FULL FUNCTION RADIO CONTROLLER
INSTRUCTION MANUAL
PREPARATION
The controller can be powered by either one of the following way:
1. Open the battery cover on the back of the controller, insert a 9V battery with
correct polarity shown in the battery compartment, then replace the battery cover.
2. Connect the controller through its DC-IN jack to a AC/DC adaptor with output of
9V, 250mA (not included).
OPERATION
The controller is to be used with other electronic devices that provide +5V signals.
Connect the controller to such devices through its RJ-11 connector. By receiving
signals via 4 pins of the RJ-11 jack from other devices, the controller will transmit
controlling signals to control various functions of R/C toys which work at the same
frequency of the controller and recognize the controlling signals from the controller.
