English (US)
Installation and operating
instructions
Table of contents
1. Location 2
2. Installing the product 3
3. Control functions 4
4. Approvals 4
5. Fault nding 6
6. Technical data 8
7. Disposing of the
product 9
1. Location
This repeater is only for
use with the ALPHA 15-55
HWR-D system and is
intended for indoor
installation only in areas
safe from droplets and
splashes.
For optimum use, place
the repeater between the
ALPHA 15-55 HWR-D
pump and the push-button
located furthest away from
the pump.
2. Installing the product
To install the repeater:
1. Connect the included
USB cable to the repeater.
2. Connect the other end
of the USB cable to the
included power adapter.
3. Fit the included plug
adapter to the power
adapter.
4. Plug the power adapter
into a power outlet to power
on the repeater.
5. The LED on the repeater
will light green to indicate the
repeater is in operation.
3. Control functions
The repeater LED lights
green when the repeater is
in operation.
4. Approvals
FCC sections
Section 15.19 (a) 3
This device complies with
Part 15 of the FCC Rules.
Operation is subject to the
following two conditions: (1)
this device may not cause
harmful interference, and (2)
this device must accept
any interference received,
including interference
that may cause undesired
operation.
Section 15.21
Any changes or modica-
tions to this equipment
not expressly approved by
the party responsible for
compliance could void the
user’s authority to operate
this equipment.
Section 15.105 (b)
This equipment has been
tested and found to comply
with the limits for a class B
digital device, pursuant to
Part 15 of the FCC Rules.
These limits are designed
to provide reasonable
protection against harmful
interference in a residential
installation.
This equipment generates,
uses and can radiate radio
frequency energy and, if not
installed and used in accord-
ance with the instructions,
may cause harmful interfer-
ence to radio communica-
tions. However, there is no
guarantee that interference
will not occur in a particular
installation. If this equipment
does cause harmful interfer-
ence to radio or television
reception, which can be
determined by turning the
equipment o and on, the
user is encouraged to try to
correct the interference by
one or more of the following
measures:
- Reorient or relocate the
receiving antenna.
- Increase the separation
between the equipment and
receiver.
be think innovate
99475028 0119
ECM: 1251564
- Connect the equipment to
an outlet on a circuit dier-
ent from that to which the
receiver is connected.
- Consult the dealer or an
experienced radio/TV techni-
cian for help.
This equipment should be
installed and operated keep-
ing the radiator at least 8 in
(20 cm) or more away from
person’s body.
Canadian ISED information
This equipment complies
with FCC/IC radiation
exposure limits set forth for
an uncontrolled environment
and meets the FCC radio
frequency (RF) Exposure
Guidelines and RSS-102 of
the IC radio frequency (RF)
Exposure rules.
Cet équipement est
conforme aux limites
99475028_0119_Repeater_HWR-D.indd 1-7 1/23/2019 3:25:49 PM
Page 8 Page 9 Page 10 Page 11 Page 12
d’exposition aux rayonne-
ment dénies par la norme
FCC / IC pour un environne-
ment non contrôlé et est
conforme aux directives
d’exposition de la FCC en
matière de radiofréquences
et la norme RSS-102, des
règles d’exposition aux
radiofréquences (RF) de l’IC.
Cet équipement doit être
installé et utilisé en mainten-
ant le radiateur à au moins
8 in (20 cm) du corps de la
personne.
This device (Repeater HWR-
D) contains license-exempt
transmitter(s)/receiver(s)
that comply with Innovation,
Science and Economic De-
velopment Canada’s license-
exempt RSS(s). Operation is
subject to the following two
conditions: 1.This device
may not cause interference.
2.This device must accept
any interference, including
interference that may cause
undesired operation of the
device. Innovation, Science
and Economic Development
Canada ICES-003 Compli-
ance Label: CAN ICES-3(B)/
NMB-3(B).
L’émetteur/récepteur exempt
de licence contenu dans le
présent appareil est con-
forme aux CNR d’Innovation,
Sciences et Développe-
ment économique Canada
applicables aux appareils
radio exempts de licence.
L’exploitation est autorisée
auxdeux conditions
suivantes : 1. L’appareil
ne doit pas produire de
brouillage; 2. L’appareil doit
accepter tout brouillage
radioélectrique subi, même
si le brouillage est suscep-
U.S.A.
GRUNDFOS Americas Corp.
9300 Loiret Boulevard
Lenexa, Kansas 66219
Phone: +1 913 227 3400
Telefax: +1 913 227 3500
Canada
GRUNDFOS Canada Inc.
2941 Brighton Road
Oakville, Ontario
L6H 6C9
Phone: +1 905 829 9533
Telefax: +1 905 829 9512
Mexico
Bombas GRUNDFOS de
México
S.A. de C.V.
Boulevard TLC No. 15
Parque Industrial Stiva
Aeropuerto
Apodaca, N.L. 66600
Phone: +52-81-8144 4000
Telefax: +52-81-8144 4010
GRUNDFOS INSTRUCTIONS
Repeater HWR-D
Installation and operating
instructions
tible d’encompromettre le
fonctionnement. Étiquette
de conformité à la NMB-003
d’Innovation, Sciences et
Développement économique
Canada : CAN ICES-3(B)/-
3(B).
This device (Repeater
HWR-D) complies with
Industry Canada RSS-247
and license-exempt RSS
standard(s). Operation is
subject to the following two
conditions: (1) this device
may not cause interference,
and (2) this device must
accept any interference, in-
cluding interference that may
cause undesired operation
of the device.
Ce dispositif est conforme
à lanorme CNR-247
d’Industrie Canada ap-
plicable aux appareils radio
exempts de licence. Son
fonctionnement est sujet aux
deux conditions suivantes:
(1) le dispositif ne doit
pas produire de brouillage
préjudiciable, et (2) ce
dispositif doit acceptertout
brouillage reçu, y compris
un brouillag e susceptible de
provoquer un fonctionne-
ment indésirable.
5. Fault nding
If the range for the push-
button is not improved
by installing the repeater,
relocate the repeater within
the house for optimum range
of wireless signals.
6. Technical data
Ambient temperature:
34 to 104 °F (1 to 40 °C)
Supply voltage for repeater
with USB plug:
5 V DC +/- 10%
Supply voltage for AC power
adapter for the repeater:
100-240 V AC +/- 10%,
50-60 Hz
7. Disposing of the
product
This product or parts of it
must be disposed of in an
environmentally sound way:
1. Use the public or private
waste collection service.
2. If this is not possible,
contact the nearest Grundfos
representative. See also
end-of-life information at
www.grundfos.com/product-
recycling
99475028_0119_Repeater_HWR-D.indd 8-14 1/23/2019 3:25:51 PM
