Gibson Innovations M2BT Bluetooth Headphones User Manual M2BT UM EN 20140609
Gibson Innovations Limited Bluetooth Headphones M2BT UM EN 20140609
User Manual
Always there to help you
Register your product and get support at
www.philips.com/welcome
M2BT
Question?
Contact
Philips
User manual
Contents
1
Important safety instructions
Hearing Safety
General information
2
2
2
2
Your wireless on-ear headset
What's in the box
Other devices
Over view of your wireless on-ear headset
3
3
3
4
3
Get started
Charge your headset
Pair the headset with your mobile phone
5
5
5
4
Use your headset
Connect the headset to a Bluetooth
device
Manage your calls and music
Wear your headset
Use with the audio cable
6
6
6
7
7
5
Technical data
8
6
Notice
Declaration of conformity
Disposal of your old product and batteries
Notice for the European Union
Trademarks
9
9
9
10
10
7
Frequently asked questions
12
EN
1
1 Important safety
instructions
Caution
•
•
•
•
•
Do not expose the headset to excessive heat.
Do not drop your headset.
Headset shall not be exposed to dripping or splashing.
Do not allow your headset to be submerged in water.
Do not use any cleaning agents containing alcohol,
ammonia, benzene, or abrasives.
If cleaning is required use a soft cloth, if necessary
• dampened with a minimum amount of water or diluted
mild soap, to clean the product.
The integrated battery shall not be exposed to
excessive heat such as sunshine, fire or the like.
Hearing Safety •
Danger
• To avoid hearing damage, limit the time you use the
headset at high volume and set the volume to a safe
level. The louder the volume, the shorter the safe
listening time is.
About operating and storage temperatures
and operating altitude
•Operate or store in a place where
temperature is between -15ºC (5ºF) and
55ºC (131ºF) (up to 90% relative humidity.
•Batter y life may be shorter in high or low
temperature conditions.
This Philips appliance complies with all
applicable standards and regulations regarding
exposure to electromagnetic fields.
Be sure to observe the following guidelines
when using your headset.
• Listen at reasonable volumes for
reasonable periods of time.
• Be careful not to adjust the volume
continuously upwards as your
hearing adapts.
• Do not turn up the volume so high that
you can’t hear what’s around you.
• You should use caution or temporarily
discontinue use in potentially hazardous
situations.
• Excessive sound pressure from earphones
and headset can cause hearing loss.
• Using the headset with both ears covered
while driving is not recommended and may
be illegal in some areas while driving.
• For your safety, avoid distractions from
music or phone calls while in traffic or
other potentially dangerous
environments.
General information
To avoid damage or malfunction:
2
EN
2 Your wireless
on-ear headset
Quick star t guide
Congratulations on your purchase, and
welcome to Philips! To fully benefit from the
suppor t that Philips offers, register your product
at www.philips.com/welcome.
With this Philips wireless on-ear headset, you
can:
• enjoy convenient wireless handsfree calls;
• enjoy and control wireless music;
• switch between calls and music;
• enjoy music on non-Bluetooth devices with
an audio cable.
Other devices
A mobile phone or device (e.g. notebook, PDA,
Bluetooth adapters, MP3 players etc) which
supports Bluetooth and is compatible to the
headset (see 'Technical data' on page 8).
Note
• You can find a list of compatible mobile phones/devices
at www.philips.com/support.
What's in the box
Philips Bluetooth wireless on-ear headset M2BT
USB charging cable（for charging only）
Audio cable
EN
3
Overview of your wireless
on-ear headset
f
e
d
c
b
a
a Audio cable jack
b Charging slot
c Microphone
d Volume/Track control button
e Call/Music button
f LED lights
4
EN
3 Get started 1
2
3
Make sure that the mobile phone is turned
on and its Bluetooth feature is activated.
Make sure that the headset is fully charged
and turned off.
Press and hold the call/music button for
10 seconds until the white and blue LED
flashes alternately.
» The headset remains in pairing mode
for 5 minutes.
Charge your headset
Note
• Before you use your headset for the first time, charge
the batter y for 4 hours for optimum batter y capacity
and lifetime.
• Use only the original USB charging cable to avoid any
damage.
Finish your call before charging the headset, as
• connecting the headset for charging will power the
headset off.
You can operate the headset normally during charging.
4 Pair the headset with the mobile phone.
For detailed information, refer to the user
manual of your mobile phone.
The following example shows you how to
pair the headset with your mobile phone.
•
1
2
Activate the Bluetooth feature of your
mobile phone, select Fidelio M2BT.
Enter the headset password "0000" (4
zeros) if prompted. For those mobile
phones featuring Bluetooth 2.1+EDR or
higher, no need to enter a password.
Connect the supplied USB charging cable to:
• the USB connector of the headset and;
• USB power source.
» LED turns white during charging
and turns off when the headset are
fully
charged.
10:35
Settings
Connectivity
Settings
10:36
Settings
10:37
Connectivity
Bluetooth
Devices Found
Tip
• Normally, a full charge takes 5 hours.
• When your batter y is empty, you can carr y on listening
music with an audio cable. Make sure the headset is off
(and not in idle mode) before using this audio cable.
Add
Bluetooth
device
Select
Back
Philips Fidelio M2BT
Enter Password
0000
Select
Back
Select
Back
Pair the headset with your
mobile phone
Before you use the headset with your mobile
phone for the first time, pair it with a mobile
phone. A successful pairing establishes a unique
encrypted link between the headset and mobile
phone. The headset stores the last 8 devices
in the memory. If you try to pair more than 8
devices, the earliest paired device is replaced by
the new one.
EN
5
4 Use your
headset
Connect the headset to a
Bluetooth device
1
2
Turn on your mobile phone/Bluetooth
device.
Press and hold the call/music button to
turn the headset on.
» The blue LED flashes.
» The headset is reconnected to
the last connected mobile phone/
Bluetooth device automatically. If the
last one is not available, the headset
tries to reconnect to the second last
connected device.
Manage your calls and music
Call/Music button
Task
Operation
Sound or LED
indicator
• 1 shor t beep
• 3 white flashes:
batter y low <
25%
• 2 white flashes:
batter y level <
50%
• 1 blue flash:
batter y level >
50%
• 1 long beep
• 1 long white
flash
1 short beep
Turn the
headset on.
Press and
hold for 1
second.
Turn the
headset off.
Press and
hold for 4
seconds.
Press once.
Note
• If you connect the headset to an iphone, ipad or ipod
Touch (iOS version 5.0 or above), the battery indicator
is displayed on the iphone, ipad or ipod Touch.
Tip
• If you turn on the mobile phone/Bluetooth device or
activate the Bluetooth feature after turning on the
headset, you have to reconnect the headset and mobile
phone/Bluetooth device manually.
Play or
pause
music.
Pick up or
terminate
a call.
Reject an
incoming
call.
Redial the
last number.
Switch
caller during
a call.
Press once.
1 short beep
Press and
hold
1 short beep
Press twice.
Press twice
1 short beep
1 long beep
Volume/Track control button
Adjust volume.
Skip forward.
Skip backward.
Mute/unmute the
microphone in
a call.
turn up/
down
Press
once
Press
twice
Press
once
1 short beep
1 short beep
1 short beep
1 short
beep/2 short
beeps
6
EN
Other headset indicator status
Use with the audio cable
Headset status
The headset is connected
to a Bluetooth device, while
the headset in standby
mode or while you are
listening to music.
The headset is ready for
pairing.
Indicator
Blue LED flashes
for ever y 8
seconds.
Note
• Finish your call before connecting the audio cable, as
this will switch off the battery power of the headset
and end an incoming call.
The headset is on but not
connected to a Bluetooth
device.
There is an incoming call.
LED flashes
white and blue
alternately.
Blue LED flashes
quickly.
With the supplied audio cable, you can use
the headset with non-Bluetooth devices or on
airplane. No battery power is required for the
headset when you use it with the audio cable.
Connect the supplied audio cable to
•the headset and;
•an external audio device.
Low batter y.
Batter y is fully charged.
Blue LED flashes
twice per
second.
White LED
flashes.
White LED is off.
Wear your headset
Adjust the headband to fit your head.
Tip
• After use, twist and fold the headset up for storage.
EN
7
5 Technical data
•
•
•
•
Minimum 10 hours of music time or talk
time
Minimum 350 hours of standby time
Normal time for a full charge: 3 hours
Rechargeable Lithium-Polymer batter y
(230 mAh)
3.5 mm audio jack for corded headset
mode
Bluetooth 2.1+EDR or 4.0, Bluetooth
mono support (Headset Profile - HSP,
Hands-Free Profile - HFP), Bluetooth
stereo supported (Advanced Audio
Distribution Profile - A2DP; Audio Video
Remote Control Profile - AVRCP)
Operating range: Up to 10 meters (33
feet)
Adjustable, flat-folding headband
Digital echo & noise reduction
Supports AAC audio
Auto power off
•
•
•
•
•
•
•
Note
• Specifications are subject to change without notice.
8
EN
6 Notice
Declaration of conformity
Hereby Philips Consumer Lifestyle, declares
that the M2BT is in compliance with the
essential requirements and other relevant
provisions
of Directive 1999/5/EC. You can find the
Declaration of Conformity on www.p4c.philips.
com.
This product has been designed, tested and
manufactured according the European R&TTE
directive 1999/5/EC.
Your product contains batteries covered by the
European Directive 2006/66/EC, which cannot
be disposed with normal household waste.
Please inform yourself about the local rules
on separate collection of batteries
because correct disposal helps to prevent
negative consequences for the
environmental and human health.
Remove the integrated battery
Note
• Make sure the headset is disconnected from the USB
charging cable before removing the battery.
Disposal of your old product
and batteries If there is no collection/recycling system for
electronic products in your country, you can
protect the environment by removing and
recycling the battery before disposing the
headset.
Your product is designed and manufactured
with high quality materials and components,
which can be recycled and reused.
1
2
3
4
When this crossed-out wheeled bin symbol is
attached to a product it means that the product
is covered by the European Directive 2002/96/
EC. Please inform yourself about the local
separate collection system for electrical and
electronic products.
Please act according to your local rules and
do not dispose of your old products with your
normal household waste.
Correct disposal of your old product helps to
prevent potential negative consequences for the
environment and human health.
Environmental information
All unnecessary packaging has been omitted.
We have tried to make the packaging easy to
separate into three materials: cardboard (box),
polystyrene foam (buffer) and polyethylene
(bags, protective foam sheet.)
Your system consists of materials which can
be recycled and reused if disassembled by
a specialized company. Please observe the local
regulations regarding the disposal of packaging
materials, exhausted batteries and old
equipment.
EN
9
Notice for the European
Union
Hereby, Philips Consumer Lifestyle,
declares
that Philips Fidelio M2BT is in compliance
with the essential requirements and other
relevant provisions of Directive
1999/5/EC.
Warning:
Any changes or modifications made to this device that are
not expressly approved by Woox Innovations may void the user’s
authority to operate the equipment.
Canada:
This device complies with Industry Canada licence-exempt RSS
standard(s). Operation is subject to the following Two conditions: (1)
this device may not cause harmful interference, and (2) this device
must accept any interference received, including interfe
rence that may
cause undesired operation.
CAN ICES(B)/NMB-3(B)
IC Radiation Exposure Statement:
This equipment complies with Canada radiation exposure limits set
forth for uncontrolled environments.
This transmitter must not be co-located or operating in conjunction
with any other antenna or transmitter.
Caution: The user is cautioned that changes or modifications not
expressly approved by the party responsible for compliance could
void the user's authority to operate the equipment.
Trademarks
Trademarks are the proper ty of Koninklijke
Philips Electronics N.V. or their respective
owners. The Bluetooth word mark and
logos are owned by the Bluetooth SIG, Inc.
and
any use of such marks by Koninklijke
Philips
Electronics N.V. is under license.
iPhone, iPad and iPod Touch are
trademarks of Apple Inc., registered in the
U.S. and other countries.
Notice for
compliance
Avis de conformité
The device complies with the FCC rules, Part 15.Operation is
subject to the following two conditions:
1. This device may not cause harmful interference, and
2. This device must accept any interference received,
including interference that may cause undesired operation.
FCC rules
This equipment has been tested and found to comply with the limits
for a Class B digital device, pursuant to part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment
generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instruction manual, may
cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the
following measures:
· Relocate the receiving antenna.
· Increase the separation between equipment and receiver.
· Connect the equipment into an outlet on a circuit different
from that to which the receiver is connected.
· Consult the dealer or an experienced radio/TV technician
for help.
FCC Radiation Exposure Statement:
This equipment complies with FCC radiation exposure limits set
forth for an uncontrolled environment. This transmitter must not be
co-located or operated in conjunction with any other antenna or
transmitter.
Cetappareilsatisfait aux règlements de la FCC partie 15 du Code of
Federal Regulations. Son fonctionnementestassujetti aux deux
conditions suivantes :
1. Cetappareil ne doit pas causer d’interférencepréjudiciable
et
2. l’appareildoit accepter touteinterférencereçue, y compris
les interférences qui peuvent causer un fonctionnement
non désiré.
Règlement de la FCC
Cetéquipement a ététesté et jugé compatible avec les
limitess’appliquant aux appareilsnumériques de la classe B,
conformément à l’article 15 du règlement de la FCC.
Ceslimitesontétédéfinies pour fournirune protection
raisonnablecontre les interférencesnuisiblesdans le cadre d’une
installation résidentielle. Cetéquipementgénère, utilise et
peutémettre de l’énergieradiofréquence et, s’iln’est pas
installéniutiliséconformément aux instructions, peut causer des
interférencesgênantes pour les communications radio.
Rien ne garantittoutefoisque des interférences ne surviendront pas
dansune installation particulière. Si cetéquipement cause des
interférencesnuisibles pour la réception de la radio ou de la
télévision, ce qui peutêtredéterminé en mettantl’équipement hors
tension puis sous tension, l’utilisateurdevra essayer de
corrigercesinterférences en effectuantuneouplusieurs des
opérationssuivantes :
Déplacezl’antenne de réception.
Augmentez la distance entre l’équipementet le récepteur.
Branchezl’équipement à uneprise d’un circuit
autrequeceluisurlequel le récepteurestbranché.
Consultez le détaillantouuntechnicien de
radiotélévisionexpérimenté.
10
EN
Énoncé de la FCC surl’exposition aux
rayonnementsradioélectriques: cetappareilestconforme aux
limitesd’exposition aux rayonnementsradioé
lectriques de la FCC pour
un environnement non contrôlé. Cetémetteur ne doit pas êtreinstallé
au mêmeendroitqu’uneautreantenneou
un autreémetteur, niutilisé avec
un teldispositif.
Avertissement :Toute modification apportée àcetappareil qui ne
serait pas approuvée expressément par Woox Innovations
peutinvaliderl'habilitation de l'utilisateuràutiliserl'appareil.
Canada :
Le présentappareilestconforme aux CNR d’Industrie Canada
applicables aux appareils radio exempts de licence.
L’exploitationestautorisée aux deux conditions suivantes : (1)
l’appareil ne doit pas produire de brouillage, et (2) l’utilisateur de
l’appareildoit accepter tout brouillageradioélectriquesubi, mêmesi le
brouillageest susceptible d’encompromettre le fonctionnement.
CAN ICES(B)/NMB-3(B)
Déclarationd’ICsurl’exposition aux radiations:
Cetéquipementestconforme aux limitesd’exposition aux radiations
définies par le Canada pour des environnements non contrôlés.
Cetémetteur ne doit pas êtreinstallé au mêmeendroitniutilisé avec
uneautreantenneou un autreémetteur.
EN 11
7 Frequently
asked questions
My Bluetooth headset does not switch on.
• The batter y is low. Charge the headset.
• The audio cable is connected to the
headset. Disconnect the audio cable.
My Bluetooth headset is connected to a
Bluetooth stereo enabled mobile phone, but
music only plays on the mobile phone speaker.
Refer to the user manual of your mobile phone.
Select to listen to music through the headset.
I cannot pair my Bluetooth headset with a
mobile phone.
The Bluetooth is disabled. Enable the Bluetooth
feature on your mobile phone and turn on the
mobile phone before you turn on the headset.
The audio quality is poor and crackling noise
can be heard.
The Bluetooth device is out of range. Reduce
the distance between your headset and
Bluetooth device, or remove obstacles between
them.
Pairing does not work.
Make sure the headset is in pairing mode.
• Follow the steps described in this user
manual (see 'Pair the headset with your
mobile phone' on page 5).
• Make sure that the LED light flashes white
and blue alternately before you release the
call/music button. Do not stop holding the
button if you see the blue LED only.
The audio quality is poor when streaming
from the mobile phone is very slow, or audio
streaming does not work at all.
Make sure your mobile phone not only
supports (mono) HSP/HFP but also supports
A2DP (see 'Technical data' on page 8).
I hear but cannot control music on my
Bluetooth device (e.g. play/pause/skip forward/
backward).
Make sure the Bluetooth audio source suppor ts
AVRCP (see 'Technical data' on page 8).
The mobile phone cannot find the headset.
• The headset may be connected to a
previously paired device. Turn off the
connected device or move it out of range.
• Pairing may have been reset or the headset
has been previously paired with another
device. Pair the headset with the mobile
phone again as described in the user
manual (see 'Pair the headset with your
mobile phone' on page 5).
I cannot see the iPhone battery indicator after
connecting the iPhone to the headset. Make
sure your iPhone iOS version is 5.0 or above.
My headset does not work when the audio
cable is connected.
Microphone function will be deactivated if a
3.5mm audio cable is connected to the headset.
In such case, your headset is only for music
enjoyment.
Voice dialing or redialing does not work on
my mobile phone.
Your mobile phone may not support this
feature.
How can I restore all original headset settings?
Press volume/track control button and call
music button until the LED flashing white for 5
times sequentially.
The other side cannot hear me on the mobile
phone.
The microphone is muted. Press volume/track
control button to enable the microphone.
For further support, visit www.philips.com/
support.
12 EN
Specifications are subject to change without notice
© 2013 Koninklijke Philips Electronics N.V.
All rights reserved.
0890
M2BT_UM_00_EN
