Gibson Innovations HTL2161 SoundBar Speaker User Manual

Gibson Innovations Limited SoundBar Speaker Users Manual

Users Manual

User manual
HTL2161B/F7
For product support, visit
www.philips.com/support
EN: For further assistance, call the customer support service in your country.
• To obtain assistance in the U.S.A., Canada, Puerto Rico, or the U.S. Virgin Islands, contact Philips Customer
Care Center at 1 (866) 226-6074
• To obtain assistance in Mexico, contact Philips Customer Care Center at 01 800 839 1989;
Mexico city: 5887-9736
For Product recycling information, please visit - www.recycle.philips.com
Question?
Contact
Philips
1EN
Contents
1 Important 2
Help and support 2
Important safety instructions 2
Care for your product 4
Care of the environment 4
2 Your SoundBar 4
Main unit 4
Remote control 4
Connectors 5
3 Connect and set up 6
Placement 6
Connect to TV 7
Connect audio from TV and other devices 7
4 Use your SoundBar 8
Adjust the volume 8
Choose your sound 8
Play audio through Bluetooth 9
MP3 player 10
USB storage devices 10
Auto standby 10
Set display brightness 10
Apply factory settings 11
5 Update software 11
Check software version 11
Update software via USB 11
6 Wall mount 12
7 Productspecications 13
8 Troubleshooting 14
9 Notice 15
4EN
Care for your product
Use only microber cloth to clean the product.
Care of the environment
Disposal of your old product and battery
Your product is designed and manufactured
with high quality materials and components,
which can be recycled and reused.
This product may contain lead and mercury.
Disposal of these materials may be regulated
due to environmental considerations. For
disposal or recycling information, please
contact your local authorities or visit
www.recycle.philips.com.
This product contains batteries:
• Dispose of batteries properly. Do not
incinerate. Batteries may explode if
overheated.
• Do not wrap in metal or aluminum foil.
Wrap in newspaper before discarding.
• It is suggested that you contact your local
town or city to determine proper battery
redemption site(s) in your area.
• Please visit www.call2recycle.org for
additional information on a recycling center
in your area for rechargeable batteries.
2 Your SoundBar
Congratulations on your purchase, and
welcome to Philips! To fully benet from
the support that Philips offers, register your
SoundBar at www.philips.com/welcome.
Main unit
This section includes an overview of the main
unit.
a (Standby-On/Standby indicator)
• Switch the SoundBar on or to standby.
• When the SoundBar is in standby, the
standby indicator turns red.
b SOURCE
Select an input source for the SoundBar.
c Display panel
d +/- (Volume)
Increase or decrease volume.
Remote control
This section includes an overview of the
remote control.
da b c
5EN
a (Standby-On)
Switch the SoundBar on or to standby.
b Source buttons
HDMI ARC: Switch your source to HDMI
ARC connection.
: Switch to Bluetooth mode.
USB: Switch to USB mode.
OPTICAL: Switch your audio source to
the optical connection.
COAX: Switch your audio source to the
coaxial connection.
AUDIO IN: Switch your audio source to
the MP3 connection (3.5mm jack).
AUX: Switch your audio source to the
AUX connection.
c / (Previous/Next)
Skip to the previous or next track in USB
mode.
b
a
c
d
f
g
h
i
j
e l
k
d (Play/Pause)
• Start, pause or resume play in USB
mode.
e BASS +/-
Increase or decrease bass.
f Volume control
• +/-: Increase or decrease volume.
• : Mute or restore volume.
g SOUND
Select a sound mode.
h SURROUND ON/OFF
Select surround or stereo sound.
i AUDIO SYNC +/-
Increase or decrease audio delay.
j DIM
Set the brightness of SoundBar display
panel.
k NIGHT
Turn night mode on or off.
l TREBLE +/-
Increase or decrease treble.
Connectors
This section includes an overview of the
connectors available on your SoundBar.
ac
h
g
f
bde
6EN
a DIGITAL IN-COAXIAL
Connect to a coaxial audio output on the
TV or a digital device.
b AUX IN (L/R)
Connect to an analog audio output on the
TV or an analog device.
c DIGITAL IN-OPTICAL
Connect to an optical audio output on the
TV or a digital device.
d DC IN
Connect to the power supply.
e HDMI OUT (ARC) - TO TV
Connect to the HDMI input on the TV.
f SUBWOOFER
Connect to the supplied subwoofer.
g (USB)
• Audio input from a USB storage
device.
• Upgrade software of this product.
• Charge a USB device.
h AUDIO IN
• Audio input from, for example, an MP3
player (3.5mm jack).
3 Connect and set
up
This section helps you connect your SoundBar
to a TV and other devices, and then set it up.
For information about the basic connections of
your SoundBar and accessories, see the quick
start guide.
Note
• For identication and supply ratings, see the type plate
at the back or bottom of the product.
• Before you make or change any connections, make sure
that all devices are disconnected from the power outlet.
Placement
Place the subwoofer at least 1 meter (3 feet)
away from your SoundBar, and ten centimeters
away from the wall.
For best results, place your subwoofer as shown
below.
7EN
Connect to TV
Connect your SoundBar to a TV. You can listen
to audio from TV programs through your
SoundBar. Use the best quality connection
available on your SoundBar and TV.
Connect to TV through HDMI (ARC)
Your SoundBar supports HDMI with Audio
Return Channel (ARC). If your TV is HDMI ARC
compliant, you can hear the TV audio through
your SoundBar by using a single HDMI cable.
1 Using a High Speed HDMI cable, connect
the HDMI OUT (ARC)-TO TV connector
on your SoundBar to the HDMI ARC
connector on the TV.
• The HDMI ARC connector on the TV
might be labeled differently. For details,
see the TV user manual.
2 On your TV, turn on HDMI-CEC
operations. For details, see the TV user
manual.
Note
• If your TV is not HDMI ARC compliant, connect
an audio cable to hear the TV audio through your
SoundBar (see 'Connect audio from TV and other
devices' on page 8).
• If your TV has a DVI connector, you can use an HDMI/
DVI adapter to connect to TV. However, some of the
features may not be available.
TV
Connect audio from TV and
other devices
Play audio from TV or other devices through
your Soundbar speakers.
Use the best quality connection available on
your TV, Soundbar, and other devices.
Note
• When your Soundbar and TV are connected through
HDMI ARC, an audio connection is not required. (see
'Connect to TV through HDMI (ARC)' on page 7)
Option 1: Connect audio through a
digital optical cable
Best quality audio
1 Using an optical cable, connect the
OPTICAL connector on your SoundBar to
the OPTICAL OUT connector on the TV
or other device.
• The digital optical connector might be
labeled SPDIF or SPDIF OUT.
TV
8EN
Option 2: Connect audio through a
digital coaxial cable
Good quality audio
1 Using a coaxial cable, connect the
COAXIAL connector on your SoundBar
to the COAXIAL/DIGITAL OUT
connector on the TV or other device.
• The digital coaxial connector might be
labeled DIGITAL AUDIO OUT.
Option 3: Connect audio through
analog audio cables
Basic quality audio
1 Using an analog cable, connect the AUX
connectors on your SoundBar to the
AUDIO OUT connectors on the TV or
other device.
DVD
4 Use your
SoundBar
This section helps you use the SoundBar to play
audio from connected devices.
Before you start
• Make the necessary connections described
in the quick start guide and the user
manual.
• Switch the SoundBar to the correct source
for other devices.
Adjust the volume
1 Press +/- (Volume) to increase or decrease
a volume level.
• To mute sound, press (Mute).
• To restore the sound, press (Mute)
again or press +/- (Volume).
Choose your sound
This section helps you choose the ideal sound
for your video or music.
Sound mode
Select predened sound modes to suit your
video or music.
1 Press SOUND to select a sound option
from the display panel.
• AUTO: Automatically select a sound
setting based on the sound stream.
• POWERFUL: Enjoy thrilling arcade
sounds, ideal for action-packed videos
and loud parties.
• BALANCED: Experience the original
sound of your movies and music,
without added sound effects.
9EN
• BRIGHT: Spice up your dull movies
and music with added sound effects.
• CLEAR: Hear every detail in your
music and clear voices in your movies.
• WARM: Experience spoken words and
music vocals in comfort.
• PERSONAL: Personalize the sound
based on your preferences.
Surround sound mode
Experience an immersive audio experience with
surround sound modes.
1 Press SURROUND ON/OFF to turn
surround mode on or off.
• On: Create a surround listening
experience.
• Off: Two-channel stereo sound. Ideal
for listening to music.
Equalizer
Change the high frequency (treble) and low
frequency (bass) settings of the SoundBar.
1 Press TREBLE +/- or BASS +/- to change
the frequency.
Synchronize video and sound
If the audio and video are not synchronized,
delay the audio to match the video.
1 Press AUDIO SYNC +/- to synchronize
the audio with the video.
Night mode
For quiet listening, night mode decreases the
volume of loud sounds when audio is played.
Night mode is only available for Dolby Digital
soundtracks.
1 Press NIGHT to turn night mode on or
off.
Play audio through Bluetooth
Through Bluetooth, connect the SoundBar with
your Bluetooth device (such as an iPad, iPhone,
iPod touch, Android phone, or laptop), and then
you can listen to the audio les stored on the
device through your SoundBar speakers.
What you need
• A Bluetooth device which supports
Bluetooth prole A2DP, AVRCP and with
Bluetooth version as 3.0 + EDR.
• The maximum operational range between
the SoundBar and a Bluetooth device is
approximately 10 meters (30 feet).
1 Press on the remote control to switch
the SoundBar to Bluetooth mode.
» BT is displayed on the display panel,
blinking.
2 On the Bluetooth device, switch on
Bluetooth, search for and select PHILIPS
HTL2161B to start connection (see the
user manual of the Bluetooth device on
how to enable Bluetooth).
» During connection, BT on the display
panel blinks.
3 Wait until you hear a beep sound from the
SoundBar.
» When the Bluetooth connection
succeeds, BT is displayed on the display
panel.
» If the connection fails, BT on the
display panel blinks continuously.
4 Select and play audio les or music on
your Bluetooth device.
• During play, if a call is coming, music
play is paused. Play resumes when the
call ends.
• If your Bluetooth device supports
AVRCP prole, on the remote control
you can press / to skip to a track,
or press to pause/resume play.
10 EN
5 To exit Bluetooth, select other source.
• When your switch back to Bluetooth
mode, Bluetooth connection remains
active.
Note
• The music streaming may be interrupted by obstacles
between the device and SoundBar, such as wall, metallic
casing that covers the device, or other devices nearby
that operate in the same frequency.
• If you want to connect your SoundBar with another
Bluetooth device, press and hold on the remote
control to disconnect the currently connected
Bluetooth device.
MP3 player
Connect your MP3 player to play your audio
les or music.
What you need
• An MP3 player.
• A 3.5mm stereo audio cable.
1 Using the 3.5mm stereo audio cable,
connect the MP3 player to the AUDIO IN
connector on your SoundBar.
2 Press AUDIO IN on the remote control.
3 Press the buttons on the MP3 player to
select and play audio les or music.
USB storage devices
Enjoy audio on a USB storage device, such as an
MP3 player and USB ash memory, etc.
What you need
• A USB storage device that is formatted for
FAT or NTFS le systems, and complies
with the Mass Storage Class.
• An MP3 le on a USB storage device
1 Connect a USB storage device to this
product.
2 Press USB on the remote control.
3 Use the remote control to control play.
Button Action
Start, pause or resume play.
/ Skip to the previous or next track.
USB During USB play, press repeatedly to
select a repeat or shufe mode, or
turn off a play mode.
Note
• This product may not be compatible with certain types
of USB storage device.
• If you use a USB extension cable, USB HUB, or USB
multi-reader, the USB storage device may not be
recognized.
• Digital camera PTP and MTP protocols are not
supported.
• Do not remove the USB storage device while it is
being read.
• DRM-protected music les (MP3) are not supported.
• Support a USB port: 5V , 1A.
Auto standby
When playing media from a connected device,
the SoundBar automatically switches to standby
after 29 minutes of button inactivity and no
audio/video play from a connected device.
Set display brightness
You can press DIM repeatedly to select a
different brightness level of the display panel on
this product.
11EN
Apply factory settings
You can reset this product to the default
settings programmed at the factory.
1 In any source mode, on the remote control
press Volume -, BASS -, and TREBLE - in
sequence within three seconds.
» When the factory settings restore is
complete, the product automatically
switches off and restarts.
5 Update software
To get the best features and support, update
your product with the latest software.
What you need
• Connect this product to your TV through
HDMI.
Check software version
In HDMI ARC source, on the remote control
press TREBLE -, BASS -, and Volume - in
sequence.
Update software via USB
1 Check the latest software version on
www.philips.com/support.
• Search for your model and click on
"Software and drivers".
2 Download the software into a USB storage
device.
a Unzip the download if zipped, and
makesurethattheunzippedleis
named "HTL2161.bin".
b Putthe"HTL2161.bin"leintheroot
directory.
3 Connect the USB storage device to the
(USB) connector on this product.
4 Switch this product to the HDMI ARC
source, and switch your TV to the HDMI
source.
12 EN
5 On the remote control, within six seconds
press twice then Volume + once, and
then hold down SURROUND ON.
» If an upgrade media is detected, on the
TV screen you are prompted to start
the update.
» If an upgrade media is not detected,
an error message is displayed on the
TV screen. Make sure that the latest
software of this product is put in the
USB storage device.
6 Press to start the update.
7 Wait until the update is completed.
» If the update is complete, this product
automatically turns off and on again.
Caution
• Do not turn off the power or remove the USB storage
device when the software update is in progress because
you might damage this player.
6 Wall mount
Note
• Improper wall mounting may result in accident, injury or
damage. If you have any query, contact Consumer Care
in your country.
• Before wall mounting, make sure the wall can support
the weight of your SoundBar.
• Before wall mount, you need not remove the four
rubber feet at the bottom of the SoundBar, otherwise
the rubber feet cannot be xed back.
Screw length/diameter
Depending on the type of wall mounting your
SoundBar, make sure that you use screws of a
suitable length and diameter.
See the illustration in the quick start guide on
how to wall mount the SoundBar.
1) Drill two holes on the wall.
2) Secure the dowels and screws in the holes.
3) Hang the SoundBar on the fastening screws.
> 25mm
3.5-4mm
4mm
13EN
7 Product
specifications
Note
• Specications and design are subject to change without
notice.
Amplier
• FTC total output power: 40W
• Left + Right: 25W (1%THD, 8ohm,
120Hz-20kHz)
• Subwoofer: 15W (1%THD, 4ohm,
30Hz-80Hz)
• RMS Total output power:
120W RMS (+/- 0.5 dB, 10% THD)
• Frequency response: 20 Hz-20 kHz / ±3 dB
• Signal-to-noise ratio:
> 65 dB (CCIR) / (A-weighted)
• Input sensitivity:
• AUX: 900 mV
• AUDIO IN: 500 mV
Audio
• S/PDIF Digital audio input:
• Coaxial: IEC 60958-3
• Optical: TOSLINK
USB
• Compatibility: Hi-Speed USB (2.0)
• Class support: USB Mass Storage Class
(MSC)
• File system: FAT16, FAT32, NTFS
• Supports MP3 le formats
• Sampling frequency:
• MP3: 8 kHz, 11 kHz, 12 kHz, 16 kHz,
22 kHz, 24 kHz, 32 kHz, 44.1 kHz,
48 kHz
• Constant bit rate:
• MP3: 8 kbps-320 kbps
Bluetooth
•Bluetooth proles: A2DP, AVRCP
•Bluetooth version: 3.0 + EDR
Main unit
•Power supply:
• Model (Philips branded AC power
adapter): DYS602-210309W; AS650-
210-AA309
• Input: 100-240 V~, 50/60 Hz 1.5 A
• Output: 21V , 3.09A
•Standby power consumption: ≤ 0.5 W
• Speaker impedance
• Woofer: 8 ohm
• tweeter: 16 ohm
• Speaker drivers:
2 x (90mm/3.5" x 34mm/1.3") woofer +
2 x 31mm/1.2" tweeter
•Dimensions (WxHxD): 843 x 52 x 60 mm
•Weight: 1.4 kg
Subwoofer
• Impedance: 3.6 ohm
• Speaker drivers: 1 x 134 mm (5.25")
woofer
• Dimensions (WxHxD):
165 x 240 x 297 mm
• Weight: 2.5 kg
Remote control batteries
• 1 x AAA-R03-1.5 V
14 EN
8 Troubleshooting
Warning
• Risk of electric shock. Never remove the casing of the
product.
To keep the warranty valid, never try to repair
the product yourself.
If you have problems using this product, check
the following points before you request service.
If you still have a problem, get support at
www.philips.com/support.
Main unit
The buttons on the SoundBar do not work.
• Disconnect the SoundBar from the power
supply for a few minutes, then reconnect.
Sound
No sound from SoundBar speakers.
• Connect the audio cable from your
SoundBar to your TV or other devices.
However, you do not need a separate
audio connection when the SoundBar and
TV are connected through HDMI ARC
connection.
• Reset your SoundBar to its factory settings.
• On the remote control, select the correct
audio input.
• Make sure that the SoundBar is not muted.
Distorted sound or echo.
• If you play audio from the TV through the
SoundBar, make sure that the TV is muted.
Audio and video are not synchronized.
• Press AUDIO SYNC +/- to synchronize
the audio with the video.
Error message is displayed on the display
panel.
• When "ERROR" is displayed, it indicates
that an input audio format is not
supported.
• When "USB ERROR" is displayed, it
indicates that the connected USB device is
not supported.
• When "HDMI ARC" blinks, it indicates
that the connected TV is not HDMI ARC
compliant or an unsupported audio format
is detected.
Bluetooth
A device cannot connect with the SoundBar.
• The device does not support the
compatible proles required for the
SoundBar.
• You have not enabled the Bluetooth
function of the device. See the user manual
of the device on how to enable the
function.
• The device is not correctly connected.
Connect the device correctly.
• The SoundBar is already connected with
another Bluetooth device. Disconnect the
connected device, then try again.
Quality of audio play from a connected
Bluetooth device is poor.
• The Bluetooth reception is poor. Move the
device closer to the SoundBar, or remove
any obstacle between the device and the
SoundBar.
The connected Bluetooth device connects and
disconnects constantly.
• The Bluetooth reception is poor. Move the
device closer to the SoundBar, or remove
any obstacle between the device and the
SoundBar.
• Turn off Wi-Fi function on the Bluetooth
device to avoid interference.
• For some Bluetooth, the Bluetooth
connection can be deactivated
automatically to save power. This does not
indicate any malfunction of the SoundBar.
15EN
9 Notice
This section contains the legal and trademark
notices.
Notice of compliance
The device complies with the FCC rules, Part
15. Operation is subject to the following two
conditions:
a This device may not cause harmful
interference, and
b This device must accept any interference
received, including interference that may
cause undesired operation.
FCC rules
This equipment has been tested and found
to comply with the limits for a Class B digital
device, pursuant to part 15 of the FCC Rules.
These limits are designed to provide reasonable
protection against harmful interference in a
residential installation. This equipment generates,
uses and can radiate radio frequency energy
and, if not installed and used in accordance
with the instruction manual, may cause harmful
interference to radio communications.
However, there is no guarantee that
interference will not occur in a particular
installation. If this equipment does cause harmful
interference to radio or television reception,
which can be determined by turning the
equipment off and on, the user is encouraged
to try to correct the interference by one or
more of the following measures:
• Relocate the receiving antenna.
• Increase the separation between
equipment and receiver.
• Connect the equipment into an outlet on
a circuit different from that to which the
receiver is connected.
• Consult the dealer or an experienced
radio/TV technician for help.
FCC Radiation Exposure Statement:This
equipment complies with FCC radiation
exposure limits set forth for an uncontrolled
environment. This equipment should be installed
and operated with a minimum distance of
20cm between the radiator and your body.
This transmitter must not be co-located or
operated in conjunction with any other antenna
or transmitter.
Warning: Any changes or modications made
to this device that are not expressly approved
by WOOX Innovations may void the user’s
authority to operate the equipment.
Model number: HTL2161B/F7
Trade Name: Philips
Responsible Party:P&F USA, Inc. PO Box 2248
Alpharetta, GA 30023-2248; 1 (866) 226-6074
Canada:
CAN ICES-3(B)/NMB-3(B)
This device complies with Industry Canada
licence-exempt RSS standard(s). Operation is
subject to the following Two conditions: (1) this
device may not cause harmful interference, and
(2) this device must accept any interference
received, including interference that may cause
undesired operation.
The device meets the exemption from the
routine evaluation limits in section 2.5 of RSS
102 and compliance with RSS-102 RF exposure,
users can obtain Canadian information on RF
exposure and compliance.
This transmitter must not be co-located or
operating in conjunction with any other antenna
or transmitter. This equipment should be
installed and operated with a minimum distance
of 20 centimeters between the radiator and
your body.
16
P&F USA Inc. PO Box 2248 Alpharetta, GA 30023-2248
ONE (1) YEAR LIMITED WARRANTY
WARRANTY COVERAGE:
This warranty obligation is limited to the terms set forth
below.
WHO IS COVERED:
This product is warranted to the original purchaser or the per-
son receiving the product as a gift against defects in materials and
workmanship as based on the date of original purchase
(“Warranty Period”) from an Authorized Dealer. The original
sales receipt showing the product name and the purchase date
from an authorized retailer is considered such proof.
WHAT IS COVERED:
This warranty covers new products if a defect in material
or workmanship occurs and a valid claim is received within
the Warranty Period. At its option, the company will either (1)
repair the product at no charge, using new or refurbished
replacement parts, or (2) exchange the product with a product
that is new or which has been manufactured from new, or ser-
viceable used parts and is at least functionally equivalent or most
comparable to the original product in current inventory,
or (3) refund the original purchase price of the product.
The company warrants replacement products or parts provided
under this warranty against defects in materials and workmanship
from the date of the replacement or repair for ninety (90) days
or for the remaining portion of the original product’s warranty,
whichever provides longer coverage for you. When a product or
part is exchanged, any replacement item becomes your property
and the replaced item becomes the company property. When a
refund is given, your product becomes the company property.
Note: Any product sold and identified as refurbished or
renewed carries a ninety (90) day limited warranty.
Replacement product can only be sent if all warranty
requirements are met. Failure to follow all requirements
can result in delay.
WHAT IS NOT COVERED - EXCLUSIONS AND LIMI-
TATIONS:
This Limited Warranty applies only to the new products that
can be identified by the trademark, trade name, or logo affixed
to it. This Limited Warranty does not apply to any non-Philips
hardware product or any software, even if packaged or sold
with the product. Non-Philips manufacturers, suppliers, or
publishers may provide a separate warranty for their own
products packaged with the bundled product.
The company is not liable for any damage to or loss of any ,
programs data, or other information stored on any media
contained within the product, or any non-Philips product or part
not covered by this warranty. Recovery or reinstallation of
programs, data or other information is not covered under this
Limited Warranty.
This warranty does not apply (a) to damage caused by accident,
abuse, misuse, neglect, misapplication, or non-Philips product, (b)
to damage caused by service performed by anyone other than
an Authorized Service Location, (c) to a product or
a part that has been modified without written permission,
or (d) if any serial number has been removed or defaced,
or (e) product, accessories or consumables sold “AS IS”
without warranty of any kind by including refurbished Philips
product sold “AS IS” by some retailers.
This Limited Warranty does not cover:
•Shipping charges to return defective product.
•Labor charges for installation or setup of the product, adjust-
ment of customer controls on the product, and installation or
repair of antenna/signal source systems outside of the product.
•Product repair and/or part replacement because of improper
installation or maintenance, connections to improper voltage
supply, power line surge, lightning damage, retained images or
screen markings resulting from viewing fixed stationary con-
tent for extended periods, product cosmetic appearance items
due to normal wear and tear, unauthorized repair or other
cause not within the control of the company.
•Damage or claims for products not being available for use, or
for lost data or lost software.
•Damage from mishandled shipments or transit accidents when
returning product.
•A product that requires modification or adaptation to enable
it to operate in any country other than the country for which
it was designed, manufactured, approved and/or authorized, or
repair of products damaged by these modifications.
•A product used for commercial or institutional purposes
(including but not limited to rental purposes).
•Product lost in shipment and no signature verification receipt
can be provided.
•Failure to operate per Owner’s Manual.
TO OBTAIN ASSISTANCE IN THE U.S.A., CANADA,
PUERTO RICO, OR U.S. VIRGIN ISLANDS…
Contact Customer Care Center at:
1 (866) 226-6074
REPAIR OR REPLACEMENT AS PROVIDED UNDER THIS
WARRANTY IS THE EXCLUSIVE REMEDY FOR THE CON-
SUMER. PHILIPS SHALL NOT BE LIABLE FOR ANY INCIDEN-
TAL OR CONSEQUENTIAL DAMAGES FOR BREACH OF
ANY EXPRESS OR IMPLIED WARRANTY ON THIS PROD-
UCT. EXCEPT TO THE EXTENT PROHIBITED BY APPLICABLE
LAW, ANY IMPLIED WARRANTY OF MERCHANTABILITY OR
FITNESS FOR A PARTICULAR PURPOSE ON THIS PRODUCT
IS LIMITED IN DURATION TO THE DURATION OF THIS
WARRANTY.
Some states do not allow the exclusions or limitation of inciden-
tal or consequential damages, or allow limitations on how long an
implied warranty lasts, so the above limitations or exclusions may
not apply to you.
This warranty gives you specific legal rights. You may have other rights which vary from state/province to state/province.
Specifications are subject to change without notice
2015 © WOOX Innovations Limited. All rights reserved.
This product was brought to the market by WOOX Innovations Limited or one of its affiliates, further referred
to in this document as WOOX Innovations, and is the manufacturer of the product. P&F is the warrantor
in relation to the product with which this booklet was packaged. Philips and the Philips Shield Emblem are
registered trademarks of Koninklijke Philips N.V.
HTL2161B_F7_UM_V1.0
P&F USA, Inc.
PO Box 2248 Alpharetta, GA 30023-2248
English HTL2161B/F7
Important
Read and understand all instructions before you use your product. If damage is caused by failure to
follow instructions, the warranty does not apply.
Help and support
For extensive online support, visit www.philips.com/support to:
• download the user manual and the quick start guide
• watch video tutorials (available only for selected models)
• ndanswerstofrequentlyansweredquestions(FAQs)
• email us a question
• chat with our support representative.
Follow the instructions on the website to select your language, and then enter your product model
number.
Alternatively,youcancontactConsumerCareinyourcountry.Beforeyoucontact,notedownthe
modelnumberandserialnumberofyourproduct.Youcanndthisinformationonthebackor
bottom of your product.
Important safety instructions
•Read these instructions.
•Keep these instructions.
•Heed all warnings.
•Follow all instructions.
•Do not use this apparatus near water.
•Clean only with dry cloth.
•Do not block any ventilation openings. Install in accordance with the manufacturer’s
instructions.
•Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus
(includingampliers)thatproduceheat.
•Do not defeat the safety purpose of the polarized or grounding-type
plug.Apolarizedplughastwobladeswithonewiderthantheother.A
grounding type plug has two blades and a third grounding prong. The wide
blade or the third prong are provided for your safety. If the provided plug
doesnottintoyouroutlet,consultanelectricianforreplacementoftheobsoleteoutlet.
•Protect the power cord from being walked on or pinched, particularly at plugs, convenience
receptacles, and the point where they exit from the apparatus.
•Only use attachments/accessories speciedbythemanufacturer.
•Use only with the cart,stand,tripod,bracketortablespeciedbythe
manufacturer or sold with the apparatus. When a cart is used, use caution when
moving the cart/apparatus combination to avoid injury from tip-over.
•Unplug this apparatus during lightning storm or when unused for long periods
of time.
•Refer all servicing toqualiedservicepersonnel.Servicingisrequiredwhentheapparatushas
been damaged in any way, such as power-supply cord or plug is damaged, liquid has been spilled
or objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture,
does not operate normally, or has been dropped.
•Battery usage CAUTION - To prevent battery leakage which may result in bodily injury,
property damage, or damage to the unit:
• Install all batteries correctly, + and - as marked on the unit.
• Do not mix batteries (old and new or carbon and alkaline, etc.).
• Remove batteries when the unit is not used for a long time.
• Thebatteriesshallnotbeexposedtoexcessiveheatsuchassunshine,reorthelike.
• PerchlorateMaterial-specialhandlingmayapply.Seewww.dtsc.ca.gov/hazardouswaste/
perchlorate.
• The product/remote control may contain a coin/button type battery, which can be swallowed.
Keep the battery out of reach of children at all times! If swallowed, the battery can cause
seriousinjuryordeath.Severeinternalburnscanoccurwithintwohoursofingestion.
• If you suspect that a battery has been swallowed or placed inside any part of the body, seek
immediate medical attention.
• When you change the batteries, always keep all new and used batteries out of reach of children.
Ensure that the battery compartment is completely secure after you replace the battery.
• If the battery compartment cannot be completely secured, discontinue use of the product.
Keep out of reach of children and contact the manufacturer.
•Apparatus shall not be exposed to dripping or splashing.
•Do not place any sources of danger on the apparatus (forexample.liquidlledobjects,lighted
candles).
•Thisapparatusmaycontainleadandmercury.Disposeaccordingtolocal,StateorFederal
laws. For disposal or recycling information, please contact your local authorities. For additional
assistance on recycling options, please contact www.mygreenelectronics.com or www.eiae.org
or www.recycle.philips.com.
•WheretheMAINSplugoranappliancecouplerisusedasthedisconnectdevice,the
disconnect device shall remain readily operable.
•Do not place this apparatus on the furniture that is capable of being tilted by a child and an
adultleaning,pulling,standingorclimbingonit.Afallingapparatuscancauseseriousinjuryor
even death.
• This apparatus should not be placed in a built-in installation such as a bookcase or rack unless
proper ventilation is provided. Make sure to leave a space of 7.8 inches (20cm) or more around
this apparatus.
Class II equipment symbol
This symbol indicates that the unit has a double insulation system.
This ‘bolt of lightning’ indicates uninsulated material within your unit may cause an
electrical shock. For the safety of everyone in your household, please do not remove
product covering.
The ‘exclamation point’ calls attention to features for which you should read the
enclosed literature closely to prevent operating and maintenance problems.
WARNING:Toreducetheriskofreorelectricshock,thisapparatusshouldnotbeexposedtorain
ormoistureandobjectslledwithliquids,suchasvases,shouldnotbeplacedonthisapparatus.
CAUTION: To prevent electric shock, match wide blade of plug to wide slot, fully insert.
Care for your product
Useonlymicroberclothtocleantheproduct.
Care of the environment
Your product is designed and manufactured with high quality materials and components,
which can be recycled and reused. Please visit www.recycle.philips.com for additional
information on a recycling center in your area.
Neverdisposeofyourproductwithotherhouseholdwaste.Pleaseinformyourselfaboutthelocal
rules on the separate collection of electrical and electronic products and batteries. The correct
disposal of these products helps prevent potentially negative consequences on the environment and
human health.
Thebatteriessupplieddonotcontaintheheavymetalsmercuryandcadmium.Nevertheless,inmany
areas batteries may not be disposed of with your household waste. Please ensure you dispose of
batteries according to local regulations.
For perchlorate material, special handling may apply. Visit www.dtsc.ca.gov/hazardouswaste/perchlorate.
Notice of compliance
ThedevicecomplieswiththeFCCrules,Part15.Operationissubjecttothefollowingtwoconditions:
a This device may not cause harmful interference, and
b This device must accept any interference received, including interference that may cause
undesired operation.
FCC rules
ThisequipmenthasbeentestedandfoundtocomplywiththelimitsforaClassBdigitaldevice,
pursuanttopart15oftheFCCRules.Theselimitsaredesignedtoprovidereasonableprotection
against harmful interference in a residential installation. This equipment generates, uses and can radiate
radio frequency energy and, if not installed and used in accordance with the instruction manual, may
cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television reception, which can be determined
by turning the equipment off and on, the user is encouraged to try to correct the interference by one
or more of the following measures:
• Relocate the receiving antenna.
• Increase the separation between equipment and receiver.
• Connecttheequipmentintoanoutletonacircuitdifferentfromthattowhichthereceiveris
connected.
• Consultthedealeroranexperiencedradio/TVtechnicianforhelp.
FCC Radiation Exposure Statement:ThisequipmentcomplieswithFCCradiationexposurelimits
set forth for an uncontrolled environment. This equipment should be installed and operated with a
minimum distance of 20cm between the radiator and your body. This transmitter must not be co-
located or operated in conjunction with any other antenna or transmitter.
Warning:Anychangesormodicationsmadetothisdevicethatarenotexpresslyapprovedby
WOOXInnovationsmayvoidtheuser’sauthoritytooperatetheequipment.
Modelnumber: HTL2161B/F7
TradeName:Philips
ResponsibleParty:P&FUSA,Inc.POBox2248Alpharetta,GA30023-2248;1-866-310-0744
Canada:
CANICES(B)/NMB-3(B)
ThisdevicecomplieswithIndustryCanadalicence-exemptRSSstandard(s).Operationissubjectto
thefollowingTwoconditions:(1)thisdevicemaynotcauseharmfulinterference,and(2)thisdevice
must accept any interference received, including interference that may cause undesired operation.
Español
Importante
Lea y asegúrese de comprender todas las instrucciones antes de usar el producto. La garantía no
cubre los daños producidos por no haber seguido las instrucciones.
Ayuda y asistencia técnica
Para obtener una amplia asistencia en línea, visite www.philips.com/support para:
• descargar el manual de usuario y la guía de inicio rápido
• ver tutoriales de video (solo disponible para modelos seleccionados)
• buscarrespuestasapreguntasfrecuentes(FAQ)
• enviarnos un correo electrónico con una pregunta
• chatear con nuestro representante de soporte.
Sigalasinstruccionesdelsitiowebparaseleccionarsuidiomaeingreseelnúmerodemodelodesu
producto.
Tambiénpuedeponerseencontactoconelserviciodeatenciónalclientedesupaís.Antes
de ponerse en contacto, anote el modelo y número de serie del producto. Puede buscar esta
información en la parte posterior o inferior del producto.
Instrucciones de seguridad importantes
•Lea estas instrucciones.
•Conserve estas instrucciones.
•Preste atención a todas las advertencias.
•Siga todas las instrucciones.
•No utilice este aparato cerca del agua.
•Utilice únicamente un paño seco para la limpieza.
•No bloquee las aperturas de ventilación. Realice la instalación de acuerdo con las
indicaciones del fabricante.
•No realice la instalación cerca de fuentes de calor como radiadores, rejillas de calefacción,
estufasuotrosequiposqueproduzcancalor(inclusoamplicadores).
•Utilice el conector polarizado o con conexión a tierra de conformidad con
las normas de seguridad. Un enchufe polarizado cuenta con dos álabes,
uno más ancho que el otro. Los conectores a tierra tienen dos conductores y una tercera
terminal de contacto para la conexión a tierra. El conductor ancho o la tercera terminal de
contactoconconexiónatierraseproveenparamayorseguridad.Sielenchufesuministradono
encaja correctamente en el tomacorriente, consulte a un electricista para reemplazar la toma.
•Proteja el cable de alimentación. Evite pisar o doblar el cable, en particular a la altura del
conector y las terminales de contacto del aparato.
•Utilice sólo los accesoriosqueespecicaelfabricante.
•Utilice sólo el carrito, el soporte, el trípode y la mesa que indica el fabricante y
los que incluye el equipo. Tenga cuidado cuando transporte el equipo en el carrito
para evitar caídas y posibles lesiones.
•Desenchufe el equipo durante tormentas eléctricas o cuando no se utilice por un
período prolongado.
•Todos los trabajos de servicio técnico deben ser realizados por personal de servicio
calicado.Soliciteelserviciodeasistenciatécnicacuando,porejemplo,elcabledealimentación
o el conector están dañados, si se derramó líquido o cayeron objetos dentro del aparato, si el
equipo estuvo expuesto a la lluvia o humedad, si no funciona normalmente o si se cayó.
•PRECAUCIÓN: para evitar que las baterías se sulfaten y puedan ocasionar lesiones, daños
materiales o en la unidad:
• Instale todas las baterías de forma correcta, de acuerdo con los signos + y - marcados en
la unidad.
• Noutilicebateríasdedistintasclases(nuevas y usadas o de carbono y alcalinas, etc.).
• Extraiga las pilas cuando no utilice la unidad durante un período prolongado.
• Noexpongalasbateríasatemperaturasaltascomolasqueemitenlaluzsolar,elfuegou
otros elementos similares.
• Este producto contiene perclorato y puede requerir un método de manipulación especial.
Visite www.dtsc.ca.gov/hazardouswaste/perchlorate.
• El producto/control remoto puede contener una batería tipo botón o moneda fácil de tragar.
Siempremantengalasbateríaslejosdelalcancedelosniños.Encasodeingestiónlabatería
podría causar lesiones graves o la muerte. Puede haber quemaduras internas graves en un plazo
de dos horas tras la ingestión.
• Sisospechaqueunabateríasehaingeridoointroducidoencualquierpartedelcuerpo,
consulte inmediatamente a un médico.
• Alcambiarlasbaterías,mantengasiemprelasbateríasnuevasyusadaslejosdelalcancedelosniños.
Veriquequeelcompartimientodelabateríaestébiencerradoluegodereemplazarlabatería.
• Sielcompartimientodelabateríanopuedecerrarse,discontinúeelusodelproducto.
Manténgalo lejos del alcance de los niños y comuníquese con el fabricante.
•No exponga el equipo a goteos ni salpicaduras.
•No coloque el aparato cerca de fuentes de peligro (por ejemplo, objetos que contengan
líquidos o velas encendidas).
•Esteaparatopuedecontenerplomoymercurio.Cumplaconlanormativalocal,estatalo
nacionalsobreeliminacióndeproductos.Comuníqueseconlasautoridadeslocalesparasolicitar
información sobre la eliminación o el reciclaje de productos. Para obtener más información
sobre las opciones de reciclaje disponibles, ingrese en cualquiera de los siguientes sitios web:
www.mygreenelectronics.com, www.eiae.org, www.recycle.philips.com.
•Sielconectordealimentaciónuotroconectorseutilizancomodispositivosdedesconexión,
deben estar accesible y fáciles de operar.
•Nocoloqueesteaparatosobremueblesqueadultosoniñospuedantirar,inclinaroutilizarpara
subirsesobreellos.Sielaparatosecae,puedecausarheridasgravesoinclusolamuerte.
• Este aparato no debe ubicarse en una instalación cerrada como una estantería o un rack, a
menosqueestéadecuadamenteventilada.Veriquequehayaunespaciomínimode20cm
(7,8 pulg) alrededor del aparato.
Símbolo de equipo de Clase II
Este símbolo indica que la unidad tiene un sistema de doble aislamiento.
Conozca estos símbolos de seguridad
El símbolo del rayo indica que los componentes sin aislamiento dentro de la unidad
pueden generar descargas eléctricas. Para la seguridad de todas las personas de su
hogar, no retire la cubierta del producto.
El signo de exclamación indica las características del producto que pueden provocar
problemas de funcionamiento y mantenimiento. Por eso, se recomienda leer el manual
de instrucciones.
ADVERTENCIA: Para reducir el riesgo de incendios o descargas eléctricas, no exponga el aparato a la
lluvia ni a la humedad, ni coloque sobre él objetos que contengan líquidos (por ejemplo, jarrones).
PRECAUCIÓN: Para evitar descargas eléctricas, el conductor ancho debe introducirse por completo
en la ranura adecuada.
Protección del producto
Utiliceúnicamenteunpañodemicrobraparalimpiarelproducto.
Cuidado del medio ambiente
Este producto ha sido diseñado y fabricado con materiales y componentes de alta calidad
que pueden reciclarse y reutilizarse. Visite www.recycle.philips.com para obtener más
información sobre los centros de reciclaje de su zona.
Nuncadesecheelproductoconelrestodelabasuradoméstica.Infórmesesobrelasnormaslocales
sobre la recolección selectiva de baterías y productos eléctricos y electrónicos. La eliminación
correcta de este tipo de productos ayuda a evitar consecuencias potencialmente negativas para el
medio ambiente y la salud humana.
Lasbateríassuministradasnocontienenlosmaterialespesadosmercurioycadmio.Sinembargo,
enmuchasáreasnosepuedeneliminarbateríasjuntoconlosdesechosdomésticos.Asegúresede
eliminar las baterías según las normativas locales.
Este producto contiene perclorato y puede requerir un método de manipulación especial. Visite www.
dtsc.ca.gov/hazardouswaste/perchlorate.
Aviso de cumplimiento
EldispositivocumpleconlosreglamentosdelaFCC,apartado15.Elfuncionamientoestásujetoalas
siguientes condiciones:
a El dispositivo no debe causar interferencias nocivas y
b debe recibir todo tipo de interferencias, incluso las que originan un funcionamiento
indeseado.
Normas de la Comisión Federal de Comunicaciones (FCC)
Este equipo se ha probado y se ha determinado que cumple con los límites para un dispositivo digital
claseB,deacuerdoconelapartado15delasnormativasdelaFCC.Estoslímitesestándestinadosa
ofrecer una protección razonable contra interferencias dañinas dentro de una instalación residencial.
Esteequipogenera,utilizaypuedeemitirenergíaderadiofrecuencia.Sinoseinstalayutilizade
conformidad con el manual de instrucciones, puede ocasionar interferencias perjudiciales en las
comunicaciones de radio.
Sinembargo,noexistegarantíadequenoseproduciráinterferenciaenunainstalaciónenparticular.
Siesteequipoprovocainterferenciasperjudicialesenlarecepciónderadiootelevisión,loque
puede determinarse al encender y apagar el equipo, se recomienda al usuario intentar corregir la
interferencia mediante una o varias de las siguientes medidas:
• Cambielaposicióndelaantenareceptora.
• Aumenteladistanciaentreelequipoyelreceptor.
• Conecteelequipoauntomacorrientedeuncircuitodiferentealqueestáconectadoel
receptor.
• Para obtener ayuda, comuníquese con el distribuidor o con un técnico de radio o televisión
calicado.
Normas sobre la exposición a campos de radiación de la FCC: este equipo cumple con la normativa
queregulaloslímitesdeexposiciónalaradiacióndeFCCparaambientesnocontrolados.Este
equipo debe instalarse y utilizarse con una distancia mínima de 20 cm entre el radiador y el cuerpo.
Nocoloqueesteaparatocercadeotrostransmisoresoantenas,niloutiliceconestetipode
dispositivos.
Advertencia:Cualquieralteraciónomodicaciónaestedispositivo,quenocuenteconlaautorización
expresadeWOOXInnovations,puedeanularelderechodelusuarioparautilizarelequipo.
Númerodemodelo: HTL2161B/F7
Nombrecomercial:Philips
Parteresponsable:P&FUSA,Inc.POBox2248Alpharetta,GA30023-2248;1-866-310-0744
Canadá:
CANICES(B)/NMB-3(B)
EstedispositivocumpleconlosestándaresRSSexentosdelicenciadeIndustryCanada.El
funcionamientoquedasujetoalassiguientescondiciones:(1)estedispositivonodebeproducir
interferencias dañinas, y (2) debe soportar cualquier interferencia, incluso aquéllas que pueden causar
un funcionamiento no deseado.
Français
1 Important
Lisezattentivementtouteslesinstructionsavantd’utiliserletéléviseur.Sidesdommagessontcausés
par le non-respect des instructions, la garantie ne sera pas applicable.
Aide et soutien
Pour un service complet à la clientèle en ligne, visitez le site www.philips.com/support pour effectuer
les opérations suivantes :
• télécharger le manuel d’utilisation et le guide de démarrage rapide
• regarder des didacticiels vidéo (pour certains modèles seulement)
• trouverdesréponsesauxquestionslesplusfréquentes(FAQ)
• nous envoyer une question par courriel
• clavarder avec un de nos représentants du service à la clientèle
SuivezlesinstructionssurlesiteWebpoursélectionnervotrelangue,ensuiteentrezlenumérode
modèle de votre produit.
Vouspouvezégalementcommuniqueravecleserviceàlaclientèledansvotrepays.Notezauparavant
le numéro de modèle et le numéro de série de votre produit. Vous pouvez trouver cette information
à l’arrière de votre appareil.
Consignes de sécurité importantes
•Lisez ces instructions.
•Conservez ces instructions.
•Tenez compte de tous les avertissements.
•Suivez toutes les instructions.
•N’utilisez pas cet appareil près de l’eau.
•Nettoyez l’appareil avec un chiffon sec seulement.
•N’obstruez aucune prise de ventilation. Installez l’appareil en conformité avec les instructions
du fabricant.
•N’installez pas l’appareil près d’une source de chaleur comme un radiateur, un registre de
chaleurouunautreappareil(incluantlesamplicateurs)quiproduitdelachaleur.
•Ne passez pas outre les instructions de sécuritéconcernantlache
polariséeoulachedemiseàlaterre.Unechepolariséeestcomposée
dedeuxbrochesdontl’uneestpluslargequel’autre.Unechedemise
à la terre est composée de deux broches et d’une broche de masse. La
brochepluslargeetlabrochedemassevisentàassurervotresécurité.Silachefourniene
peut être insérée dans la prise, consultez un électricien pour qu’il remplace votre prise désuète.
•Protégez le cordon d’alimentationdefaçonàcequ’ilnepuissepasêtreécraséoupincé;
vériezparticulièrementlesches,lesprisesetlasortieduldansl’appareil.
•Utilisez seulement les accessoiresspéciésparlefabricant.
•Utilisez seulement le chariot,lesupport,letrépiedoulatablespéciéspar
lefabricantouvenduavecl’appareil.Sivousutilisezunchariot,faitesattention
lorsquevousledéplacezand’éviterdevousblesserencasderenversementde
l’appareil.
•Débranchez cet appareil pendant les orages avec éclairs ou s’il n’est pas utilisé
pendant de longues périodes.
•Toute réparationdoitêtrefaiteparuntechnicienqualié.Uneréparationestnécessairequand
l’appareilaétéendommagé,parexemple,quandlecordonoulached’alimentationontété
endommagés, quand un objet a été introduit dans l’appareil ou quand l’appareil a été mouillé,
exposé à la pluie ou à l’humidité, qu’il ne fonctionne pas correctement ou qu’il a été échappé.
HTL2161B_F7_Safety_V1.0.indd 1 1/8/2014 5:46:25 PM
•AVERTISSEMENT relatif à l’utilisation de piles–And’éviterunefuitedespilespouvant
entraîner des blessures ou des dommages matériels :
• Installez toutes les piles correctement en alignant les pôles + et - tel qu’indiqué sur
l’appareil.
• Necombinezpasdespilesdifférentes(neuves et usagées, au carbone et alcalines, etc.).
• Retirez les piles lorsque l’appareil n’est pas utilisé pendant une longue période.
• Les piles intégrées ne doivent pas être exposées à une chaleur excessive, comme les
rayons du soleil ou le feu.
• Produits contenant du perchlorate : une manipulation particulière peut être requise.
Consulterwww.dtsc.ca.gov/hazardouswaste/perchlorate.
• L’appareil ou sa télécommande peuvent contenir une pile bouton qu’un enfant pourrait avaler.
Gardezcetypedepilehorsdeportéedesenfantsàtoutmoment!Encasd’ingestion,lapile
peut provoquer des blessures sérieuses voire la mort. De graves brûlures internes peuvent
survenir dans les deux heures suivant l’ingestion.
• Sivouscroyezqu’unepileaétéingéréeouintroduitedanslecorpsdequelqu’un,consultez
immédiatement votre médecin.
• Lorsque vous changez les piles, assurez-vous que les piles neuves et usagées sont hors
de portée des enfants. Une fois le changement de pile effectué, assurez-vous que son
compartiment est bien fermé et sécurisé.
• Sivousneparvenezpasàsécuriserlecompartimentdelapile,cessezd’utiliserl’appareil.
Gardezl’appareilhorsdeportéedesenfantsetcommuniquezaveclefabricant.
•N’exposez pas l’appareil aux éclaboussures, ni aux déversements.
•Ne placez aucune source de danger sur l’appareil (par exemple des objets remplis de liquide
ou des bougies allumées).
•Cetappareilpeutcontenirduplombetdumercure.Mettezl’appareilaurebutconformément
aux lois municipales, provinciales ou fédérales. Pour en savoir plus sur la mise au rebut ou sur le
recyclage, veuillez communiquer avec les autorités locales. Pour de plus amples renseignements
sur les diverses possibilités de recyclage, visitez les sites www.mygreenelectronics.com, www.
eiae.org ou www.recycle.philips.com.
•Silached’alimentationouuncoupleurd’appareilestutilisécommedispositifdedécouplage,
celui-ci doit rester facilement accessible.
•Neplacezpascetappareilsurunmeublequ’unenfantpourraitfairebasculerouqu’unadulte
pourrait renverser involontairement en s’appuyant ou en grimpant dessus ou encore en le
tirant. La chute d’un appareil peut provoquer des blessures graves, voire la mort.
• Cetappareilnedoitpasêtreplacédansunmeubleencastrécommeunebibliothèqueouune
étagère,àmoinsquel’emplacementoffreuneventilationsufsante.Veillezàgarderunespace
dégagé d’au moins 20 cm (7,8») autour de cet appareil.
Symbole d’équipement de classe II
Cesymbolesigniequel’appareilsurlequelilestapposéestdotéd’unedoubleisolation.
Sachez reconnaître ces symboles de sécurité
Cesymbole«d’éclair»signaledesmatériauxnonisolésprésentsdansvotreappareil
et pouvant causer un choc électrique. Pour assurer la sécurité des membres de votre
famille, veuillez ne pas enlever le couvercle du produit.
Les«pointsd’exclamation»ontpourbutd’attirervotreattentionsurdes
caractéristiques à propos desquelles vous devez lire attentivement la documentation
accompagnantl’appareiland’évitertoutproblèmedefonctionnementetd’entretien.
AVERTISSEMENT :anderéduirelesrisquesd’incendieoudechocélectrique,n’exposezpascet
appareilàlapluieouàl’humidité.Neposezpasdessusd’objetsremplisdeliquides,telsquedesvases.
ATTENTION :pouréviterleschocsélectriques,introduisezlabrochelapluslargedelachedansla
borne correspondante de la prise et poussez à fond.
Précautions d’utilisation de votre appareil
Utilisezseulementunchiffonenmicrobrepournettoyerl’appareil.
Respect de l’environnement
Votre produit a été conçu et fabriqué avec des matériaux et des composants de grande
qualité, qui peuvent être recyclés et réutilisés. Visitez le site www.recycle.philips.com pour
savoir comment trouver un centre de recyclage dans votre région.
Nejetezpasceproduitaveclesautresorduresménagères.Renseignez-voussurlesrèglesrégissantla
collecte locale des produits électriques et électroniques et des piles. La mise au rebut adéquate de ces
produits contribue à réduire le risque de conséquences négatives pour l’environnement et la santé
humaine.
Les piles fournies ne contiennent pas de métaux lourds comme le mercure et le cadmium.
Néanmoins,dansungrandnombredelocalités,ilestinterditdemettrelespilesaurebutavecles
déchets ménagers. Veuillez vous assurer de mettre les piles au rebut selon les règlements locaux.
Pour les produits contenant du perchlorate, une manipulation particulière peut être requise. Visitez le
site www.dtsc.ca.gov/hazardouswaste/perchlorate.
Avis de conformité
CedispositifestconformeauxrèglementsdelaFCC,partie15.Lefonctionnementestassujettiaux
deux conditions suivantes :
a Cet appareil ne doit pas causer d’interférence préjudiciable et
b l’appareil doit accepter toute interférence reçue, y compris les interférences qui peuvent
causer un fonctionnement non désiré.
Règlement de la FCC
Cetéquipementaététestéetjugécompatibleavecleslimitess’appliquantauxappareilsnumériques
delaclasseB,conformémentàl’article15durèglementdelaFCC.Ceslimitesontétédéniespour
fournir une protection raisonnable contre les interférences nuisibles dans le cadre d’une installation
résidentielle.Cetéquipementgénère,utiliseetpeutémettredel’énergieradiofréquenceet,s’iln’est
pas installé ni utilisé conformément aux instructions, peut causer des interférences gênantes pour les
communications radio.
Rien ne garantit toutefois que des interférences ne surviendront pas dans une installation particulière.
Sicetéquipementcausedesinterférencesnuisiblespourlaréceptiondelaradiooudelatélévision,
ce qui peut être déterminé en mettant l’équipement hors tension puis sous tension, l’utilisateur devra
essayer de corriger ces interférences en effectuant une ou plusieurs des opérations suivantes :
• Déplacez l’antenne de réception.
• Augmentezladistanceentrel’équipementetlerécepteur.
• Branchezl’équipementàuneprised’uncircuitautrequeceluisurlequellerécepteurest
branché.
• Consultezledétaillantouuntechnicienderadiotélévisionexpérimenté.
Énoncé de la FCC sur l’exposition aux rayonnements radioélectriques : cet appareil est conforme
auxlimitesd’expositionauxrayonnementsradioélectriquesdelaFCCpourunenvironnement
noncontrôlé.Cetappareildoitêtreinstalléetutiliséenconservantunedistanceminimalede
20centimètresentreleradiateuretvotrecorps.Cetémetteurnedoitpasêtreinstalléaumême
endroit qu’une autre antenne ou un autre émetteur, ni utilisé avec un tel dispositif.
Avertissement : Toutchangementoutoutemodicationapportéàcetappareilsansl’autorisation
expressedeWOOXInnovationspeutannulerledroitdel’utilisateuràutiliserl’équipement.
Numérodemodèle: HTL2161B/F7
Marque : Philips
Partieresponsable:P&FUSA,Inc.POBox2248Alpharetta,GA30023-2248;1-866-310-0744
Canada :
CANICES(B)/NMB-3(B)
CetappareilestconformeauxnormesRSSsanslicenced’IndustrieCanada.Sonfonctionnement
estassujettiauxdeuxconditionssuivantes:(1)l’appareilnedoitpascauserd’interférencesnuisibles;
(2) l’appareil doit accepter toute interférence reçue, y compris les interférences qui peuvent causer un
fonctionnement non désiré.
Specifications are subject to change without notice
2014 © WOOX Innovations Limited. All rights reserved.
This product was brought to the market by WOOX Innovations Limited or one
of its affiliates, further referred to in this document as WOOX Innovations, and is
the manufacturer of the product. P&F is the warrantor in relation to the product
with which this booklet was packaged. Philips and the Philips Shield Emblem are
registered trademarks of Koninklijke Philips N.V.
HTL2161B_F7_Safety_V1.0
P&F USA Inc. PO Box 2248 Alpharetta, GA 30023-2248
ONE (1) YEAR LIMITED WARRANTY
WARRANTY COVERAGE:
This warranty obligation is limited to the terms set forth
below.
WHO IS COVERED:
This product is warranted to the original purchaser or the per-
son receiving the product as a gift against defects in materials and
workmanship as based on the date of original purchase
(“Warranty Period”) from an Authorized Dealer. The original
sales receipt showing the product name and the purchase date
from an authorized retailer is considered such proof.
WHAT IS COVERED:
This warranty covers new products if a defect in material
or workmanship occurs and a valid claim is received within
the Warranty Period. At its option, the company will either (1)
repair the product at no charge, using new or refurbished
replacement parts, or (2) exchange the product with a product
that is new or which has been manufactured from new, or ser-
viceable used parts and is at least functionally equivalent or most
comparable to the original product in current inventory,
or (3) refund the original purchase price of the product.
The company warrants replacement products or parts provided
under this warranty against defects in materials and workmanship
from the date of the replacement or repair for ninety (90) days
or for the remaining portion of the original product’s warranty,
whichever provides longer coverage for you. When a product or
part is exchanged, any replacement item becomes your property
and the replaced item becomes the company property. When a
refund is given, your product becomes the company property.
Note: Any product sold and identified as refurbished or
renewed carries a ninety (90) day limited warranty.
Replacement product can only be sent if all warranty
requirements are met. Failure to follow all requirements
can result in delay.
WHAT IS NOT COVERED - EXCLUSIONS AND LIMI-
TATIONS:
This Limited Warranty applies only to the new products that
can be identified by the trademark, trade name, or logo affixed
to it. This Limited Warranty does not apply to any non-Philips
hardware product or any software, even if packaged or sold
with the product. Non-Philips manufacturers, suppliers, or
publishers may provide a separate warranty for their own
products packaged with the bundled product.
The company is not liable for any damage to or loss of any ,
programs data, or other information stored on any media
contained within the product, or any non-Philips product or part
not covered by this warranty. Recovery or reinstallation of
programs, data or other information is not covered under this
Limited Warranty.
This warranty does not apply (a) to damage caused by accident,
abuse, misuse, neglect, misapplication, or non-Philips product, (b)
to damage caused by service performed by anyone other than
an Authorized Service Location, (c) to a product or
a part that has been modified without written permission,
or (d) if any serial number has been removed or defaced,
or (e) product, accessories or consumables sold “AS IS”
without warranty of any kind by including refurbished Philips
product sold “AS IS” by some retailers.
This Limited Warranty does not cover:
•Shipping charges to return defective product.
•Labor charges for installation or setup of the product, adjust-
ment of customer controls on the product, and installation or
repair of antenna/signal source systems outside of the product.
•Product repair and/or part replacement because of improper
installation or maintenance, connections to improper voltage
supply, power line surge, lightning damage, retained images or
screen markings resulting from viewing fixed stationary con-
tent for extended periods, product cosmetic appearance items
due to normal wear and tear, unauthorized repair or other
cause not within the control of the company.
•Damage or claims for products not being available for use, or
for lost data or lost software.
•Damage from mishandled shipments or transit accidents when
returning product.
•A product that requires modification or adaptation to enable
it to operate in any country other than the country for which
it was designed, manufactured, approved and/or authorized, or
repair of products damaged by these modifications.
•A product used for commercial or institutional purposes
(including but not limited to rental purposes).
•Product lost in shipment and no signature verification receipt
can be provided.
•Failure to operate per Owner’s Manual.
TO OBTAIN ASSISTANCE IN THE U.S.A., CANADA,
PUERTO RICO, OR U.S. VIRGIN ISLANDS…
Contact Customer Care Center at:
1-866-310-0744
REPAIR OR REPLACEMENT AS PROVIDED UNDER THIS
WARRANTY IS THE EXCLUSIVE REMEDY FOR THE CON-
SUMER. PHILIPS SHALL NOT BE LIABLE FOR ANY INCIDEN-
TAL OR CONSEQUENTIAL DAMAGES FOR BREACH OF
ANY EXPRESS OR IMPLIED WARRANTY ON THIS PROD-
UCT. EXCEPT TO THE EXTENT PROHIBITED BY APPLICABLE
LAW, ANY IMPLIED WARRANTY OF MERCHANTABILITY OR
FITNESS FOR A PARTICULAR PURPOSE ON THIS PRODUCT
IS LIMITED IN DURATION TO THE DURATION OF THIS
WARRANTY.
Some states do not allow the exclusions or limitation of inciden-
tal or consequential damages, or allow limitations on how long an
implied warranty lasts, so the above limitations or exclusions may
not apply to you.
This warranty gives you specific legal rights. You may have other rights which vary from state/province to state/province.
P&F USA Inc. PO Box 2248 Alpharetta, GA 30023-2248
GARANTÍA LIMITADA DE UN (1) AÑO
COBERTURA DE GARANTÍA:
La obligación de esta garantía se limita a los términos establecidos a
continuación.
QUIÉNES ESTÁN CUBIERTOS:
Este producto está garantizado al comprador original o a lapersonaque lo
recibe como regalo contra defectos en los materiales y en la mano de
obra, a partir de la fecha de la compra original ("períododegarantía")en el
distribuidor autorizado.El recibo de ventas,donde aparecen el nombre del
producto y la fecha de la compra en un distribuidor autorizado, se
considerará comprobante de esta fecha.
LOQUEESTÁCUBIERTO:
Esta garantía cubre productos nuevos si se produce algún defecto enel
material o la mano de obra y se recibe un reclamo válido dentrodel
período de garantía. A su propia discreción, la compañía dentrodel
período de garantía. A su propia discreción, la compañía nuevas o
reacondicionadas;(2)cambiará el producto por uno nuevo o que se ha
fabricado con piezas nuevas o usadas utilizables, y que sea al menos
funcionalmente equivalente o lo más parecido al producto original del
inventario actual; o (3) reembolsará el precio de compra original del
producto. La compañía garantiza productos o piezas de repuesto
proporcionados bajo esta garantía contra defectos en los materiales y en
la mano de obra durante noventa (90) días o por el resto de la garantía
del producto original, lo que le promocione más cobertura. Cuando se
cambia un producto o una pieza, el artículo que usted recibe pasa a ser
de su propiedad y el que se le entrega pasa a ser propiedad de la
compañía.Cuando se proporcione un reembolso, su producto pasa a ser
propiedad la compañía.
Nota: Cualquier producto que se venda y que esté identi
como reacondicionado o renovado tiene una garantía limitada
de noventa (90) días.
El producto de reemplazo sólo se puede enviar si se cumplen
todos los requisitos de la garantía. El incumplimiento de tales
requisitos puede ocasionar un retardo.
LO QUE NO SE CUBRE: EXCLUSIONESYLIMITACIONES:
Esta garantía limitada se aplica sólo a los productos nuevos que se pueden
identificar por la marca registrada, el nombre comercial o por tener el
logotipo correspondiente. Esta garantía limitada no se aplica a ningún
producto de hardware ni de software que no sea Philips, incluso si viene
empacado con el producto o si se vende junto con éste. Los fabricantes,
proveedores o editores que no sean Philips pueden proporcionar una
garantía por separado para sus propios productos empacados con el
producto Philips.
La compañía no es responsable por ningún daño o pérdida de programas,
datos u otra información almacenados en algún medio contenido en el
producto, ni por ningún producto o pieza que no sea Philips que no esté
cubierta por esta garantía. La recuperación o la reinstalación de
programas, datos u otra información no está cubierta por esta garantía
limitada.
Esta garantía no se aplica (a) a daños causados por accidente, abuso, mal
uso, negligencia, mala aplicación o a productos que no sean Philips;
(b) a daño provocado por servicio realizado por
Esta garant
í
a le otorga derechos legales espec
í
ficos. Usted puede tener otros derechos que var
í
an entre los diferentes estados y provincias.
cualquier persona distinta de un establecimiento de servicio autorizado;
(c) a productos o piezas que se hayan modificado sin la authorización por
escrito; (d) si se ha retirado o desfigurado cualquier número de serie; y
tampoco se aplica la garantía a (e)productos, accesorios o insumos
vendidos TAL COMO ESTÁN sin garantía de ningún tipo, lo que incluye
productos Philips vendidos TAL COMO ESTÁN por algunos
distribuidores.
Esta garantía limitada no cubre:
• Los costos de envío al devolver el producto defectuoso.
• Los costos de mano de obra por la instalacion o configuración del
producto, el ajuste de controles del cliente en el producto y la
instalaciónoreparación de sistemas de antena o fuente de señal
externos al producto.
• La reparación del producto o el reemplazo de piezas debido a
instalación o mantenimiento inadecuada, a conexiones hechas a un
suministro de voltaje inadecuado, sobrevoltaje de la línea de
alimentación, daño causado por relámpagos, imágenes retenidas o
marcas en la pantalla producto de la visualización de contenido fijo
durante periodos prolongados, reparaciones cosméticas debido al
desgaste normal, reparaciones no autorizadas u otras causas que no
se encuentren bajo el control de la compañía.
• Daños o reclamos por productos que no están disponibles para su
uso, por datos perdidos o por pérdida de software.
• Daños debidoamala manipulación en el transporte o accidentes de
envío al devolver el producto.
• Un producto que requiera modificacion o adaptacion para permitir su
funcionamiento en algún país que no sea el país para el que se diseñó,
fabricó, aprobó y/o autorizó o la reparación de productos dañados
por estas modificaciones.
• Un producto que se use para propósitos comerciales oinstitucionales
(lo que incluye, entre otros, los de alquiler).
• La pérdida del producto en el envío y cuando no se pueda
proporcionar una firma que verifique el recibo.
• No operar según el Manual del propietario.
PARA OBTENER AYUDA EN LOS EE.UU., EN CANADÁ,
PUERTO RICO O EN LAS ISLAS VIRGENES DE LOS EE.UU...
Comuníquese con el Centro de Atención al Cliente al:
1-866-310-0744
LA REPARACIÓN O EL REEMPLAZO, SEGÚN LO DISPONE
ESTA GARANTÍA, ES LA SOLUCIÓN EXCLUSIVA PARA EL
CLIENTE. PHILIPS NO SERÁ RESPONSABLE DE LOS DAÑOS
INCIDENTALES O INDIRECTOS QUE INFRINJAN ALGUNA
GARANTÍA EXPRESAOIMPLÍCITA SOBRE ESTE PRODUCTO.
CON EXCEPCIÓN DE LO QUE PROHÍBA LA LEY VIGENTE,
TODA GARANTÍA IMPLÍCITA DE COMERCIABILIDAD Y
ADECUACIÓN PARA UN PROPÓSITO PARTICULAR EN ESTE
PRODUCTO ESTÁ LIMITADA EN DURACIÓN A LO QUE
ESPECIFIQUE ESTA GARANTÍA.
Algunos estados no permiten las exclusiones ni la limitación de
los daños incidentales o indirectos, ni permiten limitaciones sobre
la duración de la garantía implícita, de modo que las limitaciones
o exclusiones anteriores pueden no aplicarse a usted.
P&F USA Inc. PO Box 2248 Alpharetta, GA 30023-2248
OGARANTIE LIMITÉE DE UN (1) AN
COUVERTURE DE GARANTIE:
Cette provision pour garantie est limitée aux conditions établies
ci-dessous.
QUI EST COUVERT?
La garantie du présent produit couvre l’acheteur original ou toute
personne recevant le produit en cadeau contre tout défaut de matière ou
de main d’œuvre conformément à la date originale d’achat (« Période de
garantie ») auprès d’un distributeur agréé. Le reçu de vente original
indiquant le nom du produit ainsi que la date d’achat d’un détaillant
agréé est considéré comme une preuve d’achat.
QU'EST-CE QUI EST COUVERT?
Cette garantie couvre les nouveaux produits dans le cas où un défaut
de matière ou de main d’ uvre se présenterait et une réclamation valide
était présentée dans la période de garantie.La société pourra, à sa seule
discrétion: (1)réparer le produit gratuitement avecdes pièces de rechange
neuves ou remises à neuf; ou (2) échanger le produit pour un produit
neuf ou ayant été fabriqué à partir de pièces neuvesouusagées en bon
état et au moins fonctionnellement équivalent ou comparable au produit
d’origine actuellement en inventaire; ou (3) rembourser le prix d’achat
initial du produit. La société garantit les produits ou pièces de
remplacement prévus sous cette garantie contre tout défaut de matière
ou de mai d’œuvre à n partir de la date de remplacement ou de
réparation, pour une période de quatre-vingt-dix (90) jours ou pour la
portion restante de la garantie du produit d’origine, la plus longue de ces
couvertures étant à retenir. Lorsqu’un produit ou une pièceest échangé,
tout article de rechanged evient votre propriété et l’article remplacé
devient la propriété de la société. Lorsqu’un remboursement est effectué,
votre produit devient la propriété de la société.
Remarque : tout produit vendu et identifié comme étant remis
à neuf ou rénové porte une garantie limitée de quatre-vingt-dix
(90) jours.
Un produit de remplacement ne pourra être envoyé que si
toutes les exigences de la garantie ont été respectées. Tout
manquement de répondre à toutes les exigences pourra
entraîner un délai.
CE QUI N’EST PAS COUVERT - EXCLUSIONS ET
LIMITATIONS:
Cette garantie limitée ne s’applique qu’aux nouveaux produits pouvant
être identifiés par la marque de commerce, le nom commercial ou le logo
qui y sont apposés.Cette garantielimitée ne s’applique à aucun produit
matérielou logiciel non Philips,même si celui-ci est incorporé au produit ou
venduavec celui-ci.Les fabricants, fournisseurs ou éditeurs non-Philips
peuvent fournir une garantie séparée pour leurs propres produits intégrés
au produit fourni.
La société ne saurait être tenue pour responsable de tout dommage ou
perte de programmes, données ou autres informations mis en mémoire
dans tous les médias contenus dans le produit ou de tout produit ou pièce
non-Philips non couvert par cette garantie. La récupération ou réinstallation
des programmes, données ou autres informations n’est pas couverte par
cette garantie limitée. Cette garantie ne s’applique pas (a) aux dommages
causés par un accident, un abus, un mauvais usage une négligence, une
mauvaise application ou à un produit non-Philips, (b) aux dommages causés
par un service réalisé par quiconque autre qu’un centre de service agréé,
(c)à un produit ou pièce ayant été modifié sans permission écrite, ou
(d) si tout numéro de série a été supprimé ou défiguré, ou (e)àun
Cette garantie vous donne des droits légaux spécifiques. Il est possible que vous bénéficiiez de droits supplémentaires variant d'un État/Province à l'autre.
œ
produit, accessoire ou produit non durable vendu « TEL QUEL » sans
garantie de quelque description que ce soit par l’inclusion de produits
remisàneuf Philips vendu « TEL QUEL » par certains détaillants.
Cette garantie limitée ne couvre pas:
• les frais d’expédition pour le renvoi du produit défectueux.
• les frais de main-d’œuvre pour l’installation ou la configuration du
produit, le réglage des commandes sur le produit du client ainsi que
l’installation ou la réparation du système d’antenne/source sonor
externe au produit.
• la réparation du produit et/ou le remplacement des pièces àcause
d’une mauvaise installation ou d’un mauvais entretien, d’un raccorde-
ment à une alimentation électrique incorrecte, d’une surtension
temporaire, de dommages occasionnés par la foudre, d’une
rémanence de l’image ou de marques à l’écran résultant de l’affichage
d’un contenu stationnaire fixe pour une période de temps prolongée,
de l’aspect esthétique du produit causé par une usure normale, d’une
réparation non autorisée ou de toute autre cause non contrôlable par
la société.
• tout dommage ou réclamation pour des produits non disponibles
à l’utilisation ou pour des données perdues ou logiciel perdu.
• tout dommage causé par un mauvais acheminement du produit
ou par un accident encouru lors du renvoi du produit.
• un produit nécessitant une modification ou adaptation afin de
permettre l’utilisation dans tout pays autre que celui pour lequel il
était désigné, fabriqué, approuvé et/ou autorisé ou toute réparation
du produit endommagé par ces modifications.
• un produit utilisé à des fins commerciales ou institutionnelles (y
compris mais non de façon limitative les fins de location).
• un produit perdu lors de l’expédition sans preuve signée de la
réception.
• tout manquement d’exploiter le produit selon le manuel de
l’utilisateur.
POUR OBTENIR DE L’AIDE AUX ÉTATS-UNIS, AU
CANADA,
À PUERTO RICO OU AUX ÎLES VIERGES
AMÈRICAINES …
Communiquez avec le centre de service à la clientèle au:
1-866-310-0744
LA RÉPARATION OU LE REMPLACEMENT CONFORMÉMENT À
CETTE GARANTIE CONSTITUE LE SEUL REMÈDE POUR LE
CONSOMMATEUR. PHILIPS N’EST AUCUNEMENT RESPONSABLE
DE TOUT DOMMAGE ACCESSOIRE OU INDIRECT RÉSULTANT DE
LA VIOLATION DE TOUTE GARANTIE EXPRESSE OU IMPLICITE
SUR CE PRODUIT. SAUF DANS LAMESURE INTERDITE PAR LES
LOIS APPLICABLES, TOUTEGARANTIE IMPLICITE DE QUALITÉ
LOYALE ET MARCHANDEOU D’UTILITÉ PARTICULIÈRE DU
PRODUIT EST LIMITÉE DANSLE TEMPS À LA DURÉE DE CETTE
GARANTIE.
Certains états ne reconnaissent pas l’exclusion ou la limitation de la
responsabilité pour dommages indirects ou accessoires, ou autorisent
des limitations sur la durée d’une garantie implicite, il est donc possible
que les limitations ou exclusions mentionnées cidessus soient sans effet
dans votre cas.
HTL2161B_F7_Safety_V1.0.indd 2
Le dispositif rencontre l'exemption des limites courantes d'evaluation dans la section 2.5 de RSS 102 et la
conformite a l'exposition de RSS-102 rf, utilisateurs peut obtenir l'information canadienne sur l'exposition
et la conformite de rf.
Cet emetteur ne doit pas etre Co-place ou ne fonctionnant en meme temps qu'aucune autre antenne ou
emetteur. Cet equipement devrait etre installe et actionne avec une distance minimum de 20 centimetres
entre le radiateur et votre corps.

Navigation menu
