HLI Solutions NXBTR Bluetooth Low Energy Radio User Manual
Hubbell Building Automation, Inc. Bluetooth Low Energy Radio
User Manual
NX™ Bluetooth® Radio Module
INSTALLATION INSTRUCTIONS
9601 Dessau Road, Building One | Austin, TX 78754 Toll Free: 888-698-3242 | Fax: 512-450-1215 | www.hubbell-automation.com 3454B 12.1.2015
PRECAUTIONS
• Read and understand all instructions before beginning installation.
SAVE THESE INSTRUCTIONS!
DESCRIPTION
The Hubbell Building Automation NXBTR Bluetooth Radio Module enables wireless communication with one group
of Room Controller(s), Sensor(s), and Switches using a Smart Phone or other Bluetooth enabled hand held device. In
conjunction with an App based user interface, the user can manually control the room loads and/or perform set up and
conguration.
INSTALLATION
1. Plug the Bluetooth radio module into a Smart Port on the Room Controller or a Smart Switch. Make certain that you
hear a distinct “click” as the RJ-45 connector locks into the socket.
2. If the Bluetooth module is being in
