HELLA and KGaA BCM2R inductive application User Manual Testreport ETS 300 335
Hella KGaA Hueck & Co. inductive application Testreport ETS 300 335
Contents
- 1. Users Manual
- 2. Users Manual-Statement
Users Manual
Reference Test report no. 16010324
EUT: BCM2R
FCC ID: NBGBCM2R
FCC Title 47 CFR Part 15 C
Date of issue: 2016-03-23
Date: 2015-03-13
Vers. no. 1.15
m. dudde hochfrequenz-technik
Rottland 5a
D-51429 Bergisch Gladbach/ Germany
Tel: +49 2207-96890
Fax +49 2207-968920
Annex acc. to FCC Title 47 CFR Part 15
relating to
Hella KGaA Hueck & Co.
BCM2R
Annex no. 5
User Manual/
Functional Description
Title 47 - Telecommunication
Part 15 - Radio Frequency Devices
Subpart C – Intentional Radiators
Measurement Procedure:
ANSI C63.4-2014
ANSI C63.10-2013
Reference Test report no. 16010324
EUT: BCM2R
FCC ID: NBGBCM2R
FCC Title 47 CFR Part 15 C
Date of issue: 2016-03-23
Date: 2015-03-13
Vers. no. 1.15
m. dudde hochfrequenz-technik
Rottland 5a
D-51429 Bergisch Gladbach/ Germany
Tel: +49 2207-96890
Fax +49 2207-968920
User Manual / Functional Description of the test equipment (EUT)
BCM2R – Homologation
Author:
Dept.:
Elbers / Siekmann
E-B-PM21
Doc. name:
Process:
BCM2R_Functional_description.docx
ENG.5
Template
version:
1.9
Page:
1/4
This document is confidential. Its contents are not to be exploited, passed on or disclosed to third parties without our express permission. All rights are reserved.
Hella 8601EN_GE (2016-02)
Document History
MKS version
no.
Date
Status
Description
Person
1.0
2016/02/19
Released
Final Version
Elbers / Siekmann /
Functional Description
Project/ Modelcode:
BCM2R
Version:
1.0
BCM2R – Homologation
Author:
Dept.:
Elbers / Siekmann
E-B-PM21
Doc. name:
Process:
BCM2R_Functional_description.docx
ENG.5
Template
version:
1.9
Page:
2/4
This document is confidential. Its contents are not to be exploited, passed on or disclosed to third parties without our express permission. All rights are reserved.
Hella 8601EN_GE (2016-02)
Table of Contents
1 Functional Description – LF Transmitter ....................................... 3
2 Functional description – Receiver .................................................. 4
BCM2R – Homologation
Author:
Dept.:
Elbers / Siekmann
E-B-PM21
Doc. name:
Process:
BCM2R_Functional_description.docx
ENG.5
Template
version:
1.9
Page:
3/4
This document is confidential. Its contents are not to be exploited, passed on or disclosed to third parties without our express permission. All rights are reserved.
Hella 8601EN_GE (2016-02)
1 Functional Description – LF Transmitter
The LF-Transmitter in the BCM is part of a driving authorisation system with the following
function: Car access by sending LF-Signals for Passive Entry and Passive Start function.
General Technical Data: LF part
Temperature range:
Working temperature:
Data of LF-Part
-40 ...+85 ° C
Kind of data transmission: simplex
Center frequency:
21,85 kHz
Transmitter power
< 6mA/m @ 3m distance(free space)
Modulation:
BPSK-signal (phase shift keying)
Modulation content:
digital data
Data rate:
5,4 kBit!s ; 2,7 kBit!s
Data content:
Wake Pattern 4 Byte (5,4 Kbit!s):
Data 19Byte (2,7kbit!s)
Field no Modulation (3 to 6 times 3ms)
WP-Field (0 to 4 times 2Byte with 5,4kBit!s)
Antenna:
Serial capacity and inductivity resonance circuit
C = 150nF, L = 1601H, Q :: 80
3 (to 5) Antenna
Antenna connection:
twisted pair
Antenna position in the car: Rear antenna: trunk border (inside car)
Inside antenna: center console
Side antenna: inside door covering
BCM2R – Homologation
Author:
Dept.:
Elbers / Siekmann
E-B-PM21
Doc. name:
Process:
BCM2R_Functional_description.docx
ENG.5
Template
version:
1.9
Page:
4/4
This document is confidential. Its contents are not to be exploited, passed on or disclosed to third parties without our express permission. All rights are reserved.
Hella 8601EN_GE (2016-02)
2 Functional description – Receiver
The Receiver in the BCM is part of a driving authorisation system with the following function:
Remote control for car access by receiving RF- Signals and optional with Passive Entry function
General Technical Data: RF part
Temperature range:
Working temperature: -40 ...+85 ° C
Data of RF-Part
Kind of data transmission: simplex
Receiver:
Center frequency: 315,00 MHz
433,92 MHz
868,30 MHz
3 dB bandwith >300 kHz
Frequency tolerance: +/- 80 ppm
(production, aging, temperature)
Sensitivity typ. -95 dBm @315,00 MHz
typ. -95 dBm @433,92 MHz
typ. -95 dBm @868,30 MHz
Modulation: 2-FSK (frequency shift keying)
Frequency deviation: +/- 16 kHz @ 315 MHz (+/-50%)
+/- 16 kHz @ 433,92 MHz (+/-50%)
+/- 25 kHz @ 868,3 MHz (+/-50%)
Modulation content: digital data
Data rate: 1,3 kBit/s ; 10 kBit/s
Coding: Manchester
Data content: Remote control value (1,3 Kbit/s):
130 Zero-Bits preamble + 96 data bits
Antenna: Window antenna connected with a coax cable
