Features
-2-
Thanks for your purchase of our product. Please read through this manual before making
connections and operating this product. Retain this manual for future reference.
Bluetooth playback
AUX input
USB charging for external device
Package Contents:
User manual
User manual
AC adaptor
IMPORTANT NOTES
For Your Attention
Please read through this manual before making connections and operating this product. Retain this manual for
future reference.
Don't open the cabinet of this unit. No user-serviceable parts inside. Refer servicing to qualified personnel only.
Switch off the unit when you don't use it. Switch off the unit and disconnect it from the AC power supply when it is
not being used for a long time.
Don't install the unit in a place exposed to heating sources or direct sunshine.
Don't install the unit in a place exposed to moisture or rain.
The apparatus shall not be exposed to dripping or splashing and any object filled with liquids, such as vases shall
not be placed on it.
Install the unit on a horizontal, flat and firm surface with good ventilation. Never block the vents which will cause
malfunction resulted from overheating.
Use a soft and clean rag to clean the outside of the unit . Never clean it with chemicals or detergent.
This book is only a guide for user's operation, not a criterion for configuration.
Only use attachments/accessories specified by the manufacturer.
Where the mains plug is used as the disconnect device, the disconnect device shall remain readily operable..
-3-
FCC STATEMENT
For Your Attention
1. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions:
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received, including interference that may cause
undesired operation.
2. Changes or modifications not expressly approved by the party responsible for compliance could
void the user's authority to operate the equipment.
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation.
This equipment generates uses and can radiate radio frequency energy and, if not installed and
used in accordance with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
FCC Radiation Exposure Statement
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This
equipment should be installed and operated with minimum distance 20cm between the radiator & your body .
-4-
Panel
-5-
1. VOLUME+/-
2. STANDBY/SOURCE SELECT
3. PLAY/PAUSE
4. PREVIOUS/NEXT
(Note: All the button on the front panel
are touch keys)
5. STANDBY (red indicator)
6. AUX IN (yellow indicator)
7. BLUETOOTH (blue indicator)
1. POWER ON/OFF
2. DC IN (10V)
3. AUX INPUT
4. CHARGE PORT 5V(only used for external
device charging)
(Note: Use the USB cable to connect the USB
slot of the player to external device input
terminals to charge battery for only DC5V 1A
with mobile phone, MP3 player etc )
FRONT PANEL:
1
2
3
4
5
6
7
1234
REAR PANEL:
CHARGE
PORT 5V
Connections
-6-
Bluetooth
Model:WC 603
AUX IN
This unit has an audio input terminal.
Use the audio cable(not included) to connect the input terminal AUX IN
on the rear panel of this player, press [SOURCE ] button on the
front panel to switch to the AUX IN mode, the indicator on the front panel
indicates in yellow that the player has been switched to AUX IN mode.
SELECT
Bluetooth Connection
The model of the unit is WC 603,press [SOURCE SELECT] button on
the front panel to switch to the corresponding signal source, use your
mobile phone to search the bluetooth signal of the unit, then input the
password 0000 if necessary, the unit will synchronize to play songs on
your mobile phone while they connected successfully.
Disconnect the bluetooth on the mobile phone to switch off the bluetooth
connect.
In bluetooth mode,[PLAY/PAUSE],[NEXT], [PREVIOUS],
[VOLUME+/-] etc. are also active.
Once the bluetooth is connected to your audio device successfully for
the first time, you can power off the player then power on. The speaker
will reconnect automatically.Press [PLAY/PAUSE] to resume the
playback.
Note: Bluetooth connection range is 30 feet.
The model WC 603 in your device was not deleted.
-7-
Troubleshooting
Before resorting to maintenance service, please kindly check by yourself with the following chart.
Sound
There is no sound or
the sound is
distorted.
The volume is set to the minimum level. Turn up the volume.
Symptom Cause(s) Remedy
The buttons on the
unit doesn't work.
Switch off and unplug the unit.
Then connect the plug to the power supply
and switch it on again.
The unit is being interfered with static electricity
etc.
The AC power cord of the adaptor is not
connected to the power supply or is not connected
to a power supply
Please check that the AC power cord
of the adaptor is connected securely.
No Power
5WX2
-8-
Specifications
Power supply
DC 10V 1.5A
Working
environment
Temperature -10~+35
Relative humidity
5%~90%
Speaker output (Max)
Power consumption 15W
5V,1A
USB output (Max)
