Guard RFID Solutions TR2 433MHz RFID/RLTS Receiver User Manual Tag Exciter Location Appliance
Guard RFID Solutions 433MHz RFID/RLTS Receiver Tag Exciter Location Appliance
User Guide
PRODUCT INFORMATION
02-00112-102 Specifications Subject to Change Without Notice. © 2017 Guard RFID Solutions, Inc.
Cet appareil est conforme à la spécification RSS-210 d'Industry Canada.
Son fonctionnement est soumis aux deux conditions suivantes:
(1) cet appareil ne peut engendrer aucune interférence et
(2) il doit accepter toute interférence qu'il reçoit, y compris celles qui
peuvent altérer son fonctionnement
Guard RFID Solutions Inc.
sales@guardRFID.com
Tel: 866.785.7343
Fax: 604.524.4018
This device complies with part 15 of the FCC Rules and with Industry Canada license‐exempt RSS standard(s).
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that may cause undesired operation.
NOTE: THE MANUFACTURER IS NOT RESPONSIBLE FOR ANY RADIO OR TV INTERFERENCE CAUSED
BY UNAUTHORIZED MODIFICATIONS TO THIS EQUIPMENT SUCH MODIFICATIONS COULD VOID
THE USER’S AUTHORITY TO OPERATE THE EQUIPMENT.
FCC ID: VZKTR2
IC ID: 9937A-TR2
Tag Reader (TR2)
FE A T U R E S :
• Provides industry leading location accuracy, access control ready
• Dual internal or external antennas
• Wired or wireless networking and PoE compatible
• Capable of using IEEE 802.15.4 (433 MHz PHY) or GuardRFID wireless protocol
• Reduced maintenance cost - supports remote diagnostics and updates, reducing
overall maintenance costs and downtime
• Suitable for visible (surface mount) or hidden installation
DE S C R I P T I O N :
The Tag Reader (TR2) is a data gathering and transmission point within the GuardRFID system,
communicating wirelessly with active RFID/RTLS tags and other GuardRFID infrastructure to
provide tag location and, when combined with an I/O Module, advanced access control abilities.
Using its dual antennas, The TR2 can communicate with hundreds of active RFID/RTLS tags per
second. The TR2 is compatible with tags compliant to IEEE 802.15.4 (433 MHz PHY) or
GuardRFID’s proprietary protocol.
The TR2 can be unobtrusively installed above a false ceiling, or surface mounted to a wall or
ceiling tile if visibility is not an issue. The deployment density of TR2s depends on the required
coverage, desired location accuracy, and antenna type used—the TR2 can use its internal
antennas, the provided external whip antennas, or external, high-gain antennas. Maximum read
distance at which tags can be detected varies according to tag type and environment, but it is not
unusual to exceed hundreds of meters if using a high-gain antenna. The TR2 can achieve a
location accuracy of 3m (10 feet) in a typical office environment, which can be further optimized
by adjusting RF sensitivity within the software.
Communication with the remainder of the GuardRFID network is achieved through a wired
(Ethernet) or wireless (point to multipoint) connection.
SP E C I F I C A T I O N S :
Part Number
61-20016
Indicators
Power, network status, network data, RF data communications
Frequency
433 MHz
RFID/RTLS Protocols
IEEE 802.15.4 (433 MHz PHY)
GuardRFID wireless protocol
Network Connectivity
Wired (Ethernet), Wireless (Point-to-Multipoint), USB
Power
12VDC, 200mA max. (Ethernet), 350mA max.
Dimensions (W x H x D)
13.5 x 13.5 x 3.5cm (5.34" x 5.34" x 1.40")
Weight
180g (6.4oz.)
Operating Temperature
-10°C to 50°C (14° F to 122°F)
Humidity
0 – 95% RH non-condensing
Regulatory
FCC
Warranty
1 Year
