Guangzhou Panyu Juda Car Audio Equipment 4000705 Mono Speaker User Manual
Guangzhou Panyu Juda Car Audio Equipment Co.,Ltd. Mono Speaker
User Manual
2345678910
portable bluetooth cube speaker
We hope you enjoy your AUVIO Portable
Bluetooth® Cube Speaker. This speaker can sync
with a Bluetooth-enabled device, allowing you
to listen to music and receive hands-free calls.
Please read this user's guide before using your
new speaker.
Package Contents
•Portable Bluetooth Cube Speaker
•Micro-USB Charging Cable
•User’s Guide
Specifications
Battery .......Rechargeable 500mAh lithium polymer
Battery Charging Voltage .................................... DC 5V
Battery Charging Time ........................approx. 2 hours
Operation Time ......................................... up to 5 hours
Frequency Response ..........................150 Hz – 15 kHz
Output Power ................................................................3 W
Impedance ............................................................. 4 ohms
S/N Ratio ..................................................................≥ 65 dB
Driver...................................1.5 in. (38mm) neodymium
Bluetooth Protocol ........................................ V4.0 +EDR
Operation Range ....................................... 30 ft. (9.14m)
Specications are subject to change and improvement
without notice. Actual product may vary from the images
found in this document.
•If the electrolyte in the cells should get on your
skin, thoroughly wash with soap and water. If in the
eyes, rinse thoroughly with cool water. Immediately
seek medical attention.
•Follow the instructions for charging the speaker
and do not charge longer than recommended.
Unplug the USB cable when the battery is charged.
Use Your Speaker
Connecting to a Bluetooth Device
1. Turn on the speaker. The Bluetooth indicator
ashes quickly as your speaker searches for
Bluetooth devices.
2. Activate your device’s Bluetooth function
(refer to your device’s user’s guide). When
your device locates AUVIO BT Mono
speaker, select it. When paired, the indicator
ashes slowly.
3. You can control your speaker through your
device or with the speaker’s and + / –
buttons.
•To answer a call, press and speak into
the microphone.
•To reject a call, press and hold for 2
seconds.
© 2015 General Wireless Operations Inc.
All rights reserved. AUVIO is a registered trademark
used by General Wireless Operations Inc.
Complies with the European
Union’s “Restriction of Hazardous
Substances Directive,” which
protects the environment by
restricting specic hazardous
materials and products.
User’s Guide
4000705, 4000706, 4000707, 4000714
•If you press + / – and hear a beep, the
speaker is at its maximum/minimum
volume.
4. Turn o the speaker after use.
Notes:
•If prompted for a PIN, enter 0000.
•The speaker will disconnect from your device if
they are too far apart. To reconnect, move the
speaker closer to the device within 15 minutes.
•If the speaker malfunctions, reset it by
pressing twice quickly while the Bluetooth
indicator ashes quickly.
•Download the free AUVIO EQ App from the
App StoreSM and Google Play™ to customize
your music (compatible with devices running
iOS 5.0 or later, or Android™ 2.3.3 or later).
Device Not Pairing?
Many Bluetooth-enabled devices,
such as speakers, remember the
most recently paired source (music,
smartphone, etc.) and automatically
reconnect when turned on. This is
convenient, but can prevent you from
connecting to a new source.
If you can’t pair your speaker, you may need to
disconnect it from its previous source.
Disconnect Your Device
To disconnect the paired device, press and hold
the speaker's button for 3 seconds until the
speaker beeps twice and the Bluetooth indicator
ashes quickly. The speaker starts searching for
another Bluetooth device.
Connecting with AUX IN
For an audio device without Bluetooth
functionality, use an ⅛ in. audio cable
(not included) to connect to
the speaker’s AUX IN jack.
Notes:
•Bluetooth functionality is automatically
deactivated when AUX IN is connected.
•Use the controls on your connected device
to control playback.
FCC Information
This equipment has been tested and found to comply
with the limits for a Class B digital device, pursuant to Part
15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a
residential installation. This equipment generates, uses,
and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause
harmful interference to radio communications. However,
there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be
determined by turning the equipment o and on, the user
is encouraged to try to correct the interference by one or
more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and
receiver.
• Connect the equipment into an outlet on a circuit
dierent from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV
technician for help.
Changes or modications not expressly approved by the
party responsible for compliance could void the user’s
authority to operate the equipment.
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received,
including interference that may cause undesired operation.
Limited Warranty
RadioShack warrants this product against defects in
materials and workmanship under normal use by the
original purchaser for ninety (90) days after the date of
purchase from a RadioShack-owned store or an authorized
RadioShack franchisee or dealer. RADIOSHACK MAKES NO
OTHER EXPRESS WARRANTIES.
This warranty does not cover: (a) damage or failure
caused by or attributable to abuse, misuse, failure to
follow instructions, improper installation or maintenance,
alteration, accident, Acts of God (such as oods or
lightning), or excess voltage or current; (b) improper or
incorrectly performed repairs by persons who are not a
RadioShack Authorized Service Facility; (c) consumables
such as fuses or batteries; (d) ordinary wear and tear or
cosmetic damage; (e) transportation, shipping or insurance
costs; (f) costs of product removal, installation, set-up
service, adjustment or reinstallation; and (g) claims by
persons other than the original purchaser.
Should a problem occur that is covered by this warranty,
take the product and the RadioShack sales receipt as
proof of purchase date to any RadioShack store in the U.S.
RadioShack will, at its option, unless otherwise provided by
law (a) replace the product with the same or a comparable
product, or (b) refund the purchase price. All replaced
products, and products on which a refund is made, become
the property of RadioShack.
RADIOSHACK EXPRESSLY DISCLAIMS ALL WARRANTIES
AND CONDITIONS NOT STATED IN THIS LIMITED
WARRANTY. ANY IMPLIED WARRANTIES THAT MAY BE
IMPOSED BY LAW, INCLUDING THE IMPLIED WARRANTY
OF MERCHANTABILITY AND, IF APPLICABLE, THE IMPLIED
WARRANTY OF FITNESS FOR A PARTICULAR PURPOSE,
SHALL EXPIRE ON THE EXPIRATION OF THE STATED
WARRANTY PERIOD.
EXCEPT AS DESCRIBED ABOVE, RADIOSHACK SHALL
HAVE NO LIABILITY OR RESPONSIBILITY TO THE
PURCHASER OF THE PRODUCT OR ANY OTHER PERSON
OR ENTITY WITH RESPECT TO ANY LIABILITY, LOSS OR
DAMAGE CAUSED DIRECTLY OR INDIRECTLY BY USE OR
PERFORMANCE OF THE PRODUCT OR ARISING OUT
OF ANY BREACH OF THIS WARRANTY, INCLUDING,
The Bluetooth® word mark and logos are owned by
Bluetooth SIG, Inc. and any use of such marks by
General Wireless Operations Inc. is under license.
App Store is a service mark of Apple Inc.
Android and Google Play are trademarks of Google Inc.
4000705 / 4000706
4000707 / 4000714
09A15
Printed in China
?
Charge Your Speaker
When the battery is low, the speaker beeps.
1. Connect the supplied Micro-USB charging
cable to the speaker’s DC 5V jack and the
USB port of your computer or USB charger.
2. Unplug the charging cable when the speaker
is fully charged.
Note: The speaker charges whether ON or OFF.
Lithium Battery Notes:
•Recycle lithium batteries. Do not dispose of them
in the trash.
•Do not burn or bury batteries. Do not puncture or
crush. Do not disassemble.
• Charge batteries on a reproof surface away from
ammable items or liquids.
•Do not charge inside an automobile, especially
while driving.
Bluetooth Indicator
•Play/pause
•Answer/reject a call
•Disconnect Bluetooth
•Reset
Volume Control (–/+)
Microphone ( )
Charging Indicator
Lights red when
charging; turns o
when fully charged.
BUT NOT LIMITED TO, ANY DAMAGES RESULTING
FROM INCONVENIENCE AND ANY LOSS OF TIME, DATA,
PROPERTY, REVENUE, OR PROFIT AND ANY INDIRECT,
SPECIAL, INCIDENTAL, OR CONSEQUENTIAL DAMAGES,
EVEN IF RADIOSHACK HAS BEEN ADVISED OF THE
POSSIBILITY OF SUCH DAMAGES.
Some states do not allow limitations on how long an implied
warranty lasts or the exclusion or limitation of incidental
or consequential damages, so the above limitations or
exclusions may not apply to you. This warranty gives you
specic legal rights, and you may also have other rights which
vary from state to state. You may contact RadioShack at:
RadioShack Customer Relations
300 RadioShack Circle
Fort Worth, TX 76102 02/14
www.RadioShack.com
OFF/ON OR
