HK MGCOOL DIGITAL TECHNOLOGY PRO Action camera User Manual
HK MGCOOL DIGITAL TECHNOLOGY CO.,LIMITED Action camera
User Manual
1.Water proof up to 98 feet (30m) with a
waterproof housing required.
2. 2 inch TFT screen for videos and image
preview.
3.Detachable battery for easy replacement and
help.
4. Extend product lifespan.
5. Record videos while charging.
6. HD wide angle lens.
7. HDMI Output.
8. PC Camera.
9. Supports TF card memory expandable up to
64GB (Maximum).
10. Supports multiple video resolutions:
4K/2K/1080P/720P.
11. Supports MP4 recording format.
12. Supports multiple photo shooting modes:
Single shot & Snapper.
13. Video encryption enabled.
14. Super lightweight, small in size and available
in 2 colors.
Product features Product structure
①
②
③
④
⑤
⑥
⑦
⑧
User Ma nual
E X P L O R E R P R O
www.mgcool.cc
720P120FPS 7.0G TF
2017/01/15 09:42:05
orwill
§ 15.19 Labelling requirements.
This device complies with part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) This device may not cause harmful interference, and (2)
this device must accept any interference received, including interference that may
cause undesired operation.
§ 15.21 Information to user.
Any Changes or modifications not expressly approved by the party responsible for
compliance could void the user's authority to operate the equipment.
§ 15.105 Information to the user.
Note: This equipment has been tested and found to comply with the limits for a Class
B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential installation.
This equipment generates uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful interference
to radio communications. However, there is no guarantee that interference will not
occur in a particular installation. If this equipment does cause harmful interference to
radio or television reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference by one or more of the
following measures:
-Reorient or relocate the receiving antenna.
-Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
-Consult the dealer or an experienced radio/TV technician for help.
* RF warning for Portable device:
The device has been evaluated to meet general RF exposure requirement. The device
can be used in portable exposure condition without restriction.
