Installation Guide
PLT-02395, Rev A.3
OMNIKEY®
Smart Card Readers
Installation Guide
© 2010-2017 HID Global Corporation/ASSA ABLOY AB. All rights reserved. This document may not be reproduced, disseminated or republished in any form without the
prior written permission of HID Global Corporation.
HID Global, HID, the HID Brick Logo, ICLASS SE, OMNIKEY, and SEOS are the trademarks or registered trademarks of HID Global Corporation, or its licensors, in the U.S.
and other countries. All other trademarks, service marks, and product or service names are trademarks or registered trademarks of their respective owners.
eBase Models
1021, 3021, 3121, 5021, 5022, 5023,
5025, 5027, 5127, 5421, 5422, 5427, 6121
Americas and Corporate
611 Center Ridge Drive
Austin, TX 78753
USA
Asia Pacific
19/F 625 King’s Road
North Point, Island East
Hong Kong
Europe, Middle East and Africa
Phoenix Road
Haverhill, Suolk CB9 7AE
England
www.hidglobal.com/support
Drivers and Manuals: www.hidglobal.com/omnikey
Introduction
This guide describes physical behaviour and conformities of
OMNIKEY Smart Card Readers.
1021 USB - Desktop smart card reader in a small form factor for
desktop and mobile usage.
3021 USB - High-performance smart card reader, with a USB
interface and small form factor for desktop and mobile usage.
3121 USB - High-performance smart card reader for desktop use
with multiple standing base options in a robust housing.
5021 USB - Contactless Reader with USB interface for desktop
use that reads/writes to 13.56 MHz smart cards.
5022 USB - Contactless Reader with USB CCID-compliant
interface for desktop use that reads/writes to 13.56 MHz smart
cards.
5023 USB - A 5022 Reader with iCLASS and Seos support.
5027 USB - A 5023 Reader with Keyboard wedge.
5025 CL USB - Contactless Reader with USB CCID-compliant
interface for desktop use that reads contactless (125 kHz) Prox
cards.
5127 / 5427 CK/ 5427 UE USB - Contactless 13.56MHz/125kHz
reader with CCID/Keyboard wedge interface.
5427 G2 - Contactless 13.56MHz/125kHz reader with CCID/
Keyboard wedge interface and BLE.
5421 / 5422 USB - Dual interface PC-linked reader that reads/
writes to 13.56 MHz contactless cards and virtually any contact
smart card. 5422 includes CCID.
6121 Mobile USB - Dongle-sized smart card reader for SIM-sized
smart cards, especially well suited for use with mobile devices.
Parts
Smart Card Reader
Installation Guide
Find drivers, reader documentation supporting various
operating systems at:
www.hidglobal.com/omnikey
See the application note for card loading and handling
instructions at: www.hidglobal.com/omnikey
Specifications and Installation
For further information, contact HID support:
www.hidglobal.com/support
For driver setup, consult the OMNIKEY Smart Card User Guide.
CAUTION: Install the drivers prior to attaching the OMNIKEY
reader with the computer.
ATTENTON: Vous devez installer le driver avant de connecter le
lecteur OMNIKEY à l’ordinateur.
USB Connected Reader Specifications
Operating
Temperature 32°F to 131°F (0°C to 55°C)
PC Connector Cable
59.1 in (150 cm)
1021, 3021, 3121, 5021, 5022, 5023, 5025 CL,
5027, 5422, 5427 G2
78.7 in (200 cm)
5421, 5427 CK
Mean Time Between
Failures (MTBF) 500,000 Hours
Host Interface USB 2.0 CCID (USB 1.1 Compatible)
Host Data
Transmission Speed 12 Mbps (USB 2.0 Full Speed)
Power Supply Bus Powered
USB Connected Reader Installation
1. Connect the reader with computer; plug the USB connector
into your computer’s USB port.
2. When the reader is operational, the LED illuminates.
3. For contactless operation, hold the card next to the reader
logo. For contact smart cards, insert the card into the reader
with contacts facing up.
4. The LED blinks when the reader is exchanging data with a
card (reading/writing).
hidglobal.com An ASSA ABLOY Group brand
Regulatory
CAUTION: Any changes or modifications to this device not explicitly approved by
manufacturer could void your authority to operate this equipment.
ATTENTION: Tout changement ou modification de cet appareil sans approbation
explicite du manufacturer vous enlève les droits d’usage de cet équipement.
FCC (All Readers)
This device complies with part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) This device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that
may cause undesired operation.
FCC (Readers 1021, 3021, 3121, 6121)
Tested to comply with FCC standards FOR HOME AND OFFICE USE
Product Radio Certifications
The OMNIKEY 5022 CL and 5127CK MINI Module were tested under the FCC rules
and Industry Canada rules for a Modular Approval and therefore the following
shall apply: (reference below FCC/IC IDs)
Provided that the Antenna and tuning network have not been
changed in any way, the Final Product label may contain the HIID
Global FCC ID. Provided no other radio devices exist within the
final assembly. The end integrator may use these ID’s, as long at the
original HID Global Label is visible.
FCC ID: JQ6-OK5022CL or IC ID: 2236B-OK5022CL
FCC ID: JQ6-OK5127CKMINI or IC ID: 2236B-OK5127CKMINI
The End User/Manufacturer, will not need to repeat the intentional
emissions testing (actual radio certification), however the un-
intentional emissions testing will need to meet the FCC and IC
requirements with the module installed into the final assembly or
product. This also applies to CE Marking as defined by the R&TTE
Directive.
However, in many cases, the module may need to be retuned, due
to the eects of the product enclosure and assemblies within this
enclosure, and the de-tuning aect that this may have on the radio
circuitry. In this case and if other radios exist, Class 2 Permissive
Change is required.
In the event that the HID OEM modules Kit is modified in any way,
the radio transmitter operating at either 125 kHz, 13.56 MHz and
Bluetooth, when the module is integrated into the OEM’s final
product, Radio Certification is required for the final product.
Obtain FCC Certification by submitting the final product to a
Telecommunications Certified Body (TCB) laboratory that performs
the testing and issue the FCC Grant. Standard: Part 15, Subpart C.
Often the same TCB tests to Canada requirements and grants
certification as a Certification Body (CB). Standard: RSS-210, RSS-
GEN and RSS-310, where applicable.
The same laboratory may also be an EU Communications
Assessment Body (CAB) that is accredited to test to R&TTE Directive
requirements for CE Marking. Applicable standards:
EN 300 330, EN 301 489-3, EN 50130-4, and IEC60950.
A laboratory that is a CAB testing to R&TTE Directive requirements
will also be testing to Australia and New Zealand requirements
because of a common test standard. Standard:
AS/NZS 4268.
Asian country certifications are obtained on an individual country
basis.
OEM Final Product US Dept. of Commerce Bureau of Industry and Security
(BIS) approval is required for USA based companies who export and re-export
products using encryption.
Regulatory Compliance Assistance - HID Global provides technical assistance
and laboratory recommendations, as required.
CAUTION: Any changes or modifications to this devise not explicitly approved
by the manufacturer could void your authority to operate this equipment.
Canada Radio Certification (All Readers)
This device complies with Industry Canada license-exempt RSS standard(s).
Operation is subject to the following two conditions: (1) This device may not
cause interference, and (2) this device must accept any interference, including
interference that may cause undesired operation of the device.
Le present appareil est conforme aux CNR d’Industrie Canada applicable
aux appareils radio exempts de licence. L’exploitation est autorisée aux deux
conditions suivantes: (1) l’appareil ne doit pas produire de brouillage, et (2)
l’utilisateur de l’appareil doit accepter tout brouillage radioélectrique subi, meme
si le brouillage est susceptible d’en compromettre le fonctionnement.
CE Marking (All Readers)
HID Global hereby declares that these proximity readers are in compliance with the
essential requirements and other relevant provisions of Directive 2006/95/EC.
Por el presente, HID Global declara que estos lectores de proximidad cumplen
con los requisitos esenciales y otras disposiciones relevantes de la Directiva
2006/95/EC.
HID Global déclare par la présente que ces lecteurs à proximité sont conformes
aux exigences essentielles et aux autres stipulations pertinentes de la Directive
2006/95/EC.
A HID Global, por meio deste, declara que estes leitores de proximidade estão
em conformidade com as exigências essenciais e outras condições da diretiva
2006/95/EC.
HID Global bestätigt hiermit, dass die Leser die wesentlichen Anforderungen und
anderen relevanten Bestimmungen der Richtlinie 2006/95/EC erfüllen.
HID Global dichiara che i lettori di prossimità sono conformi ai requisiti essenziali
e ad altre misure rilevanti come previsto dalla Direttiva europea 2006/95/EC.
Download the R&TTE Declaration of Conformity (DoC) at:
http://www.hidglobal.com/certifications
Brazil (Readers 5022, 5023, 5422 and 5427 G2)
“Este equipamento opera em caráter
secundário, isto é, não tem direito a proteção
contra interferência prejudicial, mesmo de
estações do mesmo tipo, e não pode causar
interferência a sistemas operando em caráter
primário”
Chile (Readers 5022, 5422 and 5427 G2)
China (Readers 1021, 5022, 5422, 5427 and 5427 G2)
Hong Kong (Readers 5022, 5023, 5422 and 5427 G2)
India (Readers 5022, 5023, 5422 and 5427 G2)
Japan MIC (Reader 4121)
この装置は総務省の型式指定を受けています。
本製品は電波を使用したRFID機器の読み取り・書き込み装置です。
そのため使用する用途・場所によっては、医療機器に影響を与える恐れがあります。
Korean KC (Readers 1021, 3121, 4040, 4321, 5021, 5022,
5325, 5326, 5421, 5422, 5427, 5427 G2, 6121, 6221, 6321)
항목 규격 항목 규격
송신주파수 RFID:13.56 MHz 전파형식 A1D
수신주파수 RFID:13.56 MHz 발진방식 X-tal
출력 RFID: 10m에서 24.19mv이하 변조방식 AM
전원 DC 5
Mexico (Readers 5022, 5023, 5422, 5427 G2)
Singapore (Reader 5427 CK)
Taiwan (Readers 5321 and 5421)
經型式認證合格之低功率射頻電機，非經許可，公司、商號或使用者均不得擅自變
更頻率、加大功
率或變更原設計之特性及功能。低功率射頻電機之使用不得影響飛航安全及干擾合
法通信；經發現
有干擾現象時，應立即停用，並改善至無干擾時方得繼續使用。前項合法通信，指
依電信法規定作
業之無線電通信。低功率射頻電機須忍受合法通信或工業、科學及醫療用電波輻射
性電機設備之干
擾。
According to “Administrative Regulations on Low Power Radio Waves Radiated
Devices” Without permission granted by the NCC, any company, enterprise,
or user is not allowed to change frequency, enhance transmitting power or
alter original characteristic as well as performance to an approved low power
radio-frequency devices shall not influence aircraft security and interfere
legal communications; If found, the user shall cease operating immediately
until no interference is achieved. The said legal communications means radio
communications is operated in compliance with the Telecommunications Act.
The low power radio-frequency devices must be susceptible with the interference
from legal communications or ISM radio wave radiated devices.
