Guangzhou Panyu Juda Car Audio Equipment HAIOR18 ALL IN ONE SHELF SYSTEM User Manual
Guangzhou Panyu Juda Car Audio Equipment Co.,Ltd. ALL IN ONE SHELF SYSTEM
User Manual
USER GUIDE
Before using your new product, please read these instructions to prevent any damage.
All-In-One Shelf
System
NS-HAIOR18
v1
R1
www.insigniaproducts.com
Contents
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
Safety information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
Package contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
Front view . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
Back view . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
Remote control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
Setting up your shelf system . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
Turning on your shelf system . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Connecting the FM antenna . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
Setting the clock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
Adjusting the display brightness . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
Inserting remote control batteries . . . . . . . . . . . . . . . . . . . . . . . . . .9
Using your shelf system . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
Turning on your shelf system . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Selecting the sound source . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Adjusting the volume . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
Selecting the sound equalization . . . . . . . . . . . . . . . . . . . . . . . . . .10
Using the FM radio . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
Using the CD player . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
Using Bluetooth . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12
Using a USB device. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Connecting headphones . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16
Cleaning your shelf system . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Legal notices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18
ONE-YEAR LIMITED WARRANTY - INSIGNIA . . . . . . . . . . . . . . . . . . . . . .19
Introduction
Congratulations on your purchase of a high-quality Insignia product. Your
NS-HAIOR18 represents the state of the art in All-In-One Shelf Systems
and is designed for reliable and trouble-free performance.
This decive is a Bluetooth stereo system.
All-In-One Shelf System
www.insigniaproducts.com
Safety information
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
This symbol indicates that dangerous
voltage constituting a risk of electric
shock is present within your shelf
system. This label is located on the
back of your shelf system.
This symbol indicates that there are
important operating and maintenance
instructions in the literature
accompanying your shelf system.
Your shelf system utilizes a Class 1 laser to read
Compact Discs. Your shelf system is equipped
with safety switches to avoid exposure when
the CD tray is open and the safety interlocks are
defeated. Invisible laser radiation is present
when the CD tray is open and the system's
interlock has failed or been defeated. Yo u
should avoid direct exposure to the laser beam
at all times. Do not attempt to defeat or bypass
the safety switches. Do not stare into the
beam.
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this apparatus near water.
6. Clean only with dry cloth.
7. Do not block any ventilation openings.
Install in accordance with the
manufacturer’s instructions.
8. Do not install near any heat sources such
as radiators, heat registers, stoves, or
other apparatus (including amplifiers) that
produce heat.
9. Do not defeat the safety purpose of
the polarized or grounding-type plug. A
polarized plug has two blades with one
wider than the other. A grounding type
plug has two blades and a third grounding
prong. The wide blade or the third prong
are provided for your safety. If the provided
plug does not fit into your outlet, consult an
electrician for replacement of the obsolete
outlet.
10. Protect the power cord from being walked
on or pinched particularly at plugs,
convenience receptacles, and the point
where they exit from the apparatus.
11. Only use attachments/accessories
specified by the manufacturer.
12. Use only with the cart, stand, tripod,
bracket, or table specified by the
manufacturer, or sold with the apparatus.
When a cart is used, use caution when
moving the cart/apparatus combination to
avoid injury from tip-over.
13. Unplug this apparatus during lightning
storms or when unused for long periods of
time.
14. Refer all servicing to qualified service
personnel. Servicing is required when
the apparatus has been damaged in any
way, such as power-supply cord or plug
is damaged, liquid has been spilled or
objects have fallen into the apparatus, the
apparatus has been exposed to rain or
moisture, does not operate normally, or has
been dropped.
Important Safety Instructions
PORTABLE CART WARNING
(Symbol provided by RETAC)
All-In-One Shelf System
www.insigniaproducts.com
17
To reduce the risk of fire or electric shock, do not
expose this device torain, moisture, dripping, or
splashing, and no objects filled with liquids,
such as vases, shall be placed on it.
15
The wall plug is the disconnecting device.
The plug must remain readily operable.
16
Batteries should not be exposed to
excessive heat such as sunshine,
fire, or the like.
WARNING: To reduce the risk of fire or
electric shock, do not expose this
apparatus to rain or moisture.
18
All-In-One Shelf System
www.insigniaproducts.com
1. Lisez ces instructions.
2. Conservez ces instructions.
3. Tenez compte de tous les avertissements.
4. Suivez toutes les instructions.
5. N’utilisez pas cet appareil près de l’eau.
6. Nettoyez uniquement avec un chiffon sec.
7. Ne bloquez pas les ouvertures de
ventilation. Réalisez l’installation en
respectant les instructions du fabricant.
8. N’installez pas l’appareil près d’une source
de chaleur telle qu’un radiateur, un poêle
ou tout autre appareil (y compris les
amplificateurs) qui produit de la chaleur.
9. N’outrepassez pas les mesures de sécurité
de la fiche polarisée ou avec mise à la terre.
Les fiches polarisées possède deux lames
de taille différente, une plus large que
l’autre. Les fiches avec mise à la terre ont
deux lames plus une broche de mise à la
terre. La lame large et la broche de mise à
la terre sont là pour des raisons de sécurité.
Si la fiche fournie ne peut pas être insérée
dans votre prise de courant, consultez un
électricien pour la faire remplacer.
10. Empêchez le cordon d’alimentation d’être
piétiné ou pincé, en particulier au niveau
des fiches, des prises de courant et des
sorties des appareils.
Instructions importantes de sécurité
11. Utilisez uniquement les accessoires
spécifiés par le fabricant.
12. Utilisez uniquement un chariot, un support,
un trépied, une applique ou une table
spécifié par le fabricant ou vendu avec
l’appareil. Quand vous utilisez un chariot,
faites attention lorsque vous déplacez en
même temps le chariot et l’appareil qu’il ne
se renverse pas et vous blesse.
13. Débranchez cet appareil pendant un orage
ou s’il ne doit pas être utilisé pendant une
période prolongée.
14. Confiez toutes les réparations à du
personnel de service qualifié. L’appareil
doit être réparé s’il a été endommagé
de tel façon que le cordon ou la fiche
d’alimentation est endommagée, si un
liquide a coulé ou un objet est tombé à
l’intérieur, si l’appareil a été exposé à la
pluie ou à l’humidité, s’il ne fonctionne pas
normalement ou est tombé.
AVERTISSEMENT SUR LES
CHARIOTS PORTABLES
(Symbole fourni par RETAC)
All-In-One Shelf System
www.insigniaproducts.com
FCC Statement
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
1) This device may not cause harmful interference, and 2) This device must accept any interference received, including
interference that may cause undesired operation.
Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to
part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and
used in accordance with the instructions, may cause harmful interference to radio communication. However, there is no
guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference
to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged
to try to correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
RF Exposure Warning
This equipment must be installed and operated in accordance with provided instructions and the antenna(s) used for
this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be
co-located or operating in conjunction with any other antenna or transmitter. End-users and installers must be provide
with antenna installation instructions and transmitter operating conditions for satisfying RF exposure compliance.
Industry Canada Regulatory Information
This device complies with RSS-247 of the Industry Canada Rules. Operation is subject to the following two conditions: 1)
this device may not cause interference and 2) this device must accept any interference, including interference that may
cause undesired operation of the device.
Industry Canada Regulatory Information Avis d’Industrie Canada
CAN ICES-3 (B)/NMB-3 (B) CAN ICES-3 (B)/NMB-3 (B)
IC Radiation Exposure Statement: This equipment complies with IC radiation exposure limits set forth for an
uncontrolled environment.
Advertencia sobre Exposición a Radiofrecuencias (RF)
Este equipo debe instalarse u operarse de acuerdo con las instrucciones suministradas. La(antena(s) utilizada(s) con este
transmisor debe(n) instalarse de modo de proporcionar una distancia de separación mínima de 20 cm de todas las personas
y no debe colocarse u operarse conjuntamente con otra antena o transmisor. Los usuarios finales y los instaladores deben recibir
instrucciones de instalación para la antena y condiciones de operación del transmisor para satisfacer los requisitos
de exposición a radiofrecuencias.
Información Regulatoria de la Industria Canadiense
Este dispositivo cumple con la Sección RSS-247 de las Normas de la Industria Canadiense. Su funcionamiento está sujeto a las
siguientes dos condiciones: 1) este aparato no debe causar interferencia y 2) este aparato debe aceptar toda interferencia, incluida
aquélla que puede causar un funcionamiento no deseado del dispositivo.
Información Regulatoria de la Industria Canadiense
CAN ICES-3 (B)/NMB-3 (B)
Declaración IC de exposición a la radiación: Este equipo cumple con los límites de exposición a la radiación establecidos por
Declaración de la Comisión Federal de Comunicaciones de los Estados Unidos
Este dispositivo cumple con la Parte 15 de las Reglas de la FCC. Su funcionamiento está sujeto a las siguientes dos condiciones:
1) Este dispositivo no debe causar interferencia y 2) Este dispositivo debe aceptar toda interferencia recibida, incluida aquélla que
puede causar un funcionamiento no deseado.
Aviso: Este equipo ha sido probado, y se consideró que cumple con los límites de los aparatos digitales de Clase B, de acuerdo con
las especificaciones de la Parte 15 de las Reglas de la FCC. El objetivo de estos límites es ofrecer una protección razonable contra
interferencias nocivas en una instalación residencial. Este equipo genera, utiliza y puede radiar energía de radiofrecuencia y, si no
se instala y utiliza de acuerdo con estas instrucciones, puede generar interferencia perjudicial para
las radiocomunicaciones. Sin embargo, no se garantiza que no se producirá interferencia en una instalación en particular.
Si su equipo causa interferencia perjudicial para la recepción de radio o televisión, que se puede averiguar apagando y
encendiendo el equipo, intente corregirla mediante uno o varios de los siguientes procedimientos:
• Vuelva a orientar o cambie de lugar la antena receptora.
• Aumente la separación entre el equipo y el receptor.
• Conecte este equipo a un tomacorriente en un circuito diferente al que esté conectado el receptor.
• Consulte al distribuidor o a un técnico experimentado de radio y televisión para solicitar asistencia.
IC para un entorno no controlado.
NS-HAIOR18
www.insigniaproducts.com
Features
• 80W RMS total power for a superior listening experience
• 20W RMS left and right channels play audio in surround sound
• 40W RMS built-in subwoofer for rich bass
• Bluetooth connects to devices wirelessly
• FM tuner lets you listen to the radio
• CD player provides a variety of audio options
• USB port supports MP3 playback
• 3.5 mm audio input connects to analog devices
• Headphone jack enables private listening
All-In-One Shelf System
www.insigniaproducts.com
Package contents
• All-In-One Shelf System
•FM antenna
• Remote control
•Quick Setup Guide
Front view
Back view
Speaker
Speaker
Source
Remote sensor
Play/Pause
Display
Disc slot
Volume -/+
Standby
USB port
Line in
Headphone
jack
Previous
Next
Eject disc
FM antenna jack Power on/off AC power input
• AAA batteries (2)
NS-HAIOR18
www.insigniaproducts.com
Remote control
Standby
Source (input)
Eject disc
Repeat
Raise volume
Rewind/Previous/
Tune-
Preset - /
Skip back 10 tracks
Dim display/
Go back a folder
Show clock
Mute
Auto/Stop
Play/Pause
Fast forward/
Next/Tune +
Lower volume
Preset + /
Skip forward 10 tracks
Brighten display/
Open next folder
Timer/Program
Select sound equalizer
All-In-One Shelf System
www.insigniaproducts.com
Setting up your shelf system
Turning on your shelf system
1Connect the power cord to the AC jack on the back of your shelf
system, then plug the other end into a power outlet.
2Flip the power switch on the back to turn your shelf system ON.
3Press (standby) on your shelf system or remote. The shelf system
greets you with "HELLO."
NS-HAIOR18
www.insigniaproducts.com
Connecting the FM antenna
1Connect the FM antenna (included) to the ANTENNA jack on the back
of your shelf system.
2Adjust the antenna until you find the best reception.
Setting the clock
1In standby mode, press and hold CLOCK on your remote.
2Press (next) or (previous) to select a 12-hour (“12H”) or
24-hour (“24H”) clock display, then press CLOCK to save.
3Press (next) or (previous) to set the hour, then press CLOCK
to save.
4Press (next) or (previous) to set the minutes, then press
CLOCK to save.
Adjusting the display brightness
• On your remote, press DIM- or DIM+ to dim or brighten your shelf
system’s display.
Note
Press CLOCK on your remote while using the shelf system to
view the time.
Note
To enter standby mode, flip ON the power switch on the back of
your shelf system, but do not press the standby button the
front.
FM antenna jack
FM antenna
All-In-One Shelf System
www.insigniaproducts.com
Inserting remote control batteries
1Remove the remote’s battery cover.
2Insert two AAA batteries into the compartment. Make sure that the +
and – symbols on the battery match the symbols in the compartment.
3Replace the cover.
Using your shelf system
Turning on your shelf system
• Make sure that the power switch on the back of the unit is turned on,
then press STANDBY on the front of your shelf system or on the
remote control.
Selecting the sound source
• Press SOURCE repeatedly on the front of your shelf system or on
the remote control to select FM, LINE IN, BT (Bluetooth), CD, or USB.
The source you select appears on the display.
Adjusting the volume
• After you select the sound source you want, turn the VOLUME knob
to set the volume to a comfortable level.
• Press (mute) to mute the sound. Press (mute) again, or VOL+ or
– to turn the sound back on.
Cautions
• Make sure that you insert the batteries correctly.
• Do not use rechargable (Ni-Cd) batteries.
• Do not heat, open, or short-circuit batteries.
• Do not throw batteries into a fire.
• Do not mix different types of batteries or mix old and
new batteries.
• If the remote control does not function correctly or if the
operating range becomes reduced, replace the batteries.
NS-HAIOR18
www.insigniaproducts.com
Selecting the sound equalization
• Press EQ repeatedly to select the sound equalization you want.
Choose one of the following preset options: CLASSIC, POP, JAZZ,
ROCK, or FLAT.
Using the FM radio
Tuning to a station
1Press SOURCE until the display says “FM.”
2Select a radio station:
• To skip to a preset station, press PRESET- or PRESET+ on your
remote, or press or on your shelf system.
• To incrementally tune the radio frequency, press 10- or 10+ on
your remote.
Adding a preset station
You can manually program a preset station or automatically program all
stations in range. Your shelf system stores up to 30 stations.
To manually program a preset station:
1Select the station, then press PROG on your remote.
2Press (next) or (previous) to select a program number.
3Press PROG again to save the preset station.
To automatically program stations:
• Press AUTO. Your shelf system automatically assigns a program
number to each available station.
Improving FM reception
• For improved FM reception, raise and extend the FM antenna on the
back of your shelf system. You may have to reposition the antenna for
best reception.
Note
See “Adding a preset station“ on page 10 for instructions about
creating preset stations.
All-In-One Shelf System
www.insigniaproducts.com
Using the CD player
You can play audio CDs, CD-Rs, and CD-RWs in standard or 3” size.
1Press SOURCE until the display says “CD.”
2Insert your CD label-side up into the disc slot. Playback begins
automatically.
3Use the controls on the remote or shelf system to control playback.
See “Controlling CD playback on page 11.
4When finished, press (eject) to eject your disc.
Controlling CD playback
• Press (play/pause) to pause playback. Press (play/pause)
again to resume playback.
•Press
(stop) to stop playback. Press (play) to begin playback
from the beginning.
• Press or to skip to the next or previous track.
• Press and hold to fast forward.
• Press and hold to fast reverse.
•Press REPEAT to repeat the current track (“REP ONE”), repeat
the entire CD (“REP ALL”), or turn off repeat (“REP OFF”).
Note
Do not attempt to play DVDs, VCDs, or data CDs in your shelf
system.
Note
If the current track has played more than two seconds, press
to go the beginning of the currently playing track. Press
again to go to the previous track. If the current track has
played for less than two seconds, press to go the previous
track directly.
NS-HAIOR18
www.insigniaproducts.com
Using Bluetooth
Pairing your Bluetooth device
1Make sure that your Bluetooth device (like a music player or phone) is
turned on and within 33 ft. (10 m) of your shelf system.
2On your Bluetooth device, navigate to your Bluetooth settings:
•For iOS devices: Tap Settings > General > Bluetooth.
•For Android devices: Tap Settings > Wireless and networks. Tap
to activate Bluetooth, then tap Bluetooth settings.
•For PC or Mac computers: See the instructions that came with
your computer for more information.
3Press SOURCE repeatedly until the shelf system displays “BT.” Your
shelf system enters Bluetooth pairing mode.
4On your Bluetooth device, select NS-HAIOR18 in the list of devices.
The shelf system beeps twice when paired.
Playing Bluetooth audio
Playback is controlled by the Bluetooth device, by the buttons on the front
of your shelf system, and by the remote control (such as VOL+/–, , ,
and ).
Disconnecting your Bluetooth device
• Turn off the Bluetooth function on your device.
OR
• Press SOURCE to change your shelf system’s input source.
Note
If your shelf system isn’t paired in 15 seconds, “NOBT” appears
on the screen. Press SOURCE repeatedly to cycle back to
"BT" to re-enter pairing mode.
For best results, try to enable Bluetooth on your Bluetooth
device (step 2) and select the source on your shelf system
(step 3) at the same time.
Note
If prompted, enter “0000” as the passcode.
All-In-One Shelf System
www.insigniaproducts.com
Reconnecting your device
If you move out of range or turn off Bluetooth on your Bluetooth device,
the shelf system disconnects from your device and beeps twice. To restore
the connection:
• Move the audio device back into range (within 33 feet), and make
sure there is a clear line of sight and there are no obstructions
between the shelf system and the device.
The connection is automatically reestablished and the LED lights solid
blue.
Connecting to a different device
1On your Bluetooth device you are currently connected to, turn off the
Bluetooth function or unpair the shelf system in your Bluetooth device
list.
The shelf system can now be connected to another Bluetooth Device.
2Follow the section “Pairing your Bluetooth device” on page 12 to
connect a new device.
Receiving a phone call
• If a call is received while playing music through a phone, the music
stops automatically.
• When the call ends, depending on the setting of your phone, the
current track may resume playback.
Notes
The auto-connect feature may not work with some Bluetooth
devices. If this occurs, use your Bluetooth device’s settings menu
to manually select the shelf system from the list of found
Bluetooth devices.
NS-HAIOR18
www.insigniaproducts.com
Using a USB device
1Connect a USB cable from your audio device to your shelf system’s USB
port.
2Press SOURCE repeatedly until the display says “USB.”
3Use your speaker system or remote to control playback and adjust the
volume:
• Press (previous) or (next) to skip to the previous or next
track.
• Press (previous folder) or (next folder) to navigate through
your audio device's folders.
• Turn the volume knob or press Vol+ or Vol- on your remote to
adjust the volume.
Note
• Depending on the amount of data and the media speed,
it may take longer for the system to read the contents of
the USB device.
• Even when the files are in a supported format, some may
not play or display, depending on the content.
All-In-One Shelf System
www.insigniaproducts.com
Using an AUX device
1Connect a 3.5 mm audio cable (not included) from your audio device
to the shelf system’s LINE IN jack.
2Press SOURCE repeatedly until the display says “LINE IN.”
3Use the controls on your audio device to control playback and the
controls on your shelf system to adjust the volume.
Connecting headphones
• Connect your headphones to the headphone jack.
Note
Make sure that your audio device’s volume is set to at least 50%.
NS-HAIOR18
www.insigniaproducts.com
Troubleshooting
Problem Solution
No power. • Make sure that the power cord is securely connected to your shelf system
and the power outlet.
• Make sure that the power switch on the back of the unit is turned on.
The remote control
does not work.
• Replace the remote batteries.
• Make sure that you are aiming the remote control at the front of the shelf
system and that the remote sensor is not blocked.
“No Disc” error • Make sure that there is a CD in the disc tray.
• Make sure that the CD disc is correctly inserted (label side up).
• Make sure that you are using a compatible disc. (CDs, CD-Rs, and CD-RWs in
standard or 3” size.)
• Make sure that the disc is not dirty or scratched.
No sound. • Make sure that power is connected and your shelf system is turned on.
• Make sure that the power switch on the back of the shelf system is turned
on.
• Make sure that your audio device is turned on and is playing.
• Make sure that the volume on your audio device is turned up and is not set
to mute.
• Make sure that the volume is not extremely low.
• Make sure that the correct source has been selected.
• Make sure all connections are correct.
• Make sure that no wires or cables are damaged or broken.
• Disconnect the headphones. Sound will be muted if headphones are
connected.
The CD skips while
playing.
• Make sure that you are using a standard CD (normal size and shape) or 3”
CD.
• Make sure your CD is a compatible format.
• Make sure that you do not move your shelf system while it is playing and
that it is positioned on a flat, steady surface.
• Clean the CD by wiping outwards from the center (not in a circle) with a
clean cloth. If a dry cloth does not clean the CD, wipe the CD with a slightly
moistened, soft cloth, then dry it with a soft cloth. Do not use any solvents
to clean CDs.
• Your CD may be damaged. Try playing another CD.
What should I do if
my CD will not play?
• Make sure that the CD is correctly inserted with the label facing up.
• Make sure that the correct audio source is selected.
• Clean the CD by wiping outwards from the center (not in a circle) with a
clean cloth. If a dry cloth does not clean the CD, wipe the CD with a slightly
moistened, soft cloth, then dry it with a soft cloth. Do not use any solvents
to clean CDs.
• Make sure that your CD is compatible. Your shelf system can play CDs,
CD-Rs, and CD-RWs. Your CD may be damaged. Try playing another CD.
Severe hum or noise
or can’t receive FM
stations.
• Make sure that FM reception is adequate. Move the antenna or move the
unit away from possible sources of interference.
• The FM signal may be weak. Select a different station.
No sound in
Bluetooth mode.
• Make sure that the Bluetooth device is still connected. Reconnect if
necessary.
• Make sure you are playing music from your device.
• Turn up the volume on your Bluetooth device.
• Make sure that your Bluetooth device is within 33 ft. (10 m) of your shelf
system.
• Make sure that your Bluetooth device is not muted.
All-In-One Shelf System
www.insigniaproducts.com
Cleaning your shelf system
To prevent fire or shock hazard, disconnect your shelf system from the AC
power source when cleaning.
The finish on your shelf system may be cleaned with a dust cloth and
cared for as other furniture. Use caution when cleaning and wiping the
plastic parts.
Specifications
Will not pair to a
device.
• Make sure that the Bluetooth device is turned on.
• Make sure that the Bluetooth device is in pairing mode, then select
NS-HAIOR18 on the Bluetooth device. See the instructions that came with
the Bluetooth device.
• The Bluetooth device may be too far away from your shelf system. Move the
Bluetooth device within 33 ft. (10 m) of your shelf system.
• The Bluetooth device does not use a supported Bluetooth protocol (A2DP).
• Make sure your Bluetooth device is not muted.
• Make sure that your phone or device is Bluetooth-compatible.
• Try re-pairing the shelf system. See “Using Bluetooth” on page 12.
• Your shelf system may already be connected to a different Bluetooth device.
You have to turn off Bluetooth or unpair from the currently paired device
and manually connect to the other paired device.
Bluetooth signal
fades or drops out
• Shorten the distance between your shelf system and the Bluetooth device.
The maximum connection distance is 33 ft. (10 m). However, this distance
may be reduced if the wireless signal has to pass through walls or other
obstructions.
Dimensions (HxWxD) 55 x 112.2 x 185 in. (140 x 285 x 470 mm)
Weight 4 lbs. (1.8 kg)
Power supply ~100-240V AC, 50/60Hz
Audio output power 20W × 2 + 40W
Frequency response 20Hz~20kHz (±3dB)
CD compatibility CDs, CD-Rs, CD-RWs in standard or 3” size
FM frequency 87.5 - 107.9 MHz
FM presets 30
Operating environment Temperature: 14°~95°F (-10°~35°C)
Relative humidity: 5~90%
Bluetooth Transmission frequency: 2.4 GHz
Working distance: 33 ft. (10 m)
Input jacks USB and LINE IN
Problem Solution
Supported file formats
(USB)
MP3
NS-HAIOR18
www.insigniaproducts.com
Legal notices
FCC Caution:
Changes or modifications not expressly approved by the party responsible for compliance could
void the user's authority to operate the equipment.
RSS-Gen & RSS-247 statement:
This device complies with Industry Canada licence-exempt RSS standard(s).
Operation is subject to the following two conditions: (1) this device may not cause interference,
and (2) this device must accept any interference, including interference that may cause undesired
operation of the device.
Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils radio
exempts de licence. L'exploitation est autorisée aux deux conditions suivantes : (1) l'appareil ne
doit pas produire de brouillage, et (2) l'utilisateur de l'appareil doit accepter tout brouillage
radioélectrique subi, même si le brouillage est susceptible d'en compromettre le
fonctionnement.
RSS-102 Statement:
This equipment complies with Industry Canada radiation exposure limits set forth for an
uncontrolled environment.
Cet équipement est conforme à l'exposition aux rayonnements Industry Canada limites établies
pour un environnement non contrôlé.
All-In-One Shelf System
www.insigniaproducts.com
ONE-YEAR LIMITED WARRANTY - INSIGNIA
Definitions:
The Distributor* of Insignia branded products warrants to you, the original purchaser of this new
Insignia-branded product (“Product”), that the Product shall be free of defects in the original
manufacturer of the material or workmanship for a period of one (1) year from the date of your purchase
of the Product (“Warranty Period”).
For this warranty to apply, your Product must be purchased in the United States or Canada from a Best
Buy branded retail store or online at www.bestbuy.com or www.bestbuy.ca and is packaged with this
warranty statement.
How long does the coverage last?
The Warranty Period lasts for 1 year (365 days) from the date you purchased the Product. Your purchase
date is printed on the receipt you received with the Product.
What does this warranty cover?
During the Warranty Period, if the original manufacture of the material or workmanship of the Product is
determined to be defective by an authorized Insignia repair center or store personnel, Insignia will (at its
sole option): (1) repair the Product with new or rebuilt parts; or (2) replace the Product at no charge with
new or rebuilt comparable products or parts. Products and parts replaced under this warranty become
the property of Insignia and are not returned to you. If service of Products or parts are required after the
Warranty Period expires, you must pay all labor and parts charges. This warranty lasts as long as you own
your Insignia Product during the Warranty Period. Warranty coverage terminates if you sell or otherwise
transfer the Product.
How to obtain warranty service?
If you purchased the Product at a Best Buy retail store location, please take your original receipt and the
Product to any Best Buy store. Make sure that you place the Product in its original packaging or packaging
that provides the same amount of protection as the original packaging. If you purchased the Product
from a Best Buy online web site (www.bestbuy.com or www.bestbuy.ca), mail your original receipt and the
Product to the address listed on the web site. Make sure that you put the Product in its original packaging
or packaging that provides the same amount of protection as the original packaging.
To obtain warranty service, in the United States call 1-888-BESTBUY or in Canada call 1-866-BESTBUY. Call
agents may diagnose and correct the issue over the phone.
Where is the warranty valid?
This warranty is valid only in the United States and Canada at Best Buy branded retail stores or websites to
the original purchaser of the product in the county where the original purchase was made.
What does the warranty not cover?
This warranty does not cover:
• Customer instruction/education
•Installation
•Set up adjustments
• Cosmetic damage
• Damage due to weather, lightning, and other acts of God, such as power surges
• Accidental damage
•Misuse
•Abuse
•Negligence
• Commercial purposes/use, including but not limited to use in a place of business or in communal areas
of a multiple dwelling condominium or apartment complex, or otherwise used in a place of other than
a private home.
NS-HAIOR18
www.insigniaproducts.com
• Modification of any part of the Product, including the antenna
• Display panel damaged by static (non-moving) images applied for lengthy periods (burn-in).
• Damage due to incorrect operation or maintenance
• Connection to an incorrect voltage or power supply
• Attempted repair by any person not authorized by Insignia to service the Product
• Products sold “as is” or “with all faults”
• Consumables, including but not limited to batteries (i.e. AA, AAA, C etc.)
• Products where the factory applied serial number has been altered or removed
• Loss or Theft of this product or any part of the product
• Display panels containing up to three (3) pixel failures (dots that are dark or incorrectly illuminated)
grouped in an area smaller than one tenth (1/10) of the display size or up to five (5) pixel failures
throughout the display. (Pixel based displays may contain a limited number of pixels that may not
function normally.)
• Failures or Damage caused by any contact including but not limited to liquids, gels or pastes.
REPAIR REPLACEMENT AS PROVIDED UNDER THIS WARRANTY IS YOUR EXCLUSIVE REMEDY FOR BREACH
OF WARRANTY. INSIGNIA SHALL NOT BE LIABLE FOR ANY INCIDENTAL OR CONSEQUENTIAL DAMAGES
FOR THE BREACH OF ANY EXPRESS OR IMPLIED WARRANTY ON THIS PRODUCT, INCLUDING, BUT NOT
LIMITED TO, LOST DATA, LOSS OF USE OF YOUR PRODUCT, LOST BUSINESS OR LOST PROFITS. INSIGNIA
PRODUCTS MAKES NO OTHER EXPRESS WARRANTIES WITH RESPECT TO THE PRODUCT, ALL EXPRESS AND
IMPLIED WARRANTIES FOR THE PRODUCT, INCLUDING, BUT NOT LIMITED TO, ANY IMPLIED WARRANTIES
OF AND CONDITIONS OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE, ARE LIMITED IN
DURATION TO THE WARRANTY PERIOD SET FORTH ABOVE AND NO WARRANTIES, WHETHER EXPRESS OR
IMPLIED, WILL APPLY AFTER THE WARRANTY PERIOD. SOME STATES, PROVINCES AND JURISDICTIONS DO
NOT ALLOW LIMITATIONS ON HOW LONG AN IMPLIED WARRANTY LASTS, SO THE ABOVE LIMITATION MAY
NOT APPLY TO YOU. THIS WARRANTY GIVES YOU SPECIFIC LEGAL RIGHTS, AND YOU MAY ALSO HAVE
OTHER RIGHTS, WHICH VARY FROM STATE TO STATE OR PROVINCE TO PROVINCE.
Contact Insignia:
For customer service please call 1-877-467-4289
www.insigniaproducts.com
INSIGNIA is a trademark of Best Buy and its affiliated companies.
Distributed by Best Buy Purchasing, LLC
©2017 Best Buy. All rights reserved.
Made in China
www.insigniaproducts.com
1-877-467-4289 (U.S. and Canada) or 01-800-926-3000 (Mexico)
INSIGNIA is a trademark of Best Buy and its affiliated companies.
Distributed by Best Buy Purchasing, LLC
©2017 Best Buy. All rights reserved.
Made in China.
V1 ENGLISH
16-1140
