TM
LED 50L G35 Light Set
IMPORTANT SAFETY
INSTRUCTIONS
LED 50L G35 iTwinkle light show Item Number: 00650
When using electrical products, basic precautions should always
be followed including the following:
READ AND FOLLOW ALL
SAFETY INSTRUCTIONS
• This is an electrical product - not a toy! To avoid the risk
of fire, burns, personal injury and electric shock it should
not be played with or placed where small children can
reach it.
• Do not use seasonal products outdoors unless marked
suitable for indoor and outdoor use. When products are
used in outdoor applications, connect the product to a
Ground Fault Circuit Interrupting (GFCI) outlet. If one is
not provided contact a qualified electrician for proper
installation.
• This seasonal use product is not intended for permanent
installation or use.
• Do not mount or place near gas or electric heaters,
fireplaces, candles or other similar sources of heat.
• Do not secure the wiring of the product with staples or
nails, or place on sharp hooks or nails.
• Do not let lamps rest on the supply cord or on any wire.
• Unplug the product when leaving the house, when
retiring for the night, or if left unattended.
• Do not use this product for other than its intended use.
• Do not hang ornaments or other objects from cord, wire,
or light string.
• Do not close doors or windows on the product or
extension cord as this may damage the wire insulation.
• Do not cover the product with cloth, paper or any
material not part of the product when in use.
• This product has a polarized plug (one blade is wider
than the other) as a feature to reduce the risk of electric
shock. This plug will fit in a polarized outlet only one
way. If the plug does not fit fully in the outlet, reverse the
plug. If it still does not fit, contact a qualified electrician.
Do not use with an extension cord unless plug can be
fully inserted. Do not alter or replace the plug.
• Read and follow all instructions that are on the product
or provided with the product.
SAVE THESE INSTRUCTIONS
USE AND CARE INSTRUCTIONS
• When the product is placed on a live tree, the tree
should be well maintained and fresh. Do not place on
live trees in which the needles are brown or break off
easily. Keep the tree holder filled with water.
• If the product is placed on a tree, the tree should be well
secured and stable.
• Before using, or reusing, inspect product carefully.
Discard any products that have cut, damaged or frayed
wire insulation or cords, cracks in the lampholders or
enclosures, loose connections, or exposed copper wire.
• When storing the product, carefully remove the product
from wherever it is placed, including trees, branches, or
bushes, to avoid any undue strain or stress on the
product conductors, connections and wires.
• When not in use, store neatly in a cool, dry location
protected from sunlight.
Install Class 2 Power Supply To
String:
Fig. 1 Fig. 2
Fig. 3
NOTE: Use only this GE branded, Class 2 Power
Supply, Model SA3A-050-3000, manufactured by TDC
that was provided with this product.
DO NOT use this adapter with any other product.
1. Remove the Power Supply from its packing box.
2. The LED string is fitted with a 2-pronged fitting.
3. Align the notch in fitting with the inner tab on end of
Power Supply {Fig. 1}
4. Fully insert the fitting into the Power Supply {Fig. 2}
5. Screw the collar completely onto the Power Supply
turning clockwise {Fig. 3}
NOTE: LEDs are non-replaceable. Tampering with this set
voids the warranty.
CAUTION:
• To reduce the risk of fire and electric shock:
a) Do not install on trees having needles, leaves or
branch coverings of metal or materials which look
like metal, and
b) Do not mount or support strings in a manner that
can cut or damage wire insulation.
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
▪ this device may not cause harmful interference, and
▪ this device must accept any interference received,
including interference that may cause undesired
operation.
Modifications not approved by the party responsible for
compliance could void user’s authority to operate the
equipment.
NOTE: This equipment has been tested and found to
comply with the limits for Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against
harmful interference in a residential installation. This
equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful
interference to radio or television reception, which can
be determined by turning the equipment off and on, the
user is encouraged to try to correct the interference by
one or more of the following measures:
＊ Reorient or relocate the receiving antenna.
＊ Increase the separation between the equipment and
the receiver.
＊ Connect the equipment into an outlet on a circuit
different from that to which the receiver is
connected.
＊ Consult the dealer or an experienced radio/TV
technician for help.
(See other side for Operating Instructions)
TM Operating Instructions
Just follow these quick and easy steps to set up and use your
new iTwinkleLIGHTTM string set.
Remove the contents from the box; properly align
the 2-pin male connector and flat area with the
female connector on the adapter. Fully insert
together. Twist cap to fully secure.
Step 1. Plug in your set to automatically enable Bluetooth. The last lamp in
the string indicates the connection status:
a. Red Color – Connection available to Apple device.
b. Green Color – Connected to Apple device.
Note: Blue color shows the product is searching for a Bluetooth device.
Step 2: With your iPad® iPhone® iPod touch®:
Touch Settings, Bluetooth, turn ON to search for active devices.
Note: The effective operating range between your device and the string set
is up to 33’ (10m).
Step 3. Search your device to find
"00650 50L RGB”. Touch it.
Note: To install application your
device must have Internet
capability. (If you haven’t
installed the App Software)
Step 4. Once connected a window
will appear prompting you to install
the free App software.
Step 5. Touch ‘Yes’ to install.
Once installed this window will not
appear again.
Step 6. The free iTwinkleLight
App appears. Touch Free and
then touch Install App
Step 7. Once installed the
iTwinkleLight icon will appear on
your screen. Find it. Touch it to
launch program.
Step 8. If this screen appears your
Bluetooth device is available.
Touch Allow to connect or Ignore
to search for other devices.
Step 9. The
iTwinkleLight
Main Menu
appears with 4
items per
screen. Scroll to
select your
item.
Note:
A green circle
shows your
Apple device is connected to your
product. A Red dash shows your
product is not connected.
Step 10. Product
features screen
will now appear.
Touch any icon
at the bottom of
the screen to
activate that
feature.
“Made for iPod,” “Made for iPhone,” and “Made for iPad” mean that an
electronic accessory has been designed to connect specifically to iPod, iPhone,
or iPad, respectively, and has been certified by the developer to meet Apple
performance standards. Apple is not responsible for the operation of this device
or its compliance with safety and regulatory standards. Please note that the use
of this accessory with iPod, iPhone, or iPad may affect wireless performance.
©2013 Nicolas Holiday Inc.,
9F., No. 37, Guangfu N. Rd
Taipei, Taiwan 10560
All rights reserved
For Indoor Use Only 120 V 60 Hz
This is not a toy, for decorative use only.
To view these instructions online please visit us at www.geholidaylighting.com
or call customer support toll free at 1-877-398-7337
TM Features
Note: Touch the house icon in the upper right corner
to return to the iTwinkleLight Main Menu
Feature
Displays
Description
myColor
Color
Disc
Touch the circle to change
colors.
Slide to adjust brightness.
Choose from over 2000
colors.
Music
Music
Player
Touch iTwinkle Music to
enjoy 1 of 8 pre-loaded
songs and light shows.
Touch My Music to select
songs from your iTunes
music library and play songs
from any country.
Voice
Microphone
Speak… the LED lights flash
to your voice.
Select an icon to hear your
message replayed in a child-
like or Santa voice.
Pattern
Pattern
Icons
Scroll icons to select 1 of 8
programmed light shows.
Note: This pattern is used for
the myColor feature.
Tap Me
Shake
Icon
Tap to change color of lights.
Hold the device securely;
SHAKE wrist to change
colors.
