user_manual
1
Portable Digital Piano
Manual Instruction
P-200
Test Model：P-200
2
contents
Precaution .......................................................................................................................................................... 3
Panel Controls and Terminals .............................................................................................................................6
Basic operations
Power on\Panel locking\Setting the Volume\Connect Headphone\Accompaniment Volume.......................7
Chord\Synchronous starting\Prelude、Finale\A insert 1\ B insert 2.................................................................8
Sound\Rhythm function..................................................................................................................................... 8
Record\Metronome\Dual voice\Bluetooth MP3 function ................................................................................9
Demo play and teaching function\Function control\Octave............................................................................10
Transpose\Memory setting\Single button preset.............................................................................................. 11
Double keyboard\Split point setting\Effect setting...........................................................................................
12
Effect\Reverb\Chorus\Tempo\Touch.............................................................................................................. 13
Percussion music\Single Pedal(Standard)\Three Pedal(Optional).................................................................. 14
Appendix
Sound list ...........................................................................................................................................................15
Rhythm list ........................................................................................................................................................20
MIDI keyboard percussion music checking list ................................................................................................23
Demo songs list ................................................................................................................................................. 25
Specification ......................................................................................................................................................27
Troubleshooting ............................................................................................................................................... 28
3
PRECAUTIONS
PLEASE READ CAREFULLY BEFORE PROCEEDING
Please keep this manual in a safe and handy place for future reference.
WARNING
Always follow the basic precautions listed below to avoid the possibility of serious injury or
even death from electrical shock, short-circuiting, damages, fire or other hazards. These
precautions include, but are not limited to, the following:
CAUTION
Always follow the basic precautions listed below to avoid the possibility of physical injury to
you or others, or damage to the instrument or other property. These precautions include, but
are not limited to, the following:
Water warningPower supply/AC power adaptor
*Do not place the power cord near heat sources such
as heaters or radiators. Also, do not excessively bend or
otherwise damage the cord, or place heavy objects on it.
*Only use the voltage specified as correct for the
instrument. The required voltage is printed on the name
plate of the instrument.
*Use the specified adaptor (page 32) only. Using the
wrong adaptor can result in damage to the instrument or
overheating.
*Check the electric plug periodically and remove any dirt
or dust which may have accumulated on it.
Do not open
*This instrument contains no user-serviceable parts. Do
not open the instrument or attempt to disassemble or
modify the internal components in any way. If it should
appear to be malfunctioning, discontinue use immediately
and have it inspected by qualified Yamaha service
personnel.
*Do not expose the instrument to rain, use it near water or
in damp or wet conditions,place on it any containers (such
as vases, bottles or glasses) containing liquids which might
spill into any openings. If any liquid such as water seeps
into the instrument, turn off the power immediately and
unplug the power cord from the AC outlet. Then have the
instrument inspected by qualified Amason service personnel.
*Never insert or remove an electric plug with wet hands.
Fire warning
If you notice any abnormality
*Do not put burning items, such as candles, on the unit.
A burning item may fall over and cause a fire.
*When one of the following problems occur,immediately
turn off the power switch and disconnect the electric plug
from the outlet. Then have the device inspected by
Amason service personnel.
- The power cord or plug becomes frayed or damaged.
- It emits unusual smells or smoke.
- Some object has been dropped into the instrument.
- There is a sudden loss of sound during use of the
instrument.
Power supply/AC power adaptor
*Do not connect the instrument to an electrical outlet
using a multiple-connector.Doing so can result in lower
sound quality, or possibly cause overheating in the outlet.
*When removing the electric plug from the instrument
or an outlet, always hold the plug itself and not the cord.
Pulling by the cord can damage it.
*Remove the electric plug from the outlet when the
instrument is not to be used for extended periods of time,
or during electrical storms.
Location
*Do not place the instrument in an unstable position
where it might accidentally fall over.
*When transporting or moving the instrument, always
use two or more people.Attempting to lift the instrument
by yourself may damage your back, result in other injury,
or cause damage to the instrument itself.
*Before moving the instrument, remove all connected
cables, to prevent damage to the cables or injury to
anyone who might trip over them.
4
* Read carefully the attached documentation explaining
the assembly process. Failure to assemble the instrument
in the proper sequence might result in damage to the
instrument or even injury.
* When setting up the product, make sure that the AC
outlet you are using is easily accessible. If some trouble or
malfunction occurs, immediately turn off the power
switch and disconnect the plug from the outlet. Even
when the power switch is turned off, electricity is still
flowing to the product at the minimum level. When you
are not using the product for a long time, make sure to
unplug the power cord from the wall AC outlet.
* Use only the stand specified for the instrument. When
attaching the stand or rack,use the provided screws only.
Failure to do so could cause damage to the internal
components or result in the instrument falling over.
* Do not use the instrument/device or headphones for a
long period of time at a high or uncomfortable volume
level, since this can cause permanent hearing loss. If you
experience any hearing loss or ringing in the ears, consult
a physician.
Connections
* Before connecting the instrument to other electronic
components, turn off the power for all components.
Before turning the power on or off for all components, set
all volume levels to minimum.
* Be sure to set the volumes of all components at their
minimum levels and gradually raise the volume controls
while playing the instrument to set the desired listening
level.
Handling caution
* Do not insert a finger or hand in any gaps on the key
cover or instrument. Also take care that the key cover
does not pinch your finger.
* Never insert or drop paper, metallic, or other objects
into the gaps on the key cover,panel or keyboard. This
could cause physical injury to you or others, damage to
the instrument or other property, or operational failure.
* Do not rest your weight on, or place heavy objects on
the instrument, and do not use excessive force on the
buttons, switches or connectors.
Amason cannot be held responsible for damage caused by improper use or modifications to the instrument, or data that is lost or destroyed.
Using the bench (If included)
* Do not place the bench in an unstable position where it
might accidentally fall over.
* Do not play carelessly with or stand on the bench. Using
it as a tool or stepladder or for any other purpose might
result in accident or injury.
* Only one person should sit on the bench at a time, in
order to prevent the possibility of accident or injury.
* If the bench screws become loose due to extensive long-
term use, tighten them periodically using the included
tool.
* Keep special watch over any small children so that they
don’t fall off the rear of the bench.Since the bench does
not have a backrest, unsupervised use may result in
accident or in jury.
NOTICE
To avoid the possibility of malfunction/ damage to the product, damage to data, or damage to other property, follow
the notices below.
■ Handling and Maintenance
* Do not use the instrument in the vicinity of a TV, radio, stereo equipment, mobile phone, or other electric devices.
Otherwise, the instrument, TV, or radio may generate noise. When you use the instrument along with the application
on your iPhone/iPad, we recommend that you set “Airplane Mode” to “ON” on your iPhone/iPad in order to
avoid noise caused by communication.
* Do not expose the instrument to excessive dust or vibrations, or extreme cold or heat (such as in direct sunlight, near
a heater, or in a car during the day) to prevent the possibility of panel disfiguration, damage to the internal components
or unstable operation. (Verified operating temperature range: 5° – 40°C, or 41° – 104°F.)
* Do not place vinyl, plastic or rubber objects on the instrument, since this might discolor the panel or keyboard.
* In the case of a model with a polished finish, bumping the surface of the instrument with metal, porcelain, or other
hard objects can cause the finish to crack or peel. Use caution.
* During extreme changes in temperature or humidity, condensation may occur and water may collect on the surface
of the instrument. If water is left, the wooden parts may absorb the water and be damaged. Make sure to wipe any water
off immediately with a soft cloth.
Assembly
5
■ Saving data
* Saved data may be lost due to malfunction or incorrect operation. Save important data to external device such as a
computer (see online manual, Computer-related Operations; page 7)
■ About copyrights
* Copying of the commercially available musical data including but not limited to MIDI data and/or audio data is
strictly prohibited except for your personal use.
* This product incorporates and bundles computer programs and contents in which Yamaha owns copyrights or with
respect to which it has license to use others’ copyrights. Such copyrighted materials include, without limitation, all
computer software, style files, MIDI files, WAVE data, musical scores and sound recordings. Any unauthorized use of
such programs and contents outside of personal use is not permitted under relevant laws. Any violation of copyright
has legal consequences. DON’T MAKE, DISTRIBUTE OR USE ILLEGAL COPIES.
■ About functions/data bundled with the instrument
* Some of the preset songs have been edited for length or arrangement, and may not be exactly the same as the original.
■ About this manual
* The illustrations as shown in this manual are for instructional purposes only, and may appear somewhat different
from those on your instrument.
* The company names and product names in this manual are the trademarks or registered trademarks of their
respective companies.
6
Panel Controls and Terminals
1 [ ](Standby/On/Panel locking) Switch ...page 7
For turning the power on\ setting to standby or Panel locking.
2 [MASTER VOLUME] knob .......................page 7
For adjusting the volume of the entire sound.
3 [ACCOMPANY VOLUME] button .............page 7
For adjusting the accompany volume.
4 [CHORD ON/OFF] button ........................page 8
For turn on or turn off the chord function.
5 [START/STOP，SYN START] button ......page 8
For Start/Stop the accompany function.
6 [PRELUDE/CODA] button ........................page 8
For Auto play Prelude/Coda.
7 [A/FILL 1] button .......................................page 8
Music get into A mode when in automatic playing.
8 [B/FILL 2] button .......................................page 8
Music get into B mode when in automatic playing.
9 [FUNCTION] button ............................... page 10
Simultaneously press this button and specified key sets will set
different effect and function.
10 [SOUND] button .....................................page 8
Choosing the sound.
11 [RHYTHM] button ...................................page 8
Choosing the accompaniment.
12 [DATA/TEMPO] +/-button......................page 10
Press Date/Tempo button at the same time, then the demo or
teaching song will be on.
13 [METRONOME] button ..........................page 9
For Start or Stop metronome.
14 [RECORD] button .................................. page 9
For Recording the music when playing.
15 [PLAY/STOP] button .............................. page 9
For playing or stopping the music.
16 [DUAL VOICE] button ............................page 9
For In/Out dual voice effect.
17 [ ,VOL-] button ..................................page 9
Choosing the last track when playing MP3, Long press the
button to turn the volume down.
18 [ , ] button ......................................page 9
Start or stop MP3 music, Long press the button to connect with
Bluetooth.
19 [ ,VOL+] button ................................ page 9
Choosing the next track when playing MP3, Long press the
button to turn the volume up.
20 [MODE] button .......................................page 9
For switching mode when playing MP3.
21 [SD] button .............................................page 9
For connecting SD card.
22 Standard [USB] jack ...............................page 9
For connecting USB.
23 [PHONE1/2] jack ....................................page 7
For connecting a set of standard stereo headphones.
24 [USB] jack ..............................................page 7
For connecting to a computer.
25 [PEDAL UNIT] jack ...............................page 13
For connecting three pedal Cord.
26 [PEDAL] jack ........................................page 13
For connecting the sustains pedal.
27 [INPUT] jack ...........................................page 6
For Audio input jack.
28 [OUTPUT] jack .......................................page 6
For Audio output jack.
29 [DC] jack ................................................page 7
For connecting the power adapter.
ACCOMPANY
VOLUME
CHORD ON/OFF
START/TOP
SYN START
PRELUDE/CODA A/FILL1 B/FILL2
MINMAX
MASTER
VOLUME
AUTO ACCOMP-
PEDAL UNIT PEDAL
1 2 3 4 5 6 7 8 9 10 11 12 12 13 14 15 16 17 18 19 20
21 22 23 23
PEDAL UNIT PEDAL
24 25 26 27 28 29
7
Basic Operations
Turning the Power On
Panel locking
Volume adjustment
Connecting Headphone
Accompany Volume
1.Connect the plugs of the AC power adapter in the order shown in the illustration.
Use the specified adapter only. The used of other adapters may result in irreparable damage to both the adapter and the
instrument.
Remove the AC plug from the AC outlet when the instrument is not to be used for extended periods of time, or during
electrical storms.
NOTE：Follow this procedure in reverse order when disconnecting the power adapter.
CAUTION
WARNING
When you start playing, adjust the [MASTER VOLUME] on control panel to set the volume.
Do not used this instrument at a high volume level (Especially when using headphone) or your
hearing may be damaged.
Press [ACCOMPANY VOLUME] button for a second, indicator light on, then press (DATA/TEMPO)button,
indicator light on, then you can adjust the accompany volume; (range: 0-32, default: 20)
Since the instrument is equipped with two sets of standard stereo
headphones jack at the lower left, One is mute interface which
automatically shuts off the speakers when using it. The other one
is headphone interface that the headphone and speaker sound in
the same time. You can use the master volume knob to adjust the
sound level.
3. The instrument will turns the power off automatically if the instrument is not operated for approximately 30 minutes.
2. Even when the [ ]（Off/On）switch is on standby, electricity is still flowing to the instrument at a minimum level.
Please remove the AC plug from the wall AC outlet if the instrument will not be used for a period of time.
ACCOMPANY
VOLUME
CHORD ON/OFF
START/TOP
SYN START
PRELUDE/CODA A/FILL1 B/FILL2
MINMAX
MASTER
VOLUME
AUTO ACCOMP-
1. Press the [ ]button for a second. The sound will be default tone.
ACCOMPANY
VOLUME
CHORD ON/OFF
START/TOP
SYN START
PRELUDE/CODA A/FILL1 B/FILL2
MINMAX
MASTER
VOLUME
AUTO ACCOMP-
1.Press[ ]button, the panel will be in locked mode, only the unlock key can be used. The sound of counterclockwise
rotation will be turned down.
2.Press[ ]button can unlock the panel.
ACCOMPANY
VOLUME
CHORD ON/OFF
START/TOP
SYN START
PRELUDE/CODA A/FILL1 B/FILL2
MINMAX
MASTER
VOLUME
AUTO ACCOMP-
ACCOMPANY
VOLUME
CHORD ON/OFF
START/TOP
SYN START
PRELUDE/CODA A/FILL1 B/FILL2
MINMAX
MASTER
VOLUME
AUTO ACCOMP-
USBPHONE 1PHONE 2
SD
ACCOMPANY
VOLUME
DATA/TEMPO
SONG/TEACHING
AC power adapter AC power plug
8
Chord
Start/Stop, SYN Start
Prelude/Coda
A ll 1
B ll 2
Sound
Rhythm
1.Press [CHORD ON/OFF] button, indicator light on, Automatic Chord Function on.
2.Press [CHORD ON/OFF] button, indicator light off, Automatic Chord Function off.
Press [START/STOP, SYN Start] button, Digital tube blinking, then press any key to make
the automatic accompany on. (If “CHORD ON/OFF” function on, only the left side
keys will be work. To press the [START/STOP, SYN START] button again, the automatic
accompany function will turn off.
Before automatic accompany start, press [PRELUDE/CODA] button, Prelude on and get
into the main music A. Press [PRELUDE/CODE] button when automatic accompany
playing, accompany will play a coda automatically and end the music.
Press [A FILL 1] when in automatically accompany on, Accompany function will get into
main music A.
Press [B FILL 2] when in automatically accompany on, Accompany function will get into
main music B.
Press [SOUND] button, Sound choosing function is activated, The sound number will display on digital tube. Then
press [DATA/TEMPO] button to switch the sound within 5 seconds.
Press [SOUND] button when sound function activated, the sound will be switched to Grand piano sound.
Press [Rhythm] button to activate the rhythm function, then press [DATA/TEMPO] button to choose rhythm.(For
Rhythm list, refer to appendix)
CHORD ON/OFF
START/STOP
SYN START
PRELUDE/CODA
A/FILL 1
B/FILL 2
SOUND DATA/TEMPO
SONG/TEACHING
9
Record
Metronome
Dual Voice
Bluetooth MP3 Function
RHYTHM DATA/TEMPO
SONG/TEACHING
This instrument can record music, including record the accompany in the piano. Operation as follows:
Record:
1.Press [RECORD] button, indicated light is on, and default metronome will be on and start to record; Press
[METRONOME] button if you need to turn off the metronome.
2.After recording, Press [RECORD] button, indicated light is off, log out the record function.
Play:
1.Press [PLAY/STOP] button, indicated light is on, The portable piano will play the audio you recorded.
2.After playing, log out the playing function automatically and the indicated light turns off.
1. Press [METRONOME] button on the panel to enable your metronome function; The indicated light will start
flashing and the Tempo shows on the digital tube display. Default tempo: 120BPM/per minute.
2.Press [DATA/TEMPO] +/- button can adjust tempo, Tempo range:20-280BPM/per minute.
3.Press [METRONOME]button again to exit the metronome function. The Portable digital piano will save the current
setting automatically.
4. It will be default metronome when restart the instrument.
1.Press [DUAL VOICE] button, get into the dual voice effect with the flashing indicated light, Default second voice is
048 STRINGS1.
2.To select other second voice by pressing [DATA/TEMPO]+/- button, Press (DUAL VOICE)button to adjust if the
first voice needed.
3.Press [DUAL VOICE] button, indicated light off, shut down the dual voice effect and return the first voice.
Last song/turn down the volume: In playing status, press
it shortly to switch to last composition. Long press to reduce
the volume.
Play - Pause / Bluetooth Matching: In playing status,
press it shortly to play or pause, Long press for Bluetooth
matching.
Next song/Volume: In playing status, press it shortly
to switch to next composition. Long press to increase the
volume
Playing Mode: Switch between USB,SD and Bluetooth.
USB/SD indicated light: the indicated light is on when in USB\SD status.
Bluetooth indicated light: Light on when in Bluetooth status.
USB\SD Use Guideline:
The default status of Bluetooth is standby after power on.It switches to reading status after inserting USB and SD Card.
The red LED flashes during reading. Press [ ] or[ ] to select composition. Press [ ] to play or pause. The red LED
lights constantly when it is paused.
DUAL VOICE DATA/TEMPO
SONG/TEACHING
MODE
VOL- VOL+
USB/SD
Bluetooth PLAYER
(HOLD DOWN)
1234 6
5
1
2
3
4
5
6
10
Demo song play \ Teaching function
Function Control
Octave
1. Playing demo song
Play all the demo songs:
Press [DATA/TEMPO-] and [DATA/TEMPO+] button in the same time, play the demo
songs round, Press the buttons again synchronously to stop the demo song.
Select the demo song to play:
Press [DATA/TEMPO] +/- button to select the demo song.
2. Teaching function (Paipai piano teaching)
Press any key firstly (such as the forty key), then press [DATA/TEMPO-] and [DATA/TEMPO+] button
synchronously, the teaching function turns on, the forty teaching song will be on.
Being an extremely user-friendly instrument, the function of this portable piano are easily activated.Each function is
associated with one of keys on the keyboard.(The name of each function is printed under the corresponding key for
your reference)
1.Press [Function] button, Function selection is activated when indicated light is on.Then press the corresponding key
within 5 seconds.
2. Press [Function] button again or no operation within 5 seconds,the light will be turned off and exit the Function
setting status. At the time the keyboard is in corresponding function.(Note: The keyboard will be silent if in Function
setting status)
1.Press [FUNCTION] button,the indicated light is on. Then press
[OCTAVE] +/- button to adjust the keyboard volume.
2.Press [FUNCTION] button again or no operation within 5 seconds,the
light will be turned off and exit the keyboard volume setting status.
DATA/TEMPO
SONG/TEACHING
DATA/TEMPO
SONG/TEACHING
OFF ON OFF
1 2 3 4 SOFT HARDSTANDARD
BEAT
CHORUS
OFF
EFFECT
OFF
TWIN
PIANO
SPLIT EFFECT
OFF CHORUSREVERB
PERCUSSION
SPLIT
POINT
5 6
REVERB
OFF
TOUCHEFFECTKEYBOARD
FUNCTION
REGIST
BANK
OCTAVE TRANSPOSE
MEMORY 1 2 3 4
REGISTRATION MEMORY
ONE TOUCH
SETTINGS
FUNCTION
OCTAVE TRANSPOSE
MEMORY
FUNCTION
Bluetooth Use Guideline:
Long press [ ] to enter Bluetooth matching status and the blue LED flashes slowly. Use your cellphone to search
for Bluetooth device, The blue LED will flash quickly while playing if it is matched successfully. Press [ ] or [ ]
to choose music. Press [ ] to pause/play music,the Bluetooth indicated light turns on shortly and flashes when it is
paused.
If you want to switch to Bluetooth playing status when the USB and SD Card is reading, you have to press [MODE]
first to switch to Bluetooth mode for matching.
11
Transpose
Memory Setting
OCTAVE TRANSPOSE
MEMORY
FUNCTION
Transpose function can adjust 12 semitones in a Octave range by pressing the
UP or DOWN keys.
1.Press [FUNCTION] button,the indicated light is on. Then press
[TRANSPOSE] +/- button to adjust the keyboard pitch. Adjustable
range:-12~+12.
2.Press [FUNCTION] button again or no operation within 5 seconds,the light
will be turned off and shut off Transpose function.
Memory Setting：
There are 4*10=40 Memory setting available. ( Set1 to Set4, Every setting have 10 setting bank 00-09). To set Rhythm\
Sound\Accompany volume according to your preference. Example: Sound:05, Memory position, Set2, Memory bank
01.
1. Press [SOUND], then press [DATA/TEMPO]+/- to adjust the setting 05 on the display.
2. Press [FUNCTION]button, the indicator light on, Press [ REGIST BANK ]+/- button within 5 seconds to activate
the memory bank and choose memory bank01.
3. Press [MEMORY]button and press[2]key at the same time to save the setting, The instrument will save thesetting to
the setting key your pressed for next time.
Functions of Memory setting: (Lockable specification with *)
Sound Reverb/Switch Transpose Accompany
Dual voice Chorus/Switch Tone tuning Accompany volume
Double keyboard Touch/Switch Metronome Tempo
Keyboardpercussion music Harmony type/Switch Main music A/B
Vibrato/Switch Accompany mode
Memory Recall:
Example: Sound:05, Memory position, Set2, Memory bank 01.
1. Press [FUNCTION]button, the indicator light on,
2. Press [REGIST BANK]+/- button within 5 seconds to adjust the digit on the display.
3. Press [2]key to recall the memory setting.
FUNCTION
SOUND DATA/TEMPO
SONG/TEACHING REGIST
BANK
OCTAVE TRANSPOSE
MEMORY 1 2 3 4
REGISTRATION MEMORY
REGIST
BANK
MEMORY 1 2 3 4
REGISTRATION MEMORY
REGIST
BANK
MEMORY 1 2 3 4
REGISTRATION MEMORY
Single key preset
To press one key only to switch the preset playing mode, including sound,rhythm and other settings in
order to recall the preset mode when you need. When you recall one preset memory, the instrument will
change the channel immediately.
1. To choose any rhythm you want and press [FUNCTION] button, the indicated light up, then press [one touch
settings] key for a while within 5 seconds to enter Single Key Preset status.
2. After that, choose any the corresponding rhythm then press one of keys [1]-[4], the instrument will show you the
corresponding sound,rhythm,Tempo and other setting to you, very convenient for you to get into the music.
12
Split Point
Press [FUNCTION] button, the indicated light up, then press [SPLIT POINT] key within 5 seconds to get into Split
Point Setting status. At this time press any key you want as a Split Point; Press [FUNCTION] button again or no
operation within 5 seconds,the light will be turned off and exit the Split Point Setting function.
STANDARD ON OFFHARD
PERCUSSION
SPLIT
POINT
FUNCTION
REGIST
BANK
OCTAVE TRANSPOSE
MEMORY 1 2 3 4
REGISTRATION MEMORY
ONE TOUCH
SETTINGS
REGIST
BANK
OCTAVE TRANSPOSE
MEMORY 1 2 3 4
REGISTRATION MEMORY
ONE TOUCH
SETTINGS
FUNCTION RHYTHM
Double keyboard : To choose the sound of left side keyboard before pressing [SPLIT] key; Press [FUNCTION]
button, the indicated light up, then press [SPLIT] key within 5 seconds to get into Double keyboard status, the
keyboard will be divided into two keyboard. Press [DATA/TEMPO] key to choose the sound of right side keyboard.
Double piano: Press [FUNCTION] button, the indicated light up, press [SPLIT PIANO] key within 5 seconds to
enter Double piano status, Split Point will divided the keyboard into Left/Right two independent playing area with
piano tone.
Press [FUNCTION] button, the indicated light up, then press [SPLIT OFF] key to exit Double keyboard/ Double
piano status.
FUNCTION
TWIN
PIANO
SPLIT OFF
KEYBOARD
FUNCTION
DATA/TEMPO
SONG/TEACHING
SOUND
Double keyboard
The function can divide the keyboard into two independent keyboard for operation.
Left side keyboard Right side keyboard
13
Effect
1.Press [FUNCTION] button, the indicated light up, then press
[EFFECT] key within 5 seconds to activate Effect function. When
playing the piano has special effect.
2.Press [FUNCTION] button, the indicated light up, then press
[EFFECT OFF] key within 5 seconds to shut off Effect function.
FUNCTION
CHORUS
OFF
EFFECT
OFF
EFFECT CHORUSREVERB REVERB
OFF
EFFECT
Reverb
1.Press [FUNCTION] button, the indicated light up, then press
[REVERB] key within 5 seconds to activate Reverb function. When
playing the piano has reverb effect.
2.Press [FUNCTION] button, the indicated light up, then press
[REVERB OFF] key within 5 seconds to shut off Reverb function.
FUNCTION
CHORUS
OFF
EFFECT
OFF
EFFECT CHORUSREVERB REVERB
OFF
EFFECT
Chorus
1.Press [FUNCTION] button, the indicated light up, then press
[CHORUS] key within 5 seconds to activate Chorus function. When
playing the piano has Chorus effect.
2.Press [FUNCTION] button, the indicated light up, then press
[CHORUS OFF] key within 5 seconds to shut off Chorus function.
FUNCTION
CHORUS
OFF
EFFECT
OFF
EFFECT CHORUSREVERB REVERB
OFF
EFFECT
Tempo
Dynamics click as per beat 1,2,3,4,5,6.
Press [FUNCTION]button, the indicated light up, then press the
corresponding tempo key within 5 seconds can set tempo.
Press [FUNCTION] button again or no operation within 5 seconds, the
indicated light off and exit the Tempo setting
FUNCTION
1 2 3 4
BEAT
5 6
Touch
There are 5 touch curves, Default, Soft, Standard, Hard, Off.
Press [FUNCTION] button, the indicated light up, Press
the corresponding touch key to turn on the keyboard touch
function(Default).
FUNCTION
OFF ON OFFSOFT HARDSTANDARD
PERCUSSION
SPLIT
POINT
TOUCH
14
Percussion music
Single Pedal(Standard)
Three Pedal(Optional)
1.Press [FUNCTION] button, the indicated light up, press [PERCUSSION ON] key within 5 seconds to activate
keyboard Percussion music. Then press [DATA/TEMPO] +/- button to choose 00-10 group percussion music you
want, and the display will show you the data.
2.Press [FUNCTION] button, the indicated light up, press [PERCUSSION OFF] key within 5 seconds to shut off
keyboard Percussion music. The instrument will turn back to the original sound.
Please connect the sustain pedal with the sustain pedal jack, Sustain pedal is standard equipment for this instrument
P-200.
Please connect our three pedal with Pedal Unit Jack.
Sustain Pedal(Right)
Select Pedal (Middle)
Soft Pedal(Left)
FUNCTION
OFF ON OFF
SOFT HARD
STANDARD
PERCUSSION
SPLIT
POINT
TOUCH
15
Sound List
编号（Number) Instrument 乐器 LCD 显示
PIANO( 钢琴 )
00 PIANO GRD 钢琴 """GrdPiano"""
01 PIANO BRITE 明亮钢琴 """BrtPiano"""
02 PIANO ELEC 电子平台钢琴 """Etr Grd"""
03 HONKY-TONK 酒吧钢琴 """HonkTonk"""
04 E PIANO1 电子钢琴 1 """E Piano1"""
05 E PIANO2 电子钢琴 2 """E Piano2"""
06 HARPSCRD 古钢琴 """Harpsi"""
07 CLAVI 克拉维娜 """Clavinet"""
GLOCK( 钟琴 )
08 CELESTA 钢片琴 """Celesta """
09 GLOCKNSPL 钟琴 """GlockSpl"""
10 MUSIC BOX 八音盒 """MusicBox"""
11 VIBRAPHONE 振琴 """VibPhone"""
12 MARIMBA 马林巴 """Marimba """
13 XYLOPHONE 木琴 """XylPhone"""
14 TUBULR BELLS 钟管铃 """TubuBell"""
15 DULCIMER 德西马琴 """Dulcimer"""
ORGAN( 风琴 )
16 HAMND ORG 手摇风琴 """Jazz Org"""
17 PERC ORG 打击乐风琴 """Perc Org"""
18 ROCK ORG 摇滚风琴 """Rock Org"""
19 CHURCH ORG 教堂风琴 """ChrchORg"""
20 REED ORG 簧风琴 """Reed Org"""
21 ACCORDN 1 手风琴 """Accordn1"""
22 HARMONICA 口琴 """Harmonic"""
23 ACCORDN 2 探戈手风琴 """Accordn2"""
GUITAR( 吉它 )
24 GTR NYLON 尼龙弦吉它 """NylonGtr"""
25 GTR STEEL 金属弦吉它 """SteelGtr"""
26 GTR JAZZ 爵士电子吉它 """JazzGtr """
27 GTR CLEAN 清音电子吉它 """CleanGtr"""
28 GTR MUTED 弱音电子吉它 """MutedGtr"""
29 GTR OVRDRV 过速吉它 """OvrdrGtr"""
30 GTR DISTRT 失真吉它 """DistrGtr"""
31 GTR HRMNX 和声吉它 """HrmnxGtr"""
16
BASS( 贝司 )
32 ACOU BASS 原音贝司 """AcouBass"""
33 FINGR BASS 电子贝司 """FngrBass"""
34 PICK BASS 拨弦电子贝司 """PickBass"""
35 FRETLS BASS 无弦码贝司 """FrtlBass"""
36 SLAP BAS 1 击拍贝司 1 """SlapBas1"""
37 SLAP BAS 2 击拍贝司 2 """SlapBas2"""
38 SYN BASS 1 合成贝司 1 """SynBass1"""
39 SYN BASS 2 合成贝司 2 """SynBass2"""
STRING( 弦乐 )
40 VIOLIN 小提琴 """Violin """
41 VIOLA 中提琴 """Viola """
42 CELLO 大提琴 """Cello """
43 CONTRABASS 低音提琴 """CotrBass"""
44 STR TREM 颤音提琴 """Trem Str"""
45 STR PIZZ 拨奏弦乐 """Pizz Str"""
46 HARP 管弦竖琴 """Harp """
47 TIMPANI 定音鼓 """Timpani """
CONCERT( 合奏 )
48 STRINGS 1 弦乐合奏 1 """Strings1"""
49 STRINGS 2 弦乐合奏 2 """Strings2"""
50 STR SYN 1 合成弦乐 1 """Syn Str1"""
51 STR SYN 2 合成弦乐 2 """Syn Str2"""
52 CHOIR AAHS 啊声合唱 """Chr Aah"""
53 VOICE OOHS 噢声合唱 """Voic Oohs"""
54 VOICE SYN 合成音 """SynVoice"""
55 ORCH HIT 流行管弦乐 """Orch Hit"""
BRASS( 铜管乐 )
56 TRUMPT 小号 """Trumpet """
57 TROMBONE 长号 """Trombone"""
58 TUBA 大号 """Tuba """
59 MUTE TPT 弱音小号 """Mute Tpt"""
60 FR HORN 法国号 """FrchHorn"""
61 BRASS SECT 铜管合奏 """BrassSec"""
62 BRASS SYN 1 合成铜管 1 """Syn Brs1"""
63 BRASS SYN 2 合成铜管 2 """Syn Brs2"""
PIPE( 管乐器 )
64 SAX SOPRANO 直管萨克斯 """Sopra Sax"""
17
65 SAX ALTO 高音萨克斯 """Alto Sax"""
66 SAX TENOR 中音萨克斯 """Tenor Sax"""
67 SAX BTONE 低音萨克斯 """Btone Sax"""
68 OBOE 双簧管 """Oboe """
69 ENG HORN 英国管 """Eng Horn"""
70 BASSON 巴松 """Bassoon """
71 CLARINET 单簧管 """Clarinet"""
WOODPIPE
( 木管乐器 )
72 PICCOLO 短笛 """Piccolo """
73 FLUTE 长笛 """Flute """
74 RECORDER 古箫 """Recorder"""
75 PAN FLUTE 排箫 """PanFlute"""
76 BOTTLE BLOWN 瓶木管 """BtlBlown"""
77 SHAKHACHI 洞箫 """ShkHachi"""
78 WHISTLE 哨子 """Whistle """
79 OCARINA 奥卡利娜 """Ocarina """
SYNTH PIPE
( 合成管乐 )
80 SQR WAVE 方波管乐 """SqurWave"""
81 SAW TOOTH 锯齿波管乐 """SawTooth"""
82 CALLIOPE 女神管乐 """Calliope"""
83 CHIFF 鸟鸣管乐 """Chiff """
84 CHARANG 查兰管乐 """Charang """
85 VOICE LEAD 人声管乐 """VoicLead"""
86 5TH LEAD 五度管乐 """5th Lead"""
87 BASS LEAD 贝司管乐 """BassLead"""
SYNTH VOICE
( 合成音色 )
88 NEW AGE 幻想曲 """Fantasia"""
89 WARM PAD 柔和曲 """WarmPad """
90 POLY SYNTH 多重音合成 """PlySynth"""
91 CHOIR PAD 合唱 """ChoirPad"""
92 BOW GLASS 弓弦 """BowGlass"""
93 METAL PAD 金属 """MetalPad"""
94 HALO PAD 环形 """HaloPad """
95 SWEEP 刷擦 """Sweep """
18
SYNTH EFFECT
( 合成效果 )
96 RAIN FX 雨声 """IceRain"""
97 SNDTRK FX 电影效果 """SoundTrk"""
98 CRYSTAL FX 水晶 """Crystal"""
99 ATMOSPH FX 大气 """Atmosphr"""
100 BRIGHT FX 明亮 """BrightFx"""
101 GOBLIN FX 精灵 """GoblinFx"""
102 ECHO FX 回响 """Echo Fx"""
103 SCI-FI FX 科幻声 """Scifi Fx"""
FOLK SOUND
( 民族乐器 )
104 SITAR 西塔尔琴 """Sitar """
105 BANJO 班卓琴 """Banjo """
106 SHAMISEN 三味线 """Shamisen"""
107 KOTO 日本古筝 """Koto """
108 KALIMBA 卡林巴 """Kalimba """
109 BAGPIPE 风笛 """BagPipe """
110 FIDDLE 费得里小提琴 """Fiddle """
111 SHANAI 沙那 """Shanai """
PERCUSSION
( 打击乐器 )
112 TINKLE BELL 脆铃 """TinkBell"""
113 AGOGO 啊蝈蝈 """Agogo """
114 STEEL DRM 金属鼓 """SteelDrm"""
115 WOODBLK 板木鼓 """WoodBlk """
116 TAIKO DRM 日本鼓 """TaikoDrm"""
117 MLDY TOM 美妙通鼓 """MelodyTm"""
118 SYNTH DRM 合成鼓 """SynthDrm"""
119 REVRS CYM 混响钹 """RevrsCym"""
EFFECT( 效果音色 )
120 GTR NOISE 弦码杂音 """GtrNoise"""
121 BREATH 呼吸声 """Breath """
122 SEASHORE 海浪声 """SeaShore"""
123 BIRD TWEET 鸟鸣声 """Birds"""
124 TELEPHONE 电话铃声 """TelPhone"""
125 HELICOPTER 飞机声 """Helicptr"""
19
115 WOODBLK 板木鼓 """WoodBlk """
116 TAIKO DRM 日本鼓 """TaikoDrm"""
126 APPLAUSE 喝彩声 """Applause"""
127 GUNSHOT 枪声 """GunShot """
Folk Music(China)
128 YangQin 杨琴 """YangQin"""
129 LuSheng 芦笙 """LuSheng"""
130 PiPa 琵琶 """Pi Pa """
131 LiuQin 柳琴 """LiuQin"""
132 YueQin 越琴 """YueQin"""
133 DaRuan 大阮 """DaRuan"""
134 ZhonRuan 中阮 """ZhonRuan"""
135 GaoHu 高胡 """GaoHu"""
136 ErHu 二胡 """Er Hu """
137 BangDi 梆笛 """Bang Di """
138 KunDi 昆笛 """Kun Di """
139 Xiao 萧"""Xiao """
140 SanXian 三弦 """San Xian"""
141 GuZheng 古筝 """Gu Zheng"""
142 SuoNa 唢呐 """Suo Na """
143 BianZhong 编钟 """BianZhog"""
144 HuLuSi 葫芦丝 """Hu Lu Si"""
Percussion Effect
00 Standard Drums GM标准鼓组 "Std. Kit"
01 China Drums 中国鼓组 "ChinaKit"
02 Room Drums 室内鼓组 "Room Kit"
03 Jazz Drums 爵士鼓组 "Jazz Kit"
04 Pwr.Drums 重音鼓组 "Pwr. Kit"
05 Electinic Drums 电子鼓组 "ElectKit"
06 T808 Drums T808鼓组 "T808 Kit"
07 Dance Drums 舞曲鼓组 "DanceKit"
08 Brush Drums 镲类鼓组 "BrushKit"
09 Orche Drums 管弦鼓组 "OrcheKit"
10 Sfx.Drums 合成效果 "Sfx. Kit"
20
Rhythm List
No. Rhythm name (EN) Rhythm name(CN) LCD Display
00 8 Beat 1 8 拍 1 "8Beat 1"
01 8 Beat 2 8 拍 2 "8Beat 2"
02 8 Beat 3 8 拍 3 "8Beat 3"
03 8 Beat 4 8 拍摇滚 "8BeatRok"
04 8 Beat Heat 激情8拍 "8Bt Head"
05 8 Beat Pop 1 8 拍流行乐 1 "8Bt Pop1"
06 8 Beat Pop 2 8 拍流行乐 2 "8Bt Pop2"
07 16 Beat 1 16 拍 1 "16Beat 1"
08 16 Beat 2 16 拍 2 "16Beat 2"
09 16 Beat 3 16 拍 3 "16Beat 3"
10 16 Beat 4 16 拍 4 "16Beat 4"
11 16 Beat Funk 16 拍芬克 "16BtFunk"
12 16 Beat Pop 16 拍流行乐 "16BtPop "
13 16 Beat Ballad 16 拍歌谣 "16BtBald"
14 Ballad 1 叙事曲 1 "Ballad 1"
15 Ballad 2 叙事曲 2 "Ballad 2"
16 Guitar Ballad 吉它叙事曲 "GuitBlad"
17 Organ Ballad 风琴叙事曲 "OrgnBald"
18 Bluse Ballad 布鲁斯叙事曲 "BlusBald"
19 Epic Ballad 古老叙事曲 "EpicBald"
20 Rock Ballad 摇滚叙事曲 "RockBald"
21 Slow Ballad 慢板叙事曲 "SlowBald"
22 Pop Ballad 流行叙事曲 "Pop Bald"
23 Electro Pop
Ballad 电声叙事曲 "E.Ballad"
24 Polk Ballad 波尔卡叙事曲 "PolkBald"
25 Country 乡村乐 "Country"
26 Country Rock 乡村摇滚 "CntyRock"
27 Country Shuffle 乡村滑步 "CntyShuf"
28 Country Swing 乡村摇曳 "CntySwin"
29 Country Ballad 乡村叙事曲 "CntyBald"
30 Country Waltz 乡村华尔兹 "CntyWalt"
32 Slow Fox 慢板狐步舞 "SlowFox "
33 Vienna Waltz 维尼那华尔兹 "VinWaltz"
34 Salsa 萨而萨舞曲 "Salsa "
35 Disco 迪斯科 "Disco "
36 Hip Hop Pop 流行希普霍普舞 "HipHopPo"
31 House 室内舞 "House "
21
37 Analog Pop 安诺格流行乐 "AnlogPop"
38 Club Dance 俱乐部舞曲 "ClubDanc"
39 Disco Tropic 热情迪斯科 "DiscoTro"
40 Disco Hands 双人迪斯科 "DiscoHnd"
41 Two Step 双步舞 "TwoStep"
42 Polk Pop 流行波尔卡 "Polk Pop"
43 Waltz 1 华尔兹 1 "Waltz 1"
44 Waltz Pop 1 流行华尔兹 1 "WalzPop1"
45 Waltz Pop 2 流行华尔兹 2 "WalzPop2"
46 Boogie 布吉舞 "Boogie "
47 Funky Pop 新潮流行乐 "FunkyPop"
48 80's Fusion 八十年代熔合乐 "80sFusin"
49 Jazz Rock 爵士摇滚 "JazzRock"
50 Swing 1 摇曳 1 "Swing 1"
51 Dixieland 迪克西 "Dixielad"
52 Jazz Samba 爵士桑巴 "JazzSamb"
53 Jive 牛仔舞 "Jive "
54 Bebop 比波普爵士 "Bebop "
55 Bossa Nova 1 波萨诺沃舞 1 "BossaNv1"
56 Guitar Bossa 吉它波萨诺沃舞 "GitBossa"
57 Pop Bossa 流行波萨诺沃舞 "PopBossa"
58 Tango 探戈 "Tango "
59 Cha Cha 恰恰 "Cha Cha "
60 Rhumba 伦巴 "Rhumba"
61 TEX TEX 德克斯 "TEX TEX "
62 Chicago Blues 芝加哥布鲁斯 "CGO.Blus"
63 Fast Gospel 快速福音音乐 "GospelFs"
64 Big Band 大乐队 "BigBand"
65 Rap 说唱 "Rap "
66 GospelSl 慢板福音音乐 "SlwGospe"
67 Blues 布鲁斯 "Blues "
68 Blues Rock 摇滚布鲁斯 "BluesRok"
69 Gospel Shuffle 黑人福音滑步舞 "GosplShf"
70 Slow Blues 慢板布鲁斯 "SlwBlues"
71 Foxtrot 狐步舞 "Foxtrot "
72 50's Rock 五十年代摇滚乐 "50'sRock"
73 Heavy Metal 重金属 "HevyMetl"
74 Rock 1 摇滚 1 "Rock 1 "
75 Rock 2 摇滚 2 "Rock 2 "
76 Soft Rock 软摇滚 "SoftRock"
22
110 4/4 Piano 2 4/4 拍钢琴伴奏 2 "4/4Pno 2"
111 4/4 Piano 3 4/4 拍钢琴伴奏 3 "4/4Pno 3"
112 4/4 Piano 4 4/4 拍钢琴伴奏 4 "4/4Pno 4"
113 China 1 中国节奏 1（京剧 1) "China 1 "
114 China 2 中国节奏 2（京剧 2） "China 2 "
115 China 3 中国节奏 3（秧歌 1） "China 3 "
109 4/4 Piano 1 4/4 拍钢琴伴奏 1 "4/4Pno 1"
77 Slow Rock 慢板摇滚 "SlowRock"
78 Hard Rock 硬摇滚 "HardRock"
79 Rock & Roll 1 重金属摇滚 1 "Rok&Rol1"
80 Rock & Roll 2 重金属摇滚 2 "Rok&Rol2"
81 Rock Shuffle 摇滚滑步舞 "RokShuff"
82 March 进行曲 "March "
83 US. March 美国进行曲 "US.March"
84 Samba 桑巴 "Samba "
85 Polka 波尔卡 "Polka "
86 Polka Ober 军队波尔卡 "PolkaObr"
87 Tarantella 塔兰台拉舞曲 "Tarantla"
88 Slow Waltz 慢板华尔兹 "SloWaltz"
89 Ober Waltz 军队华尔兹 "ObrWaltz"
90 Rai 拉埃 "Rai "
91 Twist 1 扭扭舞 1 "Twist 1"
92 Twist 2 扭扭舞 2 "Twist 2"
93 Miami Pop 迈阿密流行曲 "MiamiPop"
94 Motown 底特律 "Motown "
95 Reggae 瑞格舞 "Reggae "
96 Swing Reggae 摇摆瑞格 "SwiRegga"
97 Mambo 曼波 "Mambo "
98 Beguine 土风舞 "Begune "
99 Musette 谬赛特 ( 法国民谣） "Musette "
100 Piano Ballad 钢琴歌谣 "PianBald"
101 Jazz Waltz 爵士华尔兹 （钢琴） "JazzWalt"
102 Bossa Nova 2 波萨诺沃舞 2( 钢琴） "BossaNv2"
103 Waltz 2 华尔兹 2 （钢琴） "Waltz 2"
104 Guitar Waltz 吉它华尔兹 "GitWaltz"
105 2/4 Piano 1 2/4 拍钢琴伴奏 1 "2/4Pno 1"
106 2/4 Piano 2 2/4 拍钢琴伴奏 2 "2/4Pno 2"
107 3/4 Piano 1 3/4 拍钢琴伴奏 1 "3/4Pno 1"
108 3/4 Piano 2 3/4 拍钢琴伴奏 2 "3/4Pno 2"
23
116 China 4 中国节奏 4（秧歌 2) "China 4 "
117 China 5 中国节奏 5 ( 凤阳花
鼓） "China 5 "
118 China 6 中国节奏 6（傣族） "China 6 "
119 China 7 中国节奏 7（藏族） "China 7 "
MIDI Keyboard Percussion Music Chart
note# note Ostand set 1Room set 2Power set 3Electri set 4Synth set
27 C1 Syn Sound Syn Sound Syn Sound Syn Sound Syn Sound
28 C#1 Slap Slap Slap Slap Slap
29 D1 Scratch1 Scratch1 Scratch1 Slap Scratch1
30 D#1 Scratch2 Scratch2 Scratch2 Scratch2 Scratch2
31 E1 Sticks Sticks Sticks Sticks Sticks
32 F1 Click Click Click Click Click
33 F#1 Metronome
Click
Metronome
Click
Metronome
Click
Metronome
Click
Metronome
Click
34 G1 Metronome
Bell
Metronome
Bell
Metronome
Bell
Metronome
Bell
Metronome
Bell
35 G#1 Kick2 Kick2 Kick2 Eleotry
Kick2 Kick2
36 A1 Kick1 Kick1 Power Kick1 Eleotry
Kick1 Synth Kick
37 A#1 Side Stick Side Stick Side Stick Side Stick Synth Side
Stick
38 B1 Snare Drum2 Snare Drum2 Power Snare Eleotry
Snare Drum2 Synth Snare
39 C2 Hand Clap Hand Clap Hand Clap Hand Clap Hand Clap
40 C#2 Snare Drum1 Room Snare1 Snare Drum1 Eleotry Room Snare Drum1
41 D2 Low Tom2 Power Low
Tom2
Power Low
Tom2
Eleotry Low
Tom2
Synth Low
Tom2
42 D#2 Closed Hi-
Hat
Closed Hi-
Hat
Closed Hi-
Hat
Closed Hi-
Hat
Synth Closed
Hi-Hat
43 E2 Low Tom1 Power Low
Tom1
Power Low
Tom1
Eleotry Low
Tom1
Synth Low
Tom1
44 F2 Pedal Hi-Hat Low Tom1 Pedal Hi-Hat Pedal Hi-Hat Synth Pedal
Hi-Hat
45 F#2 Mid Tom2 Power Mid
Tom2
Power Mid
Tom2
Eleotry Mid
Tom2
Synth Mid
Tom2
46 G2 Open Hi-Hat Open Hi-Hat Open Hi-Hat Open Hi-Hat Synth Open
Hi-Hat
47 G#2 Mid Tom1 Power Mid
Tom1
Power Mid
Tom1
Eleotry Mid
Tom1
Synth Mid
Tom1
48 A2 High Tom2 Power High
Tom2
Power High
Tom2
Eleotry High
Tom2
Synth Tom2
24
49 A#2 Crash Cymbal Crash Cymbal Crash Cymbal Crash Cymbal Synth Crash
Cymbal
50 B2 High Tom1 Power High
Tom1
Power High
Tom1
Power High
Tom1
Synth High
Tom1
51 C3 Ride Cymbal Ride Cymbal Ride Cymbal Ride Cymbal Ride Cymbal
52 C#3 Chinese
Cymbal 1
Chinese
Cymba1
Chinese
Cymbal 1
Chinese
Cymbal 1
Chinese
Cymbal 1
53 D3 Ride Bell Ride Bell Ride Bell Ride Bell Ride Bell
76 C#5 Hi Wood
Block
Hi Wood
Block
Hi Wood
Block
Hi Wood Block Hi Wood
Block
77 D5 Low Wood
Block
Low Wood
Block
Low Wood
Block
Low Wood
Block
Low Wood
Block
78 D#5 Mute Cuica Mute Cuica Mute Cuica Mute Cuica Mute Cuica
75 C5 Claves Claves Claves Claves Claves
54 D#3 Tambourine Tambourine Tambourine Tambourine Tambourine
55 E3 Splash
Cymbal
Splash
Cymbal
Splash
Cymbal
Splash
Cymbal
Splash
Cymbal
56 F3 Cowbell Cowbell Cowbell Cowbell Cowbell
57 F#3 Crash Cymbal Crash Cymbal Crash Cymbal Crash Cymbal Crash Cymbal
58 G3 Vibra-Slap Vibra-Slap Vibra-Slap Vibra-Slap Vibra-Slap
59 G#3 Ride Cymbal1 Ride Cymbal1 Ride Cymbal1 Ride Cymbal1 Ride Cymbal1
60 A3 High bomgo High bomgo High bomgo High bomgo High bomgo
61 A#3 Low conga Low conga Low conga Low conga Low conga
62 B3 Mute conga Mute conga Mute conga Mute conga Mute conga
63 C4 High conga High conga High conga High conga High conga
64 C#4 Low conga Low conga Low conga Low conga Low conga
65 D4 High Timbale High Timbale High Timbale High Timbale High Timbale
66 D#4 Low Timbale Low Timbale Low Timbale Low Timbale Low Timbale
67 E4 High Agogo High Agogo High Agogo High Agogo High Agogo
68 F4 Low Agogo Low Agogo Low Agogo Low Agogo Low Agogo
69 F#4 Cabasa Cabasa Cabasa Cabasa Cabasa
70 G4 Msracas Msracas Msracas Msracas Msracas
71 G#4 Short Hi
Whistle
Short Hi
Whistle
Short Hi
Whistle
Short Hi
Whistle
Short Hi
Whistle
72 A4 Long low
whistle
Long low
whistle
Long low
whistle
Long low
whistle
Long low
whistle
73 A#4 ShortGuiro ShortGuiro ShortGuiro ShortGuiro ShortGuiro
74 B4 logn Guiro logn Guiro logn Guiro logn Guiro logn Guiro
25
76 C#5 Hi Wood
Block
Hi Wood
Block
Hi Wood
Block
Hi Wood Block Hi Wood
Block
77 D5 Low Wood
Block
Low Wood
Block
Low Wood
Block
Low Wood
Block
Low Wood
Block
78 D#5 Mute Cuica Mute Cuica Mute Cuica Mute Cuica Mute Cuica
75 C5 Claves Claves Claves Claves Claves
54 D#3 Tambourine Tambourine Tambourine Tambourine Tambourine
55 E3 Splash
Cymbal
Splash
Cymbal
Splash
Cymbal
Splash
Cymbal
Splash
Cymbal
56 F3 Cowbell Cowbell Cowbell Cowbell Cowbell
57 F#3 Crash Cymbal Crash Cymbal Crash Cymbal Crash Cymbal Crash Cymbal
58 G3 Vibra-Slap Vibra-Slap Vibra-Slap Vibra-Slap Vibra-Slap
59 G#3 Ride Cymbal1 Ride Cymbal1 Ride Cymbal1 Ride Cymbal1 Ride Cymbal1
60 A3 High bomgo High bomgo High bomgo High bomgo High bomgo
61 A#3 Low conga Low conga Low conga Low conga Low conga
62 B3 Mute conga Mute conga Mute conga Mute conga Mute conga
63 C4 High conga High conga High conga High conga High conga
64 C#4 Low conga Low conga Low conga Low conga Low conga
65 D4 High Timbale High Timbale High Timbale High Timbale High Timbale
66 D#4 Low Timbale Low Timbale Low Timbale Low Timbale Low Timbale
67 E4 High Agogo High Agogo High Agogo High Agogo High Agogo
68 F4 Low Agogo Low Agogo Low Agogo Low Agogo Low Agogo
69 F#4 Cabasa Cabasa Cabasa Cabasa Cabasa
70 G4 Msracas Msracas Msracas Msracas Msracas
79 E5 Open Cueca Open Cueca Open Cueca Open Cueca Open Cueca
80 F5 Mute
Triangle
Mute
Triangle
Mute
Triangle
Mute Triangle Mute
Triangle
81 F#5 Open
Triangle
Open
Triangle
Open
Triangle
Open Triangle Open
Triangle
82 G5 Shaker Shaker Shaker Shaker Shaker
83 G#5 Jingle Bell Jingle Bell Jingle Bell Jingle Bell Jingle Bell
84 A5 Bell Tree Bell Tree Bell Tree Bell Tree Bell Tree
85 #5 Castanets Castanets Castanets Castanets Castanets
86 B5 Mute Surdo Mute Surdo Mute Surdo Mute Surdo Mute Surdo
87 C6 Open Surdo Open Surdo Open Surdo Open Surdo Open Surdo
Demo List
Number Chinese LCD Display
000 肖邦幻想即兴曲 Chopin Fi
001 AMS摇滚 AMASON Rock
002 喷泉 Fountain
003 巴赫钢琴曲 Bach Piano
004 巴赫小步舞曲 Minuet Bach
005 爱的罗曼史 Love Romance
006 四小天鹅 Four Cygnets
007 OP23:No.2 Puppy Wlatz
008 革命进行曲 CpnEtude
009 土尔其进行曲 Turkey March
010 肖邦练习曲 Chopin No.6
011 Minuet Menuett
012 土尔其进行曲MZT MarciaAT
013 夜曲 Chopin Night
014 钢琴歌谣 Piano Ballad
015 拉格泰姆 Ragetime
016 紫竹调 Zi Zhu Diao
017 容易受伤的女人 Sad Person
018 节奏 Fn Rhythm
019 尤金妮亚 Eugenia
020 洋娃娃之梦 Dolly's Dream
021 四小天鹅 4 Cygnets
022 古老的法兰西歌
曲Old France
023 小步舞曲 Minuet Bath
024 欢乐颂 Song of Joy
025 卖艺人 Busker
026 卖报歌 NewsPaper Sale
022 古老的法兰西歌
曲 Old France
023 小步舞曲 Minuet Bath
024 欢乐颂 Song of Joy
025 卖艺人 Busker
026 卖报歌 NewsPaper Sale
027 鸽子 Doves
028 卖汤圆 Mai Tang Yuan
029 鳟鱼 Trout
030 嬉戏曲 Curvet Piano
031 春之声圆舞曲 Spring Waltz
032 阿勒曼德舞曲 Aledeman
033 巴赫二部创意曲 Bach 2 Creative
034 月光 Moonlight
Debussy
035 采茶扑蝶 Tea & Butterfly
036 加沃特舞曲 Gavotte Dance
037 卡农 Canon Piano
038 牧童短笛 Cowboy & Flute
039 土耳其进行曲 Turkey March
040 幽默曲 Humoresque
041 进行曲 England March
042 小白船 Little Boat
043 快乐的农夫 Happy Farmer
044 小步舞曲 Minuet Piano
027 鸽子 Doves
028 卖汤圆 Mai Tang Yuan
045 小星星亮晶晶 Little Starts
046 深深的海洋 Deep Sea
047 娃哈哈 Wa Ha Ha
048 蜗牛与黄鹂鸟 Snail & Bird
049 在月光下 In Moonshine
050 在森林和原野 Nature Wonder
Land
26
067 八月桂花遍地开 August Flower
051 多年以前 Years Ago
052 彩云追月 CuaiYunZhuiYue
053 梁祝 Liang Zhu
054 铃儿响叮当 Jingle Bells
055 康定情歌 Run Hours On
Hall
056 莫斯科郊外的晚
上Moscow Nights
057 剪羊毛 Shear
058 北国之春 North Spring
059 青春舞曲 Youth Dance
060 彩虹妹妹 Rainbow
061 乘着歌声的翅膀 On Wings Of
Song
062 阿里郎 Arirang
063 夫妻双双把家还 TianXianPei
064 樱花 Sakura
065 啊，朋友再见 Bella Ciao
066 啊，苏珊娜 Oh, Susanna
068 白兰鸽 Paloma Blanca
069 采茶舞曲 Picking Tea
070 采花姑娘 Camellia Girl
071 当孩子诞生的时
候When Child Born
072 二月里来 FebruaryComing
073 凤阳花鼓 Fengyang Flower
Drum
074 孤独的牧羊人 Lonely Goatherd
075 红梅花儿开 Red Plum Flower
076 伦巴达 Lambada
077 浏阳河 LuYang River
078 洪湖水浪打浪 HongHu Rever
079 花儿为什么这样
红Flower So Red
080 荒城之月 Koujouno Tsuki
081 桔梗谣 Doraji
082 月光下的思念 Missing In
Moonlight
083 卡布里岛 Cabrits
084 来自新大陆 From the new
world
085 老黑奴 Old Black Joe
086 让我们荡起双桨 Let us row oars
087 三套车 The Mail Troika
088 桑塔露琪亚 Santa Lucia
089 山清水秀好风光 Good Scenery
090 什锦菜 Jambalaya
091 四季歌 Four Seasons
Song
092 梭罗河 Solo River
093 我的太阳 My Sun
094 洗衣歌 Washing Song
095 掀起你的盖头来 Lift Your Veil
096 小杜鹃 Little Cuckoo
097 小放牛 Little Cowboy
098 小河淌水 Fowing Stream
099 小燕子 Little Swallow
100 心恋 Heart Love
101 瑶族舞曲 Dance of Yao
Tribe
102 勇敢的鄂伦春 Brave Oroqen
103 远方的客人留下
来
Please Stay
Guest
104 云南民歌 Yunnan Folk
Song
105 在那银色月光下 Under Silver
Moon
106 咱们的领袖毛主
席Chairman Mao
107 北京的金山上 On Hall of
Beijing
108 保卫黄河 Yellow River
109 满江红 Whole River Red
111 平安夜 Christmas Eve
112 嘎达梅林 GADA Meilin
113 丹尼少年 Danny Boy
114 德聂泊尔 De Nie Er
115 钢铁是怎样练成
的
How Steel
Tempered
116 玛依拉 Maira
117 绿袖子 Green Sleeves
118 皇帝圆舞曲 Kaiser Waltz
119 蓝色多瑙河 Blue Danube
Waltz
110 噶秋莎 Katyusha
27
Specication
Exterior: Portable
Color: Black/White
Keyboard：Italian Imported 88 Grand-Response TM Key trends with hammer action & dynamic curve
Sound Source: Amason independently developed the third generation DSP sound source, Germany Famous grand
piano sound sample
Polyphony: 512
Demo song: 120 songs, Teaching function,100 teaching songs, Follow practice.
Touch: 5 piano touch curve, Default、Soft、Standard、Hard、Touch off.
Sound: 156 sounds with 128GM standard MIDI, 17 folk music, 10 series percussion music, 1 effect voice.
Rhythm: 120
Memory setting: 4 series memory setting, 10banks,4*10=40 memory settings, Panel Locking Function.
Single key preset: OTS function,4 preset device+120rhythm=480 single preset keys.
Accompaniment control: Auto chord on/off, synchronous starting, Start/Stop, A/insert 1, B/insert 2, Prelude/Finale
Record function: 2 record tracks,record、replay supported,Maximum notes for one single song is
22000,MIDI,64tracks and 16channels,Support MIDI 0&1 file
Sound Control: Grand piano tone, Dual voice, Double keyboard, Split mode, Split point.
Volume control: Master volume,Accompany volume(0-32), adjustable volume control when playing at night
Transpose: 25 gears (0,-/+12)
Octave: Three Octaves （-8，0，+8 ）
Effect: 127tremolo, 64 reverb, 64 chorus.
Metronome: Dynamics click as per beat,1,2,3,4,5,6, Tempo: 20-280per minute
Pedal: Imitated traditional grand piano pedal function, Soft, selected sustain, sustain.
USB interface: USB MIDI CP jack to support infinity record and save,64tracks and 16channels,Support MIDI 0&1
file,GM International Standard,system appending and upgrading.
Interface: USB jack, sustain pedal jack, three pedals jack, Power jack, Headphone jack, Line IN/OUT.
Power: 25W*2, DC 12V 2000mA
Dimension: 1360*290*172mm (L*W*H)
Weight: 12.5kg
Accessories: Power adapter, Sustain pedal, Music stand, Guarantee card, Quality certificate, User manual.
Optional Accessories: Portable digital piano wooden stand, Portable digital piano iron stand, Portable digital piano
three pedals.
*Specifications and descriptions in this owner's manual are for information purposes only. Amason Company
reserves the right to change or modify products or specifications at any time without prior notice. Since
specifications, equipment or options may not be the same in every countries, please check with your Amason
dealer for any question.
28
Troubleshooting
Problem Cause/Action
There is noise when turn on/off
the power This is normal , please don’t worry.
After turning on, no sound is
produced when press the keys
Please adjust the master volume or check if there is
headphone connecting the device.
The note and its timber are of a
little differences under the same
patch
This is normal.
When using the sustaining
function, some patches are
different long or short
This is normal.
The volume is too low Please adjust the master volume knob.
MIDI transmission function fail
when the MIDI Cord connecting
well
This is normal.
Noise caused when near phone This is normal, In order to avoid it please keep away
when calling
When playing piano, the pitch
is not in accordance with the
keyboard
Please check if you have activated the SPLIT mode
function and turn off it .
Pitch can not be changed when
playing piano, and the pitch
is not in accordance with the
keyboard
Please check if you have activated the SPLIT mode
function and set the split point to the highest level,
Turn off the split mode function and set the split point
back to the original.
Distortion or intermittent when
playing demo song
High temperature of the speaker when long time
playing with max volume, at the time please turn
down the volume or turn off the piano for a while then
it will be great.
Two tones come out at the
same time when playing
Dual sound function might by activated, please turn
off it to avoid it.
Pitch wrong Please conrm the pitch setting or set it to “Zero”
No automatic Accompany and
Chord
Please conrm the accompany volume or if the Chord
function is turned on.
Dynamics is not same as
before
There are 5 piano touch curve, Default、Soft、
Standard、Hard、Touch off. You might choose the
wrong dynamics. Please set the one you need.
29
Parts
Name
Hazardous Chemicals(Element)
Pb Hg Cd Cr（VI) PBB PBDE
PCB Χ ○ ○ ○ ○ ○
Cable Χ ○ ○ ○ ○ ○
Adapter Χ ○ ○ ○ ○ ○
Speaker Χ Χ Χ ○ ○ ○
Light Χ ○ ○ ○ ○ ○
○：means the hazardous chemicals of the parts comply with the standard Regulation
SJ/T11363-2006.
Χ：means the hazardous chemicals of the parts exceed the standard regulation of
SJ/T11363-2006.
NOTE: This instrument has been tested and it is according with the relevant regulations of EMC. Wireless
communication might caused the interference with this instrument. Or the instrument might caused the interference
with wireless. The user should adopt the following measure to improve it.
-
Relocation or adjust the receiving antenna.
-
Keep a distance between the device and receiver.
-
Connect the receiver and the device cord in different plug.
-
Please consult your dealer or experienced wireless technician.
Caution:Do not modified the device by yourself.
**Amason Piano Group reserves the right to change or modify products or specifications at any time without prior notice.
30
FCC Warning Statement
Changes or modifications not expressly approved by the party responsible for compliance
could
void the user’s authority to operate the equipment. This equipment has been tested and found
to
comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These
limits are designed to provide reasonable protection against harmful interference in a residential
installation. This equipment generates uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and on, the user is encouraged to try to
correct the interference by one or more of the following measures:
‐‐ Reorient or relocate the receiving antenna.
‐‐ Increase the separation between the equipment and receiver.
‐‐Connect the equipment into an outlet on a circuit different from that to which the receiver
is
connected.
‐‐ Consult the dealer or an experienced radio/TV technician for help.
This device complies with part 15 of the FCC Rules. Operation is subject to the following
two conditions: (1) This device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that may cause
undesired operation.
