HELLA and KGaA FS1271M Identification device for automotive passive entry / passive start system User Manual 2017 12 21 Description FS12P71M NAR
HELLA GmbH & Co. KGaA Identification device for automotive passive entry / passive start system 2017 12 21 Description FS12P71M NAR
Users Manual
HELLA GmbH & Co. KGaA
59552 Lippstadt
:
:
Replacement for version dated :
Radio identification device
2017-12-21 New document
Amend. Date
Amend. No.
Page
Amendment
FS1271M
HELLA FS1271M
HELLA GmbH & Co. KGaA
59552 Lippstadt
:
:
Replacement for version dated:
1 Device description
2 Application
The above-mentioned devices are intended to allow the user to comfortably control the central locking status of a vehicle.
This can be achieved by activation of the buttons described in the following picture. Furthermore, comfort to the user is
enhanced to a great extent by passive entry and passive start functionality.
The following functions are implemented:
• By pressing the lock button, the vehicle will be locked.
• To unlock the vehicle, the unlock button shall be pressed.
• Activating the tailgate remote release button will open the trunk.
• The vehicle can be locked and unlocked in passive mode without the need to manually activate any button at the
identification device.
• The engine can be started by pressing the vehicle´s start button.
Activation of the identification device is acknowledged by flashing of the LED.
Lock
Panic
Tailgate release
Unlock
Picture 1:
Hella FS1271M radio identification device
Table 1: Versions of Hella FS1271M radio identification devices for the North American market
Device designation Buttons Button functions Customer label
FS1271M 4 lock, unlock, tailgate remote release, panic AUDI
This document is to describe the Hella FS1271M radio identification devices for the North American market:
Hella FS1271M
HELLA GmbH & Co. KGaA
59552 Lippstadt
REGULATORY NOTICES
FCC Warning
Notice
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) this device may not cause harmful interference and
(2) this device must accept any interference received, including interference that may cause undesired operation.
IC Warning
This device contains licence-exempt transmitter(s)/receiver(s) that comply with Innovation, Science and Economic
Development Canada’s licence-exempt RSS(s). Operation is subject to the following two conditions:
(1) This device may not cause interference.
(2) This device must accept any interference, including interference that may cause undesired operation of the device.
Le présent appareil est conforme aux CNR d’Industrie Canada applicables aux appareils radio exempts de licence.
L’exploitation est autorisée aux deux conditions suivantes :
(
1) l’appareil ne doit pas produire de brouillage;
(
2) l’utilisateur de l’appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d’en
compromettre le fonctionnement.
Hella FS1271M
