Users Manual
KME 900 Instruction Draft
1, Receiver Circuit
The FM dual-conversion super heterodyne receiver is designed for operation in the 935-941MHz frequency
range.
The Receiver has intermediate frequencies (IF) of 82.2MHz and 455KHz.
Adjacent channel selectivity is obtained by using two band pass filters, a 82.2MHz crystal filter and a 455KHz
ceramic filter.
The FM-detector is Quadrature discriminator.
1-1 Receiver Front-end
A RF signal from antenna is coupled though the low pass filters, antenna switch and band pass filter to the
input of low noise amplifier TR201. The output of TR201 is coupled through band pass filter to input of 1’st
Mixer TR203.
Front End selectivity is provided by these band pass filter.
1-2 1’st Mixer
The 1’st Mixer is a Transistor-Mixer (TR203), that converts a RF signal the 935-941MHz range to 82.2MHz
1’st IF frequency.
In the mixer stage, A RF signal from the Front-end RF filter is applied to the input of the Transistor-Mixer.
1-3 1’st IF
The 82.2MHz 1’st IF output signal is coupled from the output of T201 through IF amplifier TR204 and Crystal
filter FL201 to IF-amplifier TR205.
The highly-selective crystal filters FL201-1 and FL 201-2 provide the first portion of the receiver IF
selectivity. The out put of the filters is coupled through the impedance-matching net work T204, C246 and
R224 to 1’st IF amplifier TR205.
1-4 2’nd Mixer, 2’nd IF filter,2’nd IF amplifier and FM detector
IC201 is an one-chip IC for FM communication system. It includes 2’nd Mixer, 2’nd IF amplifier and FM
detector.
The 2’nd Mixer is a Balanced Mixer, that converts a 1’st IF signal 82.2MHz range to 455KHz 2’nd IF
frequency. The 2’nd IF signal is applied to Ceramic Filter FL203, which provides the 455KHz selectivity.
The output of the 2’nd IF filter is applied to 2’nd IF amplifier in IC201.
The 2’nd IF signal is then amplified, filtered and limited. Discriminator (DSC201) shifts the 2’nd IF signal by
90deg and applies it to the internal FM detector.
The FM detector compares the shifted IF signal to the internal IF signal to recover the audio modulation. The
audio output of IC201 is applied to audio amplifier buffer IC205-2.
The audio output of IC205-2 is then applied to the SYSTEM CONTROL UNIT.
2, Transmitter Circuit
The Transmitter Circuit consists of one Class-A Amplifier TR101, Pre-Driver IC101, PA Module IC102, RF
Amplifier TR102, Automatic Power Control Circuit (TR105- TR107), Antenna Switch (CD103, CD105-
CD107 and CD109), Low Pass Filter (Micro Strip Line and C146-C153, C181 and C183).
2-1 Class-A Amplifier
The 896-902MHz and 935-941MHz RF input from Synthesizer output of TR316 is applied to the band pass
filter FL301 through an attenuator pad R301-R303. RF input level is about +3dBm, that is amplified to
+10dBm by TR101. This is controlled by TXENB+.
2-2 Pre-Driver
The output of TR101 is applied to the Pre-Driver IC101 through an attenuator pad R106-R108. The output of
R107 is also amplified to about 600mW by IC101. This is controlled by TXENB+. The Pre-Driver consists of
three stages RF amplifier. The first and second stages in IC101 are operated in Class-B. The third stage in
IC101 is operated in Class-C.
2-3 PA Module
The output of IC101 is applied to the PA Module IC102 through an attenuator pad R110-R112. The output of
R110 is amplified to about 13W. The PA Module consists of three stages RF amplifier. The first stage power
supply voltage is controlled by power control circuit. The second and third stage power supply voltages are
supplied by B_A+ via TR108. The first and second RF amplifiers are operated in Class-B. The third RF
amplifier is operated in Class-C.
2-4 RF Amplifier
The input (about 13W) of the RF Amplifier is amplified to 25W.
Power Supply voltage for the RF Amplifier is connected with POWER SUPPLY BOARD through C1.
2-4 Automatic Power Control
The Automatic Power Control circuit samples the output power to the antenna to maintain a constant power
level across the band. Also, a thermistor circuit (TR104 and RT101) senses the PA Module temperature to
reduce the power level when the temperature is above +110°C. The Automatic Power Control circuit controls
the supply voltage to the first stage in PA Module IC102. Directional coupler provides a sample of transmit
power for diode CD102. Diode CD102 produce a positive DC voltage proportional to the transmit circuit
output power level. When above VSWR 3, reflect coupler provides a sample of reflection power for diode
CD101. Diode CD101 and CD102 produce voltages are summed, then that is compared to APCREF (D/A
Voltage) from SYSTEM CONTROL UNIT by the amplifier TR105. The collector of TR105 is applied to DC
amplifier TR106 and TR107, then the output voltage of TR107 controls to the first stage of PA Module.
2-5 Antenna Switch and Low Pass Filter
The Antenna Switch consists of CD103, CD105-CD107, CD109 and the Low Pass Filter consists of micro
strip line and C146-C153,C181 and C183.
During transmit, TXENB+ line from SYSTEM CONTROL UNIT is high level. Transistor TR109 turns on
supply +9VT to the Class-A Amplifier and Pre-Driver, Automatic Power Control circuit and PIN diode
Antenna Switch CD103, CD105-CD107 and CD109. When transmitting, the Antenna Switch diode is low
impedance.
3, Frequency Synthesizer Circuit
The Frequency Synthesizer circuit receives PLL data, and control information from the microcomputer and
from this generates the Tx / Rx RF frequencies.
It also provides frequency lock status to SYSTEM CONTROL UNIT. It consist of the Reference Oscillator,
PLL Frequency Synthesizer chip IC305, Loop filter, Rx VCO TR307, Tx VCO TR304, Feedback Buffer
Amplifier, and Dual-Modulus Prescaler IC306. Rx VCO and Tx VCO are locked to the Reference Oscillator
by a single direct-divide synthesis loop consisting of the Feedback Buffer, Prescaler, and PLL Frequency
Synthesizer chip.
The Tx VCO operates over a frequency range of 448-451MHz and 467.5-470.5MHz.
The Rx VCO operates over a frequency range of 426.4-429.4MHz.
3-1 Reference Oscillator
The reference oscillator consists of a 1.5-PPM TCXO (Temperature Controlled Compensated Crystal
Oscillator). The standard reference oscillator frequency is 12.8MHz.
The TCXO is enclosed in a RF shielded can. The TCXO is compensated by internal temperature compensated
circuit for both low and high temperature. With no additional compensated the oscillator will provide 1.5 PPM
stability from -30°C to +60°C.
3-2 PLL Frequency Synthesizer chip
PLL Frequency Synthesizer chip IC305 contains a programmable reference oscillator divider (R), phase
detector, and programmable VCO dividers (+N, A).
A fixed integer number to obtain a 6.25KHz or 5KHz channel reference for the synthesizer divides the
reference frequency 12.8MHz from the reference oscillator.
PC PROGRAMMER can change this divide value.
The internal phase detector compares the output of the reference divider with the output of internal +N,A
counter. The +N, A count counter receives as its input the VCO frequency divided by the Prescaler and
programmed by the microcomputer.
This results in an error voltage when the phase differ and a constant output voltage when phase-detector input
compare in frequency and phase.
If a phase error is detected, an error voltage is developed and applied to the VCO DC offset and loop filter to
reset the VCO frequency. The count of the +N, A counters is controlled by the frequency data received on the
SCK-, SDT- and PLLENB- line from SYSTEM CONTROL UNIT.
When a different channel is selected or when changing to the transmit or receive mode an error voltage is
generated and appears at the phase-detector output, APD(IC305-2pin), causing the Phase Locked Loop to
acquire the new frequency.
3-3 Loop filter
The Loop filter consists of R352 through R349 and C379, C380 and C378.
This filter controls the bandwidth and stability of the synthesizer loop.
When a different channel changing or changing to the transmit or receive mode, FET switch is controlled by
PLLFST- for PLL lock up first (aplox 9mSEC).
The output of the filter is applied to the varicaps in the transmit and receive VCO’s to adjust and maintain the
VCO frequency. The use of to VCO’s allows rapid independent selection of transmit and receive frequencies
across the frequency split.
3-4 Rx VCO
The Rx VCO consists of FET oscillator TR307, and followed by high-gain buffer TR305. TR305 prevents
external loading and provides power gain.
The VCO is a colpitts oscillator with the various varactors, capacitors and coil the tank circuit.
The VCO is switched on and off DPTT- line. When DPTT- is high, the Rx VCO is turned on, transistor
TR307 and TR305 is on. The output of the Rx VCO after 2 times(through R302) is typically 0dBm. The
output is applied to the feedback buffer for the VCO frequency control and as the Receiver frequency to Rx
1’st Mixer through the Local oscillator buffer amplifier. The VCO voltage need only be set once at some
frequency of the band and split, after which it operates over the entire split with no additional tuning.
3-5 Tx VCO
The Tx VCO is basically the same as the Rx VCO. The VCO consists of FET oscillator TR304 followed by
high-gain buffer amplifier TR303. When DPTT- is low, the Tx VCO is turned on, transistor TR303 and
TR304 is on. The output of the Tx VCO after 2 times(through R301) is typically 0dBm.
3-6 Common Doubler
The common doubler consists of TR317. The common doubler does the oscillation frequency of the
reception/transmission VCO 2 times.
3-7 Feedback Buffer Amplifier
The output of Rx VCO and Tx VCO, from transistor TR305 and TR303 respectively, are supplied to Feedback
Buffer Amplifier IC301 and TR308. That drives the Dual-Modulus Prescaler IC306.
3-8 Dual-Modulus Prescaler
The Dual-Modulus Prescaler completes the Phase Lock Loop(PLL) feedback path from the PLL Frequency
synthesizer chip to the Loop Filter, to the VCO’s and Feedback Buffers and then back to the PLL Frequency
synthesizer chip through the Prescaler.
The Prescaler divides the VCO by 64 or 65 under control of MC(IC306-6pin) from the PLL Frequency
synthesizer chip. The output of the Prescaler is applied to the PLL Frequency synthesizer chip where it is
divided down 5KHz or 6.25KHz by and internal +N,A counter and compared in frequency and phase with
the divided-down frequency for the Reference Oscillator. The result of this comparison is the error voltage
used to maintain frequency lock. The +N, A counter is controlled by data received from the SYSTEM
CONTROL UNIT. Depending on the operating frequency, the DC voltage at Test Point TP301 should be
within 1.5 to 6.5 Vdc when the PLL is locked.
3-9 Lock Detect
The Lock Detect circuit consists of transistor TR310 and CD323.
If a large frequency error exists, the LD (IC305-14pin) positive lead from the PLL Frequency synthesizer chip
will carry negative spikes to the SYSTEM CONTROL UNIT. When unlock ,PLLLOCK+ is low.
3-10 Loop Modulation Circuit
The Loop Modulation Circuit consists of IC303. Tx audio is integrated about fc= 0.15Hz for Loop
Modulation. That signal is summed with the APD (IC305-2pin).
