HID Global OK5023CL Smart Card Reader User Manual
HID Global Corporation Smart Card Reader
User Manual
PLT-02395, Rev A.1
OMNIKEY®
Smart Card Readers
Installation Guide
© 2010-2016 HID Global Corporation/ASSA ABLOY AB. All rights reserved. This document
may not be reproduced, disseminated or republished in any form without the prior written
permission of HID Global Corporation. HID Global, HID, the HID logo, iCLASS SE, OMNIKEY,
and Seos are the trademarks or registered trademarks of HID Global Corporation, or its
licensors, in the U.S. and other countries.
Americas and Corporate
611 Center Ridge Drive
Austin, TX 78753
USA
Asia Pacific
19/F 625 King’s Road
North Point, Island East
Hong Kong
Europe, Middle East and Africa
Phoenix Road
Haverhill, Suolk CB9 7AE
England
www.hidglobal.com/support
eBase Models
1021, 3021, 3121, 5021,
5022, 5023, 5025, 5027,
5127, 5421, 5422, 5427, 6121
Drivers and Manuals: www.hidglobal.com/omnikey
Introduction
This guide describes physical behaviour and conformities of
the OMNIKEY Smart Card Readers.
1021 USB - Desktop smart card reader in a small form factor
for desktop and mobile usage.
3021 USB - High-performance smart card reader, with a
USB interface and small form factor for desktop and mobile
usage.
3121 USB - High-performance smart card reader for desktop
use with multiple standing base options in a robust housing.
5021 USB - Contactless Reader with USB interface for
desktop use that reads/writes to 13.56 MHz smart cards.
5022 USB - Contactless Reader with USB CCID-compliant
interface for desktop use that reads/writes to 13.56 MHz
smart cards.
5023 USB - A 5022 Reader with iCLASS and Seos support.
5027 USB - A 5023 Reader with Keyboard wedge.
5025 CL USB - Contactless Reader with USB CCID-
compliant interface for desktop use that reads contactless
(125 kHz) Prox cards.
5127 / 5427 CK/ 5427 UE USB - Contactless
13.56MHz/125kHz reader with CCID/Keyboard wedge
interface.
5421 / 5422 USB - Dual interface PC-linked reader that
reads/writes to 13.56 MHz contactless cards and virtually
any contact smart card. 5422 includes CCID.
6121 Mobile USB - Dongle-sized smart card reader for SIM-
sized smart cards, especially well suited for use with mobile
devices.
Parts
• Smart Card Reader
• Installation Guide
Find drivers, reader documentation supporting various
operating systems at:
www.hidglobal.com/omnikey
See the application note for card loading and handling
instructions at: www.hidglobal.com/omnikey
Specifications and Installation
For further information, contact HID support:
www.hidglobal.com/support.
For driver setup, consult the OMNIKEY Smart Card User Guide.
CAUTION: Install the drivers prior to attaching the
OMNIKEY reader with the computer.
ATTENTON: Vous devez installer le driver avant de
connecter le lecteur OMNIKEY à l’ordinateur.
USB Connected Reader Specifications
Operating Temperature 32° to 131° F / 0° to 55° C
PC Connector Cable
59.1 in/150 cm – Models 1021, 3021, 3121,
5022, 5023, 5027, 5422
78.7 in/200 cm – Models 5021, 5025 CL,
5421, 5427 CK
70.9 in/180 cm – Other Models
Mean Time Between
Failures (MTBF) 500,000 Hours
Host Interface USB 2.0 CCID (USB 1.1 Compatible)
Host Data
Transmission Speed 12 Mbps (USB 2.0 Full Speed)
Power Supply Bus Powered
USB Connected Reader Installation
1. Connect the reader with computer; plug the USB
connector into your computer’s USB port.
2. When the reader is operational, the LED illuminates.
3. For contactless operation, hold the card next to the
reader logo. For contact smart cards, insert the card into
the reader with contacts facing up.
4. When the reader is exchanging data with a card (reading/
writing), the LED blinks.
Regulatory
CAUTION: Any changes or modifications to this device not explicitly
approved by manufacturer could void your authority to operate this
equipment.
ATTENTION: Tout changement ou modification de cet appareil sans
approbation explicite du manufacturer vous enlève les droits d’usage de cet
équipement.
FCC (All Readers)
This device complies with part 15 of the FCC Rules. Operation is subject
to the following two conditions: (1) This device may not cause harmful
interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.
Product Radio Certifications
The OMNIKEY 5022 CL and 5127CK MINI Module were tested under the FCC
rules and Industry Canada rules for a Modular Approval and therefore the
following shall apply: (reference below FCC/IC IDs)
• Provided that the Antenna and tuning network have not been changed
in any way, the Final Product label may contain the HIID Global FCC ID.
Provided no other radio devices exist within the final assembly. The end
integrator may use these ID’s, as long at the original HID Global Label is
visible.
• FCC ID: JQ6-OK5022CL or IC ID: 2236B-OK5022CL
• FCC ID: JQ6-OK5127CKMINI or IC ID: 2236B-OK5127CKMINI
• The End User/Manufacturer, will not need to repeat the intentional
emissions testing (actual radio certification), however the un-intentional
emissions testing will need to meet the FCC and IC requirements with the
module installed into the final assembly or product. This also applies to CE
Marking as defined by the R&TTE Directive.
• However, in many cases, the module may need to be retuned, due to the
eects of the product enclosure and assemblies within this enclosure, and
the de-tuning aect that this may have on the radio circuitry. In this case
and if other radios exist, Class 2 Permissive Change is required.
• In the event that the HID OEM modules Kit is modified in any way, the
radio transmitter operating at either 125 kHz, 13.56 MHz and Bluetooth,
when the module is integrated into the OEM’s final product, Radio
Certification is required for the final product.
• Obtain FCC Certification by submitting the final product to a
Telecommunications Certified Body (TCB) laboratory that performs the
testing and issue the FCC Grant. Standard: Part 15, Subpart C.
• Often the same TCB tests to Canada requirements and grants certification
as a Certification Body (CB). Standard: RSS-210, RSS-GEN and RSS-310,
where applicable.
• The same laboratory may also be an EU Communications Assessment
Body (CAB) that is accredited to test to R&TTE Directive requirements for
CE Marking. Applicable standards:
EN 300 330, EN 301 489-3, EN 50130-4, and IEC60950.
• A laboratory that is a CAB testing to R&TTE Directive requirements will
also be testing to Australia and New Zealand requirements because of a
common test standard. Standard:
AS/NZS 4268.
• Asian country certifications are obtained on an individual country basis.
OEM Final Product US Dept. of Commerce Bureau of Industry and Security
(BIS) approval is required for USA based companies who export and re-
export products using encryption.
Regulatory Compliance Assistance - HID Global provides technical assistance
and laboratory recommendations, as required.
CAUTION: Any changes or modifications to this devise not explicitly
approved by the manufacturer could void your authority to operate this
equipment.
Canada Radio Certification (All Readers)
This device complies with Industry Canada license-exempt RSS standard(s).
Operation is subject to the following two conditions: (1) This device may
not cause interference, and (2) this device must accept any interference,
including interference that may cause undesired operation of the device.
Le present appareil est conforme aux CNR d’Industrie Canada applicable
aux appareils radio exempts de licence. L’exploitation est autorisée aux deux
conditions suivantes: (1) l’appareil ne doit pas produire de brouillage, et (2)
l’utilisateur de l’appareil doit accepter tout brouillage radioélectrique subi,
meme si le brouillage est susceptible d’en compromettre le fonctionnement.
CE Marking (All Readers)
HID Global hereby declares that these proximity readers are in compliance
with the essential requirements and other relevant provisions of Directive
2006/95/EC.
Por el presente, HID Global declara que estos lectores de proximidad
cumplen con los requisitos esenciales y otras disposiciones relevantes de la
Directiva 2006/95/EC.
HID Global déclare par la présente que ces lecteurs à proximité sont
conformes aux exigences essentielles et aux autres stipulations pertinentes
de la Directive 2006/95/EC.
A HID Global, por meio deste, declara que estes leitores de proximidade
estão em conformidade com as exigências essenciais e outras condições da
diretiva 2006/95/EC.
HID Global bestätigt hiermit, dass die Leser die wesentlichen Anforderungen
und anderen relevanten Bestimmungen der Richtlinie 2006/95/EC erfüllen.
HID Global dichiara che i lettori di prossimità sono conformi ai requisiti
essenziali e ad altre misure rilevanti come previsto dalla Direttiva europea
2006/95/EC.
Download the R&TTE Declaration of Conformity (DoC) at:
http://www.hidglobal.com/certifications
Brazil (Readers 5022 and 5023)
HHHHH-AA-FFFFF
“Este equipamento opera em caráter
secundário, isto é, não tem direito a proteção
contra interferência prejudicial, mesmo de
estações do mesmo tipo, e não pode causar
interferência a sistemas operando em caráter
primário”
Chile (Readers 5022 and 5023)
China (Readers 1021, 5022, 5427)
Hong Kong (Readers 5022 and 5023)
India (Readers 5022 and 5023)
Japan MIC (Reader 4121)
この装置は総務省の型式指定を受けています。
本製品は電波を使用したRFID機器の読み取り・書き込み装置です。
そのため使用する用途・場所によっては、医療機器に影響を与える恐れがあります。
Korean KC (Readers 1021, 3121, 4040, 4321, 5021,
5022, 5325, 5326, 5421, 5427, 6121, 6221,6321)
항목 규격 항목 규격
송신주파수 RFID:13.56 MHz 전파형식 A1D
수신주파수 RFID:13.56 MHz 발진방식 X-tal
출력 RFID: 10m에서 24.19mv이하 변조방식 AM
전원 DC 5
Mexico (Readers 5022 and 5023)
Singapore (Reader 5427 CK)
Taiwan (Readers 5321 and 5421)
經型式認證合格之低功率射頻電機，非經許可，公司、商號或使用者均不得擅自變更頻率、加大功
率或變更原設計之特性及功能。低功率射頻電機之使用不得影響飛航安全及干擾合法通信；經發現
有干擾現象時，應立即停用，並改善至無干擾時方得繼續使用。前項合法通信，指依電信法規定作
業之無線電通信。低功率射頻電機須忍受合法通信或工業、科學及醫療用電波輻射性電機設備之干
擾。
According to “Administrative Regulations on Low Power Radio Waves
Radiated Devices” Without permission granted by the NCC, any company,
enterprise, or user is not allowed to change frequency, enhance transmitting
power or alter original characteristic as well as performance to an approved
low power radio-frequency devices shall not influence aircraft security and
interfere legal communications; If found, the user shall cease operating
immediately until no interference is achieved. The said legal communications
means radio communications is operated in compliance with the
Telecommunications Act.
The low power radio-frequency devices must be susceptible with the
interference from legal communications or ISM radio wave radiated devices.
