Guangzhou Shirui Electronics SP05 Smart Pen User Manual Seewo SP05 V1 0 20160513

Guangzhou Shirui Electronics Co., Ltd Smart Pen Seewo SP05 V1 0 20160513

Contents

15_SP05 UserMan, r1.pdf

ᐛ㢰৸ᮦφ
ᶆ䍞φJਂ䬒
仒㢨φਂ䶘ᖟ㢨দ࡭θ┐ᣎᡆශθ
ᡆශተሮPPθኋᔶተሮPP
ޢᐤφfPP
Smart Pen_User Manual
Smart Pen
1. Safety and Precautions
Before using the device, please read this instruction
carefully in avoidance of any potential dangers or operations
that may cause faults to the product.
Usage Environment
Do not place the product in dusty and humid environments in
case of internal circuit fault.
Do not place the product near heating devices (such as
electrical heater).
Normal operating temperature is 0-40đ, normal operating
humidity is 10%-90%.
Children Safety
The product and accessories may contain some tiny
components. Please place them beyond the reach of children
in avoidance of swallowing danger.
Waterproof Function
The product is not waterproof. Please keep it dry.
Maintenance and Care
Maintenance of this product should be only performed by
qualified technicians.
Do not insert any sharp objects into this product.
Please avoid of intense hit or drop on the product.
Battery
Place the battery beyond the reach of children, and do not
throw it into the fire to avoid dangers.
Do not use metal object to connect the two poles of the
battery or touch the end point of the battery to avoid short
circuit to the battery.
Please drop waste batteries in the dedicated battery
recycle bin or hand them over to related departments;
otherwise, waste batteries will pollute the environment.
2. Product Function
Pen Point
Round Key
Up Key
Down Key
Square Key
Receiver
Function Key Function Description
Pen point Write on the Interative Flat Panel (IFP)
Round key
Custom function key, such as
one key to
enter writing function
Up key Page up
Down key Page down
Square Key Custom function key, such as the function
of one key to enter the whiteboard
software Note
3. Operation Tips
The built-in computer of the IFP need to be installed the
software Smart Pen and Software Note3.0 above.
Remove the receiver from the bottom of the smart pen
and insert it to the USB port on the IFP.
The receive distance of the receiver will be reduced due
to the interference of electronic devices around.
The product automatically enters the sleep state when
idle, can wake up by pressing any key.
In the select and Erase options, it enables IFP devices to
distinguish pen writing and gesture control, the smart pen
can still be wrote, select and erase function can be
replaced by hands.
4. Battery Installation
The product is powered by an AAA battery. Insert the
battery correctly oriented according to the direction shown
below. Ensure that the positive (+) and negative (-)
terminals are installed correctly.
5. Precautions
Do not reverse the positive (+) and negative (-) terminals.
Do not keep the exhausted or damaged battery inside
the product.
Remove the battery if the product will be left idle for a
long time.
6. Statements
Copyright ownership of hardware and software design
belongs to Guangzhou Shirui Electronics Co., Ltd., shall
not be reproduced, copied, or used in other ways
without permission. Otherwise Guangzhou Shirui
Electronics Co., Ltd. will have the right to pursue legal
responsibilities.
The image shown in this manual is indicative only. If there
is inconsistency between the image and the actual
product, the actual product shall govern.
Replace the battery with a new one if the product cannot
implement functions as desired or if the remote control
distance is reduced.
90mm
145mm
FCC Statement
This equipment has been tested and found to comply with the
limits for a Class B digital device, pursuant to part 15 of the
FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential
installation. This equipment generates uses and can radiate
radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful
interference to radio communications. However, there is no
guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference
to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to
try to correct the interference by one or more of the following
measures:
—Reorient or relocate the receiving antenna.
—Increase the separation between the equipment and
receiver.
—Connect the equipment into an outlet on a circuit different
from that to which the receiver is connected.
—Consult the dealer or an experienced radio/TV technician
for help.
FCC Statement
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions: (1) this
device may not cause harmful interference, and (2) this
device must accept any interference received, including
interference that may cause undesired operation.
Caution!
Any changes or modifications not expressly approved by
the party responsible for compliance could void the user's
authority to operate the equipment.
