User Manual
USER MANUAL
-1- -2- -3-
-4- -7--6--5-
FEATURES
Thanks for your purchase of our product.
Please read through this manual before
making connections and operating this
product. Retain this manual for future
reference.
Blue tooth playback
AUX input
Power supply: DC-5V
Note: Use DC adapter or USB terminal to
charge battery no matter the player power on
or off.
In low battery status, the speaker will alert
you with beep sounds, the unit will switch off
automatically if no charged in low battery
status.
Power consumption:5W
Speaker max output: 2WX2
PREVIOUS
PLAY/PAUSE/HANDS FREE
When the player is in working mode, press
to return to the previous track;
When the player is in working mode.
Press to temporarily pause a playback;
press it again to resume the playback.
Press this button to answer the phone call
in hands free when there is a phone call in.
Hold down this button for 3 seconds to
disconnected the bluetooth connections, the
speaker will turn to searching other
NEXT
When the player is in working mode, press
to skip to the next track;
VOLUME-
When the player is in working mode, press
to turn down the volume.
The minimum volume is near in silence.
VOLUME+
When the player is in working mode, press
to turn up the volume.
You will hear the beep sound when you
turn up to the maximum volume.
output terminals of mobile phone, computer,
MP3 player to the audio input terminal (AUX
IN) of this player.
When the player connect the AUX input
terminal, the player will disconnect the
bluetooth connection automatically .
When the player disconnect the AUX input
terminal, the player will return to the
previous bluetooth connnection.
When the player connect the AUX input
terminal,[VOLUME],[PREVIOUS] and
[NEXT] buttons are only control by the extra
devices.
BLUETOOTH CONNECTION
The blue indicator keeps flashing once per
second when the player in working mode.
The player need to input the password 0000
when the matching blue tooth device under
version 2.1.
When the operation too frequently or other
reason to disturb the bluetooth reconnected,
please use manually connect on the bluetooth
device.
The model of the unit is BL1602,power on
the unit then use your mobile phone to search
the bluetooth signal of the unit, the unit will
synchronize play songs on your mobile phone
while they connected successfully.
Do not drop any objects into the unit
through the openings.
Do not spill or spray liquid of any kind on or
in the unit. It may result in a fire or electric
shock.
Do not place anything heavy on the unit.
PRECAUTION
To ensure proper ventilation and proper
operation, never cover or block the slots and
opening with a cloth or other materials.
Keep the unit away from an open flame
such as fire, candle, etc.
Install the batteries correctly.
Please dispose the batteries according to
the local rule and law.
The maximum working temperature is 35
degrees Celsius.
Only use attachments/accessories
specified by the manufacturer.
Where the Mains plug is used as the
disconnect device, the disconnect device
shall remain readily operable.
Rating label are on the bottom of the unit.
WARNING: The batteries shall not be
exposed to excessive heat such as sunshine,
fire or the like.
CAUTION: Danger of explosion if battery is
incorrectly replaced.Replace only with the
same or equivalent type.
Warning: Changes or modifications to this
unit not expressly approved by the party
responsible for compliance could void the
user's authority to operate the equipment.
BLUETOOTH SPEAKER
4000375
PANEL
1345
123
1. VOLUME+
2. PREVIOUS
3. VOLUME-
4. PLAY/PAUSE
/HANDS FREE
1. POWER ON/OFF
2. DC IN 5V
3. AUX INPUT
27
68
5. NEXT
6. MICROPHONE
7. BLUETOOTH INDICATOR
8. CHARGING-INDICATOR
NOTE: This equipment has been tested and
found to comply with the limits for a Class B
digital device, pursuant to Part 15 of the FCC
Rules. These limits are designed to provide
reasonable protection against harmful
interference in a residential installation.
This equipment generates, uses and can
radiate radio frequency energy and, if not
installed and used in accordance with the
instructions, may cause harmful interference
to radio communications.
However, there is no guarantee that
interference will not occur in a particular
installation. If this equipment does cause
harmful interference to radio or television
reception, which can be determined by
turning the equipment off and on, the user is
encouraged to try to correct the interference
by one or more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the
equipment and receiver.
Connect the equipment into an outlet on a
circuit different from that to which the
receiver is connected.
Consult the dealer or an experienced
radio/TV technician for help.
INDICATOR
When the red indicator and the blue
indicator flashing alternately, the player is in
searching bluetooth signal status.
The red indicator keeps lighting when the
player connected the previous bluetooth
device, if the previous bluetooth device not
in the sevice areas, the player will return to
searching status after 20 seconds.
The blue indicator keeps flashing once per
second means bluetooth was connected,
and the model of the player will shows on
mobile phone.
It is better to switch off the unit before
charging. The charging-indicator changing
from red to light off indicates that the battery
has been fully charged.
AUX IN
matching bluetooth device when you hear
beep sounds.
This player has an extra group of audio
input terminals. You can input the analogue
Stereo audio signals from extra devices
such as mobile phone, computer,MP3
player, etc.
Use the audio cable to connect the audio
