User Manual
SHB3075
Push
User manual
Register your product and get support at
www.philips.com/support
1EN
Contents
Contents
1 Important safety instructions 2
Hearing Safety 2
General information 2
2 Your Bluetooth wireless
headphones 3
What's in the box 3
Other devices 3
Overview of your Bluetooth
wireless headphones 3
3 Get started 5
Charge your headphones 5
Pair the headphones with your
mobile phone 5
4 Use your headphones 6
Connect the headphones to a
Bluetooth device 6
Manage your calls and music 6
Wear your headset 7
5 Technical data 8
6 Notice 9
Declaration of conformity 9
Disposal of your old product
and battery 9
Compliance with EMF 9
Trademarks 10
7 Frequently asked questions 11
2EN
1 Important
safety
instructions
Hearing Safety
Danger
• To avoid hearing damage, limit the time you
use headphones at high volume and set
the volume to a safe level. The louder the
volume, the shorter the safe listening time is.
Be sure to observe the following
guidelines when using your headset.
• Listen at reasonable volumes for
reasonable periods of time.
• Be careful not to adjust the
volume continuously upwards as
your hearing adapts.
• Do not turn up the volume so high
that you can’t hear what’s around
you.
• You should use caution or
temporarily discontinue use in
potentially hazardous situations.
• Excessive sound pressure from
earphones and headphones can
cause hearing loss.
• Using headphones with both
ears covered while driving is not
recommended and may be illegal
in some areas while driving.
• For your safety, avoid distractions
from music or phone calls while
in trac or other potentially
dangerous environments.
General information
To avoid damage or malfunction:
Caution
• Do not expose headphones to excessive
heat.
• Do not drop your headphones.
• Headphones shall not be exposed to
dripping or splashing.
• Do not allow your headphones to be
submerged in water.
• Do not use any cleaning agents containing
alcohol, ammonia, benzene, or abrasives.
• If cleaning is required use a soft cloth,
if necessary dampened with a minimum
amount of water or diluted mild soap, to
clean the product.
• The integrated battery shall not be exposed
to excessive heat such as sunshine, re or
the like.
• Danger of explosion if battery is incorrectly
replaced. Replace only with the same or
equivalent type.
About operating and storage
temperatures and humidity
• Operate or store in a place where
temperature is between -15ºC
(5ºF) and 55ºC (131ºF) (up to 90%
relative humidity.
• Battery life may be shorter in high
or low temperature conditions.
3EN
2 Your
Bluetooth
wireless
headphones
Congratulations on your purchase, and
welcome to Philips! To fully benet
from the support that Philips oers,
register your product at www.philips.
com/welcome.
With this Philips wireless headphones,
you can:
• enjoy convenient wireless
handsfree calls;
• enjoy and control wireless music;
• switch between calls and music.
What's in the box
Philips Bluetooth wireless
headphones SHB3075
USB charging cable (for charging only)
Quick start guide
Other devices
A mobile phone or device (e.g.
notebook, PDA, Bluetooth adapters,
MP3 players etc) which supports
Bluetooth and is compatible to the
headphones (see ‘Technical data” on
page 8).
Overview of your
Bluetooth wireless
headphones
a
Music/call control button
b LED indicator
c
On/o button
d Microphone
7
3
1
2
4
5
6
4EN
e
Pairing/Mute button
f Micro USB charging slot
g +/-
Volume/Track control button
5EN
3 Get started
Charge your headphones
Note
• Before you use your headphones for the
rst time, charge the battery for 5 hours for
optimum battery capacity and lifetime.
• Use only the original USB charging cable to
avoid any damage.
• Finish your call before charging the
headphones, as connecting the headphones
for charging will power the headphones o.
• You can operate the headphones normally
during charging.
Connect the supplied USB charging
cable to:
• the micro USB charging slot on
the headphones and;
• the charger/USB port of a
computer.
» LED turns white during
charging and turns o when the
headphones is fully charged.
Tip
• Normally, a full charge takes 3 hours.
Pair the headphones
with your mobile phone
Before you use the headphones
with your mobile phone for the rst
time, pair it with a mobile phone.
A successful pairing establishes a
unique encrypted link between the
headphones and mobile phone. The
headphones store the last 4 devices
in the memory. If you try to pair more
than 4 devices, the earliest paired
device is replaced by the new one.
1 Make sure that the headphones
are fully charged and turned o.
2 Press and hold until the blue
and white LED ashes alternately.
» The headphones remain in
pairing mode for 5 minutes.
3 Make sure that the mobile phone
is turned on and its Bluetooth
feature is activated.
4 Pair the headphones with the
mobile phone. For detailed
information, refer to the user
manual of your mobile phone.
The following example shows you
how to pair the headphones with your
mobile phone.
1 Activate the Bluetooth feature of
your mobile phone, select Philips
SHB3075.
2 Enter the headset password
"0000" (4 zeros) if prompted. For
those mobile phones featuring
Bluetooth 3.0 or higher, no need
to enter a password.
SHB3075
SHB4405
6EN
4 Use your
headphones
Connect the
headphones to a
Bluetooth device
1 Turn on your mobile
phone/Bluetooth device.
2 Press and hold to turn the
headphones on.
» The blue LED ashes.
» The headphones are
reconnected to the
last connected mobile
phone/Bluetooth device
automatically. If the last one is
not available, the headphones
try to reconnect to the second
last connected device.
Tip
• If you turn on the mobile phone/Bluetooth
device or activate the Bluetooth feature
after turning on the headphones, you have
to reconnect the headphones and mobile
phone/Bluetooth device manually.
Note
• If the headphones fail to connect to any
Bluetooth device within range in 5 minutes,
it will switch o automatically to save the
battery life.
Manage your calls and
music
On/o
Task Button Operation
Turn the
headphones
on.
Press and
hold for 3
seconds.
Turn the
headphones
o.
Press and
hold for 5
seconds.
» The white
LED is on
and fades
out.
Music control
Task Button Operation
Play or pause
music.
Press once.
Adjust
volume.
+/-Press
once/press
and hold.
Skip forward. +Press
twice.
Skip
backward.
-Press and
hold for 3
seconds.
Call control
Task Button Operation
Pick
up/hang
up a call.
Press once.
» 1 beep.
Switch
caller
during a
call.
Press and
hold for 3
seconds.
7EN
Voice control
Task Button Operation
Siri/Google
Now.
Press once.
Other headphones indicator status
Headphones
status
Indicator
The headphones
are connected
to a Bluetooth
device, while the
headphones in
standby mode
or while you
are listening to
music.
The blue LED
ashes for every 8
seconds.
The headphones
are ready for
pairing.
The LED ashes
blue and white
alternately.
The headphones
are on but not
connected to a
Bluetooth device.
The blue LED
ashes quickly.
If no connection
can be made,
the headphones
will turn itself o
within 5 minutes.
Low battery level. The white LED
ashes 3 times for
every 10 seconds
until it is out of
power.
Battery is fully
charged.
The white LED is
o.
Wear your headset
Adjust the headband to t your head.
8EN
5 Technical
data
• Music time: 8 hours
• Talk time: 8 hours
• Standby time: 166 hours
• Normal time for a full charge: 3
hours
• Rechargeable lithium polymer
battery (240 mAh)
• Bluetooth 4.1, Bluetooth mono
support (Headset Prole - HSP,
Hands-Free Prole - HFP),
Bluetooth stereo supported
(Advanced Audio Distribution
Prole - A2DP; Audio Video
Remote Control Prole - AVRCP)
• Operating range: Up to 10 meters
(33 feet)
• Digital echo & noise reduction
• Auto power o
Note
• Specications are subject to change without
notice.
9EN
6 Notice
Declaration of
conformity
Hereby, Gibson Innovations declares
that this product is in compliance
with the essential requirements
and other relevant provisions of
Directive 2014/53/EU. You can nd the
Declaration of Conformity on www.
p4c.philips.com.
Disposal of your old
product and battery
Your product is designed and
manufactured with high quality
materials and components, which can
be recycled and reused.
This symbol on a product means that
the product is covered by European
Directive 2012/19/EU.
This symbol means that the product
contains a built-in rechargeable
battery covered by European Directive
2013/56/EU which cannot be disposed
of with normal household waste.
We strongly advise you to take your
product to an ocial collection point
or a Philips service centre to have a
professional remove the rechargeable
battery.
Inform yourself about the local
separate collection system for
electrical and electronic products
and rechargeable batteries. Follow
local rules and never dispose of the
product and rechargeable batteries
with normal household waste.
Correct disposal of old products and
rechargeable batteries helps prevent
negative consequences for the
environment and human health.
Remove the integrated battery
Note
• Make sure the headphones are disconnected
from the USB charging cable before
removing the battery.
If there is no collection/recycling
system for electronic products
in your country, you can protect
the environment by removing and
recycling the battery before disposing
the headphones.
Compliance with EMF
This product complies with all
applicable standards and regulations
regarding exposure to electromagnetic
elds.
Environmental information
All unnecessary packaging has been
omitted. We have tried to make the
10 EN
packaging easy to separate into
three materials: cardboard (box),
polystyrene foam (buer) and
polyethylene (bags, protective foam
sheet.)
Your system consists of materials
which can be recycled and reused
if disassembled by a specialized
company. Please observe the local
regulations regarding the disposal
of packaging materials, exhausted
batteries and old equipment.
Trademarks
Bluetooth
The Bluetooth® word mark and logos
are registered trademarks owned by
Bluetooth SIG, Inc. and any use of
such marks by Gibson Innovations
Limited is under license. Other
trademarks and trade names are those
of their respective owners.
Siri
Siri is a trademark of Apple Inc.,
registered in
the U.S. and other countries.
Google
Google and the Google Logo are
registered trademarks of Google Inc.
7 Frequently
asked
questions
My Bluetooth headphones do not
switch on.
The battery level is low. Charge the
headphones.
I cannot pair my Bluetooth
headphones with a mobile phone.
The Bluetooth is disabled. Enable
the Bluetooth feature on your mobile
phone and turn on the mobile phone
before you turn on the headphones.
Pairing does not work.
Make sure the headphones are in
pairing mode.
• Follow the steps described in
this user manual (see ‘Pair the
headphones with your mobile
phone” on page 5).
• Make sure that the LED light
ashes blue and white alternately
before you release . Do not stop
holding the button if you see the
blue LED only.
The mobile phone cannot nd the
headphones.
•The headphones may be
connected to a previously paired
device. Turn o the connected
device or move it out of range.
•Pairing may have been reset or the
headphones have been previously
paired with another device. Pair
the headphones with the mobile
phone again as described in the
user manual.
My Bluetooth headphones are
connected to a Bluetooth stereo
enabled mobile phone, but music only
plays on the mobile phone speaker.
Refer to the user manual of your
mobile phone. Select to listen to music
through the headphones.
The audio quality is poor and crackling
noise can be heard.
The Bluetooth device is out of range.
Reduce the distance between your
headphones and Bluetooth device, or
remove obstacles between them.
The audio quality is poor when
streaming from the mobile phone is
very slow, or audio streaming does not
work at all.
Make sure your mobile phone not only
supports (mono) HSP/HFP but also
supports A2DP (see ‘Technical data”
on page 8).
I hear but cannot control music on my
Bluetooth device (e.g. play/pause/skip
forward/backward).
Make sure the Bluetooth audio source
supports AVRCP (see ‘Technical data”
on page 8).
For further support, visit www.philips.
com/support.
2017 © Gibson Innovations Limited. All rights reserved.
This product has been manufactured by, and is sold under the responsibility
of Gibson Innovations Ltd., and Gibson Innovations Ltd. is the warrantor in
relation to this product.
Philips and the Philips’ Shield Emblem are registered
trademarks of Koninklijke Philips N.V.
UM_SHB3075_00_EN_draft0.1
WK1703
