BT-359 GPS User’s Guide

Bluetooth GPS Receiver

DOCUMENT REVISIONS

REV NO. DATE DESCRIPTION APPROVED

1.0 06-15-2006 Initial document BRF

1.1 07-21-2006 Conversion to USG text format AAK

1.2.1 09-01-2006 Modified text (Temp) AAK

trademark of GlobalSat Corporation. Windows is a register trademark of Microsoft Corporation. Acrobat is a

registered trademark of Adobe Systems Incorporated. Mac is a registered trademark of the Apple Corporation. All

other trademarks or registered trademarks are acknowledged as the exclusive property of their respective

owners.

medium, for any purpose, without prior written consent from GlobalSat Technology Corporation or USGlobalSat,

Inc. GlobalSat/USGlobalSat hereby grants the right to download one (1) copy of this manual onto a hard drive for

personal use. This manual is copyrighted and may contain proprietary information that is subject to change without

notice.

PAGE 2 OF 13 BT359_GPS_v1.2.1

BT-359 GPS

Table of Contents

PACKAGE CONTENTS..................................................................................................3

SYSTEM REQUIREMENTS ...........................................................................................3

WELCOME......................................................................................................................3

1. GETTING STARTED..................................................................................................4

2. THE BT-359................................................................................................................4

3. CHANGING THE BATTERY......................................................................................5

4. GPS FUNCTIONS......................................................................................................5

5. INITIALIZING YOUR GPS RECEIVER......................................................................7

6. USING / TESTING YOUR GPS RECEIVER (WIN / PPC only) ................................7

7. FAQ’s .........................................................................................................................9

8. CONTACT INFORMATION .....................................................................................10

9. SAFETY AND LEGAL NOTICES............................................................................10

10. LIMITED WARRANTY...........................................................................................11

11. BT-359 SPECIFICATIONS ....................................................................................12

PAGE 3 OF 13 BT359_GPS_v1.2.1

BT-359 GPS

PACKAGE CONTENTS

- Bluetooth GPS Receiver

- Driver CD-ROM with User’s Guide and test utility for WIN and Mac O/S*

- 12VDC vehicle cigarette lighter

- 110/240 0.2A VAC home/office charger (Euro AC Adapter sold separately #BT338-006A)

- USB charger interface cable

*Your can also download Installation Guides from: www.USGlobalSat.com

SYSTEM REQUIREMENTS

The GlobalSat Bluetooth GPS receivers requires a Bluetooth enabled device that can accept

accessory pairing, such as PDA’s, Smartphones, Laptops or Laptops with added Bluetooth USB

dongles.

Also a NMEA compatible navigation or map software for your operating system (O/S). Your 3rd party

mapping/navigation software may have its own system requirements, please check with software

vendor for details.

A computer with a CD-ROM drive is only required to view the Users Guide, or load the test utility

program for either Windows or Mac operating systems. These files and programs are also available for

download directly from our web-site at: http://www.USGlobalSat.com

WELCOME

Thank you for purchasing a GlobalSat Bluetooth GPS receiver! GlobalSat GPS receivers allow for real-time street

navigation by using your laptop for graphical plotting and positioning of your route. Simply pair the GPS receiver,

with your Bluetooth enabled device, install your own personal mapping software, and begin to view your position in

real-time in relation to the surrounding streets in your travel area.

You’ll find that almost any NMEA compliant mapping/charting software will be compatible with the data from your

GlobalSat Bluetooth GPS receiver.. Visit our web-site for recommended mapping programs that you can use.

http://www.USGlobalSat.com/faq_details/Mapchart.asp

PAGE 4 OF 13 BT359_GPS_v1.2.1

BT-359 GPS

1. GETTING STARTED

GlobalSat Bluetooth GPS receivers utilize a Bluetooth (short distance wireless protocol) and a built-in

active antenna for high signal tracking sensitivity. Based on the SiRF Star III Low Power chipset, our

GPS receivers support all functions (single sat updates in reduced visibility, superior urban canyon

performance, foliage lock for weak signal tracking, etc.). Our Bluetooth GPS receivers are well suited

for use with PDA’s, Smartphones, tablet PC’s and notebook PC’s and laptops which are already

Bluetooth enable. GPS receivers can be used in a wide variety of applications from in vehicle

navigation to and outdoor recreation and commercial applications.

2. THE BT-359

The BT-359W shown above and the BT359C (not shown) are models which can be found in North America, while

the BT-359S can also be found in Europe. There are no differences between these models with exception to the

cosmetic faceplate used. The “W” is a radio wave patter, the “C” is a glossy black faceplate, while the “S” has the

appearance of a solar cell graphic. Electronically they are the same device.

PAGE 5 OF 13 BT359_GPS_v1.2.1

BT-359 GPS

3. CHANGING THE BATTERY

1. Slide battery cover lock into the open UNLOCK position and lift up carefully on battery cover from

lock end at seam where cover meets the main GPS housing.

2. Use the pull tab to lift out Li-ion battery.

3. Replace battery making sure that the battery contact on the bottom side of battery touch the

contacts on the BT-359 within the battery compartment. (Pull tab should at the same end as the

battery cover lock)

4. Carefully hook the two catches of the battery cover to the GPS housing and gently close battery

cover.

5. Place battery cover lock into the “locked” position.

4. GPS FUNCTIONS

Turning the BT-359 ON / OFF

BT-359’s Power Button

Power ON:

Press the power button for 1 second until the power LED becomes lit.

Power OFF:

Press the power button 1 second until the power LED goes off.

Pull Tab

Cover Hooks Here

PAGE 6 OF 13 BT359_GPS_v1.2.1

BT-359 GPS

Power Jack

The mini-USB is a power jack that lets allows you to connect to either a DC vehicle charger or an AC

charger home/office charger for re-charging the internal Lithium-ion (Li-ion) battery. The voltage input

into the BT-359 must be 5VDC (01.6 A) center positive connector. You can also use the USB

interface cable to charge directly from your PC’s USB port. (The USB interface can only be used for

charging the GPS receiver’s battery and cannot be used to transfer data.) Upon powering your new

BT-359 GPS receiver for the first time it may require as much as 6 hours to fully charge, thereafter

charging times may be reduced. The built-in regulator will prevent your battery from being

overcharged, however it is always best to unplug the GPS receiver from the charger after charging has

completed and not to leave it connected for extended periods of time..

Status LED Functions

Power Status LED (Red/Yellow):

Red ---- Battery power is critically low. (charge immediately)

Yellow ---- Battery is currently charging .

LED off ---- Battery is charged (partial or full).

GPS Status LED (Green):

Blinking ---- GPS position is fixed (GPS signal is being received)

Steady light ---- GPS position is not fixed (no GPS signal)

Bluetooth Status LED (Blue):

Blinking (Slowly) ---- Not connected to a Bluetooth device.

Blinking (Quickly) ---- Connected to a Bluetooth device.

Auto Shut-Off (Power-Saving Mode)

To conserve battery life, whenever the GPS receiver does not detect a Bluetooth signal for over 10 minutes, the BT-

359 will automatically shut off, but only when operating from it’s internal Li-ion battery.

If connected to an external power source (AC or DC charger), then the BT-359 will remain on.

We strongly suggest that you first test your USG GPS with the included GPS Info utility program to confirm that the

GPS receiver if functioning properly on your PC and that you have successfully configured the right COM Port

setting. Once this has been done, close the GPS Info program and start your application for COM port

configuration.

NOTE: By default, your PC will not allow you to run multiple applications from a single COM port. It is important that

you close any previously opened GPS application before switching to another GPS application as the GPS receiver

and data will not be found by the new program.

There are special utilities available to split data into multiple COM ports for use by more than one application

simultaneously. (see: http://franson.com/gpsgate/ )

Mini-USB Power Port

(not for data transfer)

PAGE 7 OF 13 BT359_GPS_v1.2.1

BT-359 GPS

5. INITIALIZING YOUR GPS RECEIVER

Before using your Bluetooth GPS receiver for navigation (especially for the first time), the receiver must

obtain a local GPS fix (coordinates) of the current position. To do this, take your device loaded and

configured with your mapping software to an open area that has a clear view to the sky. Start your

software (or the included GPS Info utility program) and wait for initialization of the GPS to complete.

This may take a few minutes depending on various factors such as the distance of the current

coordinates from the last time the GPS receiver was activated, GPS signal strength and surrounding

terrain (tall trees and buildings can block the satellite signals). Once the RAW GPS data is displayed

onto the screen, if applicable for your software, a fix has been initialized (Green LED on the GPS will

also start to flash). In some cases initialization can take up to several minutes depending on the

conditions mentioned above before complete GPS data will be displayed on the screen.

Coordinates scrolling with zero’s means that the port connection is complete, but the satellite data is not

being received yet (possibly still initializing or in a bad area for satellite reception).

6. USING / TESTING YOUR GPS RECEIVER (WIN / PPC only)

Once your Bluetooth GPS receiver has been paired with your device and your personal mapping

software have been installed and the COM port configured properly, you can begin to use your

navigation system. If you don’t have a mapping, or navigation software to try out your new GPS

receiver, we’ve included a GPS test utilities called “GPS Info” (GPSInfo.exe) for Windows and Pocket

PC devices located in the Win directory and “GPS Utility” (Mac_GPS_Utiltiy_V2.dmg) is located in the

.Mac directory of the CD-ROM.

Both utilities can be download from our web-site www.USGlobalSat.com

Always select an area in the vehicle where the GPS unit will be secure and not obstruct normal driving,

visibility and safety, but still maintaining a “view to the sky” in order to receive satellite data.

WIN and PPC devices:

It is recommended that you first load and test your GPS receiver with the GPSinfo.exe. This process

will confirm you have found correct COM port number and have configured it properly.

1. Run GPSinfo.exe to load the utility.

2. Enter the proper COM port for your GPS device (see COM Port Verification above)

3. Set COM port to Baud rate: 34800

4. If no errors have been made in configuration, there should be GPS data being displayed in the

window, which is confirmation that the communication between the GPS device and the “GPSinfo”

software is working properly.

5. If there is no GPS data displayed (or data with multiple zeros in them), please exit the software and

unplug the GPS receiver from the USB port and reinsert it after 10 seconds to reset the device.

PAGE 8 OF 13 BT359_GPS_v1.2.1

BT-359 GPS

This screen shows the satellites being received (numbers) and their signal strengths.

NOTE: Configuration (or selection) of an assigned COM port for the GPS device from within your

mapping or charting software must be completed whenever using a software for the first time.

Mac Users: Mac users need to run the Mac_GPS_Utiltiy_V2.dmg located in the .Mac directory of the

CD-ROM or download the utility file from our web-site: www.USGlobalSat.com/mac

PAGE 9 OF 13 BT359_GPS_v1.2.1

BT-359 GPS

7. FAQ’s

What is the difference between the BT-359W and the BT-359S?

There is no difference between these two models with exception to the cosmetic faceplate used. The “W” is a radio

wave patter, while the “S” has the appearance of a solar cell. Internally they are the same device.

I am not getting GPS data into my application on my Windows PC.

1. Check your DEVICE MANAGER to confirm the COM Port number assigned to the GPS. Then be sure

this is the same COM port number configured in your application.

2. Be sure your Baud rate is configured correctly at:

Baud Rate: 38400

Data bit: 8

Parity: None

Stop Bit: 1

Flow Control: None

3. Configure the GPS Info utility with the correct COM Port and test your GPS receiver first before using it

in your application.

Will the GPS work with other Street Mapping software?

GlobalSat GPS receivers provides standard NMEA data for mapping software to use and convert to coordinates

and should work well with most any NMEA compliant software on the market today.

How accurate is the GPS?

The Gloablsat GPS is WAAS/EGNOS capable, and for units sold in North America through authorized resellers,

these units are WAAS/EGNOS enabled unless otherwise stated. Accuracy can be between 1~5 meters 2D RMS

with WAAS enabled and 10-15 meters 2D RMS WAAS disabled

What is ideal GPS environment?

The GPS requires an open, clear view of the sky. Buildings, covered parking areas, tunnels and dense foliage can

cause the GPS receiver to be unable to get a location fix.

If you are parked in a covered parking lot or near a tall building, it is recommended that you drive away until you

have a clear view of the sky before using the GPS receiver. You may need to give the GPS a few minutes to find or

get a fix its location.

How do I know if the GPS is ON?

If your PC is on and the COM port was configured properly, the GPS receiver is on and receiving the streaming

GPS data. This can be verified by opening your mapping software program. In addition, the GlobalSat GPS has a

built-in LED status indicator that shows the following:

LED OFF: GPS receiver is off (no power).

LED ON (solid): No fix, searching for GPS signals.

LED FLASHING: Position fix established and GPS signals are being received.

Why does the GPS not work near buildings and other tall objects?

The GPS uses satellites in the space to find out where it is. Therefore it needs a clear view of the sky. Tall buildings

and other objects that block the receiver’s view to the sky make it infeasible to determine your location. Sometimes

the satellites are not overhead but near the horizon. In these cases the GPS must have a clear view of the horizon.

Other Comments-

Please allow an adequate amount of time for the GPS receiver’s boot-up (TTF) to complete before contacting

Technical Support.

PAGE 10 OF 13 BT359_GPS_v1.2.1

BT-359 GPS

8. CONTACT INFORMATION

GlobalSat Technology Corporation (Taiwan)

www.GlobalSat.com.tw service@GlobalSat.com.tw

USGlobalSat, Inc.

www.USGlobalSat.com sales@GlobalSat.com (pre-sales GPS product questions only)

Technical Support (North America)

See our DOWNLOADS and FAQ section on our web-site for GPS solutions, driver literature updates.

http://www.USGlobalSat.com/custom.asp?recid=7

Pre-registration is required before receiving any type of technical support. Support issues submitted via

phone, fax or e-mail (any means outside of the recognized “Support Ticket” generated from your own

USGlobalSat registered account) may not be answered as quickly as with a “Support Ticket”.

Create your account and register your products at: www.USGlobalSat.com/support/custadminlogin.asp

9. SAFETY AND LEGAL NOTICES

Please read this section carefully before using the GPS receiver.

GlobalSat Technology Corporation / USGlobalSat, Inc. will not accept any responsibility whatsoever for

accidents resulting from failure to observe common sense precautions. Your personal judgment, traffic

regulations, and common sense must always take precedence over any directions produced by GPS

receiver or the mapping software

WARNING: Make sure that the GPS receiver is secure and does not interfere with driving visibility and

safety.

It is your responsibility as the vehicle operator to securely place the GPS unit and antenna so that they will not

interfere with driving and prevent operations of any safety device (such as the Airbag) in your vehicle. Do not

mount the devices in a place where the driver or passengers may receive injury during vehicle operation or collision.

For your safety, take care to route all cables away from shifters, pedals, accessory controls and mechanisms.

WARNING: Drive safely and use common sense.

It is your responsibility as the vehicle operator to drive safely, observe all traffic rules and above all use your own

personal judgment while driving. If you feel that a route suggested by the navigation software instructs you to

perform an unsafe or illegal maneuver, places you in an unsafe situation, or routes you into an area which you

consider unsafe, do not follow the instructions.

WARNING: Keep your eyes on the road.

It is your responsibility as the vehicle operator to keep your eyes on the road and be an alert driver at all times,

especially when the vehicle is moving. The vehicle’s operator should not be distracted by the navigation equipment

or software. Should there be a distraction with the ability to drive responsibly, please turn off the device. Should

you want to look at the display for a prolonged time, park the car safely, while following all traffic regulations before

looking at the display.

WARNING: To reduce the risk of fire or shock hazard, do not expose this product to rain or moisture. Do

not remove covers or open housings, there are no user serviceable parts inside. Refer servicing to

qualified personnel only.

PAGE 11 OF 13 BT359_GPS_v1.2.1

BT-359 GPS

10. LIMITED WARRANTY

GlobalSat/USGlobalSat warrants product hardware against manufacturing defects in material and workmanship

under normal use for a period of one (1) year from the original date of purchase (unless the product states

otherwise), and only when purchased from a recognized “authorized dealer”. Products purchased from any

unauthorized source, such as unauthorized e-Bay resellers, will not qualify for free warranty service/support and

may require the end-user to pre-pay fees associated with, but not limited to the support, repair, replacement and

shipping of the product to and from the service center.

Except as provided herein, GlobalSat/USGlobalSat makes no express warranties’, including but not limited to any

warranties of merchantability or fitness for particular use, or non-infringement. You acknowledge that your use of

the product or service is at your sole risk and you agree that the information provided are without warranty of any

kind by GlobalSat/USGlobalSat.

Under no circumstances, including negligence, will GlobalSat/USGlobalSat or any of its affiliates, directors, officers

or employees, or any third party be liable for any direct, indirect, incidental, special or consequential damages that

results from your use, or your inability to use, or the performance of the product(s) with respect to any liability, loss,

or arising out of any breach of this warranty, including, but not limited to any damages resulting from inconvenience,

loss of time, data, property, revenue, or profit or any indirect, special incidental or consequential damages. You

acknowledge that this limitation applies to all content information or other services available from

GlobalSat/USGlobalSat, and whether or not GlobalSat/USGlobalSat has notice of the possibility of such damages,

and whether or not to circumstances giving rise to such damages may have been within the control of

GlobalSat/USGlobalSat.

Some states do not allow the exclusion of certain warranties, so some of the above exclusions may not apply to

you. In those states, liability is limited to the fullest extent allowed by law By using the product(s), you agree to

indemnify GlobalSat/USGlobalSat and its parents, subsidiaries, affiliates, officers and employees and hold them

harmless from any and all claims and expenses, including reasonable attorney’s fees, asserted third party due to, or

arising out of your use of the service and the site.

In the event of a product defect during the first 30-days of the warranty period, you may return product and the sales

receipt as proof of purchase date to place of original purchase, or you may contact GlobalSat/USGlobalSat’s

Technical support via our web-site for a Return Merchandise Authorization (RMA) number for return to

manufacturer.

GlobalSat/USGlobalSat will, at its option, unless otherwise provided by law:

a.) Correct the defect by product repair without charge for parts and labor;

b.) Replace the product with one of the same or similar design; or

Refund the purchase price (only if purchased directly from USGlobalSat). All replaced parts and products, and

products on which a refund is made, become the property of GlobalSat/USGlobalSat. New or reconditioned parts

may be used in the performance of warranty service. Repaired or replaced parts and products are warranted for

the remainder of the original warranty period. You will be charged for repair or replacement of the product made

after the expiration of the warranty period.

This warranty does not cover:

a.) Damage or failure caused by or attributable to acts of God, abuse, accident, misuse, improper or

abnormal usage, failure to follow the instructions, improper installation or maintenance, alteration, lighting

or other incidence of excess voltage or current;

b.) Any repairs other than those provided by GlobalSat/USGlobalSat;

c.) Consumables such as fuses or batteries;

d.) Cosmetic damage;

e.) Transportation, shipping or insurance costs;

f.) Costs of product removal, installation, set-up service adjustment or reinstallation.

This warranty gives you specific legal rights, and you may also have other rights, which may vary from state to

state. Additional products bundled in this package not manufactured by GlobalSat/USGlobalSat will hold separate

warranties as expressed by the individual manufacturer of that product(s). Product specifications, functions and

features are subject to change without notice.

PAGE 12 OF 13 BT359_GPS_v1.2.1

BT-359 GPS

11. BT-359 SPECIFICATIONS

Electrical Characteristics (Receiver)

GPS Chipset SiRF Star III e/LP

Frequency L1, 1575.42 MHZ

C/A Code 1.023 MHz chip rate

Channels 20 all-in-view tracking

Sensitivity -159 dBm

Accuracy

Position Horizontal 1~ 5m 2D RMS WAAS enabled

10m 2D RMS WAAS disabled

Velocity 0.1m/sec 95% (SA off),

Time 1 micro-second synchronized to GPS time

WAAS Enabled for North America product s (USGlobalSat, Inc)

Datum

Datum WGS-84

Acquisition Rate

Hot start 1 sec., average (with ephemeris and almanac valid)

Warm start 38 sec., average (with almanac but not ephemeris)

Cold start 42 sec., average (neither almanac nor ephemeris)

Reacquisition 0.1 sec. average (interruption recovery time)

Protocol

GPS Protocol Default: NMEA 0183 (Secondary: SiRF binary)

GPS Output Data

SiRF binary >> position, velocity, altitude, status and control

NMEA 0183 MEA0183 V2.2 protocol, and supports

command: GGA, GSA, GSV, RMC, VTG, GLL v2.2 (VTG

and GLL are optional)

GPS transfer rate Software command setting (Default : 38400,n,8,1 for NMEA )

Connection Communication with host platform via Bluetooth Serial Port

Profile

Dynamic Condition

Acceleration Limit Less than 4g

Altitude Limit 18,000 meters (60,000 feet) max.

Velocity Limit 515 meters/sec. (1,000 knots) max.

Jerk Limit 20 m/sec3

Temperature

Operating 14°~ 140°F (-10°~ 60°C)

Storage -4°~ 158°F (-20°~ 70°C)

Humidity Up to 95% non-condensing

Power

Voltage 5V ±5%

Battery capacity 1100mAH

Battery Life 11 hours continuous use

Physical Characteristics

Dimension 3.23" x 1.61" x 0.53" (82 mm x 41 mm x 13.4 mm)

Due to continuous product improvements, all specifications are subject to change without notice.

FCC NOTICE

This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions:

(1) This device may not cause harmful interference, and

(2) This device must accept any interference received, including interference that may cause undesired operation.

FCC RF Exposure requirements:

This device and its antenna(s) must not be co-located or operation in conjunction with any other antenna or transmitter.

NOTE: THE MANUFACTURER IS NOT RESPONSIBLE FOR ANY RADIO OR TV INTERFERENCE CAUSED BY

UNAUTHORIZED MODIFICATIONS TO THIS EQUIPMENT. SUCH MODIFICATIONS COULD VOID THE USER'S

AUTHORITY TO OPERATE THE EQUIPMENT.

Globalsat Technology Bt 359 Users Manual BT359_GPS_v1.21

Globalsat BT-359 BT359_UserGuide

BT-359 to the manual 0ae58267-25be-4654-a8d8-e08cabb13a97

Navigation menu

Versions of this User Manual:

Views

Navigation
