Guangzhou Panyu Juda Car Audio Equipment BL6625 Bluetooth Speaker User Manual
Guangzhou Panyu Juda Car Audio Equipment Co.,Ltd. Bluetooth Speaker
User Manual
When the speaker is in working mode.
●Press this button to answer the phone call
in hands free when there is a phone call in.
●When the speaker is in bluetooth
connection status,hold down this button to
disconnected the existing bluetooth
connections, the speaker will turn to pairing
other matching bluetooth device when you
hear the voice prompt of YOUR DEVICE IS
DICONNECTED .
●When the speaker without bluetooth
connection in bluetooth mode,hold down this
Button to enter into bluetooth pairing status
when you hear the voice prompt of PAIRING.
USER MANUAL
-1- -2- -3-
-4- -7--6--5-
FEATURES PANEL
BLUETOOTH/HANDS FREE
INDICATOR
1. LINE IN
2. DC IN 5V
3. CHARGING (RED)/POWER ON
(WHITE) INDICATOR
4.POWER ON/OFF
5.BLUETOOTH INDICATOR
6.BLUETOOTH/HANDS FREE
7. PLAY/PAUSE
8. VOLUME-
9. VOLUME+
Thanks for your purchase of our product.
Please read through this manual before
making connections and operating this
product. Retain this manual for future
reference.
●Bluetooth playback
●LINE input
●Power supply: DC-5V
Note: ●Use DC adapter or USB terminal to
charge battery no matter the speaker power
on or off.
●In low battery status, the speaker will emit
Battery Low voice prompt and it will switch
off automatically if no charged in low battery
status.
●Power consumption: 6W
●Speaker max output: 7WX2
VOLUME-
●When the speaker is in working mode,
press to turn down the volume.
You will hear the beep sound when you turn
down to the minimum volume.
●When the speaker is in working mode, hold
down to skip to the previous track.
VOLUME+
●When the speaker is in working mode,
press to turn up the volume.
You will hear the beep sound when you turn
up to the maximum volume.
●When the speaker is in working mode, hold
down to skip to the next track.
LINE IN
PRECAUTION
●Do not drop any objects into the unit through the
openings.
●Do not spill or spray liquid of any kind on or in the
unit. It may result in a fire or electric shock.
●Do not place anything heavy on the unit.
●To ensure proper ventilation and proper
operation, never cover or block the slots and
opening with a cloth or other materials.
●Keep the unit away from an open flame such as
fire, candle, etc.
●Install the batteries correctly.
●Please dispose the batteries according to the
local rule and law.
●The maximum working temperature is 35
degrees Celsius.
●Only use attachments/accessories specified by
the manufacturer.
●Where the Mains plug is used as the disconnect
device, the disconnect device shall remain readily
operable.
●Rating label are on the bottom of the unit.
WARNING: The batteries shall not be exposed to
excessive heat such as sunshine, fire or the like.
CAUTION: Danger of explosion if battery is
incorrectly replaced.Replace only with the same or
equivalent type.
BLUETOOTH SPEAKER
ATGTA6625
234
1
●Hold down this button for 3 seconds to
power on/off the speaker with the voice
prompt of POWER ON/OFF.
●Power on the speaker, the blue indicator
flashing , you will hear the voice prompt of
POWER ON, the speaker is in searching
bluetooth signal status.
●The blue indicator keep solid blue means
ACCESSORY
●User manual
●USB cable
●This speaker has an extra group of audio
input terminals. You can input the analogue
stereo audio signals from extra devices such
as mobile phone, computer,MP3 player, etc.
●Use the audio cable to connect the audio
output terminals of mobile phone, computer,
MP3 player to the audio input terminal (LINE
IN) of this speaker.
●When the speaker connect the LINE input
terminal, the speaker will disconnect the
bluetooth connection automatically.
●When the speaker disconnect the LINE
input terminal, the speaker will return to the
previous bluetooth connnection.
bluetooth was connected, you will hear the
voice prompt of YOUR DEVICE IS
CONNECTED, and the model of the speaker
will shows on your device.
●It is better to switch off the unit before
charging. The charging-indicator changing
from red to light off indicates that the battery
has been fully charged.
567 8 9
PLAY/PAUSE
●Press to temporarily pause a playback;
press it again to resume the playback.
-8- -9-
resume the playback.
Note:
●Bluetooth connection range in 10 meters;
●The model ATGTA6625 in your device was
not deleted;
●After 3 minutes without connections, the
speaker go to dormant status and you need
to hold down [POWER ON/OFF] button for 3
seconds to wakes up the speaker.
BLUETOOTH CONNECTION
●The bluetooth pairing model of the
speaker is ATGTA6625, power on the
speaker then use your smart phone to
search the bluetooth signal of the unit, the
unit will synchronize to play songs on your
smart phone while they connected
successfully.
●The speaker need to input the password
0000 when the matching bluetooth device
under version 2.1.
●The bluetooth will turn to low power
consumption dormant status after 3 minutes
without connections, at this time , the blue
indicator will go out, hold down [POWER
ON/OFF] button for 3 seconds to wakes up
the speaker.
●When the operation too frequently or other
reason to disturb the bluetooth reconnected,
please use manually connect on the
bluetooth device.
●The bluetooth is connected to your smart
phone successfully for the first time,
disconnect the bluetooth on your smart
phone then reconnected it, the speaker will
memories your smart phone and repaired
automatically.Press [PLAY/PAUSE] to
Bluetooth Model:
ATGTA6625
CHECK BATTERY LEVEL
●Press power on/off to check the current
battery level in power on mode.
If the white indicator flashing
Four times=app. 100% full
Three times=app. 80% full above
Two times=app. 40%-80% full
One times=app. 20% full(indicating
Charging is needed)
-10- -11-
FCC STATEMENT
1. This device complies with Part 15 of the
FCC Rules. Operation is subject to the
following two conditions:
(1) This device may not cause harmful
interference, and
(2) This device must accept any interference
received, including interference that may
cause undesired operation.
2. Changes or modifications not expressly
approved by the party responsible for
compliance could void the user's authority to
operate the equipment.
NOTE: This equipment has been tested and
found to comply with the limits for a Class B
digital device, pursuant to Part 15 of the FCC
Rules. These limits are designed to provide
reasonable protection against harmful
interference in a residential installation.
This equipment generates uses and can
radiate radio frequency energy and, if not
installed and used in accordance with the
instructions, may cause harmful interference
to radio communications.
-12-
WWW.teamprogressive.com
R&D
DISTRIBUTING
However, there is no guarantee that
interference will not occur in a particular
installation. If this equipment does cause
harmful interference to radio or television
reception, which can be determined by
turning the equipment off and on, the user is
encouraged to try to correct theinterference
by one or more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the
equipment and receiver.
Connect the equipment into an outlet on a
circuit different from that to which the
receiver is connected.
Consult the dealer or an experienced
radio/TV technician for help.
RF warning statement:The device has been
evaluated to meet general RF exposure
requirement. The device can be used in
portable exposure condition without
restriction.
