HID Global XTENDER Xtender module User Manual
HID Global Corporation Xtender module Users Manual
Users Manual
ACCESS flexibility.
2.4 GHz Contactless
iCLASS SE® Reader Module
Bluetooth Xtender
INSTALLATION GUIDE PLT-02587, A.0
Specifications
PART NUMBER INPUT VOLTAGE (VDC) CURRENT OPERATING TEMPERATURE Frequency FCC & IC IDs
AVG PEAK
4092A02 3.3VDC
Low Power: 600uA Low Power: 5mA -13° to 158° F
(-25° to 70° C) 2.4 - 2.480 GHz FCC-ID: JQ6-XTENDER
IC ID: 2236B-XTENDER
Normal Operation: 3.8mA Normal Operation: 15mA
Note: This module conforms to standards when used in conjunction with the iCLASS SE Reader Module.
The final product, containing the modular transmitter must be labeled with its own FCC ID and IC ID. If the FCC & IC ID is not visible, when the module is installed inside the host, then the final
assembly label must contain the FCC and IC ID numbers with a statement such as follows: “Contains Transmitter Module with FCC ID: JQ6-XTENDER and IC ID: 2236B-XTENDER”.
Host Devices: iCLASS SE 3200, iCLASS SE 3210
FCC
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any
interference received, including interference that may cause undesired operation.
Canada Radio Certification
This device complies with Industry Canada license-exempt RSS standard(s). Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must
accept any interference, including interference that may cause undesired operation of the device.
Le présent appareil est conforme aux CNR d’Industrie Canada applicables aux appareils radio exempts de licence. L’exploitation est autorisée aux deux conditions suivantes : (1) l’appareil ne doit pas
produire de brouillage, et (2) l’utilisateur de l’appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d’en compromettre le fonctionnement.
CE Marking
HID Global hereby declares that these proximity readers are in compliance with the essential requirements and other relevant provisions of Directive 1999/5/EC.
Por el presente, HID Global declara que estos lectores de proximidad cumplen con los requisitos esenciales y otras disposiciones relevantes de la Directiva 1999/5/EC.
HID Global déclare par la présente que ces lecteurs à proximité sont conformes aux exigences essentielles et aux autres stipulations pertinentes de la Directive 1999/5/CE.
A HID Global, por meio deste, declara que estes leitores de proximidade estão em conformidade com as exigências essenciais e outras condições da diretiva 1999/5/EC.
HID Global bestätigt hiermit, dass die Leser die wesentlichen Anforderungen und anderen relevanten Bestimmungen der Richtlinie 1999/5/EG erfüllen.
HID Global dichiara che i lettori di prossimità sono conformi ai requisiti essenziali e ad altre misure rilevanti come previsto dalla Direttiva europea 1999/5/EC.
Download copies of the R&TTE Declaration of Conformity (DoC) at http://www.hidglobal.com/certifications.
WARNING: Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment.
