Guard RFID Solutions PPT ACTIVE RFID TAG USED FOR LOCATION AND PERIMETER PROTECTION OF PEOPLE User Manual
Guard RFID Solutions ACTIVE RFID TAG USED FOR LOCATION AND PERIMETER PROTECTION OF PEOPLE Users Manual
Users Manual
PRODUCTINFORMATION
02-00080-101 Specifications Subject to Change Without Notice. © 2012 Guard RFID Solutions, Inc.
Guard RFID Solutions Inc.
#140 – 766 Cliveden Place
Delta, BC
Canada V6M 6C7
Tel: 866.785.7343
Fax: 604.524.4018
guardRFID.com
FCC:VZKPPT
IC:9937A‐PPT
ConformstoUL‐294
This device complies with part 15 of the FCC Rules and with Industry Canada license‐exempt RSS standard(s). Operation is subject to the following
two conditions:
(1) This device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that may cause undesired operation.
NOTE: THE MANUFACTURER IS NOT RESPONSIBLE FOR ANY RADIO OR TV INTERFERENCE CAUSED BY UNAUTHORIZED MODIFICATIONS TO THIS EQUIPMENT
SUCH MODIFICATIONS COULD VOID THE USER’S AUTHORITY TO OPERATE THE EQUIPMENT.
Pediatric Patient Tag and Band
PPT-1BLF
F
EATURES
:
Unique Tamper Detection mechanism enhances security of patients
Easy to apply using innovative hypoallergenic band
Light weight and small form factor
Waterproof and easy to clean and disinfect
D
ESCRIPTION
:
The PPT-1BLF is an Active Tag for use on Pediatric, Infant or other Patients. The Tag transmits
periodic Beacon messages used for tracking and location of the Tag in real time, and additionally
includes a Low Frequency Receiver to be able to detect signals from GuardRFID’s Tag Exciters
at portals such as egress points, enabling GuardRFID’s active RFID system to control doors so as
to protect a tagged patient from leaving the perimeter, for example.
The PPT-1BLF has a battery life of 12 months, and designed to be mounted on the patient’s wrist
or ankles using a special band. The band fits all wrist sizes, and locks into place to prevent
removal of the Tag without cutting the band. Any unauthorized attempts to remove the tag by
cutting or breaking the band results in a tamper alarm being sent to GuardRFID’s system by the
Tag.
S
PECIFICATIONS
:
PPT-1BLF
PPT
B
AND
Part Number 61-10008 61-12006
Transmit Frequency 433 MHz Not Applicable
Receive Frequency 125 KHz Not Applicable
Battery Life 12 months Not Applicable
Beacon Interval 12 seconds Not Applicable
Dimensions 1.32 x 0.45” (33.5 x 11.4 mm) 10.9” (277 mm) Length
Weight 6.7 gm. 7.4 gm.
Operating
Temperature 14° F to 122°F (-10°C to 50°C) 14° F to 122°F (-10°C to 50°C)
Humidity 0 – 100% Waterproof 0 – 100% Waterproof
Regulatory FCC Part 15 Approved Not Applicable
