCd battery pack so the matel contacts on
the side of the battery are facing outward from the radio
to connect with the contacts on the battert door.
Reposition the battery cover and press down to secure.
Getting Started
1.
2.
3.
1.
2.
3.
4.
Installing the AA Batteries
Note: The T5000 and T5500 model radios can use a NiCd
rechargeable battery instead of 3 AA Alkaline batteries.
A rechargeable battery upgrade kit, is available for these
radios.
Control Buttons - Models T5500
•
•
•
•
••
•
•
•
•
T5000 & T5500 user guide --- Pg 15
15
Getting Started
T5000 & T5500 user guide --- Pg 16
16
Getting Started
Battery Meter
The battery icon shows the battery charge level, from full to empty . When
the battery is empty, the radio chirps periodically after releasing . The radio powers
off when the voltage drops below a predetermined level to protect the rechargeable
battery.
Note: Remove the batteries before storing your radio for extended periods of time.
Batteries corrode over time and may cause permanent damage to your radio.
Using the Desk Stand Charger (Optional Accessory)
The desk stand charger provides drop-in charging convenience for NiCd batteries and
can be placed on any flat surface, such as a desk or workbench. Charge the NiCd battery
overnight (at least 16 hours) before using it for the first time. After the initial charge,
an empty battery is fully charged within 14 hours.
Turn the radio off and remove the battery cover.
Remove the battery pack from the clear plastic bag.
Do not disassemble or unwrap the battery pack.
Insert the NiCd battery pack so the metal contacts on the side of the battery are
facing outward from the radio to connect with the contacts on the battery door.
Reposition the battery cover and press down to secure.
Plug the AC power supply into the plug on the desk stand.
Plug the AC power supply into a standard wall outlet.
Slide the radio into one of the charging pockets facing forward.
1.
2.
3.
4.
5.
6.
7.
To charge the battery pack separately from the radio:
Remove the battery pack from the clear plastic bag.
Do not disassemble or unwrap the battery pack.
Insert the battery pack into the charging pocket. Make sure the metal contacts on
the side of the battery are making contact with the contacts inside the charger.
Plug the AC power supply into the plug on the desk stand.
Plug the AC power supply into a standard wall outlet.
1.
2.
3.
4.
Notes
When moving between hot and cold temperatures, do not charge the battery
until the battery temperature acclimates (usually about 20 minutes).
For optimal battery life, remove the radio or battery from the charger within
16 hours. Do not store the radio in the charger.
•
•
Attaching the Belt Clip
Align the belt clip post with the hole in the back of the radio.
Gently push until the clip clicks into place.
1.
2.
Removing the Belt Clip
Push down on the release tab at the top of the belt clip to
release the catch.
Pull the belt clip away from the back of the radio.
1.
2.
T5000 & T5500 user guide --- Pg 17
17
Getting Started
T5000 & T5500 user guide --- Pg 18
18
Getting Started
Turning Your Radio On and Off
Turn clockwise to turn the radio on and counterclockwise to turn the radio off.
The radio chirps and the display briefly shows all feature icons available on your radio.
The display then scrolls through the available channels and Interference Eliminator
Codes.
Setting the Volume
Rotate while holding down or until you reach a comfortable listening
level. Rotate clockwise to increase the volume or counterclockwise to decrease
the volume.
Setting a Channel
Your radio has 22 channels. Channels 1-7 and 15-22 are 1 watt. Channels 8-14 are
0.5 watt. When the radio is on a 1 watt channel, displays. When the radio is on a
0.5 watt channel, displays.
With the radio on, press . The current channel flashes.
Press or to set the channel.
Press to save the channel setting.
1.
2.
3.
Channels and Frequencies
Channel Frequency Description Channel Frequency Description
1
2
3
4
5
6
7
8
9
10
11
462.5625 MHz
462.5875 MHz
462.6125 MHz
462.6375 MHz
462.6625 MHz
462.6875 MHz
462.7125 MHz
467.5625 MHz
467.5875 MHz
467.6125 MHz
467.6375 MHz
GMRS/FRS
GMRS/FRS
GMRS/FRS
GMRS/FRS
GMRS/FRS
GMRS/FRS
GMRS/FRS
FRS
FRS
FRS
FRS
12
13
14
15
16
17
18
19
20
21
22
467.6625 MHz
467.6875 MHz
467.7125 MHz
462.5500 MHz
462.5750 MHz
462.6000 MHz
462.6250 MHz
462.6500 MHz
462.6750 MHz
462.7000 MHz
462.7250 MHz
FRS
FRS
FRS
GMRS
GMRS
GMRS
GMRS
GMRS
GMRS
GMRS
GMRS
T5000 & T5500 user guide --- Pg 19
19
Talking and Listening
T5000 & T5500 user guide --- Pg 20
20
Special Features
Talking and Listening
To communicate, all radios in your group must be set to the same channel and
Interference Eliminator Code.
Locking the Keypad
To avoid accidentally changing your radio settings, press and hold for 3 seconds
or until displays. You can turn the radio on and off, adjust the volume, receive,
transmit, send a call tone, and monitor channels. All other functions are locked.
To unlock the radio, press and hold for 3 seconds or until is no longer
displayed.
To talk, press and hold . Hold the radio 2 to 3 inches away from your mouth when
talking.
When you finish talking, release (press to talk, release to listen).
Talk Range
Your radio is designed to maximize performance and improve transmission range.
Do not use the radios closer than 5 feet apart.
Special Features
Interference Eliminator Code
Interference Eliminator Codes help minimize interference by providing you with a choice
of code combinations.
To set the code for a channel:
Press until the code starts to flash.
Press or to select the code.
Press to save the code setting.
1.
2.
3.
You can set a different code for each channel using this procedure.
Note: You must set the Interference Eliminator Code to on an FRS radio that uses
Interference Eliminator Codes to communicate with other FRS radios that do
not have Interference Eliminator Codes.
Push to Talk Timeout Timer
To prevent accidental transmissions and save battery life, the radio emits a continuous
warning tone and stops transmitting if you press for 60 continuous seconds.
Checking the Channel Before Transmitting
Your radio has multiple channels shared on a "take turns" basis. For uninterrupted
communication, do not talk on a channel is someone else is currently talking on it.
To check for activity on a channel before you talk, press and hold or . If you
hear static, the channel is clear to use.
T5000 & T5500 user guide --- Pg 21
21
Special Features
T5000 & T5500 user guide --- Pg 22
22
Alerts
To start scanning, briefly press and release or . The scan indicator displays.
When the radio detects channel activity, it stops scanning and you can hear the
transmission. To respond to the transmitting, press within 5 seconds.
Note: If your radio's Interference Eliminator Code is set to while scanning, the
radio checks for activity on each channel regardless of the code used on the
channel. If your radio's Interference Eliminator Code is set to - , the radio
checks for activity only on channels using codes - and ignores channels
using code .
Scan Advance
If the radio stops scanning on a channel you do not want to listen to, briefly press and
release or to resume scanning for the next active channel.
Removing Channels from the Scan List (Nuisance Delete Feature)
To remove a channel so the radio does not stop on it while scanning, press and hold
or for at least 3 seconds, then release. This temporarily removes the channel
from the scan list.
To restore the channel, turn the radio off and then back on.
Note: You cannot remove the channel your radio was set to when you started the
scan (called your home channel).
Scanning Channels (Model T5500 Only)
Use scanning to monitor channels and codes for transmissions or to find someone
in your group who has accidentally changed channels.
Alerts
Channel Busy Indicator
When a channel is busy, the LED flashes twice per second.
Setting and Transmitting Call Tones
Your radio can transmit different call tones to other radios in your group so you can
alert them that you want to talk.
To set a call tone:
With the radio on, press 3 times. The current call tone setting flashes and
displays.
Press or to change and hear the call tone.
Press or to set the new call tone.
1.
2.
3.
To transmit your call tone to other radios set to the same channel and Interference
Eliminator Code as your radio, press .
Notes
The T5000 model have 5 call tones. The T5500 model have 10 call tones.
Setting the call tone to disables the call tone feature.
•
•
T50800 & T5500 user guide --- Pg 23
23
Alerts
T5000 & T5500 user guide --- Pg 24
24
Alerts
Transmitting a Talk Confirmation Tone
You can set your radio to transmit an unique tone when you finish transmitting. It's
like saying Roger or Over to let others know you are finished talking.
To turn talk confirmation on, press and hold while you turn the radio on. When
you release after transmitting, your call tone transmits and displays.
To turn talk confirmation off, turn your radio off and then back on while pressing
and holding .
•
•
QT Noise Filtering (Models T5500 Only)
The QT noise filtering feature helps ensure uninterrupted communication with other
Motorola T5000 Series radios that have this feature. This feature filters out unwanted
transmissions from other radios. It is useful in places where there is heavy radio traffic,
such as at an amusement park or ski resort.
Note: QT noise filtering is not available while the radio is scanning.
To turn QT noise filtering on or off:
Press until displays.
Press or until displays to turn noise filtering on, or until – displays to
turn noise filtering off.
Press to confirm your selection.
1.
2.
3.
To transmit to a radio that has QT noise filtering turned on:
Select the same channel and Interference Eliminator Code as the other radio.
Press to send a call tone. This allows your voice to pass through the QT noise
filter on the receiving radio.
Press and speak normally.
1.
2.
3.
Note: If you skip step 2, the beginning of your message may not be heard on the
receiving radio.
For a 30-second period, starting after the last transmission, all transmissions
received on the selected channel and code will pass through the QT noise filter.
T5000 & T5500 user guide --- Pg 25
25
Accessories
Accessories
There are many accessories (sold separately) available for your radio. For more
information, refer to the brochure included with your radio, contact the place of
purchase.
Using Audio Accessories
Turn the radio off. Plug the accessory connector into the jack. See page12 and 13
for the location of the accessory jack on your radio.
Turn the radio on. Lower the volume before placing the accessory on your head
or in your ear.
Press or while rotating to adjust the volume to a comfortable level.
To transmit, press and speak into the accessory microphone, if any.
To receive, release .
1.
2.
3.
4.
5.
Voice Activation (VOX) Accessories (Model T5500 Only)
Voice activation (VOX) allow you to talk handsfree when used with optional accessories
connected to the radio. See the Motorola Talkabout accessory brochure for available
VOX accessories.
Turn the radio off.
Insert the plug of the audio accessory firmly into the accessory jack (see page 13).
Turn the radio on. displays.
Lower the radio volume before placing the accessory on your head or in your ear.
1.
2.
3.
4.
T5000 & T5500 user guide --- Pg 26
26
Accessories
Setting the Sensitivity Level (Model T5500 Only)
Adjusting the radio’s sensitivity level helps minimize the possibility of unintended
noises triggering a transmission and helps the radio pick up soft voices.
Press until displays.
Press or to select the sensitivity level:
1.
2.
= High Sensitivity
for quiet environments = Medium Sensitivity
for most environments = Low Sensitivity
for noisy environments
When you connect a VOX accessory, the radio is automatically set to the last
chosen sensitivity level.
Note:
To transmit, speak into accessory microphone. There is a short delay between the
time you start talking and when the radio transmits.
To receive, stop talking.
5.
6.
To turn VOX off, press or remove the audio accessory.
Manufactured, distributed or sold by Giant International Ltd., official licensee for this
product. Motorola, the Motorola logo trademarks and the Motorola trade dress are
owned by Motorola, Inc. and are used under license from Motorola, Inc. Please contact
Giant International Ltd. at 800-638-5119 for questions/comments, warranty, support,
or service related to this product. MOTOROLA and the Stylized M Logo are registered
in the U.S. Patent & Trademark Office. All other product or service names are the
property of their respective owners. © Motorola, Inc. 2002.
Copyright InformationCopyright Information
T5000 & T5500 user guide --- Pg 27
27
Patent Information
Patent Information
This product is manufactured under one or more of the following United States patents.
5896277 5894292 5864752 5699006 5742484 D408396 D399821 D387758 D389158
5894592 5893027 5789098 5734975 5861850 D395882 D383745 D389827 D389139
5929825 5926514 5953640 6071640 D413022 D416252 D416893 D433001
Export Law Assurances
This product is controlled under the export regulations of the United States of America
and Canada. The Governments of the United States of America and Canada may
restrict the exportation or re-exportation of this product to certain destinations. For
further information contact the U.S. Department of Commerce or the Canadian
Department of Foreign Affairs and International Trade.
T5000 & T5500 user guide --- Pg 28
28
Copyright Information
Audible Call Tones
5 call tones (Model T5000)
10 call tones (Model T5500).
•
Low Battery Alert
Audible tone and visual display
tell you when the battery is
running down.
•
Scaning
Easily finds channel and code
by searching all combinations
(Models T5500 only).
•
1 Year Limited Warranty
For warranty details, please ask
your retailer.
•
User's Guide Included•
Illuminated Display
Easy to read your settings
in dark places.
•
Motorola Quality
Shock, drop, and temperature
tested to meet Motorola's high
quality standards.
•
MOTOROLA and the Stylized M Logo are registered in the US Patent & Trademark Office. All other product or service names are the
property of their respective owners. © Motorola, Inc. 2002.
FCC GMRS LICENSE REQUIRED
WARNING CHOKING HAZARD
SMALL PARTS
Not for children under 3 years.
This product is not intended to be used
as a toy or plaything.
22 Channels (8 GMRS,
7 GMSR/FRS, 7 FRS)
with 38 Interference
Eliminator Codes
GMRS channels feature
increased power for longer
range. 14 channels ensure
backward compatibility with
FRS two-way radios.
Eliminator Codes minimize
interference from other groups.
•
Talk Handsfree
With Voice Activation (VOX)
when used with optional
accessories (Models T5500 only)
•
• Quick Release Swivel Belt
Clip Included
• Weather-resistant
Helps protect radios against the
elements.
• Talk Confirmation Tones
Signals others you are finished
talking.
•Durable, Fixed Antenna
Maximizes talk range.
T5000 & T5500 user guide --- cover
T5000 & T5500 user guide --- back
• QT Noise Filter
Filters out unwanted
transmissions in heavy
radio traffic areas
(Models T5500 only).
User's Guide
Model T5000,T5500
UNF-CB RECREATIONAL TWO-WAY RADIOS
Helen haven't any good
pics / finished model
dummy for this cover
