© Blastpro Manufacturing, Inc.
9/10/12
BP-2-20
Shot Blasting Machine
877-495-6464
www.BLASTPROMFG.com
The BP-2-20 is designed for medi-
um-to-large jobs including indus-
trial plant and warehouse floors,
parking garages, and bridge or
ship decks. The BP-2-20 is an
electric, self-propelled machine
with a 20” blast pattern. The BP-
2-20 operates on 460 V, 3-phase
power. The BP-2-20 is based on
a tried and true design, offering
robust construction and industry
leading productivity. When cou-
pled with the BP-9-54 dust col-
lector, the BP-2-20 is a spectacu-
lar option for your surface prepa-
ration fleet.
SPECIFICATIONS
Production Capacity: +up to 4,500 ft²/hr
Blast Pattern Width: 20”
Travel Speed: 0-120 ft/min
Blast Motor: Dual 15 hp
Voltage: 460v, 3-phase, 60 hz
Amperage: 44 A
Weight: 1270 lbs
Dimensions (LxWxH): 77” x 28” x 55”
Power Cord: 55 ft.
BP-9-54
Recommended dust collector
(see separate data sheet for specifications)
FEATURES AND BENEFITS
Finger tip speed and reverse control
Easily accessible panel controls
AC inverted ground drive motor with integrated
brake
High speed, heavy duty bearing unit
Precision manufactured liner package
+Production rates will vary between material being removed and from
job-to-job. This production rate represents production values under
ideal conditions.
