HELLA and KGaA FS14P71M Identification device for automotive passive entry / passive start system User Manual Hella FS14P71M x
HELLA GmbH & Co. KGaA Identification device for automotive passive entry / passive start system Hella FS14P71M x
Users Manual
HELLA GmbH & Co. KGaA
59552 Lippstadt
Hella FS14P71M
Radio identification device
FS14P71M
2017-12-21
New document
Amend. Date
Amend. No.
Page
Amendment
:
:
Replacement for version dated :
HELLA GmbH & Co. KGaA
59552 Lippstadt
Hella FS14P71M
1 Device description
This document is to describe the Hella FS14P71M radio identification devices for the North American market:
Device designation
Buttons
Button functions
Customer label
FS14P71M
4
lock, unlock, tailgate remote release, panic
AUDI
Table 1: Versions of Hella FS14P71M radio identification devices for the North American market
2 Application
The above-mentioned devices are intended to allow the user to comfortably control the central locking status of a vehicle.
This can be achieved by activation of the buttons described in the following picture. Furthermore, comfort to the user is
enhanced to a great extent by passive entry and passive start functionality.
The following functions are implemented:
• By pressing the lock button, the vehicle will be locked.
• To unlock the vehicle, the unlock button shall be pressed.
• Activating the tailgate remote release button will open the trunk.
• The vehicle can be locked and unlocked in passive mode without the need to manually activate any button at the
identification device.
• The engine can be started by pressing the vehicle´s start button.
Activation of the identification device is acknowledged by flashing of the LED.
Picture 1: Hella FS14P71M radio identification device
Lock
Unlock
Tailgate
unlock
Panic
HELLA GmbH & Co. KGaA
59552 Lippstadt
Hella FS14P71M
REGULATORY NOTICES
FCC Warning
Notice
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) this device may not cause harmful interference and
(2) this device must accept any interference received, including interference that may cause undesired operation.
IC Warning
Canada Low-power license-exempt radio communication devices (RSSV210)
a. Common information:
Operation is subject to the following two conditions:
1. This device may not cause interference, and
2. This device must accept any interference, including interference that may cause undesired operation of the device.
a. Informations communes:
Fonctionnement est soumis aux deux conditions suivantes:
1. Ce dispositive ne peut causer des interférences, et
2. Ce dispositive doit accepter toute interférence, y compris les interférences qui peuvent causer un mauvais
fonctionnement du dispositive.
