Users Manual

User manual

www.philips.com/support

B8_37_CD-UM_EN.indd 1 3/03/2017 11:37:38 AM

B8_37_CD-UM_EN.indd 2 3/03/2017 11:37:38 AM

1EN

Contents

1 Important 2

Important safety instructions 2

Care for your product 3

Care of the environment 3

Help and support 4

2 Your product 4

Main unit 4

Remote control 5

Connectors 6

Wireless subwoofer 6

3 Connect 7

Placement 7

Pair up with the subwoofer 8

Connect audio from TV 8

Connect audio from other devices 10

Connect digital devices through

HDMI 11

4 Use your product 11

Set clock 11

Auto standby 12

Adjust the volume 12

Dolby Atmos® 12

Choose your sound 13

Play audio through Bluetooth 14

Connect Bluetooth via NFC 15

MP3 player 15

USB storage devices 15

Set display brightness 16

Apply factory settings 16

5 Update software 17

Check software version 17

Update software via USB 17

6 Wall mount 18

7 Product specications 18

8 Trouble shooting 19

9 Notice 21

Notice of compliance 21

B8_37_CD-UM_EN.indd 1 3/03/2017 11:37:38 AM

2EN

1 Important

Read and understand all instructions

before you use your product. If damage

is caused by failure to follow instructions,

the warranty does not apply.

Important safety

instructions

•Read these instructions.

•Keep these instructions.

•Heed all warnings.

•Follow all instructions.

•Do not use this apparatus near water

•Clean only with dry cloth.

•Do not block any ventilation

openings. Install in accordance with

the manufacturer’s instructions.

•Do not install near any heat

sources such as radiators, heat

registers, stoves, or other apparatus

(including ampliers) that produce

heat.

•Do not defeat the

safety purpose of

the polarized or

grounding-type plug. A polarized

plug has two blades with one wider

than the other. A grounding type

plug has two blades and a third

grounding prong. The wide blade or

the third prong are provided for your

safety. If the provided plug does

not t into your outlet, consult an

electrician for replacement of the

obsolete outlet.

•Protect the power cord from being

walked on or pinched, particularly

at plugs, convenience receptacles,

and the point where they exit from

the apparatus.

•Only use attachments/accessories

specied by the manufacturer.

•Use only with the cart,

stand, tripod, bracket or

table specied by the

manufacturer or sold with

the apparatus. When a cart is used,

use caution when moving the cart/

apparatus combination to avoid

injury from tip-over.

•Unplug this apparatus during

lightning storm or when unused for

long periods of time.

•Refer all servicing to qualied

service personnel. Servicing is

required when the apparatus has

been damaged in any way, such

as power-supply cord or plug is

damaged, liquid has been spilled

or objects have fallen into the

apparatus, the apparatus has been

exposed to rain or moisture, does

not operate normally, or has been

dropped.

•Battery usage CAUTION - To

prevent battery leakage which may

result in bodily injury, property

damage, or damage to the unit:

• Install all batteries correctly, +

and - as marked on the unit.

• Do not mix batteries (old and new

or carbon and alkaline, etc.).

• Remove batteries when the unit

is not used for a long time.

• The batteries shall not be

exposed to excessive heat such

as sunshine, re or the like.

• Perchlorate Material - special

handling may apply. See www.

dtsc.ca.gov/hazardouswaste/

perchlorate.

• The product/remote control may

contain a coin/button type battery,

which can be swallowed. Keep the

battery out of reach of children at

all times! If swallowed, the battery

can cause serious injury or death.

B8_37_CD-UM_EN.indd 2 3/03/2017 11:37:39 AM

3EN

Severe internal burns can occur

within two hours of ingestion.

• If you suspect that a battery

has been swallowed or placed

inside any part of the body, seek

immediate medical attention.

• When you change the batteries,

always keep all new and

used batteries out of reach of

children. Ensure that the battery

compartment is completely secure

after you replace the battery.

• If the battery compartment cannot

be completely secured, discontinue

use of the product. Keep out of

reach of children and contact the

manufacturer.

•Apparatus shall not be exposed to

dripping or splashing.

•

Do not place any sources of danger

on the apparatus (for example. liquid

lled objects, lighted candles).

•This apparatus may contain lead

and mercury. Dispose according

to local, State or Federal laws. For

disposal or recycling information,

please contact your local authorities.

For additional assistance on

recycling options, please contact

www.mygreenelectronics.com or

www.eiae.org or www.recycle.philips.

com.

•

Where the MAINS plug or an

appliance coupler is used as the

disconnect device, the disconnect

device shall remain readily operable.

•Do not place this apparatus on the

furniture that is capable of being

tilted by a child and an adult leaning,

pulling, standing or climbing on it. A

falling apparatus can cause serious

injury or even death.

• This apparatus should not be

placed in a built-in installation such

as a bookcase or rack unless proper

ventilation is provided. Make sure to

leave a space of 7.8 inches (20cm)

or more around this apparatus.

Class II equipment symbol

This symbol indicates that the unit has a

double insulation system.

Know these safety symbols

This ‘bolt of lightning’

indicates uninsulated material

within your unit may cause an

electrical shock. For the safety

of everyone in your household, please

do not remove product covering.

The ‘exclamation point’ calls

attention to features for which

you should read the enclosed

literature closely to prevent

operating and maintenance problems.

WARNING: To reduce the risk of re or

electric shock, this apparatus should

not be exposed to rain or moisture and

objects lled with liquids, such as vases,

should not be placed on this apparatus.

CAUTION: To prevent electric shock,

match wide blade of plug to wide slot,

fully insert.

Care for your product

Use only microber cloth to clean the

product.

Care of the environment

Disposal of your old product and

battery

Your product is designed and

manufactured with high quality

B8_37_CD-UM_EN.indd 3 3/03/2017 11:37:40 AM

4EN

materials and components, which can

be recycled and reused.

This product may contain lead and

mercury. Disposal of these materials

may be regulated due to environmental

considerations. For disposal or recycling

information, please contact your local

authorities or visit www.recycle.philips.com

This product contains batteries:

• Dispose of batteries properly.

Do not incinerate. Batteries may

explode if overheated.

• Do not wrap in metal or aluminum

foil. Wrap in newspaper before

discarding.

• It is suggested that you contact

your local town or city to determine

proper battery redemption site(s) in

your area.

• Please visit www.call2recycle.org

for additional information on a

recycling center in your area for

rechargeable batteries.

Help and support

For extensive online support, visit

www.philips.com/support to:

• download the user manual and the

quick start guide

• watch video tutorials (available only

for selected models)

• nd answers to frequently answered

questions (FAQs)

• email us a question

• chat with our support

representative.

Follow the instructions on the website

to select your language, and then

enter your product model number.

Alternatively, you can contact Consumer

Care in your country. Before you

contact, note down the model number

and serial number of your product. You

can nd this information on the back or

bottom of your product.

2 Your product

Congratulations on your purchase, and

welcome to Philips! To fully benet

from the support that Philips oers(e.g.

notication of product software

upgrade), register your product at

www.philips.com/welcome.

Main unit

This section includes an overview of the

main unit.

• Switch this product on or to

standby.

• When this product is in standby,

the standby indicator turns red.

Select an input source for this

product.

c +/- (Volume)

Increase or decrease volume.

B8_37_CD-UM_EN.indd 4 3/03/2017 11:37:40 AM

5EN

d Display panel

e NFC tag

Tap the NFC-enabled device on the

tag for Bluetooth connection.

Remote control

This section includes an overview of the

remote control.

Switch this product on or to

standby.

b Source buttons

• HDMI ARC: Switch your source

to HDMI ARC connection.

• HDMI 1: Switch your source to

the HDMI IN 1 connection.

• HDMI 2: Switch your source to

the HDMI IN 2 connection.

• COAX: Switch your audio source

to the coaxial connection.

• OPTICAL: Switch your audio

source to the optical connection.

• AUDIO IN: Toggle audio source

between AUX and AUDIO IN

connection (3.5mm jack).

• USB: Switch to USB mode.

• : Switch to Bluetooth mode.

• : Select an input source for

this product.

c /

Skip to the previous or next track in

USB and Bluetooth mode.

Start, pause or resume play in USB

and Bluetooth mode.

e BASS +/-

Increase or decrease bass.

f Volume control

• +/-: Increase or decrease

volume.

• : Mute or restore volume.

g Sound mode control

• SMART: Automatically select a

predened sound mode to suit

your video or music.

• MUSIC: Select stereo sound

mode.

• VOICE: Select voice clarity

sound mode.

• MOVIE: Select surround sound

mode.

h HEIGHT +/-

Select a height eect level for Dolby

Atmos.

B8_37_CD-UM_EN.indd 5 3/03/2017 11:37:41 AM

6EN

i AUDIO SYNC +/-

Increase or decrease audio delay.

j NIGHT

Turn night mode on or o.

k DIM

Set the brightness of the display

panel for this product.

Set clock or display clock.

m AUTO VOL.

Turn auto volume on or o.

n TREBLE +/-

Increase or decrease treble.

Connectors

This section includes an overview of the

connectors available on this product.

a HDMI OUT (ARC) - TO TV

Connect to the HDMI input on the

TV.

b HDMI IN1 / HDMI IN2

Connect to the HDMI output on a

digital device.

c USB

• Connect to a USB storage device

for audio media play.

• Upgrade software of this

product.

d DC IN

Connect to the power supply.

e AUDIO IN

Connect to an audio output on a

device via AUDIO IN or AUX source

(by pressing repeatedly AUDIO IN

on the remote control).

f OPTICAL IN

Connect to an optical audio output

on the TV or a digital device.

g COAXIAL IN

Connect to a coaxial audio output

on the TV or a digital device.

Wireless subwoofer

This product comes with a wireless

subwoofer.

a Connect (connect)

Press to to enter the pairing mode

for the subwoofer.

b Subwoofer indicator

• When the power is turned on,

the indicator lights up.

B8_37_CD-UM_EN.indd 6 3/03/2017 11:37:41 AM

7EN

• During wireless pairing between

the subwoofer and the main

unit, the indicator blinks white

quickly.

• When the pairing succeeds, the

indicator lights up white.

• When the pairing fails, the

indicator blinks white slowly.

• When wireless connection is

disconnected for 1 minute, the

indicator turns o.

c AC MAINS~

Connect to the power supply.

3 Connect

This section helps you connect this

product to a TV and other devices.

For information about the basic

connections of this product and

accessories, see the quick start guide.

Note

• For identication and supply ratings, see

the type plate at the back or bottom of the

product.

• Before you make or change any

connections, make sure that all devices are

disconnected from the power outlet.

Placement

Place the subwoofer at least 1 meter

(3 feet) away from the main unit, and

10 centimeters (4 inches) away from the

wall.

For best results, place your subwoofer

as shown below.

10cm/4”

1m/3ft

B8_37_CD-UM_EN.indd 7 3/03/2017 11:37:41 AM

8EN

Pair up with the

subwoofer

The wireless subwoofer automatically

pairs up with the main unit for wireless

connection when you turn on the main

unit and the subwoofer.

If no audio from the wireless subwoofer

can be heard, manually pair up the

subwoofer.

1 Turn on the main unit and the

subwoofer.

» If the connection to the main

unit is lost, the indicator on the

subwoofer blinks white slowly.

2 Press the CONNECT (connect)

button on the subwoofer to enter

the pairing mode.

» The indicator on the subwoofer

blinks white quickly.

3 In HDMI ARC mode (press HDMI

ARC), on the remote control, within

six seconds, press twice then

Volume + once, and then hold

down BASS +.

» If the pairing succeeds, the

indicator on the subwoofer lights

up white.

» If the pairing fails, the indicator

on the subwoofer blinks white

slowly.

4 If the pairing fails, repeat the steps

above.

Note

• If the wireless dis-connection or pairing up

lasts 1 minute, the subwoofer automatically

switches to standby and the LED on the

subwoofer turns o.

Connect audio from TV

Connect this product to a TV. You

can listen to audio from TV programs

through the speakers of this product.

Option 1: Connect to TV through

HDMI (ARC)

Best quality audio

This product supports HDMI with Audio

Return Channel (ARC). With the ARC

feature, you can hear the TV audio

through this product by using a single

HDMI cable.

What you need

• A High Speed HDMI Cable.

• Your TV supports both HDMI ARC

and HDMI-CEC (see the TV user

manual for details).

• For some TV models, enable the

external speaker output from the

TV setting menu (see the TV user

manual for details).

1 Using a High Speed HDMI cable,

connect the HDMI OUT (ARC) - TO

TV connector on this product to the

HDMI ARC connector on the TV.

• The HDMI ARC connector on the

TV might be labeled dierently.

For details, see the TV user

manual.

2 On your TV, turn on HDMI-CEC

operations.

B8_37_CD-UM_EN.indd 8 3/03/2017 11:37:42 AM

9EN

• For HDMI-CEC issues on your

TV, see the TV user manual to

make sure that the HDMI-CEC

setup is correct, or contact the

TV manufacturer if needed.

3 Press HDMI ARC on the remote

control of this product to enable the

HDMI ARC connection.

Note

• 100% interoperability with all HDMI-CEC

devices is not guaranteed.

• If your TV is not HDMI ARC compliant,

connect an audio cable to hear the TV

audio through this product.

Option 2: Connect to TV

through optical cable

Best quality audio

1 Using an optical cable, connect

the OPTICAL IN connector on this

product to the optical output on the

TV.

• The digital optical output on the

TV might be labeled OPTICAL

OUT, SPDIF or SPDIF OUT.

2 Press OPTICAL on the remote

control of this product to enable the

optical connection.

Option 3: Connect to TV

through coaxial cable

Best quality audio

1 Using a coaxial cable, connect

the COAXIAL IN connector on this

product to the coaxial output on

the TV.

• The digital coaxial output on the

TV might be labeled COAXIAL/

DIGITAL OUT or DIGITAL AUDIO

OUT.

2 Press COAX on the remote control

of this product to enable the coaxial

connection.

Option 4: Connect to TV

through analog audio cables

Basic quality audio

AUDIO OUT

RL TV

1 Using an analog cable, connect

the AUDIO IN (3.5mm jack) on this

product to the analog audio output

(red and white) on the TV.

• The analog audio output on the

external device might be labeled

AUDIO OUT.

B8_37_CD-UM_EN.indd 9 3/03/2017 11:37:42 AM

10 EN

2 Press repeatedly AUDIO IN on

the remote control until AUX is

displayed on the display panel.

Connect audio from

other devices

You may also play audio from other

devices through the speakers of this

product.

Option 1: Connect to other

device through optical cable

Best quality audio

1 Using an optical cable, connect

the OPTICAL IN connector on this

product to the optical output on the

external device.

• The digital optical output on the

external device might be labeled

OPTICAL OUT, SPDIF or SPDIF

OUT.

2 Press OPTICAL on the remote

control of this product to enable the

optical connection.

Option 2: Connect to other

device through coaxial cable

Best quality audio

1 Using a coaxial cable, connect

the COAXIAL connector on this

product to the coaxial output on the

external device.

• The digital coaxial output on

the external device might be

labeled COAXIAL/DIGITAL OUT

or DIGITAL AUDIO OUT.

2 Press COAX on the remote control

of this product to enable the coaxial

connection..

Option 3: Connect to other

device through analog audio

cables

Basic quality audio

AUDIO OUT

1 Using an analog cable, connect

the AUDIO IN (3.5mm jack) on this

product to the analog audio output

(red and white) on the external

device.

B8_37_CD-UM_EN.indd 10 3/03/2017 11:37:43 AM

11EN

• The analog audio output on the

external device might be labeled

AUDIO OUT.

2 Press repeatedly AUDIO IN on

the remote control until AUX is

displayed on the display panel.

Connect digital devices

through HDMI

Connect a digital device such as a set-

top box, DVD/Blu-ray player, or games

console to this product through a single

HDMI connection. When you connect

the devices in this way and play a le or

game, the

• video is automatically displayed on

your TV, and

• audio is automatically played on

this product.

1 Using a High Speed HDMI cable,

connect the HDMI OUT connector

on your digital device to the HDMI

IN 1/2 on this product.

2 Using a High Speed HDMI cable,

connect the HDMI OUT (ARC) - TO

TV connector on this product to the

HDMI connector on the TV.

• On your TV and the connected

device, turn on HDMI-CEC

controls (if available). For details,

see the user manual of the TV

and the device.

3 Press HDMI 1/2 on the remote

control of this product to enable the

HDMI IN connection.

• If the TV is not HDMI-CEC

compliant, select the correct

video input on your TV.

4 Use your

product

This section helps you use this product

to play media from a wide range of

sources.

Before you start

• Make the necessary connections

described in Quick start guide and

User manual.

• Switch this product to the correct

source for the other devices.

Set clock

Through clock setting, you may select a

type of standby (ECO standby without

clock display, or normal standby with

clock display ).

1 Switch this product to standby

(press ).

» --:-- (or clock) is displayed.

2 Press and hold to activate the

clock setting mode.

» --:-- blinks.

3 Press Volume +/- to select 12 hour

or 24 hour format, then press to

conrm.

• If 12 hour format is selected, then

select AM or PM for display.

»The hour digits begin to blink.

4 Press Volume +/- to set the hour,

then press to conrm.

»The minute digits begin to blink.

5 Press Volume +/- to set the minute,

then press to conrm.

»ECO begins to blink.

B8_37_CD-UM_EN.indd 11 3/03/2017 11:37:43 AM

12 EN

6 Press Volume +/- to select “ECO” or

“CLOCK”, then press to conrm.

» If you select “ECO” , in standby,

the clock is displayed for

1 minute then the display is

switched o.

» If you select “CLOCK”, in

standby, the clock is always

displayed.

View clock

1 In ECO standby or operation mode,

press .

»In ECO standby mode, the clock

is displayed for 1 minute, then

the display is switched o.

»In operation mode, the clock is

displayed 5 seconds, then the

display is switched to the current

source information.

Note

• If AC power is disconnected, the clock time

can only be retained for 24 hours.

• Extreme room temperature aects clock

accuracy.

Auto standby

When playing media from a connected

device, this product automatically

switches to standby after 15 minutes of

button inactivity and no audio/video

play from a connected device.

Adjust the volume

1 Press Volume +/- to increase or

decrease a volume level.

• To mute sound, press .

• To restore the sound, press

again or press Volume +/-.

Dolby Atmos®

In addition to horizontal distribution

of 5-channel audio, this product also

has built-in Dolby Atmos enabled

speakers as additional audio channels

to generate overhead distribution of

audio for powerful delivery of 3D sound

immersion and greater reality.

2.8~3m

0.7~0.8m

2~3m

Optimal setup for Dolby Atmos sound

• Place this product at a height of

0.7m - 0.8m.

• Ceiling height is 2.8m - 3m.

• Listening distance from this product

is 2m - 3m.

• Ceiling is not made of sound

absorbent material.

• Preferably no protrusive objects

(such as lighting and decorations)

are on the ceiling.

Best Dolby Atmos eects may achieve

through the following two use cases.

From your Blu-ray disc player:

• Movie with Dolby Atmos.

B8_37_CD-UM_EN.indd 12 3/03/2017 11:37:43 AM

13EN

• Your Blu-ray disc player is

connected to this product via

connector.

• On your Blu-ray disc player, enable

bitstream/raw audio format for

HDMI sound output.

• A high speed HDMI cable.

From your TV:

• Movie with Dolby Atmos.

• Your TV supports Dolby Atmos

bitstream/raw output.

• Your TV is connected to this product

via connector.

• A high speed HDMI cable.

Note

• For details on how to connect your Blu-ray

disc player to this product via

connector, see “Connect” > “Connect digital

devices through HDMI” in the user manual.

Enjoy Dolby Atmos sound

1 Press to select a height

surround eects level to best suit

your personal taste according to

your environment.

• : no height eect.

• : small height

eect.

• : medium

height eect.

• : big height eect.

Note

• For non-HDMI connections (such as use of

USB, Bluetooth, OPTICAL and COAXIAL),

only limited height surround eects are

generated.

Choose your sound

This section helps you choose the ideal

sound for your video or music.

Sound mode

Select predened sound modes to suit

your video or music.

• Press to create a surround

listening experience. Ideal for

watching movie.

• Press to create two-channel

or multi-channel stereo. Ideal for

listening to music.

• Press to create sound eect

which makes human voice more

clear and outstanding for listening.

• Press to automatically select

a predened sound mode (

, or ) based on input

audio content to optimize audio

performance.

Equalizer

Change the high frequency (treble) and

low frequency (bass) settings of this

product.

1 Press TREBLE +/- or BASS +/- to

change the frequency.

Synchronize video and sound

If the audio and video are not

synchronized, delay the audio to match

the video.

1 Press AUDIO SYNC +/- to

synchronize the audio with the

video.

Auto volume

Turn the auto volume on to keep the

volume constant when you switch to a

dierent source.

B8_37_CD-UM_EN.indd 13 3/03/2017 11:37:44 AM

14 EN

It also compresses the sound dynamics,

increasing the volume for quiet scenes

and decreasing the volume for loud

scenes.

1 Press to turn auto

volume on or o.

» When auto volume is turned on,

scrolls once

on the display panel.

» When auto volume is turned o,

scrolls once

on the display panel.

Night mode

For quiet listening, night mode

decreases the volume of loud sounds

when audio is played. Night mode

is only available for Dolby Digital

soundtracks.

1 Press NIGHT to turn night mode on

or o.

• When night mode is turned on,

ON NIGHT scrolls once on the

display panel.

• When night mode is turned o,

OFF NIGHT scrolls once on the

display panel.

Note

• If you turn on auto volume, night mode (if

activated) will be automatically turned o,

and vice versa.

Play audio through

Bluetooth

Through Bluetooth, connect this

product with your Bluetooth device

(such as an iPad, iPhone, iPod touch,

Android phone, or laptop), and then

you can listen to the audio les stored

on the device through the speakers of

this product.

What you need

• A Bluetooth device which supports

Bluetooth prole A2DP, AVRCP and

with Bluetooth version as 3.0.

• The maximum operational range

between this product and a

Bluetooth device is approximately

10 meters (30 feet).

1 Press on the remote control to

switch this product to Bluetooth

mode.

» BT is displayed on the display

panel, blinking.

2 On the Bluetooth device, switch

on Bluetooth, search for and select

Fidelio B8 to start connection

(see the user manual of the

Bluetooth device on how to enable

Bluetooth).

» During connection, BT on the

display panel blinks.

3 Wait until this product beeps.

» When the Bluetooth connection

succeeds, BT is displayed on the

display panel.

If the connection fails, BT

on the display panel blinks

continuously.

4 Select and play audio les or music

on your Bluetooth device.

• During play, if a call is coming,

music play is paused.

• If your Bluetooth device

supports AVRCP prole, on the

remote control you can press

/ to skip to a track, or press

to pause/resume play.

5 To exit Bluetooth, select other

source.

B8_37_CD-UM_EN.indd 14 3/03/2017 11:37:44 AM

15EN

• When your switch back to

Bluetooth mode, Bluetooth

connection remains active.

Note

• The music streaming may be interrupted

by obstacles between the device and this

product, such as wall, metallic casing that

covers the device, or other devices nearby

that operate in the same frequency.

• If you want to connect this product with

another Bluetooth device, press and hold

on the remote control to disconnect the

currently connected Bluetooth device.

Connect Bluetooth via

NFC

NFC (Near Field Communication) is a

technology that enables short-range

wireless communication between

NFC-enabled devices, such as mobile

phones.

What you need

• A Bluetooth device with NFC

function.

• For pairing, tap the NFC device on

the NFC tag of this product.

1 Enable NFC on the Bluetooth

device (see the device’ s user

manual for details).

2 Tap the NFC device onto the NFC

tag of this product until this product

beeps.

» When the Bluetooth connection

succeeds, BT is displayed on the

display panel.

» If the connection fails, BT

on the display panel blinks

continuously.

3 Select and play audio les or music

on your NFC device.

• To break the connection, tap

again the NFC device onto the

NFC tag on this product.

MP3 player

Connect your MP3 player to play your

audio les or music.

What you need

• An MP3 player.

• A 3.5mm stereo audio cable.

1 Using the 3.5mm stereo audio

cable, connect the MP3 player to

the AUDIO IN connector on this

product.

2 Press repeatedly AUDIO IN on the

remote control until AUDIO IN is

displayed on the display panel.

3 Press the buttons on the

MP3 player to select and play audio

les or music.

USB storage devices

Enjoy audio on a USB storage device,

such as an MP3 player and USB ash

memory, etc.

What you need

• A USB storage device that is

formatted for FAT16 or FAT32 le

systems, and complies with the

Mass Storage Class.

• An MP3 le on a USB storage

device.

1 Connect a USB storage device to

this product.

2 Press USB on the remote control.

3 Use the remote control to control

play.

B8_37_CD-UM_EN.indd 15 3/03/2017 11:37:44 AM

1 In HDMI ARC mode (press HDMI

ARC), on the remote control, within

six seconds, press twice then

Volume - once, and then hold

down BASS -.

» When the factory settings

restore is complete, the product

automatically switches o and

restarts.

• Press to start, pause or

resume play.

• Press / to skip to the

previous or next track.

• During USB play, press USB to

select one of the following play

modes.

• ALL RPT: repeat all the tracks

in one folder.

• OFF RPT: repeat mode is

turned o.

Note

• Support a USB storage device up to 32GB.

• This product may not be compatible with

certain types of USB storage device.

• If you use a USB extension cable, USB

HUB, or USB multi-reader, the USB storage

device may not be recognized.

• Digital camera PTP and MTP protocols are

not supported.

• Do not remove the USB storage device

while it is being read.

• DRM-protected music les (MP3) are not

supported.

• Support a USB port: 5V , 500mA.

Set display brightness

You can press DIM repeatedly to select

a dierent brightness level of the

display panel on this product.

If you select AUTO OFF, LED message is

switched o after 10 seconds of button

inactivity.

Apply factory settings

In case of no response from this

product , you can reset this product to

the default settings programmed at the

factory.

B8_37_CD-UM_EN.indd 16 3/03/2017 11:37:44 AM

5 Update

software

To get the best features and support,

update your product with the latest

software.

Check software version

In HDMI ARC mode (press HDMI

ARC), on the remote control, within six

seconds, press twice then TREBLE -

once, and then hold down BASS -.

» The software version number is

displayed on the display panel.

Update software via USB

Caution

• Do not turn o the power or remove the

USB ash drive when the software update

is in progress because you might damage

this product.

1 Check the latest software version on

www.philips.com/support.

• Search for your model and click

on "Software and drivers".

2 Download the software into a USB

ash drive.

a Unzip the downloaded le, and

make sure that the unzipped

folder is named “UPG”.

b Put the “UPG” folder in the root

directory.

3 Connect the USB ash drive to the

USB connector on this product.

4 Switch this product to HDMI ARC

source (press HDMI ARC).

5 On the remote control, within

6 seconds press twice then

Volume + once, and then hold down

MOVIE.

» “UPGRADE” (upgrade) is

displayed briey, then upgrade

progress is indicated.

» If a USB ash drive is not

connected or invalid upgrade

le is found, "ERROR" (error) is

displayed on the display panel.

6 Wait until the upgrade is completed.

» If the upgrade is complete, this

product automatically turns o

and on again.

Note

• The upgrade time may take around

8 minutes.

B8_37_CD-UM_EN.indd 17 3/03/2017 11:37:44 AM

6 Wall mount

Note

• Before wall mounting, make sure the wall

can support the weight of this product.

• For wall mounting, this product must be

securely attached to the wall in accordance

with the installation instructions. Improper

wall mounting may result in accident, injury

or damage. If you have any query, contact

Consumer Care in your country.

Screw length/diameter

Depending on the type of wall

mounting this product, make sure that

you use screws of a suitable length and

diameter.

See the illustration in the quick start

guide on how to wall mount this

product.

1) Use the supplied paper template

to mark two holes on the wall, then

secure two suitable screws in the

holes.

2) Fix the two supplied wall brackets on

this product.

3) Hang this product on the wall.

2.2-2.5 mm

8-9.5 mm 3.5-4 mm

>25 mm

7 Product

specifications

Note

• Specications and design are subject to

change without notice.

Amplier

• Total output power:

400W RMS (+/- 0.5 dB, 10% THD)

• Frequency response:

20 Hz-20 kHz / ±3 dB

• Signal-to-noise ratio: > 65 dB (CCIR) /

(A-weighted)

• Input sensitivity:

• AUX: 1900 mV

• AUDIO IN: 900 mV

Audio

• S/PDIF Digital audio input:

• Coaxial: IEC 60958-3

• Optical: TOSLINK

USB

• Compatibility: Hi-Speed USB (2.0)

• Class support: USB Mass Storage Class

(MSC)

• File system: FAT16, FAT32

• Supports MP3 le format

Bluetooth

•Bluetooth proles: A2DP, AVRCP

•Bluetooth version: 3.0

B8_37_CD-UM_EN.indd 18 3/03/2017 11:37:45 AM

Main unit

•Power supply:

• Model (Philips branded

AC power adapter):

DYS902-190473W

• Input: 100-240 V~, 50/60 Hz

1.5 A

• Output: 19V , 4.73A

•Standby without clock display:

≤ 0.5 W

•Standby with clock display: ≤ 1 W

•Dimensions (W x H x D):

1058 x 52 x 120 mm

•Weight: 3.65 kg

•Built-in speakers

• 6 x silk tweeter (1’’, 3 ohm)

• 2 x silk tweeter (0.8’’, 8 ohm)

• 4 x racetrack woofer speaker

(3.5’’ x 1’’ , 16 ohm )

• Centre channel: 2 x racetrack

full-range speaker ( 3.5’’ x 1’’,

16 ohm)

• Front/surround channel: 4 x

racetrack woofer speaker ( 3.5’’ x

1’’, 8 ohm)

Subwoofer

• Power supply: 110-127V/220-

240 V~, 50/60 Hz

• Power consumption: 60 W

• Standby power consumption:

≤ 0.5 W

• Impedance: 3 ohm

• Speaker drivers: 1 x 8’’ subwoofer

• Dimensions (W x H x D):

240 x 510 x 302 mm

• Weight: 8.9 kg

Remote control batteries

• 2 x AAA-R03-1.5 V

8 Trouble-

shooting

Warning

• Risk of electric shock. Never remove the

casing of the product.

To keep the warranty valid, never try to

repair the product yourself.

If you have problems using this product,

check the following points before you

request service. If you still have a problem,

get support at www.philips.com/support.

Main unit

The buttons on this product do not work.

• Disconnect this product from the

power supply for a few minutes, then

reconnect.

Sound

No sound from the speakers of this

product.

• Connect the audio cable from this

product to your TV or other devices.

However, you do not need a separate

audio connection when:

• the product and TV are connected

through HDMI ARC connection, or

• a device is connected to the HDMI

IN connector on this product.

• Reset this product to its factory

settings.

• On the remote control, select the

correct audio input.

• Make sure that this product is not

muted.

B8_37_CD-UM_EN.indd 19 3/03/2017 11:37:45 AM

Quality of audio play from a connected

Bluetooth device is poor.

• The Bluetooth reception is poor.

Move the device closer to this

product, or remove any obstacle

between the device and this

product.

The connected Bluetooth device

connects and disconnects constantly.

• The Bluetooth reception is poor.

Move the device closer to this

product, or remove any obstacle

between the device and this

product.

• Turn o Wi-Fi function on the

Bluetooth device to avoid

interference.

• For some Bluetooth, the Bluetooth

connection can be deactivated

automatically to save power. This

does not indicate any malfunction

of this product.

NFC

A device cannot connect with this

product via NFC.

• Make sure that the device is

supported by NFC.

• Make sure that NFC is enabled on

the device (see the device’ s user

manual for details).

• For pairing, tap the NFC device on

the NFC tag of this product.

Dolby Atmos

Cannot achieve outstanding Dolby

Atmos eects.

• For non-HDMI connections (such

as use of USB, Bluetooth, OPTICAL

and COAXIAL), limited height

surround eects are generated. See

the section of “Dolby Atmos” about

how to achieve best Dolby Atmos

eects.

No sound from the wireless subwoofer.

• Wirelessly connect the subwoofer

to the main unit.

Distorted sound or echo.

• If you play audio from the TV

through this product, make sure that

the TV is muted.

Audio and video are not synchronized.

• Press AUDIO SYNC +/- to

synchronize the audio with the

video.

Error message is displayed on the

display panel.

• When "ERROR" is displayed, it

indicates that an input audio format

is not supported.

• When "ARC" blinks, it indicates that

the connected TV is not HDMI ARC

compliant or an unsupported audio

format is detected.

Bluetooth

A device cannot connect with this

product.

• The device does not support the

compatible proles required for this

product.

• You have not enabled the Bluetooth

function of the device. See the user

manual of the device on how to

enable the function.

• The device is not correctly

connected. Connect the device

correctly.

• This product is already connected

with another Bluetooth device.

Disconnect the connected device,

then try again.

B8_37_CD-UM_EN.indd 20 3/03/2017 11:37:45 AM

• Consult the dealer or an

experienced radio/TV technician for

help.

FCC Radiation Exposure

Statement:This equipment complies

with FCC radiation exposure limits set

forth for an uncontrolled environment.

This equipment should be installed and

operated with a minimum distance of

20cm between the radiator and your

body. This transmitter must not be co-

located or operated in conjunction with

any other antenna or transmitter.

Warning: Any changes or modications

made to this device that are not

expressly approved by Gibson

Innovations may void the user’s

authority to operate the equipment.

Model number: B8/37

Trade Name: Philips

Responsible Party: Gibson Innovations

USA Inc.PO BOX 100572, Nashville TN

37224

Canada:

CAN ICES-3(B)/NMB-3(B)

This device complies with Industry

Canada’s licence-exempt RSSs.

Operation is subject to the following

two conditions: (1) this device may not

cause interference, and (2) this device

must accept any interference, including

interference that may cause undesired

operation of the device.

The device meets the exemption from

the routine evaluation limits in section

2.5 of RSS 102 and compliance with

RSS-102 RF exposure, users can obtain

Canadian information on RF exposure

and compliance.

This transmitter must not be co-located

or operating in conjunction with any

other antenna or transmitter. This

equipment should be installed and

operated with a minimum distance of

20 centimeters between the radiator

and your body.

9 Notice

This section contains the legal and

trademark notices.

Notice of compliance

The device complies with the FCC rules,

Part 15. Operation is subject to the

following two conditions:

a This device may not cause harmful

interference, and

b This device must accept any

interference received, including

interference that may cause

undesired operation.

FCC rules

This equipment has been tested and

found to comply with the limits for

a Class B digital device, pursuant to

part 15 of the FCC Rules. These limits

are designed to provide reasonable

protection against harmful interference

in a residential installation. This

equipment generates, uses and can

radiate radio frequency energy and, if

not installed and used in accordance

with the instruction manual, may

cause harmful interference to radio

communications.

However, there is no guarantee that

interference will not occur in a particular

installation. If this equipment does

cause harmful interference to radio

or television reception, which can be

determined by turning the equipment

o and on, the user is encouraged to

try to correct the interference by one or

more of the following measures:

• Relocate the receiving antenna.

• Increase the separation between

equipment and receiver.

• Connect the equipment into an

outlet on a circuit dierent from that

to which the receiver is connected.

B8_37_CD-UM_EN.indd 21 3/03/2017 11:37:45 AM

Manufactured under license from Dolby

Laboratories. Dolby, Dolby Atmos, and

the double-D symbol are trademarks of

Dolby Laboratories.

For DTS patents, see http://patents.dts.

com. Manufactured under license from

DTS Licensing Limited. DTS, the Symbol,

& DTS and the Symbol together are

registered trademarks, and DTS Digital

Surround is a trademark of DTS, Inc. ©

The terms HDMI and HDMI High-

Denition Multimedia Interface, and the

HDMI Logo are trademarks or registered

trademarks of HDMI Licensing LLC in

the United States and other countries.

The Bluetooth® word mark and logos

are registered trademarks owned by

Bluetooth SIG, Inc. and any use of such

marks by Gibson Innovations Limited is

under license. Other trademarks and

trade names are those of their

respective owners.

The N Mark is a trademark or registered

trademark of NFC Forum, Inc. in the

United States and in other countries.

Qualcomm aptX is a product of

Qualcomm Technologies International,

Ltd. Qualcomm is a trademark of

Qualcomm Incorporated, registered in

the United States and other countries,

used with permission. aptX is a

trademark of Qualcomm Technologies

International, Ltd., registered in the

United States and other countries, used

with permission.

B8_37_CD-UM_EN.indd 22 3/03/2017 11:37:46 AM

PHILIPS LIMITED WARRANTY

ONE (1) YEAR

WARRANTY COVERAGE:

PHILIPS warranty obligation is limited to the terms set forth

below.

WHO IS COVERED:

Philips warrants the product to the original purchaser or the per-

son receiving the product as a gift against defects in materials and

workmanship as based on the date of original purchase

(“Warranty Period”) from an Authorized Dealer. The original

sales receipt showing the product name and the purchase date

from an authorized retailer is considered such proof.

WHAT IS COVERED:

The Philips warranty covers new products if a defect in material

or workmanship occurs and a valid claim is received by Philips

within the Warranty Period. At its option, Philips will either (1)

repair the product at no charge, using new or refurbished

replacement parts, or (2) exchange the product with a product

that is new or which has been manufactured from new, or ser-

viceable used parts and is at least functionally equivalent or most

comparable to the original product in Philips current inventory,

or (3) refund the original purchase price of the product.

Philips warrants replacement products or parts provided under

this warranty against defects in materials and workmanship from

the date of the replacement or repair for ninety (90) days or for

the remaining portion of the original product’s warranty,

whichever provides longer coverage for you. When a product or

part is exchanged, any replacement item becomes your property

and the replaced item becomes Philips’ property. When a refund

is given, your product becomes Philips’ property.

Note: Any product sold and identified as refurbished or

renewed carries a ninety (90) day limited warranty.

Replacement product can only be sent if all warranty

requirements are met. Failure to follow all requirements

can result in delay.

WHAT IS NOT COVERED - EXCLUSIONS AND

LIMITATIONS:

This Limited Warranty applies only to the new products manu-

factured by or for Philips that can be identified by the trademark,

trade name, or logo affixed to it. This Limited Warranty does not

apply to any non-Philips hardware product or any software, even

if packaged or sold with the product. Non-Philips manufacturers,

suppliers, or publishers may provide a separate warranty for their

own products packaged with the bundled product.

Philips is not liable for any damage to or loss of any programs,

data, or other information stored on any media contained within

the product, or any non-Philips product or part not covered by

this warranty. Recovery or reinstallation of programs, data or

other information is not covered under this Limited Warranty.

This warranty does not apply (a) to damage caused by accident,

abuse, misuse, neglect, misapplication, or non-Philips product, (b)

to damage caused by service performed by anyone other than

Philips or Philips Authorized Service Location, (c) to a product or

a part that has been modified without the written permission of

Philips, or (d) if any Philips serial number has been removed or

defaced, or (e) product, accessories or consumables sold “AS IS”

without warranty of any kind by including refurbished Philips

product sold “AS IS” by some retailers.

This Limited Warranty does not cover:

• Shipping charges to return defective product to Philips.

• Labor charges for installation or setup of the product, adjust-

ment of customer controls on the product, and installation or

repair of antenna/signal source systems outside of the product.

• Product repair and/or part replacement because of improper

installation or maintenance, connections to improper voltage

supply, power line surge, lightning damage, retained images or

screen markings resulting from viewing fixed stationary con-

tent for extended periods, product cosmetic appearance items

due to normal wear and tear, unauthorized repair or other

cause not within the control of Philips.

• Damage or claims for products not being available for use, or

for lost data or lost software.

• Damage from mishandled shipments or transit accidents when

returning product to Philips.

• A product that requires modification or adaptation to enable

it to operate in any country other than the country for which

it was designed, manufactured, approved and/or authorized, or

repair of products damaged by these modifications.

• A product used for commercial or institutional purposes

(including but not limited to rental purposes).

• Product lost in shipment and no signature verification receipt

can be provided.

• Failure to operate per Owner’s Manual.

TO OBTAIN ASSISTANCE IN THE U.S.A., CANADA,

PUERTO RICO, OR U.S. VIRGIN ISLANDS…

Contact Philips Customer Care Center at:

1-888-381-0749

REPAIR OR REPLACEMENT AS PROVIDED UNDER THIS

WARRANTY IS THE EXCLUSIVE REMEDY FOR THE CON-

SUMER. PHILIPS SHALL NOT BE LIABLE FOR ANY INCIDEN-

TAL OR CONSEQUENTIAL DAMAGES FOR BREACH OF ANY

EXPRESS OR IMPLIED WARRANTY ON THIS PROD-UCT.

EXCEPT TO THE EXTENT PROHIBITED BY APPLICABLE LAW,

ANY IMPLIED WARRANTY OF MERCHANTABILITY OR

FITNESS FOR A PARTICULAR PURPOSE ON THIS PRODUCT

IS LIMITED IN DURATION TO THE DURATION OF THIS

WARRANTY.

Some states do not allow the exclusions or limitation of inciden-

tal or consequential damages, or allow limitations on how long an

implied warranty lasts, so the above limitations or exclusions may

not apply to you.

This warranty gives you specific legal rights. You may have other rights which vary from state/province to state/province.

2016

Gibson Innovations USA Inc. PO BOX 100572 Nashville TN 37224

B8_37_CD-UM_EN.indd 23 3/03/2017 11:37:46 AM

Specifications are subject to change without notice

The Philips trademark and the Philips Shield Emblem are registered trademarks of

Koninklijke Philips N.V. used under license.

This product has been manufactured by, and is sold under the responsibility of Gibson

Innovations Ltd., and Gibson Innovations Ltd. is the warrantor in relation to this product.

B8_37_UM_V1.0

B8_37_CD-UM_EN.indd 24 3/03/2017 11:37:46 AM

English SkyQuake

B8 - Important

Read and understand all instructions before you use your product. If damage

is caused by failure to follow instructions, the warranty does not apply.

Important safety instructions

•Read these instructions.

•Keep these instructions.

•Heed all warnings.

•Follow all instructions.

•Do not use this apparatus near water.

•Clean only with dry cloth.

•Do not block any ventilation openings. Install in accordance with the

manufacturer’s instructions.

•Do not install near any heat sources such as radiators, heat registers,

stoves, or other apparatus (including ampliers) that produce heat.

•Do not defeat the safety purpose of the polarized or

grounding-type plug. A polarized plug has two blades

with one wider than the other. A grounding type plug

has two blades and a third grounding prong. The wide

blade or the third prong are provided for your safety. If the provided plug

does not t into your outlet, consult an electrician for replacement of the

obsolete outlet.

•Protect the power cord from being walked on or pinched, particularly at

plugs, convenience receptacles, and the point where they exit from the

apparatus.

•Only use attachments/accessories specied by the manufacturer.

•Use only with the cart, stand, tripod, bracket or table

specied by the manufacturer or sold with the apparatus.

When a cart is used, use caution when moving the cart/

apparatus combination to avoid injury from tip-over.

•Unplug this apparatus during lightning storm or when

unused for long periods of time.

•Refer all servicing to qualied service personnel. Servicing is required

when the apparatus has been damaged in any way, such as power-

supply cord or plug is damaged, liquid has been spilled or objects have

fallen into the apparatus, the apparatus has been exposed to rain or

moisture, does not operate normally, or has been dropped.

•Battery usage CAUTION - To prevent battery leakage which may result in

bodily injury, property damage, or damage to the unit:

• Install all batteries correctly, + and - as marked on the unit.

• Do not mix batteries (old and new or carbon and alkaline, etc.).

• Remove batteries when the unit is not used for a long time.

• The batteries shall not be exposed to excessive heat such as

sunshine, re or the like.

• Perchlorate Material - special handling may apply. See www.dtsc.

ca.gov/hazardouswaste/perchlorate.

• The product/remote control may contain a coin/button type battery,

which can be swallowed. Keep the battery out of reach of children at all

times! If swallowed, the battery can cause serious injury or death. Severe

internal burns can occur within two hours of ingestion.

• If you suspect that a battery has been swallowed or placed inside any

part of the body, seek immediate medical attention.

• When you change the batteries, always keep all new and used batteries

out of reach of children. Ensure that the battery compartment is

completely secure after you replace the battery.

• If the battery compartment cannot be completely secured, discontinue

use of the product. Keep out of reach of children and contact the

manufacturer.

•Apparatus shall not be exposed to dripping or splashing.

•Do not place any sources of danger on the apparatus (for example.

liquid lled objects, lighted candles).

•This apparatus may contain lead and mercury. Dispose according to

local, State or Federal laws. For disposal or recycling information, please

contact your local authorities. For additional assistance on recycling

options, please contact www.mygreenelectronics.com or www.eiae.org or

www.recycle.philips.com.

•Where the MAINS plug or an appliance coupler is used as the disconnect

device, the disconnect device shall remain readily operable.

•Do not place this apparatus on the furniture that is capable of being

tilted by a child and an adult leaning, pulling, standing or climbing on it. A

falling apparatus can cause serious injury or even death.

• This apparatus should not be placed in a built-in installation such as

a bookcase or rack unless proper ventilation is provided. Make sure to

leave a space of 7.8 inches (20cm) or more around this apparatus.

Class II equipment symbol

This symbol indicates that the unit has a double insulation system.

Know these safety symbols

This ‘bolt of lightning’ indicates uninsulated material within your

unit may cause an electrical shock. For the safety of everyone in

your household, please do not remove product covering.

The ‘exclamation point’ calls attention to features for which you

should read the enclosed literature closely to prevent operating

and maintenance problems.

WARNING: To reduce the risk of re or electric shock, this

apparatus should not be exposed to rain or moisture and objects lled with

liquids, such as vases, should not be placed on this apparatus.

CAUTION: To prevent electric shock, match wide blade of plug to wide slot,

fully insert.

Care for your product

Use only microber cloth to clean the product.

Care of the environment

Disposal of your old product and battery

Your product is designed and manufactured with high quality

materials and components, which can be recycled and reused.

This product may contain lead and mercury. Disposal of these materials

may be regulated due to environmental considerations. For disposal

or recycling information, please contact your local authorities or visit

www.recycle.philips.com.

This product contains batteries:

• Dispose of batteries properly. Do not incinerate. Batteries may explode if

overheated.

• Do not wrap in metal or aluminum foil. Wrap in newspaper before

discarding.

• It is suggested that you contact your local town or city to determine

proper battery redemption site(s) in your area.

• Please visit www.call2recycle.org for additional information on a recycling

center in your area for rechargeable batteries.

Notice of compliance

The device complies with part 15 of the FCC Rules. Operation is subject to the

following two conditions:

a This device may not cause harmful interference, and

b This device must accept any interference received, including

interference that may cause undesired operation.

FCC rules

This equipment has been tested and found to comply with the limits for a

Class B digital device, pursuant to part 15 of the FCC Rules. These limits are

designed to provide reasonable protection against harmful interference in

a residential installation. This equipment generates, uses and can radiate

radio frequency energy and, if not installed and used in accordance with the

instruction manual, may cause harmful interference to radio communications.

However, there is no guarantee that interference will not occur in a particular

installation. If this equipment does cause harmful interference to radio or

television reception, which can be determined by turning the equipment o

and on, the user is encouraged to try to correct the interference by one or

more of the following measures:

• Relocate the receiving antenna.

• Increase the separation between equipment and receiver.

• Connect the equipment into an outlet on a circuit dierent from that to

which the receiver is connected.

• Consult the dealer or an experienced radio/TV technician for help.

FCC Radiation Exposure Statement:This equipment complies with FCC

radiation exposure limits set forth for an uncontrolled environment. This

equipment should be installed and operated with a minimum distance of

20cm between the radiator and your body. This transmitter must not be co-

located or operated in conjunction with any other antenna or transmitter.

Warning: Any changes or modications made to this device that are not

expressly approved by Gibson Innovations may void the user’s authority to

operate the equipment.

Model number: B8/37

Trade Name: Philips

Responsible Party: Gibson Innovations USA Inc.

PO BOX 100572, Nashville TN 37224

Canada:

CAN ICES-3(B)/NMB-3(B)

This device complies with Industry Canada’s licence-exempt RSSs. Operation

is subject to the following two conditions: (1) this device may not cause

interference, and (2) this device must accept any interference, including

interference that may cause undesired operation of the device.

The device meets the exemption from the routine evaluation limits in section

2.5 of RSS 102 and compliance with RSS-102 RF exposure, users can obtain

Canadian information on RF exposure and compliance.

This transmitter must not be co-located or operating in conjunction with

any other antenna or transmitter. This equipment should be installed and

operated with a minimum distance of 20 centimeters between the radiator

and your body.

Help and support

For extensive online support, visit www.philips.com/support to:

• download the user manual and the quick start guide

• watch video tutorials (available only for selected models)

• nd answers to frequently answered questions (FAQs)

• email us a question

• chat with our support representative.

Follow the instructions on the website to select your language, and then enter

your product model number.

Alternatively, you can contact Consumer Care in your country. Before you

contact, note down the model number and serial number of your product. You

can nd this information on the back or bottom of your product.

Español

Importante

Lea y asegúrese de comprender todas las instrucciones antes de usar el

producto. La garantía no cubre los daños producidos por no haber seguido

las instrucciones.

Instrucciones de seguridad importantes

•Lea estas instrucciones.

•Conserve estas instrucciones.

•Preste atención a todas las advertencias.

•Siga todas las instrucciones.

•No utilice este aparato cerca del agua.

•Utilice únicamente un paño seco para la limpieza.

•No bloquee las aperturas de ventilación. Realice la instalación de

acuerdo con las indicaciones del fabricante.

•No realice la instalación cerca de fuentes de calor como radiadores,

rejillas de calefacción, estufas u otros equipos que produzcan calor

(incluso amplicadores).

•Utilice el conector polarizado o con conexión a tierra

de conformidad con las normas de seguridad. Un

enchufe polarizado cuenta con dos álabes, uno más

ancho que el otro. Los conectores a tierra tienen dos

conductores y una tercera terminal de contacto para la conexión a tierra.

El conductor ancho o la tercera terminal de contacto con conexión a

tierra se proveen para mayor seguridad. Si el enchufe suministrado no

encaja correctamente en el tomacorriente, consulte a un electricista para

reemplazar la toma.

•Proteja el cable de alimentación. Evite pisar o doblar el cable, en

particular a la altura del conector y las terminales de contacto del

aparato.

•Utilice sólo los accesorios que especica el fabricante.

•Utilice sólo el carrito, el soporte, el trípode y la mesa

que indica el fabricante y los que incluye el equipo.

Tenga cuidado cuando transporte el equipo en el carrito

para evitar caídas y posibles lesiones.

•Desenchufe el equipo durante tormentas eléctricas o

cuando no se utilice por un período prolongado.

•Todos los trabajos de servicio técnico deben ser realizados por

personal de servicio calicado. Solicite el servicio de asistencia técnica

cuando, por ejemplo, el cable de alimentación o el conector están

dañados, si se derramó líquido o cayeron objetos dentro del aparato,

si el equipo estuvo expuesto a la lluvia o humedad, si no funciona

normalmente o si se cayó.

•PRECAUCIÓN: para evitar que las baterías se sulfaten y puedan

ocasionar lesiones, daños materiales o en la unidad:

• Instale todas las baterías de forma correcta, de acuerdo con los

signos + y - marcados en la unidad.

• No utilice baterías de distintas clases (nuevas y usadas o de carbono

y alcalinas, etc.).

• Extraiga las pilas cuando no utilice la unidad durante un período

prolongado.

• No exponga las baterías a temperaturas altas como las que emiten

la luz solar, el fuego u otros elementos similares.

• Este producto contiene perclorato y puede requerir un método de

manipulación especial. Visite www.dtsc.ca.gov/hazardouswaste/

perchlorate.

• El producto/control remoto puede contener una batería tipo botón o

moneda fácil de tragar. Siempre mantenga las baterías lejos del alcance

de los niños. En caso de ingestión la batería podría causar lesiones

graves o la muerte. Puede haber quemaduras internas graves en un

plazo de dos horas tras la ingestión.

• Si sospecha que una batería se ha ingerido o introducido en cualquier

parte del cuerpo, consulte inmediatamente a un médico.

• Al cambiar las baterías, mantenga siempre las baterías nuevas y usadas

lejos del alcance de los niños. Verique que el compartimiento de la

batería esté bien cerrado luego de reemplazar la batería.

• Si el compartimiento de la batería no puede cerrarse, discontinúe el uso

del producto. Manténgalo lejos del alcance de los niños y comuníquese

con el fabricante.

•No exponga el equipo a goteos ni salpicaduras.

•No coloque el aparato cerca de fuentes de peligro (por ejemplo, objetos

que contengan líquidos o velas encendidas).

•Este aparato puede contener plomo y mercurio. Cumpla con la

normativa local, estatal o nacional sobre eliminación de productos.

Comuníquese con las autoridades locales para solicitar información

sobre la eliminación o el reciclaje de productos. Para obtener más

información sobre las opciones de reciclaje disponibles, ingrese en

cualquiera de los siguientes sitios web: www.mygreenelectronics.com,

www.eiae.org, www.recycle.philips.com.

•Si el conector de alimentación u otro conector se utilizan como

dispositivos de desconexión, deben estar accesible y fáciles de operar.

•No coloque este aparato sobre muebles que adultos o niños puedan

tirar, inclinar o utilizar para subirse sobre ellos. Si el aparato se cae,

puede causar heridas graves o incluso la muerte.

• Este aparato no debe ubicarse en una instalación cerrada como una

estantería o un rack, a menos que esté adecuadamente ventilada.

Verique que haya un espacio mínimo de 20 cm (7,8 pulg) alrededor del

aparato.

Símbolo de equipo de Clase II

Este símbolo indica que la unidad tiene un sistema de doble aislamiento.

Conozca estos símbolos de seguridad

El símbolo del rayo indica que los componentes sin aislamiento

dentro de la unidad pueden generar descargas eléctricas. Para la

seguridad de todas las personas de su hogar, no retire la cubierta

del producto.

El signo de exclamación indica las características del producto

que pueden provocar problemas de funcionamiento y

mantenimiento. Por eso, se recomienda leer el manual de

instrucciones.

ADVERTENCIA: Para reducir el riesgo de incendios o descargas eléctricas, no

exponga el aparato a la lluvia ni a la humedad, ni coloque sobre él objetos

que contengan líquidos (por ejemplo, jarrones).

PRECAUCIÓN: Para evitar descargas eléctricas, el conductor ancho debe

introducirse por completo en la ranura adecuada.

Protección del producto

Utilice únicamente un paño de microbra para limpiar el producto.

Cuidado del medio ambiente

Eliminación del producto antiguo y las pilas

Este producto ha sido diseñado y fabricado con materiales y

componentes de alta calidad que pueden reciclarse y reutilizarse.

Este producto puede contener plomo y mercurio. La eliminación

de estos materiales puede estar sometida a regulaciones debido a

consideraciones ambientales. Para obtener información sobre el desecho

o reciclaje de estos materiales, comuníquese con las autoridades locales o

visite www.recycle.philips.com.

Este producto contiene pilas:

• Deseche las baterías de forma adecuada. No las incinere. Las baterías

pueden explotar si se sobrecalientan.

• No las envuelva en papel metálico ni de aluminio. Envuélvalas en papel

de diario antes de desecharlas.

• Se recomienda comunicarse con los funcionarios locales pertinentes

para obtener información acerca de centros de reciclaje autorizados.

• Visite www.call2recycle.org para obtener más información sobre centros

de reciclaje para pilas recargables de su zona.

Aviso de cumplimiento

El dispositivo cumple con los reglamentos de la FCC, apartado 15. El

funcionamiento está sujeto a las siguientes condiciones:

a El dispositivo no debe causar interferencias nocivas y

b debe recibir todo tipo de interferencias, incluso las que originan un

funcionamiento indeseado.

Normas de la Comisión Federal de Comunicaciones (FCC)

Este equipo se ha probado y se ha determinado que cumple con los límites

para un dispositivo digital clase B, de acuerdo con el apartado 15 de las

normativas de la FCC. Estos límites están destinados a ofrecer una protección

razonable contra interferencias dañinas dentro de una instalación residencial.

Este equipo genera, utiliza y puede emitir energía de radiofrecuencia. Si no

se instala y utiliza de conformidad con el manual de instrucciones, puede

ocasionar interferencias perjudiciales en las comunicaciones de radio.

Sin embargo, no existe garantía de que no se producirá interferencia en una

instalación en particular. Si este equipo provoca interferencias perjudiciales en

la recepción de radio o televisión, lo que puede determinarse encendiendo y

apagando el equipo, se recomienda al usuario intentar corregir la interferencia

mediante una o varias de las siguientes medidas:

• Cambie la posición de la antena receptora.

• Aumente la distancia entre el equipo y el receptor.

• Conecte el equipo a un tomacorriente de un circuito diferente del que

está conectado el receptor.

• Para obtener ayuda, comuníquese con el distribuidor o con un técnico

de radio o televisión calicado.

Normas sobre la exposición a campos de radiación de la FCC: este equipo

cumple con la normativa que regula los límites de exposición a la radiación

de FCC para ambientes no controlados. Este equipo debe instalarse y

utilizarse con una distancia mínima de 20 cm entre el radiador y el cuerpo. No

coloque este aparato cerca de otros transmisores o antenas, ni lo utilice con

este tipo de dispositivos.

Advertencia: Cualquier alteración o modicación a este dispositivo, que no

cuente con la autorización expresa de Gibson Innovations, puede anular el

derecho del usuario para utilizar el equipo.

Número de modelo: B8/37

Nombre comercial: Philips

Parte responsable: Gibson Innovations USA Inc.

PO BOX 100572, Nashville TN 37224

Canadá:

CAN ICES-3(B)/NMB-3(B)

Este dispositivo cumple con los RSSs exentos de licencia de Industry Canada.

El funcionamiento queda sujeto a las siguientes dos condiciones: (1) este

dispositivo no debe producir interferencias, y (2) debe recibir todo tipo de

interferencia, incluso aquellas que pueden causar un funcionamiento no

deseado del dispositivo.

El dispositivo cumple con la exención de límites en la evaluación de rutina en

la sección 2.5 de RSS 102 y cumple con la exposición RSS-102 RF, los usuarios

pueden obtener información canadiense sobre la exposición y cumplimiento

de RF.

No coloque este aparato cerca de otros transmisores o antenas, ni lo utilice

junto a este tipo de dispositivos. Este equipo se debe instalar y manejar a una

distancia mínima de 20 cm entre el radiador y su cuerpo.

México:

La operación de este equipo está sujeta a las siguientes dos condiciones: (1)

es posible que este equipo o dispositivo no cause interferencia perjudicial y

(2) este equipo o dispositivo debe aceptar cualquier interferencia, incluyendo

la que pueda causar su operación no deseada.

Ayuda y asistencia técnica

Para obtener una amplia asistencia en línea, visite www.philips.com/support

para:

• descargar el manual de usuario y la guía de inicio rápido

• ver tutoriales de video (solo disponible para modelos seleccionados)

• buscar respuestas a preguntas frecuentes (FAQ)

• enviarnos un correo electrónico con una pregunta

• chatear con nuestro representante de soporte.

Siga las instrucciones del sitio web para seleccionar su idioma e ingrese el

número de modelo de su producto.

También puede ponerse en contacto con el servicio de atención al cliente de

su país. Antes de ponerse en contacto, anote el modelo y número de serie del

producto. Puede buscar esta información en la parte posterior o inferior del

producto.

Français

Important

Lisez attentivement toutes les instructions avant d’utiliser le téléviseur. Si des

dommages sont causés par le non-respect des instructions, la garantie ne

sera pas applicable.

Consignes de sécurité importantes

•Lisez ces instructions.

•Conservez ces instructions.

•Tenez compte de tous les avertissements.

•Suivez toutes les instructions.

•N’utilisez pas cet appareil près de l’eau.

•Nettoyez l’appareil avec un chion sec seulement.

•N’obstruez aucune prise de ventilation. Installez l’appareil en

conformité avec les instructions du fabricant.

•N’installez pas l’appareil près d’une source de chaleur comme un

radiateur, un registre de chaleur ou un autre appareil (incluant les

amplicateurs) qui produit de la chaleur.

•Ne passez pas outre les instructions de sécurité

concernant la che polarisée ou la che de mise à

la terre. Une che polarisée est composée de deux

broches dont l’une est plus large que l’autre. Une che

de mise à la terre est composée de deux broches et d’une broche de

masse. La broche plus large et la broche de masse visent à assurer votre

sécurité. Si la che fournie ne peut être insérée dans la prise, consultez

un électricien pour qu’il remplace votre prise désuète.

•Protégez le cordon d’alimentation de façon à ce qu’il ne puisse pas être

écrasé ou pincé; vériez particulièrement les ches, les prises et la sortie

du l dans l’appareil.

•Utilisez seulement les accessoires spéciés par le fabricant.

•Utilisez seulement le chariot, le support, le trépied ou la

table spéciés par le fabricant ou vendu avec l’appareil.

Si vous utilisez un chariot, faites attention lorsque vous

le déplacez an d’éviter de vous blesser en cas de

renversement de l’appareil.

•Débranchez cet appareil pendant les orages avec

éclairs ou s’il n’est pas utilisé pendant de longues périodes.

•Toute réparation doit être faite par un technicien qualié. Une réparation

est nécessaire quand l’appareil a été endommagé, par exemple, quand

le cordon ou la che d’alimentation ont été endommagés, quand un

objet a été introduit dans l’appareil ou quand l’appareil a été mouillé,

exposé à la pluie ou à l’humidité, qu’il ne fonctionne pas correctement

ou qu’il a été échappé.

•AVERTISSEMENT relatif à l’utilisation de piles – An d’éviter une fuite

des piles pouvant entraîner des blessures ou des dommages matériels :

• Installez toutes les piles correctement en alignant les pôles + et - tel

qu’indiqué sur l’appareil.

• Ne combinez pas des piles diérentes (neuves et usagées, au

carbone et alcalines, etc.).

• Retirez les piles lorsque l’appareil n’est pas utilisé pendant une

longue période.

• Les piles intégrées ne doivent pas être exposées à une chaleur

excessive, comme les rayons du soleil ou le feu.

• Produits contenant du perchlorate : une manipulation particulière

peut être requise. Consulter www.dtsc.ca.gov/hazardouswaste/

perchlorate.

• L’appareil ou sa télécommande peuvent contenir une pile bouton qu’un

enfant pourrait avaler. Gardez ce type de pile hors de portée des enfants

à tout moment! En cas d’ingestion, la pile peut provoquer des blessures

sérieuses voire la mort. De graves brûlures internes peuvent survenir dans

les deux heures suivant l’ingestion.

• Si vous croyez qu’une pile a été ingérée ou introduite dans le corps de

quelqu’un, consultez immédiatement votre médecin.

• Lorsque vous changez les piles, assurez-vous que les piles neuves et

usagées sont hors de portée des enfants. Une fois le changement de pile

eectué, assurez-vous que son compartiment est bien fermé et sécurisé.

• Si vous ne parvenez pas à sécuriser le compartiment de la pile, cessez

d’utiliser l’appareil. Gardez l’appareil hors de portée des enfants et

communiquez avec le fabricant.

•N’exposez pas l’appareil aux éclaboussures, ni aux déversements.

•Ne placez aucune source de danger sur l’appareil (par exemple des

objets remplis de liquide ou des bougies allumées).

•Cet appareil peut contenir du plomb et du mercure. Mettez l’appareil

au rebut conformément aux lois municipales, provinciales ou

fédérales. Pour en savoir plus sur la mise au rebut ou sur le recyclage,

veuillez communiquer avec les autorités locales. Pour de plus amples

renseignements sur les diverses possibilités de recyclage, visitez les sites

www.mygreenelectronics.com, www.eiae.org ou www.recycle.philips.com.

•Si la che d’alimentation ou un coupleur d’appareil est utilisé comme

dispositif de découplage, celui-ci doit rester facilement accessible.

•Ne placez pas cet appareil sur un meuble qu’un enfant pourrait faire

basculer ou qu’un adulte pourrait renverser involontairement en

s’appuyant ou en grimpant dessus ou encore en le tirant. La chute d’un

appareil peut provoquer des blessures graves, voire la mort.

• Cet appareil ne doit pas être placé dans un meuble encastré comme

une bibliothèque ou une étagère, à moins que l’emplacement ore une

ventilation susante. Veillez à garder un espace dégagé d’au moins

20 cm (7,8») autour de cet appareil.

B8_37_Safety_V1.0.indd 1-4 2017/3/1 11:18:24

Specications are subject to change without notice.

The Philips trademark and the Philips Shield Emblem are registered trademarks of Koninklijke Philips N.V. used under license.

This product has been manufactured by, and is sold under the responsibility of Gibson Innovations Ltd., and Gibson Innovations Ltd. is the

warrantor in relation to this product.

B8_37_Safety_V1.0

Symbole d’équipement de classe II

Ce symbole signie que l’appareil sur lequel il est apposé est doté d’une

double isolation.

Sachez reconnaître ces symboles de sécurité

Ce symbole «d’éclair» signale des matériaux non isolés présents

dans votre appareil et pouvant causer un choc électrique. Pour

assurer la sécurité des membres de votre famille, veuillez ne pas

enlever le couvercle du produit.

Les «points d’exclamation» ont pour but d’attirer votre attention

sur des caractéristiques à propos desquelles vous devez lire

attentivement la documentation accompagnant l’appareil an

d’éviter tout problème de fonctionnement et d’entretien.

AVERTISSEMENT : an de réduire les risques d’incendie ou de

choc électrique, n’exposez pas cet appareil à la pluie ou à l’humidité. Ne

posez pas dessus d’objets remplis de liquides, tels que des vases.

ATTENTION : pour éviter les chocs électriques, introduisez la broche la plus

large de la che dans la borne correspondante de la prise et poussez à fond.

Précautions d’utilisation de votre appareil

Utilisez seulement un chion en microbre pour nettoyer l’appareil.

Respect de l’environnement

Mise au rebut de votre ancien appareil et de la pile

Votre produit a été conçu et fabriqué avec des matériaux et des

composants de grande qualité, qui peuvent être recyclés et réutilisés.

Ce produit peut contenir du plomb et du mercure. La mise

au rebut de ces matériaux peut être réglementée pour des raisons

environnementales. Pour en savoir plus sur la mise au rebut ou sur le

recyclage, veuillez communiquer avec les autorités locales ou visiter le site
