Guangzhou Panyu Juda Car Audio Equipment CSMP92 Sound Bar User Manual Manual
Guangzhou Panyu Juda Car Audio Equipment Co.,Ltd. Sound Bar Manual
Manual
![](/img.php?id=1870493&img=bg1.png)
USER MANUAL
CSMP92
SOUND BAR SYSTEM
![](/img.php?id=1870493&img=bg2.png)
IMPORTANT SAFETY INSTRUCTIONS:
For Your Attention
1. Read these instructions - All the safety and operating instructions should be read before this product is operated.
2. Keep these instructions- The safety and operating instructions should be retained for future reference.
3. Heed all warnings - All warnings on the appliance and in the operating instructions should be adhered to.
4. Follow all instructions - All operating and use instructions should be followed.
5. Do not use this apparatus near water -The appliance should not be used near water or moisture - for example, in
a wet basement or near a swimming pool, and the like.
6. Clean only with dry cloth.
7. Do not block any ventilation openings. Install in accordance with the manufacture-s instructions.
8. Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including
amplifiers) that produce heat.
9. Do not defeat the safety purpose of the polarized or grounding plug. A polarized plug has two blades with one
wider than the other. A grounding plug has two blades and a third grounding prong. The wide blade or the third
prong is provided for your safety. If the provided plug does not fit into your outlet, consult an electrician for
replacement of the obsolete outlet.
10. Protect the power cord from being walked on or pinched particularly at the plugs, convenience receptacles, and
at the point where they exit from the apparatus.
11. Only use attachments/accessories specified by the manufacturer.
12. Use only with the cart, stand, tripod, bracket, or table specified by the manufacturer, or sold with the apparatus.
When a cart or rack is used, use caution when moving the cart/apparatus combination to avoid injury from tip-over.
-1-
![](/img.php?id=1870493&img=bg3.png)
For Your Attention
-2-
13. Unplug the apparatus during lightning storms or when unused for long periods of time.
14. Refer all servicing to qualified personnel. Servicing is required when the apparatus has been damaged in any
way, such as power supply cord or plug is damaged, liquid has been spilled or objects have fallen into the
apparatus has been exposed to rain or moisture, does not operate normally, or has been dropped.
15. CAUTION: These servicing instructions are for use by qualified service personnel only. To reduce the risk of
electric shock, do not perform any servicing other than that contained in the operating instructions unless you
are qualified to do so.
18. Do not install this equipment in a confined or building-in space such as a book case or similar unit, and remain a
well ventilation conditions at open site. The ventilation should not be impeded by covering the ventilation openings
with items such as newspaper, table-cloths, curtains etc.
19. WARNING-To reduce the risk of fire or electric shock, do not expose this apparatus to rain or moisture. The
apparatus shall not be exposed to dripping or splashing and that objects filled with liquids, such as vases, shall not
be placed on apparatus.
20. WARNING: The battery (battery or batteries or battery pack) shall not be exposed to excessive heat such as
sunshine, fire or the like.
21. WARNING: The mains plug is used as disconnect device, the disconnect device shall remain readily operable.
16. This lightning flash with arrowhead symbol within an equilateral triangle is intended to alert the user to the
presence of non-insulated “dangerous voltage” within the product’s enclosure that may be of sufficient magnitude
to constitute a risk of electric shock.
- Warning: To reduce the risk of electric shock, do not remove cover (or back) as there are no user-serviceable
parts inside. Refer servicing to qualified personnel.
- The exclamation point within an equilateral triangle is intended to alert the user to the presence of important
operating and maintenance instructions in the literature accompanying the appliance.
17. This equipment is a Class II or double insulated electrical appliance. It has been designed in such a
way that it does not require a safety connection to electrical earth.
![](/img.php?id=1870493&img=bg4.png)
For Your Attention
-3-
FCC STATEMENT
1. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference.
(2) This device must accept any interference received, including interference that may cause undesired operation.
2. Changes or modifications not expressly approved by the party responsible for compliance could void the user's
authority to operate the equipment.
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to
Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference
in a residential installation.
This equipment generates uses and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by turning the equipment off and on, the user
is encouraged to try to correct the interference by one or more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
IC STATEMENT
This device complies with Industry Canada licence-exempt RSS standard(s). Operation is subject
to the following two conditions: (1) this device may not cause interference, and (2) this device
must accept any interference, including interference that may cause undesired operation of the
Device.
FCC Radiation Exposure Statement
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment.
Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils radio
L'exploitation est autorisée aux deux conditions suivantes : (1) l'appareil ne
et (2) l'utilisateur de l'appareil doit accepter tout brouillage
d'en compromettre le fonctionnement."
exempts de licence.
doit pas produire de brouillage,
radioélectrique subi, même si le brouillage est susceptible
CAUTION:
![](/img.php?id=1870493&img=bg5.png)
For your Attention.....................................................................................................1-3
Contents.....................................................................................................................4
Features.....................................................................................................................5
Panel.......................................................................................................................6-7
Connections...............................................................................................................8
Remote Control.......................................................................................................9-10
Basic Playback......................................................................................................11-12
Trouble shooting........................................................................................................13
Specifications............................................................................................................14
Contents
Contents
-4-
![](/img.php?id=1870493&img=bg6.png)
Features
-5-
Thanks for your purchase of our product. Please read through this manual before making
connections and operating this product. Retain this manual for future reference.
Blue tooth playback
Line input
Optical input
Full function remote control
Package Contents:
User manual
User manual
Remote control
MUTE
STANDBY
CSMP91
AUX
Bluetooth
LINE
LOUDNE
ROCK
CUSTOM
POPS JAZZ
VOCAL
CINEMA
COAX/OPT
![](/img.php?id=1870493&img=bg7.png)
TOP PANEL:
Panel
-6-
1 STANDBY
2 FUNCTION
3 VOLUME+/-
4 EQUALIZER
FRONT PANEL:
11
1 DISPLAY SCREEN
11223344
![](/img.php?id=1870493&img=bg8.png)
SIDE PANEL:
Panel
-7-
11
1 LINE INPUT
REAR PANEL:
1 AC INPUT
2 OPTICAL INPUT
3 AUX INPUT
4 SUBWOOFER OUTPUT
5 COAXIAL DIGITAL AUDIO INPUT
3344
11
22
55
![](/img.php?id=1870493&img=bg9.png)
Connections
-8-
LINE IN/AUX IN
This unit has an extra group of audio input terminals.
You can input the analogue stereo audio signals from
extra devices such as VCD, CD, VCR,MP3 player, etc.
Use the audio cable (red for right, white for left) to
connect the stereo audio output terminals of a VCD,
CD, VCR player to the stereo input terminals (LINE
IN/AUX IN) of this unit.
Its corresponding signal source is LINE IN/AUX IN
which can be available by pressing [FUNCTION] on
the top panel or pressing [AUX]/[LINE] on the remote
control.
Subwoofer Output
Use speaker cable to connect the subwoofer
output of this unit .
SUBWOOFER
Speaker Output
Bluetooth Connection
The model of the unit is Sound Bar,press [FUNCTION] on
the top panel or press [Bluetooth] on the remote control
to switch to the corresponding signal source, use your
mobile phone to search the bluetooth signal of the unit,
then input the password 0000 ,the unit will synchronize
to play songs on your mobile phone while they connected
successfully.
Coaxial Digital Audio
Use a coaxial cable to connect the coaxial output of this unit to the coaxial input of a power amplifier.
Digital Audio Input
Connections
-8-
LINE IN/AUX IN
This unit has an extra group of audio input terminals.
You can input the analogue stereo audio signals from
extra devices such as VCD, CD, VCR,MP3 player, etc.
Use the audio cable (red for right, white for left) to
connect the stereo audio output terminals of a VCD,
CD, VCR player to the stereo input terminals (LINE
IN/AUX IN) of this unit.
Its corresponding signal source is LINE IN/AUX IN
which can be available by pressing [FUNCTION] on
the top panel or pressing [AUX]/[LINE] on the remote
control.
Subwoofer Output
Use speaker cable to connect the subwoofer
output of this unit .
SUBWOOFER
Speaker Output
Bluetooth Connection
The model of the unit is Sound Bar,press [FUNCTION] on
the top panel or press [Bluetooth] on the remote control
to switch to the corresponding signal source, use your
mobile phone to search the bluetooth signal of the unit,
then input the password 0000 ,the unit will synchronize
to play songs on your mobile phone while they connected
successfully.
Coaxial Digital Audio
Use a coaxial cable to connect the coaxial output of this unit to the coaxial input of a power amplifier.
Digital Audio Input
COAXIAL
COAXIAL
Digital Audio Output
Use the optional optical cable to connect the optical output of your television or amplifier to the player.
Optical Input
OPTICAL
Optical Input
Optical Output
![](/img.php?id=1870493&img=bga.png)
Remote control
-9-
Insert the batteries into the remote control. Point the remote control at the remote sensor on the front
panel. The remote control works within a distance of about 8 metres from the sensor and within an
angle of about 30 degrees from the left and right side.
Note:
Remove the batteries when you do not intend to use the remote control for a long time.
Weak batteries can leak and severely damage the remote control.
The batteries must not be exposed to excessive heat source, such as sunshine, fire or any other
things like that.
Be environmentally friendly and dispose of batteries according to your government regulations.
Remote Control Operation
Battery Installation
Remove the battery
compartment cover on
the back of the remote
control.
Load a AAA/1.5V battery into the battery
compartment making sure that the
battery have been inserted with the
correct polarity matching the symbols +, -
as indicated inside the battery
compartment.
Replace the cover.
![](/img.php?id=1870493&img=bgb.png)
MUTE
STANDBY
CSMP91
AUX
Bluetooth
LINE
LOUDNE
ROCK
CUSTOM
POPS JAZZ
VOCAL
CINEMA
COAX/OPT
Remote Control
-10-
1 STANDBY
2 PLAY/PAUSE
3 COAXIAL/AUX IN/OPTICAL IN
4 STO P
5 PREVIOUS
6 LOUDNESS ON/OFF
7 EQUALIZER MODE
(CUSTOM/ROCK/POPS
JAZZ/VOCAL/CINEMA)
8 MUTE
9 BLUTOOTH/LINE IN
10 NEXT
11 CHANNEL LEVEL
12 VOLUME+/-
3
1
5
4
6
7
9
8
11
10
12
2
![](/img.php?id=1870493&img=bgc.png)
STANDBY
Press to switch on the unit. Press it again to put the unit in standby mode.
Press to temporarily pause a playback. Press it again to resume the playback.
Press to stop a playback .
Basic Playback
-11-
OPERATION
Press to skip to the next chapter/track.
Press to return to the previous chapter/track.
Press [VOLUME+] to turn up the volume.
Press [VOLUME-] to turn down the volume
MUTE
Press to temporarily switch off the sound . Press it again to switch it on.
Press repeatedly to switch between BLUETOOTH and LINE IN mode.
BLUETOOTH/
LINE IN
Press repeatedly to switch among COAXIAL ,AUX IN and OPTICAL mode.
COAXIAL/AUX IN
/OPTICAL
VOL+
VOL-
Press to select the equalizer modes, CUSTOM, ROCK, POPS, JAZZ, VOCAL, CINEMA.
CUSTOM/ROCK/POPS
JAZZ/VOCAL/CINEMA
![](/img.php?id=1870493&img=bgd.png)
Basic Playback
-12-
on/off loudness .Press to switch
LOUDNESS
Press this key repeatedly to select a channel or the overall volume, then press [VOLUME+]/
[ VOLUME-] to adjust its level.
CH-LEVEL
![](/img.php?id=1870493&img=bge.png)
-13-
Troubleshooting
Before resorting to maintenance service, please kindly check by yourself with the following chart.
Sound
There is no sound or
the sound is
distorted.
The audio cables aren't connected securely.
The volume is set to the minimum level.
The sound is switched off.
Connect the audio cables securely.
Turn up the volume.
Press [MUTE] on the remote control to
switch on the sound.
Press [PLAY/PAUSE].
The remote
control does not
function.
There is no battery in the remote control.
The batteries are out of charge.
The remote control isn't pointed to the remote
sensor.
The remote control is out of its operating area.
The unit is shut down.
Install a AAA/1.5V battery in it.
Replace the batteries with new ones.
Make sure that the remote control is
pointed to the remote control sensor.
Make sure the remote control is within
the operating area.
Switch off the unit and disconnect it from
the AC outlet. Then power on the unit again.
Symptom Cause(s) Remedy
The buttons on the
unit doesn't work.
Switch off and unplug the unit.
Then connect the plug to the power supply
and switch it on again.
The unit is being interfered with static electricity
etc.
The AC power cord is not connected to the power
supply or is not connected to a power supply
securely.
Please check that the AC power cord
is connected securely.
No Power
![](/img.php?id=1870493&img=bgf.png)
15WX2+30W
-14-
Specifications
Power supply
AC ~110-240V,50/60Hz
Working
environment
Temperature -10~+35
Relative humidity
5%~90%
Power output (Max)
Power consumption 20W
Frequency response
1.5dB(20Hz~20kHz)
![](/img.php?id=1870493&img=bg10.png)
