Users Manual

TomTom Wireless GPS MkII Specification & Guide
Edition: Draft 04 Page 1 of 3 18 Jan 2005
Copyright ©2005 TomTom B.V. All rights reserved.
TomTom® is a registered trademark of Palmtop B.V., The Netherlands.
BLUETOOTH is a trademark owned by Bluetooth SIG, Inc., U.S.A. and licensed to TomTom B.V.
The information in this document is subject to change without notice. TomTom B.V. shall not be liable for technical or
editorial errors or omissions contained herein; not for incidental or consequential damages resulting from the performance
or use of this material. This document contains information protected by copyright. No part of this document may be
photocopied or reproduced in any form without prior written consent from TomTom B.V.
Edition: Draft 04
! Important Regulatory Information
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. End users must
follow the specific operating instructions for satisfying RF exposure compliance. This transmitter must not be co-located
or operating in conjunction with any other antenna or transmitter.
Notice: Any changes or modification not expressly approved by the party responsible could void the user’s
authority to operate the device.
This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received, including interference that may cause undesired operation
This Class B digital apparatus complies with Canadian ICES-003.
Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada
TomTom Wireless GPS MkII Specification & Guide
Edition: Draft 04 Page 2 of 3 18 Jan 2005
Important Safety Notices and Warnings
Global Positioning System
The Global Positioning System (GPS) is a satellite-based system that provides location and timing information around the
globe. GPS is operated and controlled under the sole responsibility of the Government of the United States of America, who
are responsible for its availability and accuracy. Any changes in GPS availability and accuracy may impact the operation of
your GPS receiver. Environmental conditions will affect the operation of your GPS receiver. TomTom B.V. cannot accept
any liability for the availability and accuracy of GPS.
Use With Care
Use of a GPS receiver for navigation does not by any means substitute for the need to drive with due care and attention.
Aircraft and Hospitals
Use of devices with an antenna is prohibited on most aircraft, in many hospitals and in many other locations. The TomTom
Wireless GPS receiver must not be used in these environments.
Heat Reflective Shields
Newer model vehicles may have a heat reflective shield embedded in the windshield preventing proper GPS signal
reception if the receiver is placed behind the windshield. To enable proper reception:
(a) Place the receiver in a different position, or
(b) Place the receiver behind the rear view mirror, where many vehicles have an opening in the heat reflective shield,
indicated by a black outline
Battery
This product uses a Lithium-Ion battery. Please charge the battery fully before first use. Refer to operational temperature
ranges in the specification appendix. Operation in low (below 0ºC/32ºF) or high (over 45ºC/110ºF) temperatures will affect
power supply efficiency and the ability to charge the battery. All Lithium-Ion batteries will experience power supply efficiency
deterioration over time, even if not used, and have a limited life expectancy. Permanently powering the battery will reduce
life expectancy. Do not continue recharging the battery if it does not recharge within the specified time. Do not pierce, open
or disassemble the battery. Do not swallow the battery. If the battery leaks and you come into contact with the leaked fluids,
rinse thoroughly with water and seek medical attention immediately.
Do not use your product in a humid, wet and/or corrosive environment. Do not put, store or leave your product in or near a
heat source; in a high temperature location; in strong direct sunlight; in a microwave oven; in a pressurized container, and
do not expose it to temperatures over 60ºC (140ºF). Failure to follow these guidelines may cause the Lithium-Ion battery to
leak acid; become hot; explode; or ignite and cause injury and/or damage.
THE LITHIUM-ION BATTERY CONTAINED IN THE PRODUCT MUST BE RECYCLED OR
DISPOSED OF PROPERLY. USE ONLY WITH SUPPLIED CHARGER(s) AND SUPPLIED AC
ADAPTOR FOR BATTERY CHARGING.
Installation, Use & Maintenance
Do not attempt to service this product yourself. Do not open, puncture or disassemble the product.
Ensure that the GPS receiver has an unobstructed view of the sky. Protect your product from excessive heat (see previous
paragraph), extreme cold (see previous paragraph), dust, liquids and direct sunlight. Do not use in a humid environment. Do
not use the product on an unstable surface. When using the product in a mobile environment always fasten the product to
prevent accidental movement of it. Handle all parts, cables and connectors with care. Only use supplied and suggested
accessories and power supplies. Ensure that any power supply and/or AC adapter is cooled by placing it in a ventilated
area. The power supply and/or AC adapter and the receiver unit may become warm or hot during operation. Unplug the
product from any external power source before cleaning. Only clean the product with a dry cloth. Follow the instructions in
this manual carefully.
TomTom Wireless GPS MkII Specification & Guide
Edition: Draft 04 Page 3 of 3 18 Jan 2005
Operation
Specification
On/Off button Press & hold for 1s to switch on/off
Press & hold for 3s to perform reset
Green LED GPS Status Solid on: Acquiring GPS Fix
Flashing Green: Has GPS Fix
User interface
Red/Amber LED Power
Status Solid Red: Battery Low
Solid Amber: Battery charging
Bluetooth
connection Please refer to the Bluetooth connection setup instructions in the documentation that comes with
your PDA, Smartphone or laptop. You will need to set up a Serial Port connection between the
GPS receiver and your device. The GPS receiver will appear to your device as the “TomTom
Wireless GPS MkII” and its GPS signal will be output on its “GPS serial output”. To ensure ease of
use, create a Bluetooth bond between your device and the GPS receiver. The pairing code is
0000. Please check specific device setup information on our support pages at www.tomtom.com.
Configuring your
software
After setting up the Bluetooth connection, you will need to modify the properties of the software on
your PDA, Smartphone or laptop to use the GPS signal from the GPS receiver. Please refer to the
documentation of your device, and of your software. Choose the NMEA protocol.
Size 87.8 x 43.0 x 15.1 mm Mechanical
Weight 68g
Battery 1200mAh Lithium Ion built-in cell
Battery life 10hours typical use
Charge time Less than 4 hours
Power
Charging From CLA (cigarette lighter adaptor or AC Adaptor
Chipset SiRF Star III
Frequency L1, 1575.42MHz
C/A Code 1.023 MHz Chip Rate
Channels 20 channel all-in-view tracking
Tracking sensitivity -159dBm
Update rate 1Hz
Cold start <1 minute typical
Warm start <30 seconds typical
Hot start <10 seconds typical
Reacquisition time <1 second from max 30second blockage
Datum WGS-84
Protocol NMEA 0183 Version 2.2
GPS
Antenna Built-in omnidirectional antenna
Profile Serial Port Profile (SPP)
Class Class II Version 1.2
Bluetooth
Default PIN 0000
Storage Temperature -20 to +70 degrees Celsius
Operating Temperature -10 to +60 degrees Celsius
Humidity Up to 75% non-condensing
Drop 2m onto concrete
Environmental
Fluid & Dust Protection IP54
