HID Global OK5022CL USB Contactless Smart Card Reader User Manual
HID Global Corporation USB Contactless Smart Card Reader Users Manual
Users Manual
© 2010-2015 HID Global Corporation/ASSA ABLOY AB. All rights reserved.
eBase Models: 1021, 3021, 3121, 4040, 4121, 4321,
5021, 5022 CL, 5025, 5121, 5125, 5127,
5127CK Mini, 5321, 5325, 5326, 5421,
5427, 6121, 6221, 6321
Drivers and Manuals: www.hidglobal.com/omnikey
North America & Corporate
611 Center Ridge Drive
Austin, TX 78753
USA
Asia Pacific
19/F 625 King’s Road
North Point, Island East
Hong Kong
Europe, Middle East & Africa
Phoenix Road
Haverhill, Suffolk CB9 7AE
England
support.hidglobal.com
Installation Guide
OMNIKEY
®
Smart Card Readers
3121-906-ENEN, B.5
OMNIKEY Smart Card Reader Installation Guide
2 © 2010-2015 HID Global Corporation/ASSA ABLOY AB. All rights reserved.
Introduction
This guide describes physical behavior and conformities of the OMNIKEY Smart Card Readers.
1021 USB - Desktop smart card reader in a small form factor for desktop and mobile usage.
3021 USB - High-performance smart card reader, with a USB interface and small form factor for
desktop and mobile usage.
3121 USB - High-performance smart card reader for desktop use with multiple standing base
options in a robust housing.
4040 Mobile PCMCIA - High-performance smart card reader for mobile use in laptops and PDAs
with PCMCIA interface.
4121 CL - Mobile ExpressCard 34mm - Contactless Reader with ExpressCard® interface for
Laptops and mobile devices that reads/writes to 13.56 MHz smart cards.
4321 Mobile ExpressCard 54 - High-performance smart card reader for mobile use in laptops
and mobile devices with the ExpressCard interface.
5125 / 5325 USB Prox - Dual interface PC-linked reader that reads contactless (125kHz) HID
Prox cards and reads/writes virtually any contact smart card.
5121 / 5321 / 5421 USB - Dual interface PC-linked reader that reads/writes to 13.56 MHz
contactless cards and virtually any contact smart card.
5127 / 5427 CK/ 5427 UE USB - Contactless 13.56MHz/125kHz reader with CCID/Keyboard
wedge interface.
5021 / 5022 CL / 5321 CL USB - Contactless Reader with USB interface for desktop use that
reads/writes to 13.56 MHz smart cards.
5025 CL USB - Contactless Reader with USB CCID-compliant interface for desktop use that
reads contactless (125 kHz) Prox cards.
5321 CL SAM USB - Dual interface PC-linked reader that reads/writes to 13.56 MHz contactless
cards and virtually any SIM-sized contact smart card.
5326 DFR USB - Contactless Dual Frequency (13.56MHz/125kHz) Reader with CCID interface.
6121 Mobile USB - Dongle-sized smart card reader for SIM-sized smart cards, especially well
suited for use with mobile devices.
6221 USB - Dongle-sized reader for SIM-sized smart cards and Micro-SD cards, especially well
suited for use with mobile devices.
6321 Mobile USB - Dongle-sized Dual interface PC linked reader that reads/writes to 13.56 MHz
contactless smart card and virtually any SIM-sized contact smart card.
Parts
• Smart Card Reader
• Installation Guide
Find drivers, reader documentation supporting various operating systems at
http://www.hidglobal.com/omnikey.
See the application note for card loading and handling instructions at
http://www.hidglobal.com/omnikey.
Installation Guide OMNIKEY Smart Card Reader
© 2010-2015 HID Global Corporation/ASSA ABLOY AB. All rights reserved. 3
Specifications and Installation
For further information, contact HID support: http://support.hidglobal.com/.
For driver setup, consult the OMNIKEY Smart Card User Guide.
CAUTION: Install the drivers prior to attaching the OMNIKEY reader with the computer.
ATTENTON: Vous devez installer le driver avant de connecter le lecteur OMNIKEY à l'ordinateur.
USB Connected Reader Specifications
Operating Temperature
0°- 55° C / 32°- 131° F
PC Connector Cable
150 cm / 59.1 in - Models 1021, 3021
200 cm / 78.7 in - Models 5021, 5025 CL, 5421, 5427 CK
180 cm / 70.9 in - Other Models
Mean Time Between Failures (MTBF)
500,000 Hours
Host Interface
USB 2.0 CCID (USB 1.1 Compatible)
Host Data Transmission Speed
12 Mbps (USB 2.0 Full Speed)
Power Supply
Bus Powered
USB Connected Reader Installation
1. Connect the reader with computer; plug the USB connector into your computer’s USB port.
2. When the reader is operational, the LED illuminates.
3. For contactless operation, hold the card next to the reader logo. For contact smart cards,
insert the card into the reader with contacts facing up.
4. When the reader is exchanging data with a card (reading/writing), the LED blinks.
PCMCIA and ExpressCard Reader Specifications
4321
4121 CL
4040
Operating Temperature
0°- 55° C / 32°- 131° F
Mean Time Between Failures (MTBF)
500,000 Hours
Host Interface
ExpressCard
54mm ExpressCard 34mm PCMCIA
Host Data Transmission Speed
12 Mbps
16 Mbps
Power Supply
Bus Powered
PCMCIA
PCMCIA and ExpressCard Reader Installation
1. Insert the reader into the compatible interface slot of your Notebook or mobile device.
2. If the reader is operational, observe the reader in your operating system’s Device Manager.
3. For contactless operation, hold the card next to the logo on the reader. For contact smart
cards, insert the card into the reader with contacts facing up.
OMNIKEY Smart Card Reader Installation Guide
4 © 2010-2015 HID Global Corporation/ASSA ABLOY AB. All rights reserved.
Regulatory
CAUTION: Any changes or modifications to this device not explicitly approved by manufacturer could
void your authority to operate this equipment.
ATTENTION: Tout changement ou modification de cet appareil sans approbation explicite du
manufacturer vous enlève les droits d'usage de cet équipement
FCC (All Readers)
This device complies with part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) This device may not cause harmful interference, and (2) this device must accept
any interference received, including interference that may cause undesired operation.
Product Radio Certifications
The OMNIKEY 5022 CL and 5127CK MINI Module were tested under the FCC rules and Industry
Canada rules for a Modular Approval and therefore the following shall apply: (reference below
FCC/IC ID’s)
• Provided that the Antenna and tuning network have not been changed in any way, the Final
Product label may contain the HIID Global FCC ID. Provided no other radio devices exist
within the final assembly. The end integrator may use these ID’s, as long at the original
HID Global Label is visible.
• FCC ID: JQ6-OK5127CKMINI or IC ID: 2236B-OK5127CKMINI
• FCC ID: JQ6-OK5022CL or IC ID: 2236B-OK5022CL
• The End User/Manufacturer, will not need to repeat the intentional emissions testing (actual
radio certification), however the un-intentional emissions testing will need to meet the FCC
and IC requirements with the module installed into the final assembly or product. This also
applies to CE Marking as defined by the R&TTE Directive.
• However, in many cases, the module may need to be retuned, due to the effects of the
product enclosure and assemblies within this enclosure, and the de-tuning affect that this
may have on the radio circuitry. In this case and if other radios exist, Class 2 Permissive
Change is required.
• In the event that the HID OEM modules Kit is modified in any way, the radio transmitter
operating at either 125 kHz, 13.56 MHz and Bluetooth, when the module is integrated into
the OEM’s final product, Radio Certification is required for the final product.
• Obtain FCC Certification by submitting the final product to a Telecommunications Certified
Body (TCB) laboratory that performs the testing and issue the FCC Grant. Standard: Part
15, Subpart C.
• Often the same TCB tests to Canada requirements and grants certification as a
Certification Body (CB). Standard: RSS-210, RSS-GEN and RSS-310, where applicable.
• The same laboratory may also be an EU Communications Assessment Body (CAB) that is
accredited to test to R&TTE Directive requirements for CE Marking. Applicable standards:
EN 300 330, EN 301 489-3, EN 50130-4, and IEC60950.
• A laboratory that is a CAB testing to R&TTE Directive requirements will also be testing to
Australia and New Zealand requirements because of a common test standard. Standard:
AS/NZS 4268.
• Asian country certifications are obtained on an individual country basis.
OEM Final Product US Dept. of Commerce Bureau of Industry and Security (BIS) approval is
required for USA based companies who export and re-export products using encryption.
Regulatory Compliance Assistance - HID Global provides technical assistance and laboratory
recommendations, as required.
CAUTION: Any changes or modifications to this devise not explicitly approved by the
manufacturer could void your authority to operate this equipment.
Installation Guide OMNIKEY Smart Card Reader
© 2010-2015 HID Global Corporation/ASSA ABLOY AB. All rights reserved. 5
Canada Radio Certification (All Readers)
This device complies with Industry Canada license-exempt RSS standard(s). Operation is subject to
the following two conditions: (1) This device may not cause interference, and (2) this device must
accept any interference, including interference that may cause undesired operation of the device.
Le present appareil est conforme aux CNR d'Industrie Canada applicable aux appareils radio
exempts de licence. L'exploitation est autorisée aux deux conditions suivantes: (1) l'appareil ne doit
pas produire de brouillage, et (2) l'utilisateur de l'appareil doit accepter tout brouillage radioélectrique
subi, meme si le brouillage est susceptible d'en compromettre le fonctionnement.
CE Marking (All Readers)
HID Global hereby declares that these proximity readers are in compliance with the essential
requirements and other relevant provisions of Directive 2006/95/EC.
Por el presente, HID Global declara que estos lectores de proximidad cumplen con los requisitos
esenciales y otras disposiciones relevantes de la Directiva 2006/95/EC.
HID Global déclare par la présente que ces lecteurs à proximité sont conformes aux exigences
essentielles et aux autres stipulations pertinentes de la Directive 2006/95/CE.
A HID Global, por meio deste, declara que estes leitores de proximidade estão em conformidade com
as exigências essenciais e outras condições da diretiva 2006/95/EC.
HID Global bestätigt hiermit, dass die Leser die wesentlichen Anforderungen und anderen relevanten
Bestimmungen der Richtlinie 2006/95/EG erfüllen.
HID Global dichiara che i lettori di prossimità sono conformi ai requisiti essenziali e ad altre misure
rilevanti come previsto dalla Direttiva europea 2006/95/EC.
Download copies of the R&TTE Declaration of Conformity (DoC) at
http://www.hidglobal.com/certifications.
Taiwan (Readers 5321 and 5421)
經型式認證合格之低功率射頻電機，非經許可，公司、商號或使用者均不得擅自變更頻率、加大功
率或變更原設計之特性及功能。低功率射頻電機之使用不得影響飛航安全及干擾合法通信；經發現
有干擾現象時，應立即停用，並改善至無干擾時方得繼續使用。前項合法通信，指依電信法規定作
業之無線電通信。低功率射頻電機須忍受合法通信或工業、科學及醫療用電波輻射性電機設備之干
擾。
According to “Administrative Regulations on Low Power Radio Waves Radiated Devices” Without
permission granted by the NCC, any company, enterprise, or user is not allowed to change frequency,
enhance transmitting power or alter original characteristic as well as performance to an approved low
power radio-frequency devices shall not influence aircraft security and interfere legal communications;
If found, the user shall cease operating immediately until no interference is achieved. The said legal
communications means radio communications is operated in compliance with the
Telecommunications Act.
The low power radio-frequency devices must be susceptible with the interference from legal
communications or ISM radio wave radiated devices.
OMNIKEY Smart Card Reader Installation Guide
6 © 2010-2015 HID Global Corporation/ASSA ABLOY AB. All rights reserved.
Singapore (Readers 5427 CK)
Japan MIC (Reader 4121)
この装置は総務省の型式指定を受けています。
本製品は電波を使用したRFID機器の読み取り・書き込み装置です。
そのため使用する用途・場所によっては、医療機器に影響を与える恐れがあります。
Korean KC (Readers 1021, 3121, 4040, 4321, 5021, 5022 CL, 5325, 5326, 5421, 5427, 6121,
6221, 6321)
항목 규격
송신주파수
RFID:13.56 MHz
수신주파수
RFID:13.56 MHz
출력
RFID: 10m에서 24.19mv이하
전원
DC 5
전파형식
A1D
발진방식
X-tal
변조방식
AM
