User Manual
HBK-001
Bluetooth car kit manual
Features
ò Embedded Audio Gateway profile
ò Plug in existing mobile phone via 2.5 φ phone jack
ò User-friendly interface that can be used with Bluetooth enabled
headset devices.
ò Support DC output function for charger
ò 10 meter working distance
Front panel
1. Car kit power in plug
2. Status LED
3. Charger output plug
4. Audio cable
5. Holder eject
6. Pair key
Pair with Headset
1. Plug-in the car kit to the car cigar slot and you will see the green LED
flash per 2 seconds (*1).
2. Please let car kit into the pairing mode.
3. You can press the ‘Pair Key’ 3 seconds continually.
You will see the green LED is flashing per 0.5 second then you can
release the press.
4. When pair is finished (*2), the device will enter standby mode. The green
LED is flashing per 2 seconds.
(*1) Only in standby mode, you can do pair procedure.
If you don’t sure which state is. You can plug-out and plug-in of car kit
plug again and wait the green LED flash once per 2 seconds. This is
standby mode now.
(*2) ¡If green LED turn off 3~6 seconds, you need restart pair procedure
again.
¡ Once pair is successful, you needn’t do pair procedure next time unless
you change another headset.
Note: The default PIN code is 1234
Connect with mobile phone
1. Plug audio cable into the headset ready mobile phone(*3).
2. Maybe you need enable the auto answer function in your mobile
phone.
3. It will auto transfer to the headset directly when the call in.
Please adjust proper volume from your phone in order to avoid too much
sidetone or distortion.
4. It will auto enter the standby mode or low power mode if headset supports
for the power saving when ends call. It is like the hand-free in your
Bluetooth headset.
(*3) ¡Please refer to your wire headset plug header in order to select 3
or 4 nodes header of audio cable.
¡Some mobile phones are not headset ready, they may need an
adapter in order to transfer to 2.5 φ phone jack.
LED status
Standby mode Green LED flash once/2 sec
Pair mode Green LED flash once/0.5 sec
Talk mode Green LED flash once/1 sec
FCC Statement
1.THIS DEVICE COMPLIES WITH PART 15 OF THE FCC RULES. OPERATION
IS SUBJECT TO THE FOLLOWING TWO CONDITIONS: (1) THIS DEVICE
MAY NOT CAUSE HARMFUL INTERFERENCE AND (2) THIS DEVICE MUST
ACCEPT ANY INTERFERENCE RECEIVED, INCLUDING INTERFERENCE
THAT MAY CAUSE UNDESIRED OPERATION.
2. Notice: The changes or modifications not expressly approved by the party
responsible for compliance could void the user’s authority to operate
the equipment.
3. IMPORTANT NOTE: To comply with the FCC RF exposure compliance
requirements, no change to the antenna or the device is
permitted. Any change to the antenna or the device could
result in the device exceeding the RF exposure
requirements and void user’s authority to operate the
device.
