Substrate Technology, Inc.
1384 Bungalow Rd.
Morris, Illinois 60450
+1.815.941.4800
Fax +1.815.941.4600
www.substratetechnology.com
Concrete
Flooring Applications
Terrazzo
Marble
Granite
Diamond Systems for STI-4430
STI-4430 Prep/Master®
Project sizes over 20,000 SF / 1,858 m2
220V/230V - Item #434430230
380V/480V - Item #434430480
4425 220V/230V - Item #434425230
4425 380V/480V - Item #434425480
Production Rates
Mastic Removal 725 SF /67 m2 per hr
Thin Set Removal 725 SF /67 m2 per hr
Mil Coatings Removal 575 SF /53 m2 per hr
Polished Concrete 5,025 SF /467 m2 per hr
Speci cations
Motor 30 HP - 3 phase | 22kW
Power Source 220/230 VAC 1 or 3 Phase 60 Hz
380/480 VAC 3 Phase 50-60Hz
Power Cord 30 ft./9m (6-4)
Vacuum Hose
Connection
3 in./76mm x 25 ft./8m
Weight 1,460 lbs. | 662 kg
Tool RPM 250RPM (30Hz) to 750RPM (90Hz)
Number of Tools 24
Tools Attachment
Style
EG Proprietary Attachment
System
Dimensions 80”L x 44”W x 52”H
203 cm x 112 cm x 132 cm
Recommended
Vacuum Duo Vac (630CFM) with
pre-separator or equivalent
