HANA Micron Inc. Host MP3 Player Users Manual
Users Manual
Quick Guide for Host MP3P
index
1 main part of product
2 part name and function
3 display LCD & manu for each mode
4 3 quick step for listening the music
5 caution for safety
6 homepage address & How to firmware upgrade
7 benefit of resistering as a customer
8 features
9 COPYRIGHT NOTICE
10 standard
11 warranty
12 basic instruction for host mp3p bullet cradle
1 main part of product
Host MP3P Bullet / stereo earphone / USB data cable / quick guide / keyring case
2 part name and function
(lock&unlock/firmware download)
choice switch
Bullet left side
Bullet Front side
lock
unlock
firmware ownload/reset
② display LCD
③ usb data cable
connecting port
FF:previous song/previous menu
menu mode/set repeat
[REW]next song/next menu
Bullet right side
earphone keychain groove
seperable usb memory(slide form)
Bullet rear
Bullet top
⑧ ear phone jack
⑤
④(previous song/mode
menu/shortcut to
modemenue/nextsong/repeat
track/speed control/jog switch)
⑦volume control spinnig
button
⑨ on/off/
p
lay/
p
ause
button
⑦ volume control
spinning button
1. lock/unlock, firmware download(reset)mode select switch
- you can lock or unlock the menu butoon for each part, you can download the firmware to solve
problem(or reset)
2. display LCD
- dsplay condition of playing mp3p player by image and text
ex) battery, lock, (repeat) play,condition of play, play process and time,repeat mode, song number, song
title, words, sound effect, menu, file, frequency,volume
3. usb data cable connecting port(download firmware
- in case of charging or downlading firmware or reset, you can set the downloaded firmware by conneting
usb usb data cable after set firmware downloading mode
[ff]next song(menu)/[rw]previous song(menu)/mode menu/shortcut to mode menu/[a-b]track
repeat/speed control/select jog switch
- you can move to next/previous menu by controlling jog switch up and down
- you can go to mode menu and select menu by pushing jog switch, , even during playing mode you can go
to mode menu by pushing jogswitch for 3 second
- during playing you can listen a certain track repeatly if you push jog switch at starting track and finish
track
- you can control playing speed controlling jogswitch up and down)
4. earphone groove
-can attach earphone ketchain
5. seperatible usb memory
- as a usb drive and mp3 player memory, you can keep,move,control songs or files easily separated)
6. volume control spinning button
-you can control volume by spinning
7. earphone jack
- you can hear by connecting stereo earphone
8. 전원켜기&끄기/재생/일시정지 버튼(on&off/play/pause botton)
- 전원을 켜려면 3초 이상, 전원을 끄려면 6초 이상 길게 누르시고, 가볍게 한번만 누르시면 음악을 듣거나 일
시정지를 시킬수 있습니다.(push 3 sec for off, 6sec for off, little touch for listening music or pause)
3 LCD display & menu of modes
ON) OFF
1. Music Mode
PLAY MODE :
(Default Repeat All)
Normal(NOR)
/Shuffle Folder(F)/ Shuffle Once(1)/ Shuffle Repeat(R)
/Track Once(TR)
/Repeat Folder(RF)/Repeat All(RA)/Repeat Track(RT)
/ Exit
EQUALIZER :
(Default Normal)
Normal / Rock / Jazz / Classical / Pop / Custom / QBS 3D / Exit
SELECT FOLDER :
Select Folder / Open Folder / Exit
Setting :
LCD Contrast [ 0 ~ 30 ] (Default 15)
/BackLight Time [ 1 ~ 20 ] (Default 5)
/Language [English/Germany/Spain/French/Chinese Trad/Chinese Simp/Japanese/Korean]
(Default English)
/Idle ShutDown Time [ 1 ~20 ]
/ Information Memory
/ Factory Setting : Default Setting
/ Exit
Watch :
Time Set : year, month, day, time, minute setting
Alram Set : FM frequency, time, minute,
Alram On/Off setting
Delete :
Delete File / Exit
Exit :
2. FM Mode
FM :
Mono/Stereo [ Mono / Stereo ]
Auto Preset [ ON / OFF ]
Manual Preset [ P01 ~ P20 ]
Preset Delete [ All / Each ]
3. Mode Select
Mode : [ Music / FM ]
4 3 quick step for listening the music
if you want to charge battery, connect player to computer using usb data cable. Charge for 1 hour.(caution : this
product need to be connected to a high electricity usb data cable or usb2.0 hub. It doesn’t work by connecting
keyboard or low electricity usb port)
1 step : detatching usb(mp3 player memory also
push the seperatable usb at the back of mp3 player and connect to usb port)
2 step :
2단계 : saving mp3/bvr/wma/ogg file
after saving sound source in usb, detatch usb memory using safe hardware removing icon
(if you want to buy music source on line)
3 step : play
after connecting usb which has sound source, listen to the music or change institution and enjoy the music
5 homepage address and firmware upgrade
you can get access to the information about our product by connecting www.hanausb.com and download file
You can upgrade product’s quality by downloading firmware
6 benefit of resistering as a customer
email service about online AS,new product information,firmware upgrade,events
7 feature
1. unlimited memory expansion with Seperatable memory
It is possible to expand memory by replacing memory and use general USB also,
[128MB, 256MB, 512MB, 1GB, 2GB]
2. outstanding quality multi codec / full OGG available
Not just MPEG1/2/2.5 LAYER3, VBR, WMA but also OGG which is regarded as the new Audio condensation
technique are available to play
[OGG, MPEG1/2/2.5 LAYER3, VBR, WMA]
3. various EQ effect which you can enjoy 3D sound with QBS 3D Stereo
- 10 levels of selectable sound image position wherever you wish
- 10 levels of selectable sound amplification as you wish
- QBS 7 Band Graphic Equalizer makes it play outstanding sound by controlling radio frequency
[-12dB ~ +12dB]
- various EQ Mode “Classic, Rock, Pop, Jazz, Ballad, Live, Bass” is essential
- User EQ Mode provide to control it by hands
4. FM Radio receipt and Voice Recording(Under consideration)
FM broadcastion receipt by More powerful Stereo Sound with FM Radio receipt function
- real time FM broadcasting recording, Voice recording support
- Saving of Broadcasting channel up to 20
- Whenever you wish you can save and listen to FM broadcasting as file
5. Enjoy lyrics listening to music
lyric support service with throughout lyric Database manager
6. Firmware Upgrade support
you can maintain you product in the best condition with Firmware upgrade support through website
7. easy to select music and more various replay mode
- you can select music even while you are listening
- various replay mode [all, Dir, Repeat1, Repeat Dir, Repeat all]
8. section replay function and LCD Display for multi language support to study foreign language
- to help your language study we provide section reply function
- LCD display that provide multi national languages such as English, Deusch, French, Spanish, Japanese,
Chinese, Korean
9. Li-Polimer Battery adoption
need to charge only one time to play up to 10 hours due to re-chargeable batter and loaded charge IC
Cradle which support charge function(not yet decided)
10. Alarm and automatic sleep function
alarm and sleep function such as Morning call with RTC
11. USB 2.0 Client, 1.1 Host support
12. High Speed USB 2.0의 Storage
Separatable Memory can be used as USB 2.0
8 COPYRIGHT NOTICE
Details which is written this manual can be changed without any notification because of function upgrade or any
change
Any Company, institute, product, person and event used as example are not real., and you must not infer them.
User must obey literarily property and we have no responsibility on it
Any part of this munual cannot be copied, searched, saved in a system or transmitted for any purpose without
hana micron’s agreement.
Hana Micron can keep the patent, brand right, copyright, or other intellectual proprietary rights
Except rights that we provide you here, this manual doesn’t give you any rights which are connected to the
patent, brand right, copyright, or other intellectual proprietary rights
2005~ HANA Micron Inc. All right reserved.
9 specification
1. Model : HHMP-1000
2. Flash Memory(Separatable) 128MB/256MB/512MB/1GB/2GB/4GB/8GB
3. MPEG Decoding
MPEG Play
MPEG 1/2/2.5 LAYER3
WMA
4. Earphone output : left 18mW right 18mW (16 ohm, MAX)
5. s/n rate : 85 dB (MP3)
6. Play time : 10 hours more base on 128Kbps (44.1KHz)/mp3
7. PC interface : USB Ver. 2.0
8. power : 4.2V / 440 mAh inner lithium polymer battery
9. external size : HORIZONTAL x VERTICAL (37.5 X 75)
10. weight : 40g(contain with battery)
11. Accessory that can be used together
family & car Kit
- Host MP3P Bullet Cradle
- Host MP3P Bullet Cradle car available DC Adaptor
- Host MP3P Bullet Cradle familial DC Adaptor
- Host MP3P Bullet Cradle DC Gender
- Host MP3P Bullet Cradle contact magnet
10 mp3 player warranty
The warranty for this hardware product of HANA Micron is limited as regulated below
You can be served for any defect of Aiva Series Host MP3 Player occurred within one year of purchasing date.
If any defect occurred within one year of purchase, under the our regulations..
It can be repaired with our new part
It can be replaced with new product or new parts, so that it will be functionally same to original product with on
your expenses.
If any defect occurred and your request is accepted within 30 days of your purchase, the fee for repair, deliver
or exchange will be advanced on mutual expenses.
This warranty is made by or for our company, and applied to hardware product by Hana Micron’s brand, brand
name, or logo that can be distinguished from other company’s products.
This warranty is not applied to the Software that we provide.
Hana Micron does not take any responsibility for any damage or loss of data or information included in the
product that we provide. This warranty is not applied to Recovery or re-installment for Program, Data, or
information.
Even if it is still under warranty, you will be paid in the event of below.
(1) any damage cause by accident, abuse, misuse, or other products of customer
(2) In the case of any defect by a customer’s fault(damage by shock or input of a different thing
(3) any defect caused by personal repair or conversion, not by our customer service center
(4) any damage caused by a natural disaster
(5) Even if it is still under warranty, in case that a product nothing wrong is accepted more than 2 times
* We don’t take any responsibility for the recovery of data loss or compensation for USB
Service Guide
Free of Charge Services:
- Services are free for one year after purchase from the Customer Service Center.
However, service is charged for the following cases:
- When product failure results from an error or carelessness on the customer’s part (damages due to shock or
the entry of foreign substances).
- When product failure results from a repair or product modification by the customer.
- Product damage from natural disasters.
Many products for which service is requested have no faults. Therefore, before calling our Customer Service
Center for servicing, carefully read the User Guide and check for any trouble first.
We do not take responsibility for data loss on the mobile storage device.
Customer Service Center
Room 902, First Ssangyong IT Twin Tower,
442-17 Sangdaewon-dong, Jungwon-gu, Seongnam-shi,
Gyeonggi-do, Korea, 462-807
TEL: +82-(0)502-111-7272 FAX: +82-(0)31-608-5540
E-mail: adminusb@hanausb.com
HANA Micron Inc.
Customer Center
Hana Micron Inc
11 [eparate product] Basic Manual for Host MP3P Bullet Cradle Kit
1) Host MP3P Bullet Cradle’s constituent
Host MP3P Bullet Cradle (Main Product)
/ Bullet Cradle DC/DC Adaptor / Cradle AC/DC Adaptor
/ Bullet Cradle - DC Adaptor for car /
/ Bullet Cradle DC Gender / Cradle contact magnet
2) part name & function
Bullet Cradle Front
② Cradle holder
FM Tx selection
switch①
FM transmitter freq.
106.7MHz
FM Tx Freq. 107.9MHz
FM Transmitter off
Bullet Cradle rear
Bullet Cradle right side
1. FM transmission setup Switch & FM transmission turn off
- You may listen to the music which is playing on MP3 Player with a Speaker of Home or Car audio, using FM
Transmitter function loaded in the cradle.
2. cradle holder
- If you set Host MP3 Player Bullet on Cradle, you may create an atmosphere with light.
3. DC adaptor connection jack
- Home or car DC Adaptor is connected with and powered by Cradle, and if Host MP3 Player Bullet is
connected, it may be charged.
4. Audio Connection
5. Extra USB prot
- It a port which can be used with USB Memory(including almost every USB memory and other company’s
products) which is already in use, and if you save a MP3 file and connect the port, it will be recognized into
MP3 Player Bullet의 Master Memory and play.
3) Three phases to listen to the music with Cradle FM Transmitter function
DC jack③ ④ Audio in
External USB port⑤
Preparation : There should be Car or home audio which is loaded Radio that FM Transmission is available.
Step 1 : to connected cradle into power
Connect car or home DC Adaptor into Dc Adaptor included(important : the product only deals with 220V) set
FM Switch radio frequency you wish.
Step 2 : to turn on the car or home audio with radio
After you turn on the car or home audio, set cradle frequency with the radio frequency equally
Step 3 : to setup the Host MP3 Player Bullet with Cradle and listen to the music
Set up Host MP3 Player Bullet including mp3 with cradle and push the play button. Enjoy the music with car or
home audio machine. If Extra USB is connected with another USB, you can enjoy other music in the second
USB circuit.
