Gibson Innovations E200BT Bluetooth Headphones User Manual E200BT

Gibson Innovations Limited Bluetooth Headphones E200BT

E200BT User Manual

QUICK START
GUIDE
Quick start guide
[ 1.0 Charge the battery ]
1. Plug one end of USB cable into the charger (or into the USB port of a computer).
2. Plug the other end of the cable into the micro USB charging slot on the headset.
3. When the headset is charging, a white indicator light will be displayed.
4. When the headset is fully charged, the white light goes o.
1. Turn the headset on. Press and hold for 2 sec.
2. Turn the headset o. Press and hold for 4 sec. A white
indicator light turns on for 1.5 sec. and then the
headset will turn o.
Please refer to www.onkyo.com/welcome for the full user manual
Volume/
Track
control
Microphone
[ 2.0 Turn on and o the headset ]
1. Make sure your headset is turned o.
2. Press and hold until an alternating blue and white
light flashes.
3. Turn on the Bluetooth function on your phone.
4. Your phone will start searching for Onkyo E200BT.
5. Follow the on-screen instructions to pair your phone.
(Check your phone’s user manual for details)
‘0000’ not required for
some mobile phones
Settings
Select Back
Connectivity
10:32
Enter Password
****
0000
Settings
Devices Found
Select Back
10:31
Onkyo E200BT
Settings
Bluetooth
Select Back
Connectivity
10:30
Add
Bluetooth
device
[ 3.0 Manual Pairing ]
www.onkyo.com
E200BT
Languages x 1: EN
QUICK START GUIDE
Box size: W95 x H150 x D25 mm
QSG size: W89 x H144 mm( Folded)
Binding: 1. Folded / 2. Glue / 3.Saddle stitch
Sleeve size: W210 x H50 mm
QSG (A1/B1) - Print color: 2 colors ( Black + PMS186c)
Revised illustration_EN (2015.07.23)
A white light triple flashes every 10 seconds.
An alternating white and blue light flashes.
A blue light flashes at every 8 seconds.
A blue light flashes rapidly.
The battery is low.
The headset is in pairing mode.
The headset is switched on but not connected.
If no connection can be made, the headset will
turn o itself after 5 minutes.
The headset is both paired & connected.
[ 5.0 LED Indicator light ]
Mute/unmute the mic
while in a call
Press once
MUSIC CONTROLS CALL CONTROLS
Volume up Press once
[ 4.0 Use music and call controls ]
Play/Pause Press once
Reject incoming call Press & hold
for 2 sec.
Press twice
Pick up call/Hang up Press once
Switch caller while
in a call
Micro USB
charging slot
On/O button,
Music/Call
control
LED
indicator
light
E200BT
EN
Skip forward Long Press
Volume down Press once
Skip backward Long Press
2015 © Gibson Innovations Limited.
All rights reserved.
This product has been
manufactured by, and is sold under
the responsibility of Gibson
Innovations Ltd., and Gibson
Innovations Ltd. is the warrantor in
relation to this product.
Gibson Innovations Netherlands
B.V. Building
English:
Notice of compliance
The device complies with the FCC rules, Part 15. Operation is subject to the following two conditions:
1. This device may not cause harmful interference, and
2. This device must accept any interference received, including interference that may cause undesired
operation.
FCC rules
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of
the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed
and used in accordance with the instruction manual, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be determined by turning the equipment off and
on, the user is encouraged to try to correct the interference by one or more of the following measures:
• Relocate the receiving antenna.
• Increase the separation between equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
FCC Radiation Exposure Statement:
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment.
This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter.
Canada:
This device complies with Industry Canada licence-exempt RSS standard(s). Operation is subject to the following
Two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference
received, including interference that may cause undesired operation.
CAN ICES-3(B)/NMB-3(B)
IC Radiation Exposure Statement:
This equipment complies with Canada radiation exposure limits set forth for uncontrolled environments.
This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter.
Caution: The user is cautioned that changes or modifications not expressly approved by the party responsible for
compliance could void the user's authority to operate the equipment.
French:
Avis de conformité
Cet appareil satisfait aux règlements de la FCC partie 15 du Code of Federal Regulations. Son fonctionnement est
assujetti aux deux conditions suivantes :
1. Cet appareil ne doit pas causer d’interférence préjudiciable et
2. l’appareil doit accepter toute interférence reçue, y compris les interférences qui peuvent causer un
fonctionnement non désiré.
Règlement de la FCC
Cet équipement a été testé et jugé compatible avec les limites s’appliquant aux appareils numériques de la classe B,
conformément à l’article 15 du règlement de la FCC. Ces limites ont été définies pour fournir une protection
raisonnable contre les interférences nuisibles dans le cadre d’une installation résidentielle. Cet équipement génère,
utilise et peut émettre de l’énergie radiofréquence et, s’il n’est pas installé ni utilisé conformément aux instructions,
peut causer des interférences gênantes pour les communications radio.
Rien ne garantit toutefois que des interférences ne surviendront pas dans une installation particulière. Si cet
équipement cause des interférences nuisibles pour la réception de la radio ou de la télévision, ce qui peut être
déterminé en mettant l’équipement hors tension puis sous tension, l’utilisateur devra essayer de corriger ces
interférences en effectuant une ou plusieurs des opérations suivantes :
Déplacez l’antenne de réception.
Augmentez la distance entre l’équipement et le récepteur.
Branchez l’équipement à une prise d’un circuit autre que celui sur lequel le récepteur est branché.
Consultez le détaillant ou un technicien de radiotélévision expérimenté.
Canada :
Le présent appareil est conforme aux CNR d’Industrie Canada applicables aux appareils radio exempts de licence.
L’exploitation est autorisée aux deux conditions suivantes : (1) l’appareil ne doit pas produire de brouillage, et (2)
l’utilisateur de l’appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d’en
compromettre le fonctionnement.
CAN ICES-3(B)/NMB-3(B)
Déclaration d’IC sur l’exposition aux radiations:
Cet équipement est conforme aux limites d’exposition aux radiations définies par le Canada pour des
environnements non contrôlés.
Cet émetteur ne doit pas être installé au même endroit ni utilisé avec une autre antenne ou un autre
émetteur.
