HANGZHOUNFORD TOOLS LM121 Transmitter User Manual

User Manual

User manual

There are two keys on the product, which each of them is pressed

can generate a serial of digital code with the carrier at modulator stage by

way of FSK mode and to the transmitter antenna. And of course there

are different from each other in key value. What is more,every time we

press any of the key will generate a different serial of digital code

comparing with the former time, and it varies according to some rules.

Acorrding to the designation,the carrier frequency is defined at

433MHZ and at a specified fundamental frequency +5KHZ or -5KHZ.

Antenna is printed in PCB

The transmitter is powered by 12V Battary.

Main function description

The product is used for controlling the opening and closing of a

door.

Up key

Down key

There are two keys on the product which marked up key an down

key.

Up key is defined to open door and the down key is defined to close

the door.

If we need open the door ,we can press the up key.on the contrary ,we

press the down key.

There ia another function that we can just use one key to control the

door opening and closing .For example,if we need open the door,we can

press the up key,and after that,we need close it ,we have two ways,one is

press the down key,and the other one is we press the up key again.
