-1- - 2--3--4--5-
-6--7--8--9--10--11-
QQI
Mini Cloud P/T Camera
Model: U5886
Product Quick Guide
Version No.: 1.3
Before using the product, please read the guide carefully to avoid
any damages to the product in virtue of faulty operation or misuse.
Appearance
Photosensitive
induction
Lens
Microphone
Antenna
Thermo sensitive
induction
Micro SD card slot
SET key
Indicator light
Power adapter port
Installation Instructions
Download and install client-end APP
1.For iPhone/iPad client-end: open App Store， search
for “QQI”, click Download Link for downloading and
installation.
2. For Android client-end: enter “Google Play” Store,
search for “QQI”, click Download Link for downloading
and installation.
User registration
Please register a user after installing APP.
Connection with power
The standard DC5V power adapter is suitable for
connecting with power, and the indicator light of camera
is on and self inspection proceeds if the connection is
successful.
1. After logging in APP, add device and operate according
to tips.
4 When the cell phone displays the two-dimension code,
At this time, the camera shall be put next to the phone.
5.The beep means information reading is successful.
Click “I heard” to establish connection.
Watching Video and Operating
1.
connected camera lens and check video etc.
2.Operation such as taking photos, picture recording,
talking back, music, setting, viewing event list can be
made on the intelligent client-end.
After successfully connected to, enter into the
Regulation of camera lens viewing angle
Note: 1.Pictures taken manually with intelligent client-
end are saved on the intelligent client-end.
2.Automatic photographing and video files of manual
vide and motion detection are saved on the micro SD
card of camera.
Setting
1 Click the icon on the real-time monitoring interface
to enter the setting menu of camera. Users may change
relevant parameters.
Function Features
High definition, intelligent cloud, remote real-time
caring.
Support IOS system and Android system.
Camera, recording, saving, playback.
Two-way audio talkback.
Smoothing music customizing and recoding.
Motion detection and temperature alarm function.
Maximally support the cyclic recording of 32GB
micro SD card.
Technical Parameters
Image sensor: 1/4-inch CMOS
Video image resolution: 720P high definition
Perspective: 270°horizontal, 120°vertical
Night visual range: ≤5m
Audio sensitivity: ≤-47db
Receiving sensitivity: -80dbm (Min.)
Operation voltage: DC+5V/1A
Operation temperature: -10℃ ~ + 50℃
Operation humidity: 20% ~ 90% RH
Size (LxWxH): 85 x85 x105mm
Weight: 225g
※Any small changes to all parameters will be done
without prior notice.
Kindly Reminder
1.After camera network connection, the user account is
bound to the camera.
2.After the registered user account is bound to the
camera, other accounts are inapplicable to the camera,
and can be added after unbinding.
3.After the registered user account is bound to the
camera, the remote real-time view of monitor can be
realized with this account through network on intelligent
client-end.
Packing List
After open the packages, please contrast with the figure
below to verify whether the accessories are complete.
I II
III IV
V
V IVII VII I
The product conforms to the previsions prescribed in
Article 15 of FCC. The operations of the product meet
the following requirements:
1) No harmful interference will be produced by the
instrument.
2) The instrument shall be able to receive the
interference from the outside. Users have no rights
to make any changes or modifications to the product
without the permission of inspection body.
EU Environmental Provisions
E-waste cannot be mixed with household garbage;
corresponding local government sector or recycling
stations shall be responsible for circular process.
FCC Certification Information:
※
figures in this User's Manual.
No further notice will be given for any tiny changes to the
QQI
QQI
(Before connection: wireless router normally connects
to the network and then connect the WiFi of cellphone
to this router. When connecting to the camera, it should
be within the scope of this wireless router.)
Camera Network Connecting Device
※Take the operation of Android client-end for example,
and refer to Android client-end for IOS client-end.
Video camera Power adapter Quick Guide
USB wire
2
can be heard.
3 Please input your WiFi name and password:
Shortly press “SET” key on the camera, “beep ” sound
4.Press “SET” key in power-on status of the camera until
the indicator light is off. After the camera is reconnected
with the network, the device is removed from the account.
At this time, binding is successfully removed.
Y
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equipment generates, uses and can radiate
radio frequency energy and, if not installed and used in accordance with the instructions, may cause
harmful interference to radio communications. However, there is no guarantee that interference will not
occur in a particular installation. If this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and on, the user is encouraged to try to
correct the interference by one or more of the following measures:
—Reorient or relocate the receiving antenna.
—Increase the separation between the equipment and receiver.
—Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
—Consult the dealer or an experienced radio/TV technician for help.
Thisdevicecomplieswithpart15oftheFCCrules.Operationissubjecttothefollowingtwo
conditions:
(1)thisdevicemaynotcauseharmfulinterference,and
(2)thisdevicemustacceptanyinterferencereceived,includinginterferencethatmaycause
undesiredoperation.
Changesormodificationstothisunitnotexpresslyapprovedbythepartyresponsiblefor
compliancecouldvoidtheuser'sauthoritytooperatetheequipment.
