Guangzhou Winson Information Technology T60 barcode Scanner User Manual
Guangzhou Winson Information Technology Co., Ltd. barcode Scanner
User Manual
LED Indicator
LED Indicaon Explanaon
Blue lights blinking Decoding Succssfully
Buzzer
Beep Indicaon Explanaon
One Beep Decoding Successfully
Connuous Beep Successfully parameter seng
Buzzer
LED Indicator
Scanning window
Trigger Buon
(1).USB Cable (2).RS232 Cable
Best reading distance 5~20CM
Contents:● Barcode Scanner ●Quick Start Guide
● warranty card ● Cerficate
● USB / RS232 Cable
● Power Adapter (RS232 )
121311113
2D Barcode Scanner
Quick Start Guide
2D
1 Scanner Overview
Barcode scanner
Note: Product appearance depends on goods
2 Cable plug&Unplug
3 Scanning Angle Methods and distance
4
Decode Settings
Seng Step
Configuraon method: Scan the funcon bar code directly.
①Defaults Parameter
Restore All Factory Defaults
②Firmware Version
Version
Manual Trigger Mode – Normal (Default)
③Trigger Mode
Manual Trigger Mode – Cellphone
Presentaon Mode – Normal
Presentaon Mode - Cellphone
④Auto Trigger
*Disable auto trigger
⑦Code39 Setting
*Disable Full ASCII Code39
Enable Full ASCII Code39
⑤Suffix Values
*0x0D (CR)
0x0A (LF)
0x0D 0x0A (CR LF)
TAB
⑥Illumination
High Level Illuminaon
Middle Level Illuminaon
Low Level Illuminaon
Illuminaon OFF
Restore Symbology Default
Only Enable Retail Barcode
⑧Symbologies
Enable All Symbologies
