Filter information
3 HEPA Filters 81 (ft²), 99.99% at 0.3 microns
480
13
16
480
120
630
201300408
201300408
CFM:
HP:
Amp:
Volt:
Water lift:
Weight:
Product code:
Product code:
T10000 Specifications
Manometer: measures the
negative pressure within
the tank and alerts the
operator when the filters
need servicing.
Separator Attachment:
Heavy duty hitch for
directly attaching an Er-
mator Pre-Separator.
Filter Sock Assembly:
superior pre-filtration of
dust to maintain airflow
and increase time between
filter cleaning.
Pull the bag down. Attach two ties with a 5” gap Cut between the ties.
A drop-down dustless disposal system
The T10000 Features Longopac
®
Jet Pulse with easy reach lever: efficient, safe
filter cleaning without exposing operator to dust.
Relief Valve: protects turbine motor from over-
heating in the event of a blocked hose or
clogged filter.
Three Individually Tested and Certified HEPA
Filters: each filter provides a minimum
efficiency of 99.99% at .3 microns
Control Panel with one-touch start feature: pro-
tects from overloads.
Integrally mounted power receptacle: fast,
convenient hook-up to power source and grinder.
Eliminates need for electrical distribution box.
4-inch casters w/brake: excellent mobility,
stability and increased safety.
When used in tandem with the C5500, the 480Volt T10000 represents the most power-
ful HEPA Dust Extractor / Pre-separator used worldwide in the concrete grinding and
polishing market. Much improved over its predecessors, models T55, T75 and T8600,
the T10000 is packed with plenty of power and filter area. It exceeds the requirements
of even the most demanding three-head grinders.
Equipped with 3 tested and certified HEPA filters ensuring clean air exhaust. A primary
sock-style prefilter provides long, uninterrupted service and can be cleaned efficiently
from outside the tank via Jet Pulse air pressure. The unique 72 foot Longopac
®
allows
fast, drop-down, dust free disposal into approximately 25 individually sealed bags.
Comes with 3-inch, 33-ft hose and complete floor tool kit including 2”, 25’ hose, wand
and floor tool, and 50 amp distribution box.
Creating Clean Air for Construction, Abatement, and Restoration
T10000 3P HEPA Dust Extractor
Toll-free: 855-736-2869 • Fax: 813-685-6782 • Email: orders@ermatorusa.com
ermatorusa.com • 10702 N. 46th Street - Tampa, FL 33617
