HID Global OK5127FARGO Contactless 13.56MHz/125KHz Reader Module User Manual
HID Global Corporation Contactless 13.56MHz/125KHz Reader Module
User Manual
© 2010 – 2011 HID Global Corporation - All rights reserved.
Base Models: 1021, 3021, 3121, 4040, 4321, 5021
5121, 5125, 5127, 5321, 5325, 6121,
6221, 6321, 7121.
Drivers and Manuals:
http://www.hidglobal.com/omnikey
North America
15370 Barranca Parkway
Irvine, CA 92618
USA
Asia Pacific
19/F 625 King’s Road
North Point, Island East
Hong Kong
Europe, Middle East & Africa
Phoenix Road
Haverhill, Suffolk CB9 7AE
England
support.hidglobal.com
Installation Guide
OMNIKEY®
Smart Card Readers
3121-906-ENEN, A.54
OMNIKEY® Smart Card Reader Installation Guide
2 © 2010 – 2011 HID Global Corporation - All rights reserved.
Introduction
This guide describes physical behavior and conformities of the OMNIKEY® Smart Card
Reader family.
1021 USB - Desktop smart card reader in a small form factor for desktop and mobile
usage.
3021 USB - High-performance smart card reader, with a USB interface and small form
factor for desktop and mobile usage.
3121 USB - High-performance smart card reader for desktop use with multiple standing
base options in a robust housing.
4040 Mobile PCMCIA - High-performance smart card reader for mobile use in laptops
and PDAs with PCMCIA interface.
4321 Mobile ExpressCard 54 - High-performance smart card reader for mobile use in
laptops and PDAs with the ExpressCard™ interface.
5125 / 5325 USB Prox -– Dual interface PC-linked reader that reads contactless
(125kHz) HID Prox cards and reads/writes virtually any contact smart card.
5121 / 5321 USB - Dual interface PC-linked reader that reads/writes to both 13.56 MHz
contactless cards and virtually any contact smart card.
5127 USB - Contactless 13.56MHz/125kHz reader that reads/writes to both 13.56 MHz
and 125kHz contactless cards and virtually any contact smart card.
6121 Mobile USB - Fully functional smart card reader for SIM-sized smart cards,
especially well suited for use with mobile devices.
6221 USB - SIM-size contact smart card and Micro-SD reader, especially well suited for
use with mobile devices.
6321 Mobile USB - Dual interface PC linked reader that reads/writes to 13.56 MHz
contactless smart card and virtually any SIM-sized contact smart card.
7121 USB Biometric - Full-size smart card reader with a Biometric stripe sensor in a
desktop housing.
Parts
Smart Card Reader
Installation Guide
Find drivers, reader documentation supporting various operating systems at
http://www.hidglobal.com/omnikey.
See the application note for card loading and handling instructions at
http://www.hidglobal.com/omnikey.
Installation Guide OMNIKEY® Smart Card Reader
© 2010 – 2011 HID Global Corporation - All rights reserved. 3
Specifications and Installation
Note: Radio module 5127 should not be installed within a system
and operated simultaneously with other radio transmitters. When
integrating the 5127 module into a final product, the product needs
to have a label showing:
Contains FCC ID: JQ6-OK5127FARGO, IC: 2236B-OK5127FARGO
For further information, contact HID support: http://support.hidglobal.com/.
For driver setup, consult the OMNIKEY Smart Card User Guide
(http://www.hidglobal.com/documents/ok3121_userguide_ins_en.pdf).
CAUTION: Install the drivers prior to attaching the OMNIKEY reader with the computer.
USB Connected Reader Specifications
Operating Temperature
0°-55°C / 32°-131°F
PC Connector Cable
180 cm / 70.9 in
(150 cm / 59,1 in - Models 1021 & 3021)
Meantime between Failure (MTBF)
500,000 Hours
Host Interface
USB 2.0 CCID (USB 1.1 Compatible)
Host Data Transmission Speed
12 Mbps (USB 2.0 Full Speed)
Power Supply
Bus Powered
USB Connected Reader Installation
1. Connect the reader with your computer; plug the USB connector into your
computers USB port.
2. When the reader is operational, the LED illuminates.
3. For contactless operation, hold the card next to the reader logo. For contact
smart cards, insert the card into the reader with contacts facing up.
4. When the reader is exchanging data with a card (reading/writing), the LED blinks.
PCMCIA and ExpressCard Reader Specifications
4321
4040
Operating Temperature
0°-55°C / 32°-131°F
Meantime between Failure (MTBF)
500,000 Hours
Host Interface
ExpressCard™ 54 mm
PCMCIA
Host Data Transmission Speed
12 Mbps
16 Mbps
Power Supply
Bus Powered
PCMCIA
OMNIKEY® Smart Card Reader Installation Guide
4 © 2010 – 2011 HID Global Corporation - All rights reserved.
PCMCIA and ExpressCard Reader Installation
1. Insert the reader into the compatible interface slot of your Notebook or PDA.
2. If the reader is operational, observe the reader in your operating system’s Device
Manager.
3. For contactless operation, hold the card next to the logo on the reader. For
contact smart cards, insert the card into the reader with contacts facing up.
Installation Guide OMNIKEY® Smart Card Reader
© 2010 – 2011 HID Global Corporation - All rights reserved. 5
Regulatory
FCC / Canada Radio Certification
CAUTION: Any changes or modifications to this device not explicitly approved by
manufacturer could void your authority to operate this equipment.
This device complies with part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) This device may not cause harmful interference, and (2) this device must accept any
interference received, including interference that may cause undesired operation.
This device complies with Industry Canada license-exempt RSS standard(s). Operation is subject to
the following two conditions:
(1) This device may not cause interference, and (2) This device must accept any interference,
including interference that may cause undesired operation of the device.
Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils radio
exempts de licence. L'exploitation est autorisée aux deux conditions suivantes : (1) l'appareil ne
doit pas produire de brouillage, et (2) l'utilisateur de l'appareil doit accepter tout brouillage
radioélectrique subi, même si le brouillage est susceptible d'en compromettre le fonctionnement.
CE Marking
HID Global hereby declares that these products are in compliance with the essential requirements
and other relevant provisions of the applicable Directives. A DoC copy can be found at
http://certifications.hidglobal.com.
Nur in Verbindung mit zertifiziertem PC.
Taiwan
According to "Administrative Regulations on Low Power Radio Waves Radiated Devices"
Without permission granted by the DGT, any company, enterprise, or user is not allowed to
change frequency, enhance transmitting power or alter original characteristic as well as
performance to a approved low power radio-frequency devices. The low power radio-frequency
devices shall not influence aircraft security and interfere legal communications; If found, the user
shall cease operating immediately until no interference is achieved. The said legal
communications means radio communications is operated in compliance with the
Telecommunications Act. The low power radio-frequency devices must be susceptible with the
interference from legal communications or ISM radio wave radiated devices.
Singapore
Approved by IDA for use in Singapore. DA103548
Japan ITE
Korean
