Gigaset A490/A495
- The base station at a glance
ECO DECT
- Reduced energy consumption
- Reduced transmission power
Safety precautions
Caring for your phone
- Contact with liquid
First steps
Making calls
Using the directory and lists
Operating the answering machine (A495)
Locating a handset ("paging")
Registering handsets
- Manually registering handsets to Gigaset A490/A495
De-registering handsets
Using mutliple handsets
Setting the alarm clock
- Activating/deactivating the alarm clock
- Setting the wake-up time
Phone settings
Appendix
Service (Customer Care)
- End-user limited warranty
- Menu tree

A490/A495

NAM

A31008

M2200

R301

3S19

verv

ew.

2012

Gigaset A490/A495

±U

12/11 11:56am

INT MENU

1 Charge status of the batteries

2 Answering machine icon (A495 only)

3 Display keys

4Message key

Flashes: new messages received

5Use

t to activate the menu for setting

the volume

6Speaker key

7 Control key (u)

8Talk key

9Directory key

(press down on the control key)

10 End call key and

On/Off button

11 Ringer tone on/off

(press and hold in idle status)

12 Keypad lock on/off (press and hold)

13 Flash key

- Consultation call (flash)

- Dialing pause (press and hold)

14 Microphone

15 Mute key 11

The handset at a glance

Display keys on handset:

Pressing a key launches the function that appears above that key in the display.

Display Function when pressed

INT Call other registered handsets ¢ page 14.

MENU Open main/submenu (see Menu tree ¢ page 24).

“ Go back one menu level.

UScroll up/down or adjust volume with u.

T Move cursor to left/right with u.

˜Backspace deletes one character at a time.

OK Confirm menu function or save entry.

Please note

Charge the handset for

18 hours before first use.

A490/A495

NAM

A31008

M2200

R301

3S19

verv

ew.

2012

The base station at a glance

A495 only:

1Registration/paging button:

Search for handsets

(press briefly, "Paging" ¢ page 13).

(press and hold ¢ page 13).

2On/Off button: activate and deactivate an-

swering machine.

Lights up: answering machine is activated.

Flashes: answering machine is operating.

3Volume keys: (x = quieter; t = louder)

During message playback: adjust the speak-

ing volume.

While phone is ringing: adjust ringer volume.

4Play/Stop key:

Play back messages from the answering ma-

chine, or cancel playback.

Flashes: new messages available.

Flickering: memory is full.

During message playback:

5 Delete current message.

6 Skip to the start of the current message (press

once) or go to the previous message (press

twice).

7Skip to next message.

ECO DECT

You are helping to protect the environment with your Gigaset A490/A495.

Reduced energy consumption

Your telephone has an energy-saving adapter plug and uses less energy.

Reduced transmission power

The transmission power of your telephone is reduced automatically:

The handset's transmission power is reduced depending on the distance to the base sta-

tion. The base station’s transmission power is reduced to almost zero when only one

handset is registered and the handset is in the base station.

You can reduce the transmission power of the handset and base station even more by

using Eco Mode (see Menu tree page 25):

70% transmission power reduction in standby mode (top left display icon ½) and during

a call. The range of the base station is reduced. Press and hold the talk key c to check

that the base station can be reached. You will hear the dialling tone if the base station can

be reached.

A490/A495

NAM

A31008

M2200

R301

3S19

verv

ew.

2012

Safety precautions

Emergency numbers cannot be dialed if the key-

pad lock (¢ page 1) is activated!

Not all of the functions described in this user

guide are available in all countries.

Caring for your phone

Wipe down the base station and handset

with a damp cloth (no solvents) or an anti-

static cloth. Never use a dry cloth. This can

cause static.

Contact with liquid

If the handset comes into contact with liq-

uid:

◆Switch the handset off and remove the

batteries immediately.

◆Allow the liquid to drain from the hand-

set.

◆Pat all parts dry, then with the battery

compartment open and the keypad fac-

ing down place the handset in a dry,

warm place for at least 72 hours (not in

a microwave, oven, etc.).

◆Do not switch on the handset again

until it is completely dry.

When it has fully dried out, you will nor-

mally be able to use it again.

Read this user guide and the safety precautions

carefully before use. Explain their contents and

the potential hazards associated with using the

telephone to your children.

Use only the power adapter sup-

plied.

Only insert approved rechargeable

batteries of the same type. Never use

ordinary (non-rechargeable) batteries

as they may pose a health hazard or

cause injury.

Using your telephone may affect

nearby medical equipment. Be aware

of the technical conditions in your par-

ticular environment, e.g. doctor's sur-

gery.

Notice to Hearing Aid Wearers:

This phone system is compatible with

inductively coupled hearing aids.

Do not install the phone in a bathroom

or shower room. The handset and base

station are not splashproof.

Do not use your phone in environ-

ments with a potential explosion haz-

ard, e.g. paint shops.

If you give your phone to a third party,

make sure you also give them the user

guide.

Remove faulty base stations from use

as they could interfere with other wire-

less services.

Disposal

Batteries should not be disposed of in

general household waste. Observe the

local waste disposal regulations,

details of which can be obtained from

your local authority or the dealer you

purchased the product from.

All electrical and electronic equipment

must be disposed of separately from

general household waste using the

sites designated by local authorities.

The appropriate disposal and separate

collection of used equipment serve to

prevent potential harm to the environ-

ment and to health. They are a prereq-

uisite for the re-use and recycling of

used electrical and electronic equip-

ment.

For further information on disposing of

your used equipment, please contact

your local authority, your refuse collec-

tion service or the dealer you pur-

chased the product from.

A490/A495

NAM

A31008

M2200

R301

3S19

start

ng.

2012

First steps

Checking the package contents

◆One Gigaset A490/A495 base station,

◆One power adapter,

◆One Gigaset A49H handset,

◆One phone cord,

◆Two batteries,

◆One battery cover,

◆One user guide.

If you have purchased a model with multiple handsets, the package should con-

tain two batteries, a battery cover and a charging cradle with power adapter for

each additional handset.

Setting up the base station and charging cradle (if included)

The base station and charging cradle are designed for use in dry rooms in a tem-

perature range of +41°F to +113°F.

¤Set up the base station at a central location in your building on a flat, non-slip

surface.

The phone's feet do not usually leave any marks on surfaces. However, due to the

multitude of different varnishes and polishes used on today's furnishings, the

occurrence of marks on the surfaces cannot be completely ruled out.

You can also mount the base station and charging cradle on the wall.

Please note:

◆Never expose the telephone to the influence of heat sources, direct sunlight or

other electrical devices.

◆Protect your Gigaset from moisture, dust, corrosive liquids and fumes.

Please note

Pay attention to the range of the base station.

This is up to 984 feet in unobstructed outdoor areas and up to 165 feet inside

buildings.

A490/A495

NAM

A31008

M2200

R301

3S19

start

ng.

2012

Connecting the base station

¤Connect the plug from the power

adapter 1.

¤Plug the power adapter into the plug

socket 2.

¤Then connect the telephone jack 3

and insert the cables into the cable

ducts.

Please note:

◆The power adapter must always be

connected, as the phone will not

operate without electrical power.

◆Use only the power adapter and

phone cord supplied. Pin connec-

tions on telephone cables can vary.

Setting up the handset for use

The display is protected by a plastic film.

Please remove the protective film!

Inserting the batteries and closing the battery cover

Warning

Use only rechargeable nickel-metal hydride (NiMH) UL-approved AAA batter-

ies recommended by Gigaset Communications GmbH (¢ page 16). Never

use a conventional (non-rechargeable) battery or other battery types as this

could result in significant health risks and personal injury. For example, the

batteries could explode. The phone could also malfunction or be damaged as

a result of using batteries that are not of the recommended type.

A490/A495

NAM

A31008

M2200

R301

3S19

start

ng.

2012

Placing the handset in the base/charger

¤Place the handset in the base/charger with its display facing forward.

Each handset of your package is registered with the base at the factory. You do not

need to register the handset again. To use your handset with a different base or

use additional handsets with your base, you must register the handset manually

(¢ page 13).

To charge the batteries, leave the handset in the base/charger.

Please note

Only place the handset in the base/charger that came with the handset.

¤Insert the batteries with the polar-

ity in the correct direction.

The polarity is indicated in/on the

battery compartment.

¤Slide the battery cover from the

bottom up onto the casing until it

clicks into place.

¤To open the battery cover, for

instance to replace the bat-

teries, press the ribbing at

the top of the battery cover

and slide it downward.

A490/A495

NAM

A31008

M2200

R301

3S19

start

ng.

2012

Initial charging and discharging of the batteries

The correct charge level can only display if the batteries are first fully charged and

discharged.

Charge status of the batteries

The charge status is indicated by the top right display icon. After the initial charg-

ing procedure a complete charging to full capacity takes at least 18 hours.

◆U battery full

◆e steady: medium capacity

◆e flashes: batteries almost flat

◆U flashes: charging when the handset is in the charging cradle

Please note

◆To get the full talk and standby times, 2 to 3 full charge and discharge

cycles are needed.

◆After the third battery charge and discharge you may replace your handset

in the base station or charging cradle after every call.

◆Always repeat the charging and discharging procedure if you remove the

batteries from the handset and reinsert them.

◆The batteries may warm up during charging. This is not dangerous.

◆After a while, the charge capacity of the batteries will decrease for techni-

cal reasons.

Warning

Please ensure that the handset is in the charging cradle if you are absent for a

long time (e.g. during holidays) or remove the batteries from the handset. Oth-

erwise the batteries could be damaged.

¤Place the handset in the base station or charging cradle for 18

hours.

¤Then remove the handset from the base station or charging cra-

dle and do not replace it until the batteries are completely dis-

charged.

18 h

A490/A495

NAM

A31008

M2200

R301

3S19

start

ng.

2012

Setting the date and time

Set the date and time so that the correct date and time can be assigned to incom-

ing calls, and so that the alarm can be used.

MENU ¢ Settings ¢ OK ¢ Date/Time ¢ OK

¢ Date: ¢ ~ (enter the month, day and year in 6-digit format) ¢ OK

¢ Time: ¢ ~ (enter hours and minutes in 4-digit format, change am/pm by press-

ing P or #) ¢ OK ¢ a (press to return to idle state)

Display in idle state

Once the phone is registered and the time set, the idle

display shows as in this example.

If the answering machine is activated (A495), the

answering machine icon ± displays in the header.

Your answering machine is set with a pre-recorded

announcement.

Activating/deactivating the handset

Press and hold the a key to activate or deactivate the handset.

If you place a deactivated handset in the base station or charging cradle, it will

automatically activate.

Your phone is now ready for use.

If you have any questions about using your phone, please read the tips on trouble-

shooting ("Troubleshooting" ¢ page 17) or contact our Customer Care team

page 21.

Please note

When entering the time and date, you can move the position of an entry to the

left or right by pressing the control button up or down.

±U

12/11 11:56am

INT MENU

A490/A495

NAM

A31008

M2200

R301

3S19

2012

Making calls

Making external calls and

ending calls

External calls are calls using the public tele-

phone network.

~ (Enter the phone number) ¢c.

The phone number is dialed. (Or you can

first press and hold c to hear the dial tone

and then enter the number.) During the call

you can adjust the earpiece volume using

t and set the volume with u.

End the call/cancel dialing:

Press the end call key a.

Accepting a call

The handset indicates an incoming call by

ringing and by a display on the screen. The

base station indicates an incoming call by

ringing (A495 only).

Press the talk key c to accept the call.

When Auto Answer is activated (see Menu

tree ¢ page 25), simply remove the hand-

set from the base station/charging cradle.

In idle state, use t to activate the menu for

setting the ringer volume and use u to set

the volume.

Caller ID

Caller ID (CID) and Caller Name ID (CNID) are

optional subscription services provided by

your telephone service provider. These fea-

tures supply incoming caller identification

information that displays on your handset.

When you get a call, the caller's number dis-

plays on your handset; the caller's name

displays if it is stored in the directory or if

CNID has been requested.

Muting

You can mute your handset when making

external calls. Your caller can no longer hear

you but you can still hear them.

Press the Mute key m during the call to

activate/deactivate the function.

Speakerphone

(A490/A495)

Activating while dialing:

Enter the number ~ and press the speaker

key d. The speaker key is illuminated red

now.

Switching between earpiece and speaker

mode:

During a call and when listening to the

answering machine (A495 only), press the

speaker key d to activate or deactivate

the speakerphone.

During a call, use t to activate the menu

for setting the speaker volume and use u

to set the volume.

Using the directory and

lists

directory

v ¢ MENU ¢ New Entry ¢ OK

¢ ~ (enter number) ¢ OK

¢ ~ (enter name) ¢ OK

Selecting a directory entry

Open the directory with v. You have the

following options:

◆Use u to scroll through the entries until

the required name is selected.

◆Enter the first character of the name and

scroll to the entry with u, if required.

Dialing with the directory

v ¢ u (select entry) ¢ c

Using other functions

v ¢ u (select entry) ¢ MENU

The following functions can be selected

with u:

Sending the directory to another

handset

Prerequisites:

◆The sending and receiving handsets

must both be registered to the same

base station.

◆The other handset and the base station

can send and receive directory entries.

v ¢ u (select entry) ¢ MENU

¢ Send List ¢ OK ¢ u (select number of

the receiving handset) ¢ OK

While the list is being transferred the hand-

set displays Copy #/#, identifying the hand-

set numbers affected. When the transfer is

complete, both handsets beep.

Last number redial list

This list contains the 10 last dialed numbers.

Dialing from the last number redial

list

c (press briefly) ¢ u (select entry) ¢ c

Managing entries in the last number

redial list

c (press briefly) ¢ u (select entry)

¢ MENU

You can select the following settings:

New Entry Create and save a new

entry for the directory.

Show Number Display the phone

number.

Use Number Edit or add to the number.

Then dial or use other

functions with MENU.

Edit Entry Edit selected entry.

Delete Entry Delete selected entry.

Delete List Delete all directory

entries.

Send List Send the complete list to

another handset

(¢ page 10).

Use Number Edit or add to the number.

Then dial or use other

functions with MENU.

Copy to Dir. Copy an entry to the direc-

tory.

Delete Entry Delete selected entry.

Delete List Delete all entries.

A490/A495

NAM

A31008

M2200

R301

3S19

2012

Calls list/answering machine

(network mailbox) list

The message key flashes as soon as a new

entry appears in the calls list/answering

machine list. A message appears in the dis-

play.

When you press the f key, all the lists dis-

play. If only one list contains new messages,

this opens automatically.

Calls list

Prerequisite: CID (¢ page 9)

Depending on the type of list set

(¢ page 25), the calls list contains:

◆answered calls

◆missed calls

◆calls recorded by the answering

machine (A495 only)

Depending on the type of list set, all num-

bers of the last 25 incoming calls are saved

or just the missed calls are saved.

The calls list displays as follows:

Number of new entries + number of old, read

entries

Open the calls list

f ¢ CallsList 01+02 ¢ OK

The last incoming call displays.

If necessary, use u to select another entry.

Using other functions

u (select entry) ¢ MENU

The following functions can be selected

with u:

Returning a call from the calls list

f ¢ CallsList 01+02 ¢ OK

¢ u (select entry) ¢ c

Answering machine list (A495 only)

You can use the answering machine list to

listen to the messages that are on the

answering machine.

The answering machine list displays as fol-

lows:

Number of new messages + number of old,

played back messages

Opening the answering machine list

f ¢ VoiceMail 01+02 ¢ OK

If you have new messages, playback begins

with the first new message, otherwise with

the first old message. Call date and time (if

set) are announced each time before play-

back.

During message playback

◆use t to activate the menu for setting

the volume and use u to set the vol-

ume.

◆press MENU to select the following func-

tions with u:

Please note

If calls are saved in the network mail-

box, you will receive a message if the

appropriate settings have been made

(depending on your network provider).

Delete Entry Delete current entry.

Copy to Dir. Copy an entry to the direc-

tory.

CallsList 01+02

Date/Time Call date and time (if set).

Status New Call: new missed call.

Old Call: entry already

read.

Show Name If you requested CNID,

you can view the name

registered for this phone

number with your net-

work provider.

Delete List Warning! All old and new

entries are deleted.

Repeat Repeat current message.

Next Play next message.

Previous Play previous message.

Delete Delete current message.

VoiceMail 01+02

A490/A495

NAM

A31008

M2200

R301

3S19

2012

Operating the

answering machine

(A495)

The answering machine can be operated

from the handset or by using the key on the

base station (¢ page 1).

The telephone is supplied with a pre-

recorded announcement. You can only

record your own announcement messages

using the handset. The pre-recorded

announcement is used if no personal

announcement is available.

If the memory is full, the answering

machine switches itself off automatically. It

activates again automatically when you

delete old messages.

Activating/deactivating the

answering machine

MENU ¢ VoiceMail ¢ OK ¢ Answer

Mach. ¢ OK ¢ On/Off ¢ OK

When you switch on the answering

machine, the ± icon appears in the dis-

play.

Recording your own announcement

MENU ¢ VoiceMail ¢ OK

¢ Announcements ¢ OK

¢ Rec announce ¢ OK ¢ Speak after OK

¢ OK

You hear the ready tone (short tone). Speak

your announcement (at least 3 sec.). Press

Stop recording to confirm or press a or ”

to reject your recording. After recording,

the announcement plays back for you to

check.

Playing back or deleting

announcements

See Menu tree ¢ page 24.

Playing/deleting messages

Open the answering machine list to play

back messages (¢ page 11).

Deleting all old messages

MENU ¢ VoiceMail ¢ OK

¢ Delete all old ¢ OK (Confirm the secu-

rity prompt)

Picking up a call from the answering

machine

You can still accept a call while the answer-

ing machine is recording the message by

pressing c. Recording stops and you can

speak to the caller.

Setting up the answering

machine

The answering machine has already been

preset at the factory. Make individual set-

tings using the handset.

Details on setting a delay time, after which

the answering machine is to answer a call,

as well as details on setting the recording

length and activating call screening during

the recording, are available from the Menu

tree ¢ page 24.

Using key 1 for fast access to

the answering machine

(network mailbox)

Simply press and hold key 1 on the hand-

set and you are connected directly to the

answering machine (network mailbox).

See Menu tree ¢ page 24.

Please note

Recording ends automatically when

the max. recording time of 170 seconds

is reached or if there is a break in speak-

ing of more than 2 seconds.

A490/A495

NAM

A31008

M2200

R301

3S19

2012

Operating remotely when on

the move

You can check and activate your answering

machine from any other telephone (hotel,

pay phone, etc.).

Prerequisites:

◆You have set a system PIN other than

0000 ¢ page 25.

◆The phone you are using for remote

operation has touch tone dialing

(DTMF), i.e. you hear different tones

when you press the keys.

Calling the answering machine and

playing back messages

~ (Dial your own number) ¢ while listening

to your announcement: press the 9

key and

enter the system PIN

Use the following keys:

Activating the answering machine

~ (Enter your own number and allow the

phone to ring until you hear the message:

"Please enter PIN") ¢ ~ enter system PIN

Your answering machine is activated. It tells

you how much memory time is left. The

messages now play back. The answering

machine cannot be deactivated remotely.

Locating a handset

("paging")

You can locate your handset using the base

station.

◆Briefly press the registration/paging

button on the base station (¢ page 1).

◆All handsets will ring simultaneously

("paging"), even if the ringer tones are

deactivated.

End paging: briefly press the register/pag-

ing key on the base station (¢ page 1) or

the talk key c on a handset.

Registering handsets

You can register up to four handsets on

your base station (Gigaset A39H/A49H rec-

ommended).

Manually registering handsets to

Gigaset A490/A495

1. On the base station:

press and hold the registration/paging key

(¢ page 2) for min. 3 sec.

2. On the handset:

within 60 sec. of pressing the registration/

paging key

MENU ¢ Settings ¢ OK ¢ Handset

¢ OK ¢ Register HS ¢ OK ¢ Enter the

system PIN of the base station (default is 0000)

¢ OK.

Registering flashes in the display.

Registration takes approx. 1 minute.

Go to the start of the current mes-

sage.

Press twice to go back to the previ-

ous message.

BStop playback. Press again to

resume.

3Skip to next message.

0Delete current message.

Please note

Each additional handset must be regis-

tered on the base station for it to work

properly!

Please note

If you change the standard PIN 0000

please note that the new PIN must con-

sist of 4 digits!

A490/A495

NAM

A31008

M2200

R301

3S19

2012

De-registering

handsets

Handsets can only be de-registered by

resetting the base station to its default set-

tings with the hardware reset. This will

also reset every other setting ¢ page 15.

Using mutliple

handsets

Making internal calls

Internal calls are free calls to other handsets

registered to the same base station.

To make a call to other handsets, press

◆INT ¢ ~ (1...4, enter internal number

of the handset), the handset is called or

◆INT ¢ star key P, all handsets are

called.

When a participant answers you can speak

to them. To end the call, press a.

Internal consultation call/

connecting a call

When you are using one handset for an

external call, press the INT key to call one or

all handsets.

◆Before the internal participant answers,

press the end call key a; the call is

diverted to the participant who answers

the call.

◆After the internal participant answers,

you can talk to him. Press the end call

key to divert the call a, or press the “

display key to reconnect to the external

participant.

Listening in to an external call

When you are conducting an external call,

an internal participant can listen in on this

call and take part in the conversation (con-

ference).

Prerequisite: The Listening in function

must be activated.

Activating/deactivating listening in

MENU ¢ Settings ¢ OK ¢ Base ¢ OK

¢ Listening in ¢ OK ¢ On/Off ¢ OK

Internal listening in (conference)

To listen in to an existing external call, press

and hold the c key. You can listen in to the

call. All participants hear a signal tone.

To end: press the end call key a. All partic-

ipants hear a signal tone.

If the first internal participant presses the

end call key a, the handset that has "lis-

tened in" remains connected to the exter-

nal participant.

Setting the alarm clock

Activating/deactivating the alarm

clock

MENU ¢ Alarm Clock ¢ OK ¢ Activa-

tion ¢ OK ¢ Off or On ¢ OK

When activated:

¢ Set the wake-up time ¢ OK

When the alarm clock rings, press any key to

switch it off for 24 hours. If the alarm clock

is set, the wake-up icon l appears on the

screen and the wake-up time displays

instead of the date.

Setting the wake-up time

MENU ¢ Alarm Clock ¢ OK ¢ Wake-up

time ¢ OK

Enter the wake-up time in hours and min-

utes , change am/pm by pressing P or #,

then press OK.

A490/A495

NAM

A31008

M2200

R301

3S19

2012

Phone settings

For details on audio settings, see Menu tree

¢ page 24.

For details on setting the system PIN on the

base station, see the Menu tree

¢ page 25.

Changing the display

language

MENU ¢ Settings ¢ OK ¢ Handset

¢ OK ¢ Language ¢ OK ¢ select the

language ¢ OK

If you accidentally choose a language you

do not understand, press

MENU ¢ v ¢ v ¢ v ¢ OK ¢ v

¢ OK ¢ OK

Select another language with u and press

OK.

Resetting the handset

You can reset individual settings and

changes that you have made. Entries in the

directory and the handset's registration to

the base station are retained.

MENU ¢ Settings ¢ OK ¢ Handset

¢ OK ¢ Reset Handset ¢ OK ¢ Reset?

¢ OK

Cancel the reset with a.

After the reset the calls list is empty!

Restoring the base station to

the factory settings

When restoring factory settings:

◆All handsets are de-registered (with

hardware reset only)

◆Individual settings are reset

◆Voice mail entries are deleted (only

applicable for A495 with software reset)

◆The system PIN is reset to the original

code 0000

Only the date and time are set to default.

Software reset

MENU ¢ Settings ¢ OK ¢ Base ¢ OK

¢ Base Reset ¢ OK ¢ Reset? ¢ OK

Hardware reset

Disconnect the power cord from the base

station. Hold down the registration/paging

button (¢ page 1) on the base station

while reconnecting the power cable to the

base station. Release the key after approxi-

mately 5 seconds.

Changing the dialing mode

You can set the dialing mode via the menu.

MENU ¢ Settings ¢ OK ¢ Base ¢ OK

¢ Dialling Mode ¢ OK ¢ select Tone

dialling or Pulse ¢OK.

Setting flash

You can set the flash time manually.

MENU ¢ Settings ¢ OK ¢ Base ¢ OK

¢ Recall ¢ OK ¢ select Short or

Medium or Long ¢OK.

A490/A495

NAM

A31008

M2200

R301

3S19

2012

Appendix

Entering letters/characters

Press the relevant key the number of times

indicated.

Briefly press the pound key # to switch

from "Abc" to "123" mode, from "123" to

"abc"mode and from "abc" to "Abc" mode.

Standard characters

1) Space

Specifications

Recommended batteries

Technology: Nickel-metal-hydride

(NiMH)

Size: AAA (Micro, HR03)

Voltage: 1.2 V

Capacity: 650 mAh

We recommend the following types of bat-

tery:

◆GP 550/700 mAh

◆Yuasa Phone 700/800 mAh

◆Peacebay 550/650 mAh

◆Corun Ni-MH AAAJ650 (650 mAh)

◆Highpower HFR-44AAAJ650 (650 mAh)

(Valid at the time of going to press)

The handset is supplied with nickel-metal

hydride UL-approved AAA batteries.

Base station power consumption

General specifications

*) country-specific

1x 2x 3x 4x 5x 6x 7x 8x 9x 10x 11x 12x 13x 14x

11£$¥¤

2a b c 2 ä á à â ã ç

Id e f 3 ë é è ê

4gh i 4 ï í ì î

5j k l 5

Lm n o 6 ö ñ ó ò ô õ

Mp q r s 7 ß

Nt u v 8 ü ú ù û

Ow x y z 9 ÿ ý æ ø å

Q. , ? ! 0 + - : ¿ ¡ " ’ ; _

P * / ( ) < = > %

# Abc

-->

123

-->

abc # @ \ & §

In standby mode

– Handset in base station

– Handset outside base station

approx. 1.3 W

approx. 0.8 W

During a call approx. 1.0 W

DECT standard is supported*

WDCT standard is supported*

Range up to 984 feet outdoors

up to 165 feet indoors

Operation time

(DECT version)

– Talk time

– Standby time

up to 12 hours

up to 177hours

Operation time

(WDCT version)

– Talk time

– Standby time

up to 6 hours

up to 144 hours

Base station power

supply

100/240 V~, 50 Hz

Environmental con-

ditions in operation

+41°F to +113°F, 20% to

75% relative humidity

A490/A495

NAM

A31008

M2200

R301

3S19

2012

Troubleshooting

If you have any questions about using your

telephone, visit our website at

www.gigaset.com/service

for 24-hour support. The table below con-

tains a list of common problems and possi-

ble solutions.

Industry Canada Certification

Operation is subject to the following two condi-

tions (1) this device may not cause interference,

and (2) this device must accept any interference,

including interference that may cause undesired

operation of the device.

NOTICE: The Industry Canada label identifies cer-

tified equipment. This certification means that the

equipment meets certain telecommunications

network, protective, operational and safety

requirements as prescribed in the appropriate

Terminal Equipment Technical Requirements doc-

ument(s). The Department does not guarantee

the equipment will operate to the user’s satisfac-

tion.

Before installing this equipment, users should

ensure that it is permissible to be connected to

the facilities of the local telecommunications

company. The equipment must also be installed

using an acceptable method of connection. The

customer should be aware that compliance with

the above conditions may not prevent

degradation of service in some situations.

Repairs to certified equipment should be coordi-

nated by a representative designated by the sup-

plier. Any repairs or alterations made by the user

to this equipment, or equipment malfunctions,

may give the telecommunications company

cause to request the user to disconnect the equip-

ment.

Users should ensure for their own protection that

the electrical ground connections of the power

utility, telephone lines and internal metallic water

pipe system, if present, are connected together.

This precaution may be particularly important in

rural areas

NOTE: Users should not attempt to make such

connections themselves, but should contact the

appropriate electric inspection authority,

or electrician, as appropriate.

This product meets the applicable Industry

Canada technical specifications.

The Ringer Equivalence Number is an indication

of the maximum number of devices allowed to be

connected to a telephone interface. The termina-

tion of an interface may consist of any combina-

tion of devices subject only to the requirement

that the sum of the RENs of all devices does not

exceed five.

This Class B digital apparatus complies with Cana-

dian ICES-003.

Cet appareil numérique de la classe B est con-

forme à la norme NMB-003 du Canada.

Problem Cause Solution

Nothing

appears in

the display.

The hand-

set is not

switched

on.

The batter-

ies are

empty.

Press the end call

key a for approx.

5 seconds or place the

handset in the base

station.

Charge or replace the

batteries.

No wireless

connection

to the base

station,

Base search

flashes in

the display.

The hand-

set is out-

side the

range of

the base

station.

Move the handset

closer to the base

station.

The base

station is

not turned

on.

Check the mains con-

nector on the base sta-

tion ¢ page 5.

No wireless

connection

to the base

station,

HS flashes

in the dis-

play.

The hand-

set is not

registered

¢ page 13.

You cannot

hear a

ringer/dial-

ing tone

from the

fixed line

network.

The phone

cord sup-

plied has

not been

used or

has been

replaced

by a new

cord with

the wrong

jack con-

nections.

Please always use the

phone cord supplied or

ensure that the

pin connections are

correct when purchas-

ing from a retailer.

Error tone

sounds after

system PIN

prompt.

PIN forgot-

ten.

The sys-

tem PIN

you have

entered is

incorrect.

Reset the system PIN to

the default 0000 using

the software reset

¢ page 15.

All handsets are

de-registered. All set-

tings are reset. All lists

are deleted.

A490/A495

NAM

A31008

M2200

R301

3S19

2012

FCC / ACTA Information

Warning: Changes or modifications to this unit

not expressly approved by Gigaset Communica-

tions USA LLC could void the FCC authority to

operate the equipment. This includes the addi-

tion of any external antenna device.

This equipment complies with Part 68 of the FCC

rules and the requirements adopted by the ACTA.

On the bottom of the base station is a label that

contains, among other information, a product

identifier in the format US:AAAEQ##TXXXX. If

requested, this number must be provided to the

telephone company.

A plug and jack used to connect this equipment

to the premises wiring and telephone network

must comply with the applicable FCC Part 68 rules

and requirements adopted by the ACTA.

A compliant telephone cord and modular plug is

provided with this product. It is designed to be

connected to a compatible modular jack that is

also compliant. See installation instructions for

details.

The REN is used to determine the number of

devices that may be connected to a telephone

line. Excessive RENs on a telephone line may result

in the devices not ringing in response to an

incoming call. In most but not all areas, the sum of

RENs should not exceed five (5.0). To be certain of

the number of devices that may be connected to

a line, as determined by the total RENs, contact

the local telephone company. For products

approved after July 23, 2001, the REN for this

product is part of the product identifier that has

the format US:AAAEQ##TXXXX. The digits repre-

sented by ## are the REN without a decimal point

(e.g., 03 is a REN of 0.3). For earlier products, the

REN is separately shown on the label.

A copy of the supplier's Declaration of Conformity

(SDoC) is available at this Internet address:

www.gigaset.com/docs.

If this equipment causes harm to the telephone

network, the telephone company will notify you

advance, that temporary discontinuance of serv-

ice may be required. But if advance notice isn’t

practical, the telephone company will notify the

customer as soon as possible. Also, you will be

advised of your right to file a complaint with the

FCC if you believe it is necessary.

The telephone company may make changes in its

facilities, equipment, operations or procedures

that could affect the operation of the equipment.

If this happens the telephone company will pro-

vide advance notice in order for you to make nec-

essary modifications to maintain uninterrupted

service. If you experience trouble with this tele-

phone system, disconnect it from the network

until the problem has been corrected or until you

are sure that the equipment is not malfunction-

ing.

If trouble is experienced with this equipment, for

repair or warranty information, please contact

Support at 1-866 247-8758. If the equipment is

causing harm to the telephone network, the tele-

phone company may request that you disconnect

the equipment until the problem is resolved. This

equipment is of a type that is not intended to be

repaired by the Customer (user).

This telephone system may not be used on coin

service provided by the telephone company. Con-

nection to party line service is subject to state tar-

iffs. Contact the state public utility commission,

public service commission or corporation com-

mission for information. Privacy of communica-

tions may not be ensured when using this phone.

If your home has specially wired alarm equipment

connected to the telephone line, ensure the

installation of this equipment does not disable

your alarm equipment. If you have questions

about what will disable alarm equipment, consult

your telephone company or a qualified installer.

This telephone system equipment has been

tested and found to comply with the limits for

Class B digital device, pursuant to Part 15 of the

FCC Rules. Operation is subject to the following

two conditions: (1) This device may not cause

harmful interference, and (2) This device must

accept any interference received, including inter-

ference that may cause undesired operation.

These limits are designed to provide reasonable

protection against harmful interference in a resi-

dential installation. Some cordless telephones

operate at frequencies that may cause interfer-

ence to nearby TV’s and VCR’s; to minimize or pre-

vent such interference, the system base should

not be placed near or on top of a TV or VCR; and, if

interference is experienced, moving the base far-

ther away from the TV or VCR will often reduce or

eliminate the interference.

However, there is no guarantee that interference

will not occur in a particular installation. If this tel-

ephone system does cause harmful interference

to radio or television reception, which can be

determined by turning the system off and on, the

user is encouraged to try to correct the interfer-

ence by one or more of the following measures:

1. Reorient or relocate the receiving antenna.

2. Increase the separation between the base sta-

tion and receiver.

3. Connect the base station into an outlet on a cir-

cuit different from that to which the receiver is

connected.

4. Consult the dealer or an experienced radio TV

technician for help.

Notice for Direct Inward Dialing ("DID")

ALLOWING THIS EQUIPMENT TO BE OPERATED IN

SUCH A MANNER AS TO NOT PROVIDE FOR

PROPER ANSWER SUPERVISION IS A VIOLATION

OF PART 68 OF THE FCC‘S RULES.

Notice to Hearing Aid Wearers:

This phone system is compatible with inductively

coupled hearing aids.

A490/A495

NAM

A31008

M2200

R301

3S19

2012

Power Outage:

In the event of a power outage, your cordless

telephone will not operate. The cordless tele-

phone requires electricity for operation. You

should have a telephone that does not require

electricity available for use during power outages.

Notice:

The installation of the base unit should allow

at least 8 inches between the base and persons to

be in compliance with FCC RF exposure guide-

lines.

For body worn operation, the portable part

(handset) has been tested and meets FCC RF

exposure guidelines. Use with an accessory that

contains metal parts may not ensure compliance

with FCC RF exposure guidelines.

Notice to telephone company service:

If you need service from your telephone company,

please provide them with the information

Facility interface Code (FIC)

Service Order Code (SOC)

Universal Service Order Code (USOC)

as indicated on the label on the bottom side of the

base station.

Safety precautions

Before using your telephone equipment, basic

safety instructions should always be followed to

reduce the risk of fire, electric shock and injury to

persons.

1. Read and understand all instructions.

2. Follow all warnings and instructions marked on

the product.

3. Unplug this product from the wall telephone

jack and power outlet before cleaning. Do not use

liquid cleaners or aerosol cleaners. Use damp

cloth for cleaning.

4. Do not use this product near water, for example,

near a bathtub, wash bowl, kitchen sink, or laun-

dry tub, in a wet basement or near a swimming

pool.

5. Place this product securely on a stable surface.

Serious damage and/or injury may result if the

unit falls.

6. Slots or openings in the cabinet and the back

and bottom are provided for ventilation, to pro-

tect it from overheating. These openings must not

be blocked or covered. This product should never

be placed near or over a radiator or heat register,

or in a place where proper ventilation is not pro-

vided.

7. This product should be operated only from the

type of power source indicated on the marking

label. If you are not sure of the type of AC line

power to your home, consult your dealer or local

power company.

8. Do not place objects on the power cord. Install

the unit where no one can step or trip on the cord.

9. Do not overload wall outlets and extension

cords as this can result in the risk of fire or electric

shock.

10. Never push objects of any kind into this prod-

uct through cabinet slots as they may touch dan-

gerous voltage points or short out parts that

could result in the risk of fire or electric shock.

Never spill liquid of any kind on this product.

11. To reduce the risk of electric shock or burns, do

not disassemble this product. Take it to a qualified

service center when service is required. Opening

or removing covers may expose you to dangerous

voltages, dangerous electrical current or other

risks. Incorrect reassembly can cause electric

shock when the appliance is subsequently used.

Disconnect TNV circuit connector before remov-

ing cover.

12. Unplug the product from the wall outlet and

refer servicing to qualified service personnel

under the following conditions:

a.) When the power cord is damaged or frayed.

b.) If liquid has been spilled into the product.

c.) If the product has been exposed to rain or

water.

d.) If the product does not operate normally by

ing the operating instructions. Adjust only

those controls

that are covered by the operating

instructions because improper adjustment of

other controls may result in damage and may

require extensive work by a qualified technician

to restore the product to normal operation.

e.) If the product has been dropped or physically

has been damaged.

f.) If the product exhibits a distinct change in per-

formance.

13. Avoid using a telephone (other than a cordless

type) during a thunderstorm. There may be a

remote risk of electrical shock from lightning.

Therefore we suggest a surge arrestor.

14. Do not use the telephone to report a gas leak

in the vicinity of the leak.

15. Emergency/911 numbers may not be dialed if

the keypad is locked.

16. Minimum No. 26 AWG telecommunication line

cord must be used with this phone.

A490/A495

NAM

A31008

M2200

R301

3S19

2012

BATTERY SAFETY PRECAUTIONS

To reduce the risk of fire, injury or electric shock,

and to properly dispose of batteries, please read

and understand the following instructions.

CONTAINS NICKEL METAL HYDRIDE BATTERY. BAT-

TERY MUST BE RECYCLED OR DISPOSED OF PROP-

ERLY. DO NOT DISPOSE OF IN MUNICIPAL WASTE.

1. Only use the batteries specified for use with this

product.

2. DO NOT USE NICKEL CADMIUM OR LITHIUM

BATTERIES, or mix batteries of different sizes or

from different manufacturers in this product. DO

NOT USE NONRECHARGEABLE BATTERIES.

3. Do not dispose of the batteries in a fire; the cells

may explode. Do not expose batteries to water.

Check with local codes for special disposal

instructions.

4. Do not open or mutilate the batteries. Released

electrolyte is corrosive and may cause damage to

the eyes or skin. The electrolyte may be toxic if

swallowed.

5. Exercise care in handling the batteries in order

not to short the batteries with conducting materi-

als such as rings, bracelets, and keys. The batteries

or conducting material may overheat and cause

burns or fire.

6. Charge the batteries provided with, or identi-

fied for use with, this product only in accordance

with the instructions and limitations specified in

the user’s manual. Do not attempt to charge the

batteries with any means other than that speci-

fied in the users manual.

7. Periodically clean the charge contacts on both

the charger and handset.

A490/A495

NAM

A31008

M2200

R301

3S19

2012

Service (Customer Care)

Customer Care Warranty for Cordless Products

To obtain Customer Care Warranty service,

product operation information, or for problem resolution, call:

Toll Free: 1-866 247-8758

End-user limited warranty

This product is covered by a one year limited war-

ranty. Any repair replacement or warranty service,

and all questions about this product should be

directed to: 1-866 247-8758.

This limited, non-transferable warranty is pro-

vided to the original buyer/end-consumer ("you")

for systems, handsets and accessories (collec-

tively, "Product") provided by Gigaset Communi-

cations USA LLC or Gigaset Communications Can-

ada Inc. (collectively "Gigaset NAM"). Gigaset

NAM warrants to you that at the date of purchase,

the Product is free of defects in workmanship and

materials and the software included in the Prod-

uct will perform in substantial compliance to its

program specifications.

1. WARRANTY PERIOD

The Product warranty period is one (1) year from

the original date of purchase by you. Proof of pur-

chase (e.g., sales slip or invoice) must be provided

with any Product returned during the warranty

period. Batteries supplied with the Products are

warranted to be free from defects at the time of

purchase only.

2. EXCLUSIVE REMEDY

Gigaset NAM's entire liability and your exclusive

remedy if the Product is defective in materials or

workmanship during the warranty period and is

returned shall be that the Product will be repaired

or replaced as set forth in Section 4 below. Recon-

ditioned replacement components, parts or

materials may be used in the replacement or

repair. Data in the memory of the Product may be

lost during repair.

3. THIS LIMITED WARRANTY DOES NOT

COVER AND IS VOID WITH RESPECT TO

THE FOLLOWING:

– Cosmetic damage, physical damage to the

surface of the Product, including, without lim-

itation, breakage, cracks, dents, scratches or

adhesive marks on the LCD screen or outside

casing of the Product.

– Products which have been repaired, main-

tained or modified (including the antenna) by

anyone other than Gigaset NAM or a Gigaset

NAM-approved repair facility, or that have

been improperly installed.

– Cost of installation, removal or reinstallation.

– Damage due to any telephone, electronic,

hardware or software program, network,

Internet or computer malfunctions, failures,

or difficulties of any kind, including without

limitation, server failure or incomplete, incor-

rect, garbled or delayed computer transmis-

sions.

– Equipment and components not manufac-

tured, supplied or authorized by Gigaset

NAM.

– Modification of the Product's components, or

operation of the Product in an unsuitable

environment or in a manner for which it is not

intended, including but not limited to failures

or defects caused by misuse, abuse, accidents,

physical damage, abnormal operation,

improper handling or storage, neglect, altera-

tions, unauthorized installation, removal or

repairs, failure to follow instructions, prob-

lems caused by the carrier's network cover-

age, exposure to fire, water or excessive mois-

ture or dampness, floods, or extreme changes

in climate or temperature, acts of God, riots,

acts of terrorism, spills of food or liquids,

viruses or other software flaws introduced

into the Product or other acts which are not

the fault of Gigaset NAM and which the Prod-

uct is not specified to tolerate, including dam-

age caused by mishandling or blown fuses.

– Products which have had warranty stickers,

electronic serial number and/or serial number

label removed, altered, rendered illegible or

fraudulently applied to other equipment.

– Signal reception problems (unless caused by

defect in material or workmanship in the

Product).

– Products operated outside published maxi-

mum ratings.

– Performance of the Products when used in

combination with other products or equip-

ment not manufactured, supplied or author-

ized by Gigaset NAM.

– Consumables (such as batteries and fuses).

– Payments for labor or service to representa-

tives or service centers not authorized to per-

form product maintenance by Gigaset NAM.

– Loss of data.

– Testing and examination discloses that the

alleged defect or malfunction in the Product

does not exist.

A490/A495

NAM

A31008

M2200

R301

3S19

2012

This warranty does not cover customer education,

instruction, installation or removal, set up adjust-

ments, problems related to service(s) provided by

a carrier or other service provider, and/or signal

reception problems. Gigaset NAM shall not be

responsible for software, firmware, information,

or memory data contained in, stored on, or inte-

grated with any Products returned for repair,

whether under warranty or not. This warranty is

valid only in the country in which it is purchased

(i.e., the United States of America or Canada

respectively, but not both).

USE WITH ACCESSORIES NOT SUPPLIED

BY GIGASET NAM OR NOT OTHERWISE

EXPRESSLY AUTHORIZED BY GIGASET

NAM MAY VOID WARRANTY.

4. WARRANTY CLAIM PROCEDURE

All warranty claims must be made by notifying

Gigaset NAM prior to the expiration of the war-

ranty period. Gigaset NAM's obligation to provide

warranty support shall not extend past the end of

the warranty period, except that any product

repaired or replaced during the warranty period

shall continue to be warranted for the balance of

such warranty period or thirty (30) days, which-

ever is greater.

Support service will be provided for you by

accessing the toll free customer service number:

1-866 247-8758

5. LIMITATION OF WARRANTY

Gigaset NAM makes no warranty or representa-

tion that the software in the Products will meet

your requirements or will work in combination

with any hardware or applications software prod-

ucts provided by third parties, that the operation

of the software will be uninterrupted or error free,

or that all defects in the software products will be

corrected.

6. LIMITATION ON REMEDIES; NO

CONSEQUENTIAL OR OTHER DAMAGES

Your exclusive remedy for any breach of this lim-

ited warranty is as set forth above. Except for any

refund elected by Gigaset NAM, YOU ARE NOT

ENTITLED TO ANY DAMAGES, INCLUDING BUT

NOT LIMITED TO CONSEQUENTIAL DAMAGES,

if the Product does not meet the limited warranty

, and, to the maximum extent allowed by applica-

ble law, even if any remedy fails of its essential

purpose. The terms below ("Exclusion of Inciden-

tal, Consequential and Certain Other Damages")

are also incorporated into this limited warranty .

Some states/jurisdictions/provinces do not allow

the exclusion or limitation of incidental or conse-

quential damages, so the above limitation or

exclusion may not apply to you. This limited war-

ranty gives you specific legal rights. You may have

others which vary from state/jurisdiction/prov-

ince to state/jurisdiction/province.

7. DISCLAIMER OF WARRANTIES

GIGASET NAM AND ITS SUPPLIERS PROVIDE THE

PRODUCT AND SUPPORT SERVICES (IF ANY) AS IS

AND WITH ALL FAULTS. THE LIMITED WARRANTY

IS IN LIEU OF ANY OTHER EXPRESS WARRANTIES

(IF ANY) CREATED BY ANY DOCUMENTATION OR

PACKAGING EXCEPT FOR THE LIMITED WAR-

RANTY, AND TO THE MAXIMUM EXTENT PERMIT-

TED BY APPLICABLE LAW IS IN LIEU OF ANY

IMPLIED OR STATUTORY WARRANTIES, INCLUD-

ING, BUT NOT LIMITED TO, THE IMPLIED WARRAN-

TIES OF MERCHANTABILITY AND FITNESS FOR A

PARTICULAR PURPOSE, OF ACCURACY OR COM-

PLETENESS OR RESPONSES, OF RESULTS, OF

WORKMANLIKE EFFORT, OF LACK OF VIRUSES

AND OF LACK OF NEGLIGENCE, ALL WITH REGARD

TO THE PRODUCT, AND THE PROVISION OF OR

FAILURE TO PROVIDE SUPPORT SERVICES. ALSO,

THERE IS NO WARRANTY OR CONDITION OF TITLE,

QUIET ENJOYMENT, QUIET POSSESSION, OR COR-

RESPONDENCE TO DESCRIPTION OR NONIN-

FRINGEMENT WITH REGARD TO THE PRODUCT.

Some states/jurisdictions/provinces do not allow

limitations on how long an implied warranty lasts

or the exclusion or limitation of incidental or con-

sequential damages, so the above exclusions or

limitations may not apply to you. If an implied

warranty or condition is created by your state/

province and federal or state/provincial law pro-

hibits disclaimer of it, you also have an implied

warranty or condition, BUT ONLY AS TO DEFECTS

DISCOVERED DURING THE PERIOD OF THIS LIM-

ITED WARRANTY (ONE YEAR). AS TO ANY DEFECTS

DISCOVERED AFTER THE ONE YEAR PERIOD,

THERE IS NO WARRANTY OR CONDITION OF ANY

KIND. This limited warranty gives you specific

legal rights, and you may also have other rights

which vary from state to state/province to prov-

ince. In no event shall Gigaset NAM's liability

exceed the cost of repairing or replacing defective

Products as provided herein, and any such liabili-

ties will terminate upon expiration of the war-

ranty period.

Any supplements or updates to the Product or the

software in the Product, including without limita-

tion, any (if any) software fixes or upgrades or bug

fixes provided to you after the expiration of the

one year limited warranty period are not covered

by any warranty or condition, express, implied or

statutory.

A490/A495

NAM

A31008

M2200

R301

3S19

2012

8. EXCLUSION OF INCIDENTAL,

CONSEQUENTIAL AND CERTAIN OTHER

DAMAGES

TO THE MAXIMUM EXTENT PERMITTED BY APPLI-

CABLE LAW, IN NO EVENT SHALL GIGASET NAM,

SELLER OR THEIR SUPPLIERS BE LIABLE FOR ANY

SPECIAL, INCIDENTAL, INDIRECT, OR CONSE-

QUENTIAL DAMAGES WHATSOEVER (INCLUDING,

BUT NOT LIMITED TO, DAMAGES FOR LOSS OF

PROFITS OR CONFIDENTIAL OR OTHER INFORMA-

TION, FOR BUSINESS INTERRUPTION, FOR PER-

SONAL INJURY, FOR LOSS OF PRIVACY, FOR FAIL-

URE TO MEET ANY DUTY INCLUDING OF GOOD

FAITH OR OF REASONABLE CARE, FOR NEGLI-

GENCE, AND FOR ANY OTHER PECUNIARY OR

OTHER LOSS WHATSOEVER) ARISING OUT OF OR

IN ANY WAY RELATED TO THE USE OF OR INABIL-

ITY TO USE THE PRODUCT, THE PROVISION OF OR

FAILURE TO PROVIDE SUPPORT SERVICES, OR

OTHERWISE UNDER OR IN CONNECTION WITH

ANY PROVISION OF THIS LIMITED WARRANTY,

EVEN IN THE EVENT OF THE FAULT, TORT (INCLUD-

ING NEGLIGENCE), STRICT LIABILITY, BREACH OF

CONTRACT OR BREACH OF WARRANTY OF

GIGASET NAM OR SELLER OR ANY SUPPLIER, AND

EVEN IF GIGASET NAM OR SELLER OR ANY SUP-

PLIER HAS BEEN ADVISED OF THE POSSIBILITY OF

SUCH DAMAGES. REPAIR OR REPLACEMENT, AS

PROVIDED UNDER THE WARRANTY, IS YOUR SOLE

AND EXCLUSIVE REMEDY FOR BREACH OF THE

LIMITED WARRANTY.

9. LIMITATION OF LIABILITY AND

REMEDIES

NOTWITHSTANDING ANY DAMAGES THAT YOU

MIGHT INCUR FOR ANY REASON WHATSOEVER

(INCLUDING, WITHOUT LIMITATION, ALL DAM-

AGES REFERENCED ABOVE AND ALL DIRECT OR

GENERAL DAMAGES), THE ENTIRE LIABILITY OF

GIGASET NAM, SELLER AND ANY OF THEIR SUP-

PLIERS UNDER ANY PROVISION OF THIS LIMITED

WARRANTY AND YOUR EXCLUSIVE REMEDY FOR

ALL OF THE FOREGOING (EXCEPT FOR ANY REM-

EDY OF REPAIR OR REPLACEMENT ELECTED BY

GIGASET NAM OR SELLER OR SUPPLIER WITH

RESPECT TO ANY BREACH OF THE LIMITED WAR-

RANTY) SHALL BE LIMITED TO THE GREATER OF

THE AMOUNT ACTUALLY PAID BY YOU FOR THE

PRODUCT OR FIVE DOLLARS ($5.00 USD/CAN).

THE FOREGOING LIMITATIONS, EXCLUSIONS AND

DISCLAIMERS SHALL APPLY TO THE MAXIMUM

EXTENT PERMITTED BY APPLICABLE LAW, EVEN IF

ANY REMEDY FAILS ITS ESSENTIAL PURPOSE.

10. GOVERNING LAW

If this Product was purchased in the United States

of America this limited warranty will be governed

by the laws of Texas, and exclude the United

Nations Convention on Contracts for the Interna-

tional Sale of Goods. If this Product was purchased

in Canada this limited warranty will be governed

by the laws of the Province of Ontario and the fed-

eral laws of Canada applicable therein, and

exclude the United Nations Convention on Con-

tracts for the International Sale of Goods.

If you want to learn more about Gigaset Service or

for Support on your Gigaset phone, visit our web

site at http://www.gigaset.com or please call

1-866 247-8758.

Issued by

Gigaset Communications GmbH

Frankenstr. 2a, D-46395 Bocholt

Subject to availability. Rights of modifications

reserved.

Product attributes subject to change.

We reserve the right, to make changes without

notice in equipment design and/or components.

Part Number: A31008-M2200-R301-5-3S19

A490/A495

NAM

A31008

M2200

R301

3S19

2012

Menu tree

Your phone has an extensive range of fea-

tures. These are offered in the form of

menus.

To select a function while the phone is in

idle state, press MENU (open menu), use

the t and v keys to scroll to the function

you require and press OK to confirm.

To return to idle state: press the a key.

Alarm Clock

Activation Activating/deactivating the alarm clock

Wake-up time Input format: HHMM,

change am/pm by pressing P or #

Audio Settings

Handset Volume Earpiece 3 levels available

Speaker 5 levels available

Ringer Volume 5 levels + "Crescendo" available

Ringer Melody External Calls 10 melodies available

Internal Calls 10 melodies available

Alarm Clock 10 melodies available

Advis. Tones Switch advisory tones (e.g. positive or negative confirma-

tion, key tones) on or off.

VoiceMail

Set Key 1

(all devices)

Netw. Mailbx Assign key 1 with network mailbox and enter

the network mailbox number (in idle state, press

and hold key 1 to dial).

Netw. Mailbx: your network provider's answering

machine; must be requested separately. The net-

work mailbox list can display if your network pro-

vider supports this function and if key 1 has

been assigned with the network mailbox.

(Devices

with answering

machine only)

Answer Mach. Assign key 1 with answering machine

(in idle state, press and hold to dial).

Answer Mach. Activating/deactivating the answering machine

Call Screening Handset You can use the speaker on the handset to screen a

message that is being recorded.

Base You can use the speaker on the base station to

screen a message that is being recorded.

Announcements Rec announce ¢ page 12

Play announce Play your announcement

Del announce Delete your announcement

A490/A495

NAM

A31008

M2200

R301

3S19

2012

Message Length Maximum No limit per call (overall recording time up to

12 minutes).

1 Minute Limit the recording time to 1 minute per call.

2 Minutes Limit the recording time to 2 minutes per call.

3 Minutes Limit the recording time to 3 minutes per call.

Ring Delay Immediately Call is answered immediately.

10 sec Call is answered after 10 seconds.

18 sec Call is answered after 18 seconds.

30 sec Call is answered after 30 seconds.

Auto If there are no new messages, the answering

machine answers a call after 18 seconds. If new

messages are present, the answering machine

answers a call after just 10 seconds.

Language Set the language for answering machine messages.

Delete all old ¢ page 12

Settings

Date/Time Enter date (MMDDYY format), then time (HHMM format, change am/pm by

pressing P or #) ¢ page 8

Handset Language (English,

Spanish or French)

Set the display language ¢ page 15

Auto Answer Automatically activate/deactivate auto answer

¢ page 9

Call list type Missed Calls ¢ page 11

All Calls ¢ page 11

Reset Handset Reset the handset ¢ page 15

Base Audio Settings (A495

only)

Ringer Volume 5 levels + Cres-

cendo available

Ringer Melody 10 melodies avail-

able

System PIN Change system PIN (default is 0000)

Base Reset Restore factory settings ¢ page 15

Additional Eco Mode Activating/

deactivating

¢ page 2

Listening in Activate/deactivate the function ¢ page 14

Dialling Mode Tone dialling ¢ page 15

Pulse ¢ page 15

Recall Set the current flash time ¢ page 15

A490/A495

NAM

A31008

M2200

R301

3S19

2012

Issued by

Gigaset Communications GmbH

Frankenstr. 2a

D-46395 Bocholt

Rights of modification reserved.

www.gigaset.com

A31008-M2200-R301-5-3S19

Gigaset A490 A495 User Guide A390

Navigation menu

Versions of this User Manual:

Views

Navigation
