Good Way Technology WD6030 USB Z-Wave dongle User Manual WD6020 UserMan
Good Way Technology Co., Ltd. USB Z-Wave dongle WD6020 UserMan
(WD6020) UserMan
WD6020/WD6030/WD6031/WD6032
（USB Z-Wave
®
Dongle）
User’s Manual
1. Software Specification
▓
Generic Device Class：
GENERIC_TYPE_STATIC_CONYROLLER
▓
Specific Device Class：
SPECIFIC_TYPE_PC_CONTROLLER
▓
Command Classes：
COMMAND_CLASS_CONTROLLER_REPLICATION_V1
COMMAND_CLASS_BASIC_V1
COMMAND_CLASS_VERSION_V1
2. Hardware Specification
3. Installation
4. Product Specification
▓
Power：USB bus powered
▓
Interface：Compliant with USB 2.0 version
specification.
▓
Full speed USB data transmission rate up
to 12Mbps.
▓
Frequency：908.42(US)/868.42(EU)/
922.5 MHz (JP)
▓
Data Rate： 100 kbps
▓
Operation Range：Up to 100 feet
▓
Operation Temperature：0~40 degree
▓
Regulatory Approvals：FCC/CE/TELEC
Only for Android
5. You can scan the QR code .Download
and installation the Z-control APP.
6. Regulatory Compliance
FCC conditions
FEDERAL COMMUNICATIONS COMMISSION
INTERFERENCE STATEMENT
This equipment has been tested and found to comply
with the limits for a Class B digital device, pursuant to
part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful
interference in a residential installation. This equipment
generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with
the instructions, may cause harmful interference to
radio communications. However, there is no guarantee
that interference will not occur in a particular installation.
If this equipment does cause harmful interference to
radio or television reception, which can be determined
by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or
more of the following measures:
▓ Reorient or relocate the receiving antenna.
▓ Increase the separation between the equipment
and receiver.
▓ Connect the equipment into an outlet on a circuit
different from that to which the receiver is
connected.
▓ Consult the dealer or an experienced radio/ TV
technician for help.
CAUTION:
Any changes or modifications not expressly approved
by the grantee of this device could void the user's
authority to operate the equipment.
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received,
including interference that may cause undesired
operation.
CE
This equipment is in compliance with the requirements
of the following regulations: EN 55 022: CLASS B
WEEE Information
For EU (European Union) member users:
According to the WEEE (Waste electrical and electronic
equipment) Directive, do not dispose of this product as
household waste or commercial waste. Waste electrical
and electronic equipment should be appropriately
collected and recycled as required by practices
established for your country.
For information on recycling of this product,
please contact your local authorities, your
household waste disposal service or the shop
where you purchased the product.
20131106
